Revitive Medic 2837AB User manual

Medic
CIRCULATION BOOSTER®
Model number /
Numéro de modèle :
2837AB
Drug Free/Sans Médicament
Clinically Proven/Eicacité Cliniquement Prouvée
Certified Medical Device/Dispositif Médical
Manuel de l’utilisateur
FR
Veuillez lire attentivement le
manuel de l’utilisateur avant
d’utiliser ce produit.
UTILISEZ EXCLUSIVEMENT SELON L’USAGE
PRÉCONISÉ. Si les symptômes persistent,
veuillez consulter un professionnel de santé
User’s Manual
EN
Please read the user’s manual
Carefully before using this product. USE ONLY AS DIRECTED. If symptoms persist,
consult your healthcare professional
TECHNOLOGY TECHNOLOGIE
|
®
5839_IFU04_18244309.indd 15839_IFU04_18244309.indd 1 06/10/2021 16:4406/10/2021 16:44

2 3
How-to videos
For videos of setup and using your
Revitive system, go to:
support.revitive.com
For best results
Use daily
30-60 min
Intensity 40+
for 60+ days
2-year warranty
To activate your free 2-year warranty
please register your device at:
support.revitive.com
Table of contents
What’s in the box? 4
Parts and Controls 5-6
Introduction to Revitive 7-8
Operator profile 7
Indications for use 7-8
Important Safeguards 9-14
Who should NOT use Revitive 9
Warnings and Cautions 10-12
Safety Precautions 13
Adverse Reactions 14
Instructions for use 15-25
Step 1: Setting up Revitive for use 16
Step 3: Using the foot-pads 17-18
Step 4: Using the Dual Mode Body Pads
19-23
4.1: Switching between EMS and TENS mode 24
Step 5: Cleaning and storing 25
Replacing the batteries & Body Pads 25
Troubleshooting 26-28
Technical Specifications 30-32
Warranty 33
EN
5839_IFU04_18244309.indd 2-3
5839_IFU04_18244309.indd 2-3
06/10/2021 16:44
06/10/2021 16:44

4 5
What’s in the box? Parts and controls
On opening the carton, please check that the following components are
provided. If you think anything is missing, please contact us using the helpline
numbers on the back of this booklet.
Power adapter
Cable length 180cm
Revitive Medic
Electrode Body Pads
Electrode cord
Cable length 150cm
Remote control
AAA batteries x 2
1
2
3
4
5
6
Carry handle
Control panel/
display
AC/DC power
adaptor socket
Body Pads socket
Foot-pads
IsoRocker®
Power ON/OFF
EN
5839_IFU04_18244309.indd 4-5
5839_IFU04_18244309.indd 4-5
06/10/2021 16:44
06/10/2021 16:44

6 7
Introduction to Revitive
Operator Prole
The intended operator profile is based on users in the home environment who may
suer from immobility, osteoarthritis of the knee, poor circulation and related issues
such as pain, leg stiness and swelling in the legs, ankles and feet. It is also suitable for
rehabilitation following knee-surgery.
Revitive is intended for use by the end user in a non-clinical setting and without the
supervision or intervention of a clinician during use.
A typical user may be of any adult age range and is not specific to any demographic of
gender, ethnicity or educational background.
Intensity
level
Power
ON/OFF
TENS
EMS
Remote control
Control panel
Time
remaining
Intensity Control – /+
Intensity
Control – /+
EMS TENS
Parts and controls
Electrical Muscle Stimulation (EMS)
Indications for use
When using the foot-pads, Revitive is intended to:
• Reduce pain and discomfort in the legs/ankles/feet - caused by poor circulation
(Peripheral Arterial Disease).
• Improve circulation in the legs - caused by Peripheral Arterial Disease.
• Improve circulation to reduce or prevent blood-pooling (stasis) - caused by poor
circulation (Chronic Venous Insuiciency/varicose veins).
• Increase walking distance before the onset of claudication symptoms (pain) – caused
by Peripheral Arterial Disease.
• Improve symptoms associated with varicose veins/ Chronic Venous Insuiciency.
• Help maintain leg vein health - by increasing circulation, delivering more oxygenated-
blood and reducing swelling (oedema) in the legs, feet & ankles.
When using electrode pads, applied to the legs, Revitive is
intended to:
• Reduce pain and discomfort in the legs/ankles/feet - caused by Diabetic Peripheral
Neuropathy, or swelling (oedema) due to osteoarthritis or following surgery
• Reduce swelling in the legs/ankles/feet - caused by being immobile due to
osteoarthritis or an injury.
EN
5839_IFU04_18244309.indd 6-7
5839_IFU04_18244309.indd 6-7
06/10/2021 16:44
06/10/2021 16:44

