Respironics Wee Sight 1017920 User manual

INSTRUCTIONS FOR USE
1. Install the batteries.
2. Press the On/Off switch on the bottom of the Wee
Sight to turn the unit ON.
3. Place the Wee Sight on a flat surface or hold in
your hand, then place the patient’s hand, palm down,
over the top of the Wee Sight and LED.
NOTE: To improve vein location and view, tighten the
skin by draping the patient’s fingers over the Wee
Sight.
4. Dim the room lights for better illumination.
5. Insert the IV catheter, then turn the Wee Sight OFF
by pressing the On/Off switch.
WARNING
•LED radiation. DO NOT stare into beam. Class 2 LED product.
CAUTIONS
•Do not submerge the Wee Sight into liquids.
•Do not place liquids near the device.
•Do not mix battery types. For replacement, use only AA alkaline batteries.
•Do not recharge non-rechargeable batteries.
NOTES
•Discard device upon failure of an LED and/or the On/Off switch.
•Dispose of the device in accordance with local regulations.
•Clean the Wee Sight in accordance with the standard hospital protocol for
cleaning.
•Replace batteries upon degradation of the device functionality.
•Batteries are the only serviceable parts. Children’s Medical Ventures
recommends replacing both batteries at the same time.
The Wee SightTM is a portable, LED, battery-operated device that is intended to
assist in locating veins in the patient’s extremities.
Transilluminator
Item 1017920
Caution: US federal law restricts this device to sale by or on the order of a
physician.
On/Off Switch
Battery Door
INSTRUCTIONS FOR USE
THE HEART OF DEVELOPMENTAL CARE
SM

SPECIFICATIONS
BATTERY TYPE AA alkaline batteries
TYPE OF PROTECTION AGAINST Internally Powered
ELECTRIC SHOCK
OUTPUT LIGHT WAVELENGTH 629nm
Respironics
1001 Murry Ridge Lane, Murrysville, PA 15668-8550
USA 1-800-345-6443 Outside USA 1-724-387-4000
Respironics Deutschland
Gewerbestrasse 17, 82211 Herrsching Germany
[phone]
www.childmed.com www.respironics.com
1018836
HM 1/23/04
www.respironics.com
THE HEART OF DEVELOPMENTAL CARE
SM
Made in China
