resideo M35758A User manual

Electrode Steam Homeowner’s Manual
Homeowner’s Operating Manual
33-00165EFS-01
33-00165EFS-03

Electrode Steam
NEED HELP? For assistance with this product please visit www.resideo.com
or call Resideo Customer Care toll-free at 18004681502.
Read and save these instructions.
Steam Humidification System 3300165EFS03 1
EVERYDAY
OPERATION
INTRODUCTION WARRANTY
CLEANING AND
MAINTENANCE
YOUR NEW
Electrode Steam
INTRODUCTION
Safety Definitions and Precautions..................................2
Welcome .........................................................3
How is the Electrode Steam different from
other humidifiers? ..........................................3
What safety features does the
Electrode Steam have? .....................................3
How should I get started? .......................................3
How does the Electrode Steam work? ...............................4
YOUR NEW Electrode Steam
Which Electrode Steam model do I have?............................5
Which humidity control do I have?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
How is my Electrode Steam installed? ...............................6
Remote mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
What Electrode Steam parts do I need to know?.....................7
What should I expect from my Electrode Steam? ....................8
EVERYDAY OPERATION
How do I operate the Electrode Steam?..............................9
How do I use the humidity control? .............................9
What should my humidity setpoint be?........................10
What is a frost setting?........................................10
What do the lights tell me? ........................................11
CLEANING AND MAINTENANCE
What should I do at the end of the season?........................12
What if I go on vacation? ......................................12
What should I do if the LED light is
blinking, or if something is wrong? ............................12
WARRANTY
5Year Limited Warranty ..........................................13

INTRODUCTION
Must be installed by a trained, experienced technician.
Read these instructions carefully. Failure to follow these instructions can damage the product or cause a
hazardous condition.
Please read this manual completely. It is important that you understand how the Electrode Steam works, and
how to safely perform the required maintenance procedures. Read and understand all safety-related labels
found on and posted near the Electrode Steam. These labels provide additional instructions and important
safety information.
Safety Definitions
These safety terms identify information you must read.
CAUTION: Indicates a hazardous situation which, if not avoided, could cause bodily injury or
property damage.
WARNING: Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Safety Precautions
WARNING: Electrocution Hazard.
The Electrode Steam uses 120V or 240V, which can cause death or serious injury. Take precautions
when service is being preformed on the Electrode Steam or when removing the water tank or cover. If
in doubt, turn off the breaker which is operating the Electrode Steam and disconnect HVAC equipment
power before servicing.
CAUTION: Heavy Equipment and Water Hazard.
Improper installation or misuse can cause death, blindness, and water damage to home. Be sure you
know how to turn the Electrode Steam off, and how to drain the water tank safely.
CAUTION: Steam Condensation and Freezing Water Hazard.
Be sure the Electrode Steam Humidifier is located in a conditioned space, as well as having proper
condensate and drain line locations. Improper installation can result in water damage to home.
Make sure you read and understand the following safety hazards before installing, using, or
working with the Electrode Steam:
• Do not direct the steam nozzle at people.
• Water inside cylinder can be very hot. Read the warning label on the Electrode Steam and make sure
you understand the hazards of scalding hot water in the cylinder.
• Scalding danger from draining water. When the water tank empties, draining water can be hot
enough to cause injury. Make sure you know where the water exits the drain hose. Be certain hot
water will not pose a hazard to people or pets.
Safety Definitions and Precautions
Steam Humidification System 33-00165EFS—03
2

INTRODUCTION
Congratulations on your new humidifier.
The Resideo Electrode Steam humidifier provides the high performance and efficiency of steam, with easier
maintenance than traditional humidifiers.
We are sure the Electrode Steam will be a welcome addition to your home.
• How is the Electrode Steam different from other humidifiers?
- The steam goes directly into your hot air supply duct, rather than evaporating from a wet pad, which
requires furnace temperature to produce humidity efficiently.
- The Electrode Steam delivers humidity independent of your furnace. This allows you to achieve ideal
humidity levels in your home, year-round.
- The Electrode Steam wastes less water than flow-through humidifiers.
- The Electrode Steam operates automatically, just like a thermostat, to keep your home’s humidity at the
desired level.
- The Electrode Steam is easy to maintain. Just have your HVAC professional change the steam cylinder
when the unit determines its life is about to expire.
• What safety features does the Electrode Steam have?
- Separate sensors and water monitoring (via the electrodes and software) monitor water within the tank.
These two important components prevent the tank from being over-filled, running dry, and optimize
steam production with various water qualities.
- The auto-adaptive feature monitors the Electrode Steam humidifier’s water supply, current, and load. The
unit also self-tests on a regular basis, letting you know when the unit should be serviced.
• How should I get started? Your Electrode Steam must be installed by an HVAC Professional Installer. If
the Electrode Steam has just been installed, it should either be running and humidifying your home, or
waiting for a humidity call from the humidity control provided.
Once the Electrode Steam is up and running, all you have to do is use the humidity control to change the
humidity to your desired comfort.
Welcome!
Please read this manual completely for tips on getting the most out of your Electrode Steam.
Read your humidity control manual and make sure you know how to operate your system.
If you have questions, now or later, please ask your Installer or call Resideo Customer Care
at 18004681502.
Steam Humidification System 33-00165EFS—03 3