8 9
Introduction to Revitive
Read all instructions before use.
Save these instructions.
Revitive should not be used by some people.
Do not use if (contraindications):
• You are fitted with an electronic implanted device such as a heart
pacemaker or Automatic Implantable Cardioverter Defibrillator (AICD)
• You are pregnant
• You are being treated for, or have the symptoms of, an existing Deep Vein
Thrombosis (“DVT”)
Long periods of inactivity can put you at greater risk of developing Deep Vein
Thrombosis (DVT). DVT is a blood clot and usually occurs in a deep leg vein.
If part of the DVT breaks o it may lead to potentially life-threatening
complications such as pulmonary embolism.
If you have been inactive for prolonged periods and suspect you may
have a DVT, consult your doctor immediately. To prevent dislodging the
clot do not use Revitive.
In some cases of DVT there may be no symptoms. However it is important
to be aware of the symptoms that may include:
• Pain, swelling and tenderness in one of your legs (usually your calf)
• A heavy ache in the aected area
• Warm skin in the area of the clot
• Redness of your skin, particularly at the back of your leg, below
the knee
Leg symptoms, especially where combined with certain underlying medical conditions,
such as high blood pressure, high cholesterol, smoking or diabetes may be an indicator
of poor circulation associated with peripheral arterial disease.
Consult your doctor as soon as possible if you show any signs of DVT, or have leg
symptoms combined with any of the risk factors.
Important safeguards
Electrical Muscle Stimulation (EMS)
Indications for use continued
When using electrode pads, applied to the legs, Revitive is
intended to:
• Improve circulation to reduce or prevent blood-pooling (stasis) - caused by diabetes or
by being immobile following surgery.
• Increase muscle strength to help regain mobility in the legs aected by being
immobile due to COPD, osteoarthritis or following surgery.
If you are otherwise healthy and have a sedentary lifestyle or spend long periods inactive,
Revitive may help to:
• Alleviate tired, aching & heavy legs, including cramp
• Reduce swollen feet & ankles
• Help maintain leg vein health
• Strengthen leg muscles
• Actively increase circulation
Transcutaneous Electrical Nerve Stimulation
(TENS) Indications for use
When using electrode pads, Revitive is intended to provide:
• Temporary relief of pain of musculoskeletal or neuropathic origin
• Relief of arthritis-associated pain
• Relief and management of chronic pain, associated with musculoskeletal pain,
osteoarthritis and fibromyalgia
• Relief of post-surgical and post-traumatic pain
The above Indications for Use are certified under the Medical Devices Directive 93/42/EEC.
EN
5839_IFU04_18244309.indd 8-9
5839_IFU04_18244309.indd 8-9
06/10/2021 16:44
06/10/2021 16:44

