Datalogger DL3
www.resol.com
Manual
en
*11200030* 11200030
Thank you for buying this RESOL product.
Please read this manual carefully to get the best performance from this unit. Please keep this manual carefully.
Mounting
Electrical connection
Operating controls
Short manual

en
2
Information about the product
Proper usage
The RESOL datalogger DL3 is connected to RESOL
controllers via the VBus®interface. It enables logging
of system data and parameterisation of a solar ther-
mal system.
• Use in dry interior rooms only.
• Avoid ambient temperatures lower than 0 °C or
higher than 40 °C.
• Do not expose to strong electromagnetic fields.
Improper use excludes all liability claims.
Note
Notes are indicated with an information sym-
bol.
CE-Declaration of conformity
The product complies with the relevant di-
rectives and is therefore labelled with the
CE mark. The Declaration of Conformity
is available upon request, please contact
RESOL.
Note
Strong electromagnetic fields can impair the
function of the device.
ÎMake sure the device as well as the sys-
tem are not exposed to strong electro-
magnetic fields.
Disposal
• Dispose of the packaging in an environmentally
sound manner.
• Dispose of old appliances in an environmentally
sound manner. Upon request we will take back your
old appliances bought from us and guarantee an en-
vironmentally sound disposal of the devices.
Safety advice
Please pay attention to the following safety advice
in order to avoid danger and damage to people and
property.
Instructions
Attention must be paid to the valid local standards,
regulations and directives!
Target group
These instructions are exclusively addressed to au-
thorised skilled personnel.
Only qualified electricians should carry out electrical
works.
Description of symbols
WARNING! Warnings are indicated with a warn-
ing triangle!
ÎThey contain information
on how to avoid the danger
described.
Signal words describe the danger that may occur,
when it is not avoided.
• WARNING means that injury, possibly life-threat-
ening injury, can occur.
• ATTENTION means that damage to the appli-
ance can occur.
ÎArrows indicate instruction steps that should be
carried out.
Contents
1 Overview................................................... 3
2 Included..................................................... 4
3 About this manual.................................... 4
4 Installation ................................................ 4
4.1 Wall mounting .........................................................5
4.2 Electrical connection..............................................5
4.3 Connecting the VBus®cable ................................. 6
4.4 Connecting the sensors ........................................6
4.5 Connecting the network cable............................6
5 Operating controls, display and
connections............................................... 7
5.1 Operating control LED .........................................7
5.2 Buttons......................................................................7
5.3 Display.......................................................................7
5.4 LAN connector.......................................................8
5.5 USB interface...........................................................8
5.6 SD memory card slot ............................................8
5.7 Power supply connection......................................8
5.8 RESOL VBus®connection .....................................8
6 Firmware update with SD card .............. 8
7 Data export .............................................. 9
7.1 Data export over SD card....................................9
8 Accessories ............................................... 9
9 Spare parts................................................ 9
© 20110729_11200030_DL3_short manual.monen.indd
Subject to technical change. Errors excepted.

en
3
1 Overview
Be it solar thermal, heating or DHW heat exchange
controllers – with the RESOL DL3 you can easily
and conveniently log system data of up to 6 RESOL
controllers. Get a comprehensive overview of all con-
trollers connected with the large full graphic display.
Transfer data with an SD memory card, or use the
LAN interface to view and process data on your PC.
Data logging and parameterisation of up to 6 VBus®
master devices
• Temperature measurements and logging via inte-
grated sensor inputs possible
• Current loop interface 0(4)-20 mA
• BACnet functionality for BACnet-conform trans-
mission and reception of data
• Data logging onto SD card
Technical data
Housing: Plastic, PC-ABS and PMMA
Protection type: IP 20 / EN 60529
Protection class: III
Ambient temperature: 0 ... 40 °C
Dimensions: 144 x 208 x 43 mm
Mounting: Wall mounting
Display: Full graphic display for status visualisation
and operating control LED
Operation: Via three push buttons
Inputs: For 3 Pt1000 temperature sensors, 1 current
loop interface 0(4)-20 mA
Interfaces: 6 x VBus®(slave), 1 x SD memory card
slot, 1 x LAN (10/100), 1 x USB master
Power supply: 12 V / 1 A (external mains adapter)