INTRODUCTION
Steam Generation
• Once the unit receives a demand signal and the safety loop between terminal 1 and 2 is closed, the
humidifier closes the contactor and measures the electrical current.
• If the demand is lower than the actual output the inlet valve is kept closed and output is reduced by letting
the water level in the cylinder decrease by evaporation.
• If demand is higher than the actual output, after a brief delay the fill valve is activated and water flows into
the fill cup. Water from the fill cup flows into the bottom of the cylinder through a hose connected to the
drain valve housing.
Note: The cylinder is gravity fed from the fill cup. If backpressure from the steam line is too high it will cause
water to back up in the fill cup and flow down the overflow line to the drain.
• As soon as the water in the cylinder comes in contact with the energized electrodes, current flows through
the water. The resistance of the water to the electrical charge generates heat and in turn steam. The
electrical current (and steam output) increases as the level of water increases, as more of the electrode
becomes submerged. The unit continues to fill until the current matches demand or the high water sensor
detects a high water level.
• The Electrode Steam repeats the fill and boil down cycle repeatedly to match output to demand.
• Over time minerals in the water will adhere to the cylinder electrodes. The humidifier will automatically fill
to a higher water level to maintain full capacity during the life of the cylinder. Eventually because of scale
formation it will no longer be possible for the humidifier to reach its full capacity. The Electrode Steam
software monitors this condition and, when detected, will stop operating and flash the yellow LED in a
repeating sequence of 4 flashes.
Drains
• As steam is produced, minerals are left behind, increasing the conductivity of the water. The Electrode
Steam patented auto adaptive cycle will monitor the water conductivity and perform drains to maintain the
water at optimal conductivity for peak performance.
• The auto adaptive cycle ensures cylinder life is maximized. It does this by keeping the tightest control and
most efficient use of water during the entire cylinder life.
Steam Distribution
Steam generated by the humidifier may be introduced into the air in several different ways. The most
common method for adding the steam into the air is to mount a steam distributor tube in a supply air duct.
Steam Line
The steam line between the cylinder steam outlet and the distributor serves two purposes: it is used as a
conduit to transfer the atmospheric steam from the humidifier to the distributor, as well as providing a means
to remove condensate.
Condensate Return
Whenever steam is distributed condensate is formed in the distribution system. Insulating steam lines is one
important way to reduce the amount of condensate formed. Steam lines are sloped so that condensate does
not collect in the lines and create a restriction to steam flow. The condensate must be collected and removed
from the system so that it does not build up and leak into the duct. Condensate can be returned to the
Electrode Steam fill cup to reduce water waste or can be fed to drain.
How does the Electrode Steam work?
Steam Humidification System 33-00165EFS—03
4

YOUR NEW
Electrode Steam
The Electrode Steam is available in two sizes, each with a different humidifying capacity:
The Electrode Steam produces 11 gallons per day (GPD) when run on 120 V and 22 GPD when run on
240 V. It is generally suitable for homes 8,000 to 32,000 cubic feet in size.
Which Electrode Steam model do I have?
The proper model for your home depends on many
factors. Size of the area to be humidified, ceiling height,
window and insulation type, as well as your geographic
area, all affect how much humidity your
home needs.
Some activities in your home may create heavier loads
for the Electrode Steam. Vented fireplaces, high exhaust
from fans, or driers can reduce humidity in your home
and make the Electrode Steam work harder.
Your Professional Installer or salesperson will have
considered these and other factors when choosing the
best Electrode Steam model for your unique situation.
Sizing
IMPORTANT: The Electrode Steam should only be installed if it has been sized properly. Do not use
square feet when sizing a humidifier installation. Instead, cubic feet must be used, since the humidity is
filling a volume of space (width x length x height). Also, take into consideration the “tightness” of a home’s
construction.
Table 1. AHRI Recommended Humidity (in gallons per day).
Construction Type 8,000 ft312,000 ft316,000 ft320,000 ft324,000 ft328,000 ft332,000 ft3
Tight 3.3 4.3 5.4 7.5 9.6 11.7 16
Average 7.6 9.6 11.8 16 20.3 24.4 33
Loose 11.7 14.9 18.1 24.5 30.8 37.1 50
Table 2. Steam humidifier(s) necessary for application.a
Construction Type 8,000 ft312,000 ft316,000 ft320,000 ft324,000 ft328,000 ft332,000 ft3
Tight 11 GPD 11 GPD 11 GPD 11 GPD 11 GPD 11 GPD (x2) or
22 GPD (x1)
11 GPD (x2) or
22 GPD (x1)
Average 11 GPD 11 GPD 22 GPD 22 GPD 22 GPD 11 GPD (x3) or
22 GPD (x2)
11 GPD (x3) or
22 GPD (x2)
Loose 22 GPD 22 GPD 22 GPD 11 GPD (x3) or
22 GPD (x2)
11 GPD (x3) or
22 GPD (x2)
11 GPD (x4) or
22 GPD (x2)
11 GPD (x5) or
22 GPD (x3)
aIn the table above, 11 GPD indicates a steam humidifier configured to run on 120 V and 22 GPD indicates a steam humidifier
configured to run on 240 V.
Steam Humidification System 33-00165EFS—03 5
This label displays the model number
and date code of your Electrode Steam.
M35758A
Golden Valley Minnesota 55422
MADE IN CANADA
MODEL:
VOLTS 1: KW:
HM700A1000 S/N: XXXXXXX
110-120
PHASE: 1HZ: 60
1.4
DATE: XXXXXXXXX
2583297A
220-240
VOLTS 2: F. L.A: GPD:
12.0
F. L.A: GPD:
12.0
2.9
KW:
Auto-Adaptive
11
22
1
LISTED 205X
HUMIDIFIER

