ResMed Lumis 100 VPAP ST User manual

User guide
User guide
English | Deutsch | Français | Italiano | Nederlands | Español | Português |Türkçe

English 1
ENGLISH
Welcome
The Lumis™100 VPAP ST and Lumis 150 VPAP ST are bilevel positive airway pressure devices.
WARNING
•Read this entire guide before using the device.
•Use the device according to the intended use provided in this guide.
•The advice provided by your prescribing doctor should be followed ahead of the
information provided in this guide.
•This device is not suitable for ventilator-dependent patients.
Indications for use
Lumis 100 VPAP ST
The Lumis 100 VPAP ST device is indicated to provide non-invasive ventilation for patients weighing
more than 13 kg with respiratory insufficiency or obstructive sleep apnoea (OSA). It is intended for
home and hospital use.
The humidifier is intended for single patient use in the home environment and re-use in a
hospital/institutional environment.
Lumis 150 VPAP ST
The Lumis 150 VPAP ST device is indicated to provide non-invasive ventilation for patients weighing
more than 13 kg or more than 30 kg in iVAPS mode with respiratory insufficiency or obstructive
sleep apnoea (OSA). It is intended for home and hospital use.
The humidifier is intended for single patient use in the home environment and re-use in a
hospital/institutional environment.
Clinical benefits
The clinical benefit of CPAP and bilevel therapy for the treatment of OSA is a reduction in apnoeas,
hypopnoeas and sleepiness, as well as improved quality of life.
The clinical benefits of bilevel therapy for the treatment of respiratory insufficiency may include;
improvement in overall survival, daytime symptoms, blood gases, health-related quality of life and
sleep quality, and a decrease in hospitalisations and dyspnoea.
The clinical benefit of humidification is the reduction of positive airway pressure related side effects.
Intended patient population/medical conditions
Obstructive pulmonary diseases (eg, Chronic Obstructive Pulmonary Disease), restrictive pulmonary
diseases (eg, diseases of the lung parenchyma, diseases of the chest wall, neuromuscular
diseases), central respiratory regulation diseases, obstructive sleep apnoea (OSA) and obesity
hypoventilation syndrome (OHS).

2
Contraindications
Positive airway pressure therapy may be contraindicated in some patients with the following pre-
existing conditions:
•severe bullous lung disease
•pneumothorax or pneumomediastinum
•pathologically low blood pressure, particularly if associated with intravascular volume depletion
•dehydration
•cerebrospinal fluid leak, recent cranial surgery, or trauma.
Adverse effects
You should report unusual chest pain, severe headache, or increased breathlessness to your
prescribing physician. An acute upper respiratory tract infection may require temporary
discontinuation of treatment.
The following side effects may arise during the course of therapy with the device:
•drying of the nose, mouth, or throat
•nosebleed
•bloating
•ear or sinus discomfort
•eye irritation
•skin rashes.
At a glance
The Lumis includes the following:
•Device
•HumidAir™humidifier (if supplied)
•Air tubing
•Power supply unit
•Travel bag
•SD card (already inserted).
Contact your care provider for a range of accessories available for use with the device including:
•Air tubing (heated and non-heated): ClimateLineAir™, ClimateLineAir Oxy, SlimLine™, Standard
•HumidAir humidifier
•Side cover for use without the humidifier
•Filter: Hypoallergenic filter, standard filter
•Air10™DC/DC converter (12V/24V)
•SD card reader
•Air10 oximeter adapter
•Air10 USB adapter
•Power Station II
•Air10 tubing elbow

English 3
About your device
1
Air outlet
6
HumidAir humidifier
2
Air filter cover
7
Screen
3
Retention clip
8
Adapter cover
4
Power inlet
9
SD card cover
5
Serial number and device number
About the control panel
Start/Stop button
Press to start/stop therapy.
Press and hold for three seconds to enter power save
mode.
Dial
Turn to navigate the menu and press to select an option.
Turn to adjust a selected option and press to save your
change.
Home button Press to return to the Home screen.
Different icons may be displayed on the screen at different times including:
Ramp Time Wireless signal strength (green)
Humidity Wireless transfer not enabled (grey)
Humidifier warming No wireless connection
Humidifier cooling Airplane Mode

4
Setup
CAUTION
Do not overfill the humidifier as water may enter the device and air tubing.
1. With the device on a stable level surface, grip the retention clip on the back of the device and
pull up to open. Note: The retention clip is shown in the open position.
2. (a) Plug the power connector into the device power inlet then (b) push down the retention clip to
secure in place. Connect one end of the power cord into the power supply unit and the other end
into the power outlet.
3. Connect the air tubing firmly to the air outlet located on the rear of the device.
4. Open the humidifier and fill it with water up to the maximum water level mark.
Do not fill the humidifier with hot water.
5. Close the humidifier and insert it into the side of the device.
6. Connect the free end of the air tubing firmly onto the assembled mask.
See the mask user guide for detailed information.
Recommended masks are available on www.resmed.com.
