ReSound ONE Programming manual

ReSound Smart Fit cable guide
ITEM NUMBER DESCRIPTION
Noahlink Wireless
CS53 flex strip & CS44 socket cable
(R&L)
120310800 Noahlink Wireless
29022 907 69019 CS44 – Red, Long
39022 907 69029 CS44 – Blue, Long
419533900 CS53 Flex Strip
Programming adapter &
CS44 socket cable (R&L)
ENZO Programming adapter &
CS44 socket cable (R&L)
519902500 PRG ADAPTER 2
619215000 Programming Kit, ENZO
ReSound ONETM RIE, BTE - - -
ReSound LiNX QuattroTM Customs, RIE,
BTE
Customs, RIE 61-DRW,
BTE 67-DW
RIE 62-DRW, BTE 77-DW,
BTE 88-DW -
ReSound ENZO QTM BTE - BTE 88-DWH BTE 98-DW
ReSound KeyTM Customs, RIE,
BTE
Customs, RIE 61-DRW,
BTE 67-DW
RIE 62-DRW, BTE 77-DW,
BTE 88-DWH BTE 98-DW
Customs by ReSound Rechargeable
Customs
Custom models
With the battery door ajar, insert the flex strip
into the slot beside the hinge pin. The black dot
on the flex strip should be facing away from the
battery door. The flex strip is fully inserted when
the black dot abuts the hearing instrument case.
Close the battery door once the flex strip
is inserted.
RIE 61DRW
Locate the programming slot below the push-
button. Open the battery door. With the black dot
on the flex strip facing the push button on the
hearing instrument, insert the flex strip into the slot
and close the battery door.
Mini BTE 67-DW
Locate the programming slot below the
microphone port. With the black dot on
the flex strip facing the push button on the
hearing instrument, insert the flex strip
into the slot, until the black dot abuts the
hearing instrument case.
123
4
2 3
5
62
Programming interface overview
NOTE: Strongly recommend to use fresh batteries for non-rechargeable models.
Cable connection for non-wireless programming
RIE 62-DRW,
BTE 77-DW & BTE 88-DWH
To connect the programming adaptor,
hold it at a 45° angle and insert the small
pins at the tip of the adaptor into the
square cut-out on the underside of the
hearing instrument. Once in place, move
the adaptor in the direction of the
battery compartment and then gently
click it into place.
BTE 98 -DW
[1] Locate and push out the battery door pin using the pin
removal tool. [2] Pull out the battery door and [3] add the
ENZO programming adapter (19215000) and secure it with
the pin. [4] Insert a new size #675 battery and close the door.
[5] Connect CS44 socket cable.
1. 2. 3.
4. 5.

To ensure successful programming, always use a fresh battery. Remove the protective foil from the battery and wait for one to two
minutes before inserting the battery into the hearing aid to allow the battery to fully activate.
ReSound battery guide
BEHIND-THE-EAR HEARING AIDS
RECEIVERINEAR TRADITIONAL BEHINDTHEEAR
Mini RIE RIE Mini BTE BTE & Power BTE Super
Power BTE
BATTERY
Integrated
Lithium-ion #312 #13 #312 Integrated
Lithium-ion #13 #675
ReSound ONE RTx61-DRWC RTx61-DRW RTx62-DRW -
RTx77-DWC
RTx88-DWC
RTx88-DWHC
- -
ReSound LiNX Quattro REx61-DRWC REx61-DRW REx62-DRW REx67-DW -REx77-DW
REx88-DW -
ReSound ENZO Q -----EQx88-DWH EQx98-DW
ReSound Key -KEx61-DRW KEx62-DRW KEx67-DW -KEx77-DW
KEx88-DWH KEx98-DW
Manufacturer according to FDA:
GN ReSound North America
8001 E Bloomington Freeway
Bloomington, MN 55420
USA
1-800-248-4327
pro.resound.com MK60 4817 Rev L 2022.05
CUSTOM HEARING AIDS
RECHARGEABLE CUSTOM MICROPHONE
INHELIX TRADITIONAL CUSTOM
Half Shell/ITC* Full Shell MIH CIC ITC ITE/Half Shell ITE/Full Shell
BATTERY Integrated
Lithium-ion
Integrated
Lithium-ion
#13/312 #10A #312 #13/312 #13/312
Customs by ReSound RTxITC-DWC RTxITE-DWC
- - - - -
ReSound LiNX Quattro - -
RExMIH-W RExCIC-W RExITC-DW RExITE-DW RExITE-DW
ReSound Key - -
-KExCIC-W KExITC-DW KExITE-DW KExITE-DW
*Devices will be built as small as possible
based on the patient’s ear anatomy.