YOUR NEW
Electrode Steam
The Electrode Steam comes supplied with a HumidiPRO Digital Control (see below), or you can use your home
thermostat (Prestige IAQ, VisionPro, or The Round). You will use the humidity control to set the desired humidity
level for your home, and to turn the Electrode Steam on and off.
HumidiPRO Digital Control
• Automatic humidification control with advanced
window protection
• Optional manual humidification or
dehumidification control
Your HVAC Professional Installer will install the Electrode Steam in a proper location in your home. The best
location depends on your furnace type and configuration, and how your living space is arranged around the
furnace ducts. Your Electrode Steam will be remote mounted.
Remote mounting. The Electrode Steam is installed
some distance away from your furnace supply duct.
An insulated hose carries steam from the Electrode
Steam to a suitable location on the supply duct.
Remote mounting is required for the Electrode
Humidifier.
How is my Electrode Steam installed?
M35763
Steam Humidification System 33-00165EFS—03
6
Which humidity control do I have?

YOUR NEW
Electrode Steam
You should be familiar with the following components:
Water Drain Line: Drains water from humidifier.
What Electrode Steam parts do I need to know?
Cylinder: Current heats the water inside the
cylinder to make steam.
HumidiPRO Digital Control: Controls
humidity levels, and turns on/off the
Electrode Steam.
Steam Hose: Conduit to transfer the steam
from the humidifier to the distributor.
On/Off/Drain Switch: Turns power on/off to
humidifier controller and drains the cylinder.
Steam Humidification System 33-00165EFS—03 7
M35762

YOUR NEW
Electrode Steam
Resideo wants to make sure you know what to expect from your new Electrode Steam installation. Make sure
you discuss these items with your Professional Installer:
• Achieving Humidity Setpoint. It may take up to a week of continuous operation to initially achieve
the humidity setpoint. This depends on factors such as weather, size of home, furnishings in the home,
and insulation. Once this is achieved, the Electrode Steam should not have to run as much to maintain
humidity.
• On/Off Noise. When the humidifier starts up after being off, the unit will run a self-test sequence and
may a “click” noise, engaging the fill & drain valves. This is normal .
• Ideal Humidity. 35% relative humidity in typical winter weather is considered ideal for indoor comfort by
industry experts. You can adjust to your own comfort or until there is condensation on the windows. Lower
the setpoint if condensation appears.
• Unit Not Humidifying. If the Electrode Steam is not running but the humidity is below the desired setting,
the humidity control may have a frost protection setting. See “What is a frost setting?” on page 10. The
Cylinder may also be at the end of its life, in which case you will be notified by the LED sequence.
• Setpoint Not Reached. If humidity doesn’t reach the setpoint, the Electrode Steam may be under-sized
for the home. This can be due to insulation, windows, arid climate, and other environmental factors. Also,
the outdoor temperature may be too low to maintain the humidity level.
• Home Ventilation. Excessive ventilation exhausts humidified air and replaces it with dry air. This can
make it hard to maintain the humidity setpoint. If you are installing a ventilator, use a solution that retains
moisture. An Energy Recovery Ventilator (ERV) is recommended.
• LED Status Lights. The HM700 user interface includes 2 LEDs that provide information about the
humidifier status. Please see “What do the lights tell me?” on page 11 for more information.
• Water Draining. It is normal for the Electrode Steam to periodically drain some water automatically. This
is due to the humidifier maintaining the perfect level of water conductivity and steam output.
• Water Conductivity. Your home’s water conductivity determines how quickly the Electrode Steam will
produce steam and also how often the replacement steam cylinder needs to be replaced.
• Energy Consumption. You may notice a slight increase in overall energy consumption when operating
any humidifier. However, the Electrode Steam will make the home feel warmer. This allows you to lower
the temperature setting on the thermostat. Every degree lower on the thermostat can save up to 3% on
heating costs.
What should I expect from my Electrode Steam?
Steam Humidification System 33-00165EFS—03
8