en
4
2 Included 3 About this manual
This document is a short manual for the DL3 Datalog-
ger.This short manual contains information about the
following topics:
• Installation
• Electrical connection
• Operating controls
• Display screens
• Using the SD card
A detailed manual with the complete information
about the web interface can be found on the included
CD.
4 Installation
ATTEN-
TION!
ESD damage!
Electrostatic discharge can lead to
damage to electronic components!
ÎTake care to discharge prop-
erly before touching the in-
side of the device. To do so,
touch a grounded surface
such as a radiator or tap!
ATTEN-
TION!
Short circuit!
A short circuit can lead to damage to
electronic components!
ÎClose the housing before
establishing the mains con-
nection!
Initial installation must be effected by the system in-
staller or qualified personnel named by the system
installer.
If one of the items mentioned below is missing or de-
fective, please contact your distributor:
1 Datalogger DL3
2 Mains adapter
3 Interchangeable mains adapter plugs
(EURO, UK, USA,AUS)
4 VBus®cable
5 Network cable (CAT5e, RJ45), 1 m
6 Wall plugs and screws
7 Terminal block for extending the
VBus®cable
8 USB adapter cable
9 CD with ServiceCenter software and detailed
manual
10 Short manual (picture similar to original prod-
uct)
11 SD card
1
2
38
5
67
9
10
4
11

en
5
4.1 Wall mounting
The unit must only be located in dry interior rooms.
It is not suitable for installation in hazardous locations
and should be protected against electromagnetic
fields.
Please pay attention to separate routing of sensor ca-
bles and mains cables.
ÎChoose a mounting location.
ÎUnscrew the crosshead screw from the cover
and remove the cover.
ÎMark the upper fastening point on the wall. Drill
and fasten the enclosed wall plug and screw leav-
ing the head protruding.
ÎHang the housing from the upper fastening point
and mark the lower fastening points (centres
180 mm).
ÎDrill 2 holes (Ø 6 mm) and insert the wall plugs.
ÎFasten the housing to the wall with the lower fas-
tening screw and tighten.
ÎCarry out the electrical connection according to
the terminal allocation.
ÎReattach the cover and fasten it using the cross-
head screws included.
Crosshead
screw
Cover
Cable conduits with strain
relief
Buttons
12.5
180
180
100 144
208
16.75
43.3
Upper fastening
Lower fastening
In order to run cables through the cable
glands, break off the corresponding flaps!

en
6
4.2 Electrical connection
Note
Connecting the device to the power supply
must always be the last step of the instal-
lation!
Carry out the connection of the Datalogger
(pos. 1) to other modules in the order de-
scribed below:
ÎConnect the data cable (RESOL VBus®, pos. 3)
to the controller (pos. 4) and the DL3 (pos. 1).
If necessary, extend the cable using the terminal
block included and a common two-wire cable.
ÎConnect the mains adapter (pos. 2) to the DL3
and to a mains socket.
ÎFor a direct connection to a router or a PC, con-
nect the datalogger to a router (pos. 6) or a PC
(pos. 7) using the network cable (included with
the DL3, pos. 5).
Power supply is carried out via an external mains
adapter.The supply voltage of the mains adapter must
be 100 ... 240V~ (50 ... 60 Hz).
The mains adapter and a VBus®cable are included
with the DL3.
1
2
3
4
5
6
7
Router
4.3 Connecting the VBus®cable
The DL3 Datalogger is connected to one or several
controllers via VBus®cables. The corresponding ter-
minal allocation is described in the controller manual.
The VBus®cable can be extended using the terminal
block included and a common two-wire cable.
VBus®connection at the terminals:
1 / 2 = VBus®connection 1 (slave)
3 / 4 = VBus®connection 2 (slave)
5 / 6 = VBus®connection 3 (slave)
7 / 8 = VBus®connection 4 (slave)
9 / 10 = VBus®connection 5 (slave)
11 / 12 = VBus®connection 6 (slave)
To the VBus®connections 1 ... 6, master devices (con-
trollers) can be connected.
4.4 Connecting the sensors
Connect the Pt1000 temperature sensors to the fol-
lowing terminals with either polarity:
•
⊥
/ S1 ... S3 = Temperature sensors S1 to S3
Connect the sensor using a 0(4)-20 mA signal as
specified by the manufacturer to the following ter-
minals:
•
⊥
/ CL = Current loop interface 0(4)-20 mA
4.5 Connecting the network cable
The DL3 Datalogger can be connected to a computer
or a router by using a network cable (CAT5e, RJ45).
ÎConnect the network cable included to the net-
work adapter of the computer or the router.
12
VBus 1
3456 910
DL3
DE-45527 Hattingen
VBus 2 VBus 3 VBus 4
78
VBus 5
11 12
Master/Slave
VBus 6
Made in Germany
12V
1A max.
LAN USB S1 S2 S3
0(4)-20 mA current loop
ATTEN-
TION!
VBus®network malfunction!
Separating the device from the
power supply while the VBus® is still
connected will lead to a VBus®net-
work malfunction!
ÎSeparate VBus®connections
before separating the device
from the power supply!

