Manual
Vibratory Sieve Shaker AS 300 control
Translation

2
Copyright
© Copyright by
Retsch GmbH
Retsch-Allee 1-5
42781 Haan
Germany

3
Table of Contents
1Notes on the manual............................................................................................................................. 6
1.1 Explanation of signs and symbols ..................................................................................................... 6
1.2 Disclaimer.......................................................................................................................................... 6
1.3 Copyright............................................................................................................................................ 6
2Safety...................................................................................................................................................... 7
2.1 Explanations of the Safety Instructions ............................................................................................. 8
2.2 General Safety Instructions ............................................................................................................... 9
2.3 Repairs............................................................................................................................................. 10
3Confirmation Form for the Managing Operator................................................................................ 11
4Technical Data..................................................................................................................................... 13
4.1 Degree of Protection........................................................................................................................ 13
4.2 Emissions......................................................................................................................................... 13
4.3 Electromagnetic Compatibility (EMC).............................................................................................. 13
4.4 Rated Power.................................................................................................................................... 13
4.5 Dimensions and Weight................................................................................................................... 14
4.6 Required Floor Space...................................................................................................................... 14
4.7 Receptacle Volume.......................................................................................................................... 14
4.8 Feed Grain Size............................................................................................................................... 15
4.9 Payload............................................................................................................................................ 15
4.10 Suitable Sieve Diameters ................................................................................................................ 15
5Packaging, Transport and Installation .............................................................................................. 16
5.1 Packaging........................................................................................................................................ 16
5.2 Transport.......................................................................................................................................... 16
5.3 Temperature Fluctuations and Condensation ................................................................................. 16
5.4 Conditions for the Installation Site................................................................................................... 17
5.5 Electrical Connection....................................................................................................................... 18
5.6 Type Plate Description..................................................................................................................... 18
5.7 Removing the Transportation Lock.................................................................................................. 19
6First Commissioning........................................................................................................................... 21
6.1 Sieve Clamping Unit "standard"....................................................................................................... 22
6.2 Sieve Clamping Unit "comfort"......................................................................................................... 23
7Operating the Device .......................................................................................................................... 25
7.1 Use of the Device for the Intended Purpose.................................................................................... 25
7.2 Principle of Operation ...................................................................................................................... 26
7.3 Views of the device.......................................................................................................................... 27
7.3.1 Front............................................................................................................................................. 27
7.3.2 Back............................................................................................................................................. 28
7.4 Switching On / Off............................................................................................................................ 29
7.5 Selection of the Test Sieves............................................................................................................ 29
7.6 Performing a Sieving ....................................................................................................................... 29
8Controlling the Device ........................................................................................................................ 30
8.1 Operating Controls, Displays and Functions................................................................................... 30
8.1.1 Start Process ............................................................................................................................... 30
8.1.2 Stop Process................................................................................................................................ 31
8.2 Pause Process................................................................................................................................. 31
8.3 Amplitude......................................................................................................................................... 31
8.3.1 Amplitudes in Dependence on the Load...................................................................................... 32
8.4 Time................................................................................................................................................. 34
8.5 Optimisation of Time and Amplitude................................................................................................ 34
8.6 Interval............................................................................................................................................. 35
8.6.1 Interval Time................................................................................................................................ 35

4
8.7 Programme Mode............................................................................................................................ 35
8.7.1 Select a Program......................................................................................................................... 36
8.7.2 Edit a Program............................................................................................................................. 36
8.7.3 Save a Programme...................................................................................................................... 36
8.8 Signal Tone...................................................................................................................................... 36
8.8.1 Operating Hours........................................................................................................................... 36
8.8.2 Software Version ......................................................................................................................... 37
8.9 Date ................................................................................................................................................. 37
9Wet Sieving .......................................................................................................................................... 38
9.1 Installing the Slash Protection ......................................................................................................... 38
9.2 Performing the Wet Sieving............................................................................................................. 39
10 EasySieve®........................................................................................................................................... 42
11 Error Messages and Information Notes............................................................................................ 43
11.1 Error Messages ............................................................................................................................... 43
11.2 Information Notes ............................................................................................................................ 43
12 Return for Service and Maintenance................................................................................................. 45
13 Cleaning, Wear and Maintenance ...................................................................................................... 46
13.1 Cleaning........................................................................................................................................... 46
13.1.1 Cleaning of Test Sieves........................................................................................................... 46
13.1.1.1 Cleaning of Test Sieves with Mesh Sizes > 500 µm ....................................................... 46
13.1.1.2 Cleaning of Test Sieves with Mesh Sizes < 500 µm ....................................................... 46
13.1.1.3 Drying of Test Sieves....................................................................................................... 47
13.2 Wear ................................................................................................................................................ 47
13.3 Maintenance .................................................................................................................................... 47
13.3.1 Replacing the Fuses................................................................................................................ 48
14 Accessories ......................................................................................................................................... 49
14.1 Test Sieves...................................................................................................................................... 49
14.1.1 Certificate................................................................................................................................. 49
14.1.2 Calibration Service................................................................................................................... 50
14.2 Sieving Aids..................................................................................................................................... 50
14.3 Add-on Weight................................................................................................................................. 51
15 Disposal................................................................................................................................................ 52
16 Index ..................................................................................................................................................... 53