en
7
5 Operating controls, display and
connections
The following elements are featured on / in the hous-
ing of the DL3 datalogger:
3 push buttons (1)
1 SD memory card slot (2)
1 LAN socket (3)
1 power supply socket (4)
3 sensor inputs (Pt1000) (5)
1 current loop interface 0(4)-20 mA (6)
6 VBus®connections (7)
12
VBus 1
3456 910
VBus2VBus 3VBus4
78
VBus 5
11 12
Master/Slave
VBus 6 12V
1A max.
LAN U SB S1 S2 S3
0(4) -20 mA current loop
Datalogger DL3
1
2
3
4
5
6
7
Positions of the operating controls and connections
5.1 Operating control LED
The operating control LED indicates the operating
status of the DL3 datalogger by issuing flashing signals.
Red/green flashing: The device is booting
Green: The device is ready for operation
/ SD card can be removed
Green flashing: Do not remove the SD card!
Data are being copied onto the
SD card
Red flashing: An error has occured.The error
will be indicated on the display
LED off: No power supply
5.2 Buttons
The device is operated via the three push buttons
next to the display.The push buttons have the follow-
ing functions:
• Button 1: Scrolling upwards
• Button 3:Activating the display
• Button 2: Scrolling downwards
3
1
2Datalogger DL3
5.3 Display
During normal operation, the display of the DL3 Da-
talogger is in the status level (see fig.).
If no button has been pressed within a couple of min-
utes, the display illumination is switched off.
ÎPress any key to reactivate the display illumina-
tion.
Status display
During normal operation, the display of the DL3 Da-
talogger is in the status level indicating the following
information:
• Data memory progress bar (fill level)
• Remaining logging time in days
• VBus®devices connected
• Sensors connected
The data memory progress bar is divided into 10 seg-
ments. Each segment represents 10 % of the memory
capacity.
Data memory progress bar
1
0%
890 d
VBus
100%
23 456
Sensors
CL 123
• Segment filled:The memory capacity of this seg-
ment is fully occupied.
• Segment flashing:The memory capacity of this seg-
ment is partly occupied.
The arrow above the data memory progress bar indi-
cates the remaining logging time in days.
In the bottom left-hand area of the status display, each
VBus®device connected with a functioning VBus®
communication is indicated by a corresponding filled
checkbox.
In the bottom right-hand area of the status display,
each sensor connected is indicated by a correspond-
ing filled checkbox.
VBus®screen
In the VBus®screen, VBus®information about the
VBus®devices connected is indicated.
In the left-hand area of the screen, the number of
bytes received (Rx) is indicated. In the right-hand area
of the screen, the number of bytes transmitted (Tx)
is indicated.
A VBus®device connected with a functioning VBus®
communication is indicated by a corresponding filled
checkbox in the bottom area of the screen.
Each VBus®device has its own screen. The connec-
tions VBus®1 to VBus®6 are displayed each in their
own screen.

en
8
1
VBus
23 456
VBus 1
Rx
4231165
Tx
131155
Sensors
CL 123
ÎIn order to leave the status level and access the
VBus®screens, press button 2.
ÎThe display indicates information about theVBus®
device.
ÎIn order to access information about further
VBus®devices, scroll down by pressing button 3.
Sensor screen
In the sensor screen, information about the sensors
connected is indicated.
In the left-hand area of the screen, the resistance value
of the corresponding sensor is indicated. In the right-
hand area of the screen, the temperature value of the
corresponding sensor is indicated in °C.
A sensor connected is indicated by a corresponding
filled checkbox in the bottom area of the screen.
Each sensor has its own screen. The data of the in-
puts CL and S1 to S3 are displayed each in their own
screen.
1
VBus
23 456
Sensor 1
1136 Ohm 35 °C
Sensors
CL 123
ÎIn order to leave the status level and access the
sensor screens, press button 2.
ÎPress button 2 to scroll down through the VBus®
screens until the sensor screens appear.
5.4 LAN connector
12
VBus 1
3456 910
VBus2VBus3VBus 4
78
VBus 5
11 12
Master/Slave
VBus 6
12V
1A max.
LAN U SB
S1 S2 S3
0(4)-20 mA current loop
Datalogger DL3
The integrated LAN connector is located on the
terminal strip of the device.The LAN connector sup-
ports transfer rates of up to 100 MBit per second.
5.5 USB interface
12
VBus 1
3456 910
VBus2VBus3VBus 4
78
VBus 5
11 12
Master/Slave
VBus 6 12V
1A max.
LAN U SB
S1 S2 S3
0(4)-20 mA current loop
Datalogger DL3
The DL3 is equipped with a USB interface to which
the USB adapter cable can be connected.
In order to connect the USB adapter cable to the
DL3, proceed as follows:
ÎConnect the USB adapter cable to the interface
marked USB.
Presently, the firmware of the device does not
support external USB devices.As soon as USB
support becomes possible, it will be made
available via an automatic DL3 Datalogger
firmware update.
5.6 SD memory card slot
Datalogger DL3
SD memory card slot
The SD memory card slot is located at the front of
the device. By means of the SD memory card slot,
logged data can be transferred onto an SD card of up
to 2GB memory capacity.
The memory of an SD card in the slot is used
for data transfer only. It will not enlarge the
memory of the DL3 datalogger.
Do not use an SD-HC card!
5.7 Power supply connection
Power supply is carried out via an external mains
adapter. The connection terminals are located inside
the housing of the DL3 datalogger.
5.8 RESOL VBus®connection
The DL3 datalogger is connected to one or several
RESOL controllers via VBus®cables. The connection
terminals are located inside the housing of the DL3
datalogger.