Notes on the manual
5

Notes on the manual
6
Pos: 1.1 /0000 Firmen neutral/0030 Übersc hriften/1. Überschrift en/1 Hinweise zur Bedie nungsanleitung @ 0 \mod_122234741 5287_9.docx @ 26 31@ 1 @ 1
1 Notes on the manual
Pos: 1.2/ 0000F irmenneutral/0 000M odule/1000 Hinweise zur Bedien ungsanleitung @ 0\m od_1228722945175_9 .docx @ 4058 @ @ 1
This manual provides technical guidelines for the safe operation of the device. Read this
manual through carefully before installing, putting into service and operating the device.
Reading and understanding this manual is essential for handling the device safely and as
intended.
This manual does not contain any repair instructions. Please contact your supplier or contact
Retsch GmbH directly if anything is unclear or you have questions about these guidelines or the
device, or in the case of any faults or necessary repairs.
You can find further information about your device at https://www.retsch.com on the pages for
the specific device concerned.
Amendment status:
The document amendment 0006 of the "Vibratory Sieve Shaker AS 300 control" manual has
been prepared in accordance with the Machinery Directive 2006/42/EC.
Pos: 1.3 /0000 Firmen neutral/0030 Übersc hriften/1.1 Überschrifte n/11 Erklärungen zu Z eichen und Symbolen @ 3 2\mod_153 0532085977_9.docx @ 2 54358 @ 2 @ 1
1.1 Explanation of signs and symbols
Pos: 1.4 /0000 Firmen neutral/0000 Module/ 2000 Erklärung Zeic hen und Symbole @ 12\m od_144541742 9596_9.docx @ 91031 @ @ 1
In this document the following signs and symbols are being used:

Reference to a recommendation and/or an important information
→
Reference to a chapter, table or figure

Action instruction
│Name│
Software menu function
[Name]
Software button
⟨Name⟩
Software checkbox
Pos: 1.5/ 0000F irmenneutral/0 030 Überschriften/1.1 Üb erschriften/11 Haftungsa usschluss @ 12\mod_144 5422176588_9.docx @ 9162 8@ 2 @ 1
1.2 Disclaimer
Pos: 1.6 /0000 Firmen neutral/0000 Module/ 1005H aftungsaussc hluss @ 12\mod_ 144541728378 7_9.docx @ 90992 @ @ 1
This manual has been prepared with great care. We reserve the right to make technical
changes. We assume no liability for personal injuries resulting from the failure to follow the
safety information and warnings in this manual. No liability will be assumed for damage to
property resulting from the failure to follow the information in this manual.
Pos: 1.7 /0000 Firmen neutral/0030 Übersc hriften/1.1 Überschrifte n/11 Urheberrech t@ 1 2\mod_144 5422883945_9.docx @ 9 1640 @ 2 @ 1
1.3 Copyright
Pos: 1.8 /0000 Firmen neutral/0000 Module/ 1010Ur heberrecht @ 12\mod_14454 17285503_9.docx @ 91005 @ @ 1
This document or parts of it or its content may not be reproduced, distributed, edited or copied
in any form without prior written permission of Retsch GmbH. Damage claims shall be asserted
in the case of infringements.
Pos: 2/ 0000 Firmenneutr al/0000 Module/------- Seitenum bruch -------@ 9\m od_1427185989165 _0.docx @ 76350 @ @ 1

Safety
7
Pos: 3.1/ 0000F irmenneutral/0 030Üb erschriften/1. Übersc hriften/1 Sicherheit @ 32\mo d_1530532306253_ 9.docx@ 2 54376 @ 1@ 1
2 Safety
Pos: 3.2 /0000 Firmen neutral/0000 Module/ 2030 Sicherheitshinw eise Gerät @ 18\mo d_147340778765 4_9.docx @ 128095 @ @1
Safety Officer
The operating company itself must ensure the following with respect to persons authorised to
work on the device:
−that they have read and understood all regulations contained in the chapter on safety;
−that they are aware before they start work of all instructions and regulations for the target
group related to the work;
−that they have easy access to the manual for this device at all times;
−that they have been familiarised with the safe and correct handling of the device before
starting work on it, by means of a verbal introduction by a competent person and/or using
this manual.
Improper operation can lead to personal injuries. The operating company itself is
responsible for its safety and that of its staff. The operating company itself must ensure that no
unauthorised persons have access to the device.
Pos: 3.3/ 0000F irmenneutral/0 000M odule/2025 Zielgrupp eGerä t@ 12\m od_144541743 4495_9.docx @ 91057 @ @ 1
Target group
All those operating, cleaning or working with or on the device.
This device is a modern, powerful product from Retsch GmbH and has been developed in line
with the state-of-the art. The device is safe to use when operated correctly and when following
the instructions in this manual.
Pos: 3.4 /0000 Firmen neutral/0000 Module/ 2031 VORSICHT Em bedded Keine Bedienu ngv on Personen unter divers en Einflüssen @ 19 \mod_14780 75510931_9.docx @ 1 33462 @ @ 1
People under the influence of intoxicating substances (medications, drugs, alcohol) or who
are overtired may not operate the device or work on the device.
Pos: 3.5 /0000 Firmen neutral/0000 Module/------- Seite numbruch ------- @ 9\mod_14271 85989165_0.docx @ 76350 @ @ 1

Safety
8
Pos: 3.6 /0000 Firmen neutral/0030 Übersc hriften/1.1 Überschrif ten/11 Erklärungen zu d en Sicherheitshinweis en @ 0\mod_12 22344569771_9.d ocx @ 2484 @ 2 @ 1
2.1 Explanations of the Safety Instructions
Pos: 3.7/ 0000F irmenneutr al/0000 Module/2000 Einleitung Erkl ärungenW arnhinweis e@ 32\m od_153053558 4791_9.docx @ 254394 @ @ 1
The following warnings in this manual warn of possible risks and damage:
Pos: 3.8 /0000 Firmen neutral/0035 War nhinweise/0001 GEF AHR/G0000 GEFAHR V orlage @ 17\mod_1 473405815457 _9.docx @ 128018 @ @ 1
DANGER
D1.0000
Risk of fatal injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Pos: 3.9 /0000 Firmen neutral/0000 Module/ 2005 Erklärung Sicherh eitshinweis Gef ahr@ 17\mod_147 3407755436_9.d ocx @ 128059 @ @ 1
Fatal or serious injuries may result if the “Danger” sign is disregarded. There is a very high
risk of a life-threatening accident or lasting personal injury. The signal word DANGER is
additionally used in the running text or in instructions.
Pos: 3.10 /0000 Firme nneutral/0035 Warn hinweise/0002 WARNUN G/W0000 WARNUN G Vorlage @ 17 \mod_147340633 4925_9.docx @ 12804 6@ @1
WARNING
W1.0000
Risk of life-threatening or serious injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Pos: 3.11 /0000 Firme nneutral/0000 Modul e/2010 Erklärung Sich erheitshinweis Warn ung @ 17\mod_1 473407756058_9. docx @ 128068 @ @ 1
Life-threatening or serious injuries may result if the “Warning” sign is disregarded. There is
an increased risk of a serious accident or of a possibly fatal personal injury. The signal word
WARNING is additionally used in the running text or in instructions.
Pos: 3.12 /0000 Firme nneutral/0035 Warnhinw eise/0003 VORSICH T/V0000 VORS ICHT Vorlage @ 17\m od_147340632 7022_9.docx @ 12803 7@ @ 1
CAUTION
C1.0000
Risk of injuries
Source of danger
−Possible consequences if the danger is ignored.
•Instructions and information on how to avoid the risk.
Pos: 3.13 /0000 Firme nneutral/0000 Modul e/2015 Erklärung Sich erheitshinweis Vorsic ht @ 17\mod_14 73407756844_9.d ocx @ 128077 @ @ 1
Average to slight injuries may result if the “Caution” sign is disregarded. There is an average
or slight risk of an accident or personal injury. The signal word CAUTION is additionally
used in the running text or in instructions.
Pos: 3.14 /0000 Firme nneutral/0000 Modul e/-------Seitenum bruch ------- @ 9\mod_142718598 9165_0.docx @ 76350 @ @ 1

Safety
9
Pos: 3.15 /0000 Firme nneutral/0035 Warn hinweise/0004 HINW EIS/H0000 HINWEIS V orlage @ 17\m od_1473406318798 _9.docx @ 128028 @ @ 1
NOTICE
N1.0000
Type of damage to property
Source of the damage to property
−Possible consequences if the information is ignored.
•Instructions and information on how to avoid the damage to
property.
Pos: 3.16 /0000 Firme nneutral/0000 Modul e/2020 Erklärung Sich erheitshinweis Hinweis @ 18\mod_1 473407757578 _9.docx @ 128086 @ @ 1
Damage to property may result if the information is disregarded. The signal word NOTICE is
additionally used in the running text or in instructions.
Pos: 3.17 /0000 Firme nneutral/0030 Überschrif ten/1.1 Überschrift en/11 Generelle Sich erheitshinweis e@ 0 \mod_122234 4568974_9.docx @ 2463 @ 2 @ 1
2.2 General Safety Instructions
Pos: 3.18 /0000 Firme nneutral/0035 Warnhinw eise/0003 VORSICH T/V0002 VORS ICHT Bedienungs anleitung lesen @ 18\mo d_1473413592 327_9.docx @ 12812 2 @ @ 1
CAUTION
C2.0002
Risk of injury
Lack of knowledge of the manual
−The manual contains all safety-related information. Disregarding the
manual can therefore lead to injuries.
•Read the manual carefully before operating the device.
Pos: 3.19 /0000 Firme nneutral/0035 Warnhinw eise/0003 VORSICH T/V0015 VORS ICHT Veränderung enam G erät @ 40\mod _15609352223 41_9.docx @ 304448 @ @ 1
CAUTION
C3.0015
Risk of injury
Improper modifications to the device
−Improper modifications to the device can result in injuries.
•Do not make any unauthorised changes to the device.
•Only use the spare parts and accessories approved by Retsch
GmbH!
Pos: 3.20 /0000 Firme nneutral/0035 Warnhinw eise/0004 HINW EIS/H0012 HINWEIS V eränderungen am Ger ät @ 18\mod_14 73414474874_9.d ocx @ 128140 @ @ 1
NOTICE
N2.0012
Changes to the device
Improper modifications
−The conformity declared by Retsch GmbH with the European Directives
will lose its validity.
−Any warranty claims will be terminated.
•Do not make any modification to the device.
•Use spare parts and accessories that have been approved by Retsch
GmbH exclusively.
Pos: 3.21 /0000 Firme nneutral/0000 Modul e/-------Seitenum bruch ------- @ 9\mod_1 427185989165_0.docx @ 7635 0@ @ 1