en
9
6 Firmware update with SD card
New firmware versions extend the functional range
and enhance the operation.
In order to run a firmware update over the SD mem-
ory card slot, proceed as follows:
ÎFormat the SD card using the FAT 32 format
ÎInsert the SD card into the SD card slot of the DL3
The operating control LED starts flashing (green).
Wait until the operating control LED is permamently
green.
A folder is created on the SD card. Logged data are
copied into the folder.
ÎRemove the SD card from the DL3
ÎInsert the SD card into an external SD card slot
Copy the firmware update file into the folder cre-
ated before
ÎRemove the SD card from the external SD card
slot
ÎInsert the SD card into the SD card slot of the DL3
The operating control LED starts flashing (green).
Wait until the operating control LED is permamently
green.
A firmware update is being run.
When the firmware update is completed, the DL3 au-
tomatically reboots.
7 Data export
There are 2 different ways to export logged data from
the DL3 datalogger:
1. Export logged data onto an SD memory card.The
data are stored as a VBus format file and can be
read out on a computer using the RESOL Serv-
iceCenter software.
2. Export logged data onto a computer over the
web interface. Different file formats can be se-
lected.
Information about exporting data over the
web interface can be found in the detailed
manual on the included CD.
7.1 Data export over SD card
In order to copy data onto an SD card, proceed as
follows:
ÎInsert the SD card into the SD card slot
The operating control LED flashes (green):
The card has been recognised and data are being
transferred.
The operating control LED is permanently green:
The transfer is completed.The card can be removed.
8 Accessories
Temperature sensors
The product range includes high-precision platinum
temperature sensors, flatscrew sensors, outdoor
temperature sensors, indoor temperature sensors,
cylindrical clip-on sensors, also as complete sensors
with immersion sleeve.
Sensor-/VBus®extension cable,
100 m coil
Art. no.: 280 051 00
SD card
Art. no.: 180 007 40
9 Spare parts
Mains adapter 100 ... 240 V~ (12 V , 1A max)
Art. no.: 720 004 60
VBus®cable, 1.50 m
Art. no.: 750 012 15
USB cable with 5-pole port
Art. no.: 750 000 92

en
10
Notes

en
11
Notes

Distributed by: RESOL – Elektronische Regelungen GmbH
Heiskampstraße 10
45527 Hattingen / Germany
Tel.: [phone] / 96 48 - 0
Fax: [phone] / 96 48 - 755
www.resol.com
[email protected]
Important note
The texts and drawings in this manual are correct to the best of our knowledge.As
faults can never be excluded, please note:
Your own calculations and plans, under consideration of the current standards and
directions should only be basis for your projects.We do not offer a guarantee for
the completeness of the drawings and texts of this manual - they only represent
some examples.They can only be used at your own risk. No liability is assumed for
incorrect, incomplete or false information and / or the resulting damages.
Note
The design and the specifications can be changed without notice.
The illustrations may differ from the original product.
Imprint
This mounting- and operation manual including all parts is copyrighted. Another
use outside the copyright requires the approval of RESOL – Elektronische Rege-
lungen GmbH. This especially applies for copies, translations, micro films and the
storage into electronic systems.
Editor: RESOL – Elektronische Regelungen GmbH