Safety
10
Pos: 3.22 /0000 Firme nneutral/0030 Überschrif ten/1.1 Überschrift en/11 Reparature n @ 0\mod_12236 24336511_9.docx @ 2978 @ 2 @ 1
2.3 Repairs
Pos: 3.23 /0000 Firme nneutral/0000 Modul e/2035 Reparature n @ 12\mod_144541 7441889_9.docx @ 91096 @ @ 1
This manual does not contain any repair instructions. For safety reasons, repairs may only be
carried out by Retsch GmbH or an authorised representative or by qualified service technicians.
In case of repair, please inform…
…the Retsch GmbH representative in your country,
…your supplier, or
…Retsch GmbH directly.
Service address:
Pos: 4/ 0000 Firmenneutr al/0000 Module/------- Seitenum bruch -------@ 9\m od_1427185989165 _0.docx @ 76350 @ @ 1

Confirmation Form for the Managing Operator
11
Pos: 5.1 /0000 Firmen neutral/0030 Übersc hriften/1. Überschrift en/1 Bestätigungsform ular für den Betreiber @ 1 \mod_1248959 947510_9.docx @ 12 690 @ 1 @ 1
3 Confirmation Form for the Managing Operator
Pos: 5.2 /0000 Firmen neutral/0000 Module/ 3000 Bestätigung G erät@ 12\mod_14 45417538545_9.d ocx @ 91135 @ @ 1
This manual contains essential instructions for operating and maintaining the device which must
be strictly observed. It is essential that they be read by the user and by the qualified staff
responsible for the device before the device is commissioned. This manual must be available
and accessible at the place of use at all times.
The user of the device herewith confirms to the managing operator (owner) that he has received
sufficient instructions about the operation and maintenance of the system. The user has
received the manual, has read and taken note of its contents and consequently has all the
information required for safe operation and is sufficiently familiar with the device.
The managing operator should for legal protection have the user confirm the instruction about
the operation of the device.
Pos: 5.3 /0000 Firmen neutral/0000 Module/ 3001 Bestätigung Untersc hriften @ 17\m od_14676180416 20_9.docx @ 1240 43@ @ 1
I have read and taken note of the contents of all chapters in this manual as well as all
safety instructions and warnings.
User
Surname, first name (block letters)
Position in the company
Place, date and signature
Managing operator or service technician
Surname, first name (block letters)
Position in the company
Place, date and signature
Pos: 5.4 /0000 Firmen neutral/0000 Module/------- Seite numbruch ------- @ 9\mod_14271 85989165_0.docx @ 76350 @ @ 1

Confirmation Form for the Managing Operator
12
Pos: 6/ 0000 Firmenneutr al/0000 Module/------- Seitenum bruch -------@ 9\m od_1427185989165 _0.docx @ 76350 @ @ 1

Technical Data
13
Pos: 7.1/ 0005R ETSCH/00 30Üb erschriften/1. Überschrift en/1Tec hnischeD aten @ 0\mod _1222344525522_9.d ocx @ 2407@ 1 @ 1
4 Technical Data
Pos: 7.2/ 0005R ETSCH/00 30Üb erschriften/1.1 Überschrif ten/11Sc hutzart @ 0\mod_12 26491839164_9.docx @ 3 328@ 2 @ 1
4.1 Degree of Protection
Pos: 7.3 /0005 RETSCH /0005 Bedienungsa nleitungen/AS 200 / AS 3 00s erie/Module/10 05Sc hutzart AS 200 / A300 S erie B/ A S 400c ontrol @ 14\m od_14492261 54520_9.docx @ 9493 4@ @ 1
−IP54 (IP20 in the area of the sieve carrier passage)
Pos: 7.4 /0005 RETSCH /0030 Überschriften/ 1.1Ü berschrifte n/11 Emissionen @ 0\mo d_1226487095 021_9.docx @ 3310 @ 2@ 1
4.2 Emissions
Pos: 7.5 /0005 RETSCH /0035W arnhinweis e/0003 VORSICHT/ V0011 VORSICHT Ü berhören von akustisch en Signalen (Siebger äusche) @ 18\mo d_147342273181 7_9.docx @ 12832 3@ @1
CAUTION
C4.0011
Possibility of acoustic signals not being heard
Loud sieving noises
−Possible acoustic alarms and voice communication might not be heard.
•Consider the volume of the sieving noise in relation to other acoustic
signals in the work environment. Additional visual signals may be
used.
Pos: 7.6/ 0005R ETSCH/00 35Warn hinweise/0003 VORSICHT/ V0017 VORSICHT Geh örschaden (Siebmaschi nen)@ 18\m od_147342 2732597_9.docx @ 128332 @ @ 1
CAUTION
C5.0017
Hearing damage
A high sound level may be generated depending on the type of material, the
number of sieves, the sieving aid used, the amplitude set and the duration of the
sieving
−Excessive noise in terms of level and duration can cause impairments or
permanent damage to hearing.
•Ensure suitable noise protection measures are taken or wear ear
protection.
Pos: 7.7 /0005 RETSCH /0005 Bedienungsa nleitungen/AS 200 / AS 30 0s erie/Module/10 10Emissi onen AS 300 con trol B@ 1 6\mod_146 1153485197_9. docx@ 105320 @ @ 1
Sound parameters:
The sound parameters are also influenced by the set amplitude, the number of test sieves and
the properties of the sample material.
Example:
Number of test sieves:
5
Amplitude:
1.5 mm
Feed material:
Quartz sand (< 1 mm)
Sieve clamping unit:
"comfort"
At these operating conditions, the workplace related equivalent continuous sound level
Leq = 59.8 dB(A).
Pos: 7.8 /0005 RETSCH /0030 Überschriften/ 1.1Ü berschriften/ 11El ektromagnetisch e Verträglichkeit (EMV) @ 14\mod_1 449224825974_9. docx @ 94910 @ 2 @ 1
4.3 Electromagnetic Compatibility (EMC)
Pos: 7.9 /0005 RETSCH /0000 Geräteneutr al/Module/1012 EMV Kl asse A @ 14\mod_ 1456910540468_ 9.docx @ 100128 @ @ 1
−EMC class according to DIN EN 55011: A
Pos: 7.10 /0005 RETSCH/ 0000 Gerätene utral/Module/101 1Elektr omagnetische V erträglichkeit Siebm aschinen @ 14\m od_14492249665 43_9.docx @ 94922 @ @ 1
Strong electromagnetic interference fields, such as high-power radio transmitters, can have an
adverse influence on the amplitude control of the AS 300 control. Once the source of the
interference is eliminated, the AS 300 control will return to normal operation by itself.
Pos: 7.11 /0005 RETSCH/0 030Ü berschriften/1.1 Überschrift en/11N ennleistung @ 0\m od_1226491873164 _9.docx @ 3334 @ 2@ 1
4.4 Rated Power
Pos: 7.12 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 20 0 /AS 300 serie/Module /1015N ennleistung AS 2 00/ A S 300 Serie B @ 13\m od_14491359135 41_0.docx @ 94648 @ @ 1
~ 460 W (VA)

Technical Data
14
Pos: 7.13 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1 Abmessungen un d Gewicht @ 0\mo d_1226492212173_ 9.docx @ 3352 @ 2 @ 1
4.5 Dimensions and Weight
Pos: 7.14 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/1 020 Abmessungen und Gewic ht AS 300 control B @ 16\mod_14 61141674781_9.docx @ 104952 @ @ 1
−Height without sieve clamping unit: 222 mm
−Height with sieve clamping unit: 852 mm
−Width: 417 mm
−Width with "comfort" clamping unit: 566 mm
−Depth: 384 mm
−Weight without sieve stack, without clamping unit: ~ 42 kg
Pos: 7.15 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1 Erforderliche Stan dfläche @ 0\mod_1 226492678414 _9.docx @ 3364 @ 2 @ 1
4.6 Required Floor Space
Pos: 7.16 /0005 RETSCH/ 0035 Warnhinweise /0003 VORSICH T/V0047 VORSICHT H erabfallen des G erätes @ 18\mod_14 73422733269_9.d ocx @ 128341 @ @ 1
CAUTION
C6.0047
Risk of injury caused by the device falling down
Incorrect installation of the device
−Due to its weight, the device can cause injuries if it falls down.
•Only operate the device on a sufficiently large, strong and stable
workstation.
•Ensure that all of the device feet are securely supported.
Pos: 7.17 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/1 025 Erforderlich e Standfläche AS 200 / AS 300 Seri e B@ 1 3\mod_144 9135914571_9.docx @ 9 4674 @ @ 1
−Width of the base: 450 mm
−Depth of the base: 450 mm
−No safety clearances required
Pos: 7.18 /0005 RETSCH/ 0000 Gerätene utral/Module/103 0Anf orderungen an den St andort Siebmaschi nen @ 13\mod_1449 135915257_9.d ocx @ 94687 @ @ 1
Location requirements:
The device must be placed on a vibration-free, plane, stable and free surface to avoid
transmission of vibrations. A level base ensures the uniform distribution of the sample over the
sieve mesh fabric, as well as the stability of the device.
Pos: 7.19 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1 Aufnahmevolume n @ 1\mod_12 41508533945_9.d ocx @ 8777 @ 2 @ 1
4.7 Receptacle Volume
Pos: 7.20 /0005 RETSCH/ 0000 Gerätene utral/Module/103 5Aufn ahmevolumen Si ebmaschinen @ 16\m od_146115457 7794_9.docx @ 10533 3@ @ 1
The maximum receptacle volume (the maximum feed quantity) depends on various factors such
as number and aperture size of the test sieves, maximum grain size and width of distribution of
the sample material.
Pos: 7.21 /0005 RETSCH/ 0000 Gerätene utral/Module/103 6Auf nahmevolumen 3 05mm Analysensie be@ 16\mod_ 1461141767119_9.d ocx @ 105238 @ @ 1
Examples for the maximum feed quantity according to DIN 66165 for test sieves of 305 mm
(12") in diameter are listed in the following table:
Mesh size
Max. feed quantity
Max. permitted oversize material
according to DIN 66165
25 µm
29 cm3
15 cm3
45 µm
44 cm3
22 cm3
63 µm
58 cm3
29 cm3
125 µm
88 cm3
44 cm3
250 µm
132 cm3
66 cm3
500 µm
205 cm3
102 cm3
1 mm
292 cm3
146 cm3
2 mm
511 cm3
256 cm3
4 mm
804 cm3
402 cm3
8 mm
1315 cm3
658 cm3

Technical Data
15
Pos: 7.22 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1 Aufgabegröße @ 3\m od_130216 1462732_9.docx @ 24 620 @ 2@ 1
4.8 Feed Grain Size
Pos: 7.23 /0005 RETSCH/ 0000 Gerätene utral/Module/104 0Aufg abegröße Analys ensiebe @ 26\m od_1505395904484 _9.docx @ 220396 @ @ 1
Traditional dry sieving is performed in the particle size range of 40 µm to 125 mm. By means of
sieving aids or with wet sieving the measurement range can be extended to 20 µm. The
maximum feed grain size depends on the sample material, the number and aperture size of the
test sieves and the type of the sieving machine.
Examples for the maximum feed grain size according to DIN 66165 are listed in the following
table:
Mesh size
Max. feed grain size
according to DIN 66165
Mesh size
Max. feed grain size
according to DIN 66165
22 µm
710 µm
4 mm
25 mm
45 µm
1 mm
8 mm
45 mm
63 µm
1.4 mm
16 mm
71 mm
125 µm
2.5 mm
22.4 mm
90 mm
250 µm
4 mm
45 mm
150 mm
500 µm
6 mm
63 mm
180 mm
1 mm
10 mm
90 mm
230 mm
2 mm
16 mm
125 mm
300 mm
Pos: 7.24 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/1 041 Aufgabegröße A S 300c ontrol B @ 16\mod _1461155625919_ 9.docx @ 105359 @ @ 1
The Vibratory Sieve Shaker AS 300 control is designed for the measurement range of 20 µm to
40 mm.
Pos: 7.25 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1Z uladung @ 14\mo d_1454659163 441_9.docx @ 98178 @ 2 @ 1
4.9 Payload
Pos: 7.26 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/1 045Z uladung AS 300 co ntrolB @ 50\mod _1596538868048_9. docx @ 379890 @ @ 1
Voltage
100 V
200 V
230 V
Maximum sample quantity:
3 kg
4 kg
5 kg
Maximum sieve stack weight:
7 kg
9,5 kg
11 kg
Maximum payload:
10 kg
13,5 kg
16 kg
The maximum payload is calculated from the amount of sample quantity (sample material) and
sieve stack mass (test sieves and clamping device) depending on the available nominal voltage.
For the calculation, a "comfort" sieve tensioning unit was used, the weight of which is approx. 5
kg.
−Maximum sieve stack height: 510 mm
−Maximum number of fractions: 10 (height of test sieves and collecting pan: 40 mm) /
10 (height of test sieves and collecting pan: 50 mm (2")) /
19 (height of test sieves and collecting pan: 25 mm (1"))
Pos: 7.27 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1 Verwendbare Sieb durchmesser @ 14 \mod_1 454662558474_9.d ocx@ 982 28@ 2 @ 1
4.10 Suitable Sieve Diameters
Pos: 7.28 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/1 050 Verwendbare Sieb durchmesser AS 300 co ntrol B @ 16\mod _1461141767951_9. docx @ 105264 @ @ 1
−Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8") / 305 mm (12") /
315 mm
Pos: 8/ 0000 Firmenneutr al/0000 Module/------- Seitenum bruch -------@ 9\m od_1427185989165 _0.docx @ 76350 @ @ 1

Packaging, Transport and Installation
16
Pos: 9.1 /0000 Firmen neutral/0030 Übersc hriften/1. Überschrift en/1 Verpackung, Tra nsport und Aufstellu ng@ 0 \mod_12264 94451893_9.docx @ 3 380 @ 1 @ 1
5 Packaging, Transport and Installation
Pos: 9.2 /0000 Firmen neutral/0030 Übersc hriften/1.1 Überschrif ten/11 Verpacku ng@ 0\mod_12264 95088973_9.docx @ 3 392 @ 2 @ 1
5.1 Packaging
Pos: 9.3 /0000 Firmen neutral/0000 Module/ 4000 Verpackung @ 12\m od_144541 8086744_9.docx @ 91 434 @ @ 1
The packaging has been adapted to the mode of transport. It complies with the generally
applicable packaging guidelines.
Pos: 9.4/ 0000F irmenneutral/0 035W arnhinweise/000 4HINW EIS/H0001 HINWEIS Aufb ewahrung der Verpackung @ 18 \mod_147341556056 4_9.docx @ 128167 @ @ 1
NOTICE
N3.0001
Complaint or return
Keeping the packaging
−Inadequate packaging and insufficient securing of the device can
jeopardise the warranty claim in the event of a complaint or return.
•Keep the packaging for the duration of the warranty period.
Pos: 9.5/ 0000F irmenneutral/0 030Üb erschriften/1.1 Überschrif ten/11 Transport @ 0\mo d_1226495164391_ 9.docx @ 3398@ 2 @ 1
5.2 Transport
Pos: 9.6/ 0000F irmenneutral/0 035W arnhinweise/0 004HINW EIS/H0017 HINWEI STrans port@ 1 8\mod_147341 5561032_9.docx @ 128176 @ @ 1
NOTICE
N4.0017
Damage to components
Transport
−Mechanical or electronic components may be damaged during transport.
The device must not be knocked, shaken or thrown during transport.
•Move the device gently during transport.
Pos: 9.7 /0000 Firmen neutral/0035 Warnhi nweise/0004 HINWEI S/H0014 HINWEI SR eklamationen @ 18\mod_ 1473415561968_ 9.docx@ 1 28185 @ @ 1
NOTICE
N5.0014
Complaints
Incomplete delivery or transport damage
−The forwarding agent and Retsch GmbH must be notified immediately in
the event of transport damage. It is otherwise possible that subsequent
complaints will not be recognised.
•Please check the delivery on receipt of the device for its
completeness and intactness.
•Notify your forwarding agent and Retsch GmbH within 24 hours.
Pos: 9.8 /0000 Firmen neutral/0030 Übersc hriften/1.1 Überschrifte n/11 Temperatursc hwankungen und Ko ndenswasser @ 11\m od_14359059 83675_9.docx @ 8491 6@ 2 @ 1
5.3 Temperature Fluctuations and Condensation
Pos: 9.9/ 0000F irmenneutral/0 035W arnhinweise/000 4HINW EIS/H0016 HINWEIS Temp eraturschwankunge n@ 18\m od_147341 5562519_9.docx @ 128194 @ @ 1
NOTICE
N6.0016
Damaged components due to condensation
Temperature fluctuations
−The device may be exposed to substantial fluctuations in temperature
during transport. The ensuing condensation can damage electronic
components.
•Wait until the device has acclimatised before putting it into service.
Pos: 9.10 /0000 Firme nneutral/0000 Modul e/4004 Zwischenlag erung @ 14\mod_ 1449227681266_9.d ocx @ 94946 @ @ 1
Temporary storage:
Also in case of an interim storage the device must be stored dry and within the specified
ambient temperature range.

Packaging, Transport and Installation
17
Pos: 9.11 /0000 Firme nneutral/0030 Überschrif ten/1.1 Überschrift en/11 Bedingunge nf ür den Aufstellort @ 0\m od_122649702 9322_9.docx @ 34 28@ 2 @ 1
5.4 Conditions for the Installation Site
Pos: 9.12 /0000 Firme nneutral/0035 Warnhinw eise/0004 HINW EIS/H0021 HINWEIS Um gebungstemp eratur 5°C bis 40°C @ 18 \mod_1473415 563563_9.docx @ 128 203 @ @ 1
NOTICE
N7.0021
Ambient temperature
Temperatures outside the permitted range
−Electronic and mechanical components may be damaged.
−The performance data alter to an unknown extent.
•Do not exceed or fall below the permitted temperature range (5 °C to
40 °C ambient temperature) of the device.
Pos: 9.13 /0000 Firme nneutral/0000 Modul e/4010 Aufstellen des G erätes @ 12\mod _1445418101455 _9.docx @ 91525 @ @ 1
−Installation height: max. 2 000 m above sea level
Pos: 9.14 /0000 Firme nneutral/0000 Modul e/4005 Umgebungst emperatur 5°C bis 40°C @ 1 2\mod_14454 18096385_9.docx @ 91499 @ @ 1
−Ambient temperature: 5 °C –40 °C
Pos: 9.15 /0000 Firme nneutral/0000 Modul e/4006 Luftfeuchtigk eit @ 14\mod_144 9471425923_9.docx @ 94958 @ @ 1
−Maximum relative humidity < 80 % (at ambient temperatures ≤31 °C)
For ambient temperatures UTbetween 31 °C and 40 °C, the maximum relative humidity value LF
linearly decreases according to LF= –(UT–55) / 0.3:
Ambient temperature
Max. rel. humidity
≤31 °C
80 %
33 °C
73.3 %
35 °C
66.7 %
37 °C
60 %
39 °C
53.3 %
40 °C
50 %
Pos: 9.16 /0000 Firme nneutral/0035 Warn hinweise/0004 HINW EIS/H0015 HINWEIS L uftfeuchtigkeit @ 18\m od_147341 5564338_9.docx @ 12 8212@ @1
NOTICE
N8.0015
Humidity
High relative humidity
−Electronic and mechanical components may be damaged.
−The performance data alter to an unknown extent.
•The relative humidity in the vicinity of the device should be kept as
low as possible.
Pos: 9.17 /0000 Firme nneutral/0000 Modul e/-------Seitenum bruch ------- @ 9\mod_142718598 9165_0.docx @ 76350 @ @ 1

Packaging, Transport and Installation
18
Pos: 9.18 /0000 Firme nneutral/0030 Überschrif ten/1.1 Überschrift en/11 Elektrischer A nschluss @ 0\mo d_1226565067445_ 9.docx @ 3500 @ 2 @ 1
5.5 Electrical Connection
Pos: 9.19 /0005 RETSCH/ 0035 Warnhinw eise/0002 WARNUN G/W0015 WARNUN G Lebensgefahr d urch Stromschlag (Ansc hluss an Steckdosen ohn e Schutzleiter) @ 27\m od_151082908 0017_9.docx @ 2257 54@ @ 1
WARNING
W2.0015
Risk to life caused by an electric shock
Connection to socket without a protective earth conductor
−Connecting the device to sockets without a protective earth conductor can
lead to life-threatening injuries caused by an electric shock.
•Always operate the device using sockets with a protective earth
conductor (PE).
Pos: 9.20 /0000 Firme nneutral/0035 Warnhinw eise/0004 HINW EIS/H0022 HINWEIS El ektrischer Anschluss @ 18\mod_ 1473415564928_9.d ocx @ 128221 @ @ 1
NOTICE
N9.0022
Electrical connection
Failure to observe the values on the type plate
−Electronic and mechanical components may be damaged.
•Connect the device only to a mains supply matching the values on
the type plate.
Pos: 9.21 /0000 Firme nneutral/0000 Modul e/4015 Elektrisch erA nschluss @ 18\mo d_1473407848410_ 9.docx @ 128113 @ @ 1
WARNING When connecting the power cable to the mains supply, use an external fuse that
complies with the regulations applicable to the place of installation.
−Check the type plate for details on the necessary voltage,frequency, and maximum
external current source fuse for the device.
−The listed values must agree with the existing mains supply.
−Only use the supplied power cable to connect the device to the mains supply.
Pos: 10.1 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1T ypenschild Beschr eibung @ 3\mod_ 1280933953941 _9.docx @ 22302 @ 2 @ 1
5.6 Type Plate Description
Pos: 10.2 /0005 RETSCH/ 0000 Gerätene utral/Module/100 0Ty penschild Retsch @ 12\m od_144541 7988309_9.docx @ 91 408 @ @ 1
Fig. 1: Type plate
1 Device designation
2 Year of production
3 Part number
4 Serial number
5 Manufacturer’s address
6 CE marking
7 Disposal label
8 Bar code
1
2
3
4
5
6
7
8
9
10
11
12
14
13

Packaging, Transport and Installation
19
9 Power version
10 Mains frequency
11 Capacity
12 Amperage
13 Number of fuses
14 Fuse type and fuse strength
In the case of queries please provide the device designation (1) or part number (3), as well
as the serial number (4) of the device.
Pos: 11.1 /0005 RETSCH/ 0030 Überschrifte n/1.1 Überschriften/1 1Tr ansportsicher ung entfernen @ 0\mo d_1227530921 618_9.docx @ 3980 @ 2 @ 1
5.7 Removing the Transportation Lock
Pos: 11.2 /0000 Firme nneutral/0035 Warnhinw eise/0002 WARNUN G/W0005 WARNUN G Schwerer Perso nenschaden (Hera bfallende Lasten) @ 18\mo d_1473667539154_9. docx @ 128550 @ @ 1
WARNING
W3.0005
Risk of injury due to the device falling down
Lifting the device above head height
−The device can fall causing serious injuries when lifted above head
height.
•Never lift the device above head height!
Pos: 11.3 /0005 RETSCH/ 0035 Warnhinweise /0004 HINWEIS/H0 018 HINWEIS Tra nsportsicherung @ 18 \mod_14736 68242245_9.docx @ 1 28559 @ @ 1
NOTICE
N10.0018
Transportation lock
Transport without transportation lock, or operation with transportation lock
−Mechanical components may be damaged.
•Only transport the device with mounted transportation lock.
•Do not operate the device with built-in transportation lock.
Pos: 11.4 /0005 RETSCH/ 0005 Bedienungs anleitungen/AS 200 / AS 3 00 serie/Module/4 000Tr ansportsich erung entfernen AS 300 contr ol B @ 18\mod_147 3659020758_9. docx@ 128451 @ @ 1
Fig. 2: Removing the transportation lock
SM
SM
ST

Packaging, Transport and Installation
20
Fig. 3: Mounting the rubber disc
The transportation lock consists of two long hexagonal screws (SM) securing the drive through
the sieve plate (ST).
Loosen the hexagonal screws (SM) on both sides of the sieve plate (ST) by means of a
13 mm open-end wrench and remove them.
Keep the transportation lock for later transport.
Remove the protective foil from the adhesive tape located on the underside of the rubber
disc (GM).
Position the rubber disc (GM) centrally on the sieve plate (ST) and press it down firmly.
NOTICE The weight without sieve stack and sieve clamping unit amounts approx. 42 kg. The
device must only be lifted by two people.
Pos: 12 /0000 Firmenne utral/0000 Module/------- Seitenum bruch ------- @ 9\mod_142718 5989165_0.docx @ 76350 @ @ 1
GM
ST