10 11
Warnings
When applying foot-pads or electrode body pads:
• There is a chance you may experience skin irritation or burns beneath the electrode
pads or hypersensitivity due to the electrical stimulation
• Ensure that any moisturizer/gel/balm is evenly applied and thoroughly absorbed
into the skin before applying stimulation. There is a chance that uneven application
of a moisturizer/gel/balm could increase the risk of skin irritation or burn, when
using the electrical stimulation
• Symptoms may worsen during the initial treatment phase before getting better.
This may occur if the body has not fully adjusted to increased muscular activity
and blood circulation. If this occurs, reduce the intensity and the duration of
treatment which will reduce the initial symptoms. If symptoms persist consult
with your doctor
When not to use Revitive:
• There are times you should not use Revitive. Do not use Revitive:
•In the presence of electronic monitoring equipment
•Together with a life-supporting medical electronic device
•When you are in the bath or shower
•While you are sleeping
• In conjunction with a brace or cast without first consulting with your doctor
• Use of this equipment adjacent to or stacked with other equipment should be
avoided because it could result in improper operation. If such use is necessary,
this equipment and the other equipment should be observed to verify that they
are operating normally
Additional Warnings:
• Use of accessories and cables other than those specified or provided by the
manufacturer of this equipment could result in increased electromagnetic emissions
or decreased electromagnetic immunity of this equipment and result in improper
operation
• Portable RF communications equipment (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches)
to any part of the Revitive System, including cables specified by the manufacturer
Warnings
Consult with your doctor before using this device if:
• You are in the care of a doctor
• You have a history of heart problems
• You have had medical or physical treatment for your pain
• You have suspected or diagnosed heart disease
• You have suspected or diagnosed epilepsy
• You are unsure about the suitability of Revitive for you
• You are unsure about the cause of your symptoms
If you have a metallic implant:
• If you have a metallic implant, you may experience pain or discomfort near the
implant when applying electrical stimulation. If this should occur discontinue use
and seek advice from your doctor
• The electrical stimulation may feel more intense close to a metallic implant. It is
safe to continue use provided no pain is experienced. You may need to adjust the
intensity to a comfortable level
When applying foot-pads or electrode body pads:
• Do not use the electrode pads on your head, face, neck or chest
• Application of the electrodes near the thorax (chest) may increase the risk of cardiac
fibrillation
• Do not apply foot-pads or electrode pads directly on these areas:
• on open wounds or rashes; swollen, red, infected or inflamed areas; or skin
eruptions (such as phlebitis, thrombophlebitis, varicose veins, cellulitis)
• on, or close to, malignant tumours
• on areas treated with radiotherapy (within the past 6 months)
• on reproductive organs
• on opposing thighs and refer to pad placement diagrams in this User’s Manual for
correct placement
• When using TENS do not apply to areas of skin that lack sensation.
• Electrode pads are for single person use only. Do not share electrode pads with
others
• Do not use electrode pads aer their use-by date
Important safeguards EN
5839_IFU04_18244309.indd 10-11
5839_IFU04_18244309.indd 10-11
06/10/2021 16:44
06/10/2021 16:44

12 13
Safety Precautions
• Do not stand on the machine. Use only when seated
• Do not position the Revitive so that it is diicult to disconnect or turn o
• Use the device only for its intended purpose
• Do not expose the device to extreme heat
• Do not spill liquid on the device or its accessories
• Do not overload the electrical socket
• Keep device out of the reach of children
• Keep power cords and cables out of the reach of children to prevent risk of
strangulation
• Revitive foot-pads may be used by multiple persons. Ensure device is cleaned aer
each use
• During use, do not touch foot-pads with your hands until the device has powered o
• Use Revitive only with the accessories supplied by, or purchased from, the
manufacturer
• Check Body Pads, cords and cables periodically for damage
• Do not open Revitive or repair it yourself. This will invalidate your warranty and may
cause serious harm
• In the unlikely event your Revitive malfunctions, disconnect it from the power
source and contact your nearest authorized agent
• It has been reported that some universal remote control devices (e.g. for TV
etc.) can change the settings on Revitive if used during a treatment. If this should
occur, simply adjust the time or intensity settings on Revitive back to where you want
them using the Revitive Remote Control, or using the device Control Panel
• Revitive has passed the required tests for Electromagnetic Interference (EMI); it
may still be aected by excessive emissions and/or may interfere with more
sensitive equipment
• Aer any exposure to hot or cold temperatures outside the specified operating
range of 10 – 40°C allow the product to re-adjust to the recommended operating
temperatures to ensure continued product performance
Cautions
When applying foot-pads or electrode body pads:
• Be careful when applying stimulation over areas of skin that lack normal
sensation.
It may cause skin irritation due to the inability to feel stimulation until the intensity
is too high. Use a low intensity to achieve a gentle muscle contraction, and/or
use for a shorter time, to avoid over-stimulation. Check for signs of skin irritation
(redness), bruising or pain. If in doubt consult your doctor
• This product is not intended for use by persons with reduced physical, sensory or
mental capabilities, unless they are supervised by a person responsible for their
safety
When using EMS:
• Be careful when applying stimulation:
•Over the abdomen during menstruation
•Aer recent surgical procedures (within the past 6 months) as stimulation may
disrupt your healing process
•If your tissues are likely to bleed following an injury such as a muscle tear - it is
recommended not to stimulate the immediate area within the first 12 hours
aer sustaining the injury. Use a low intensity and/or shorter time to avoid
over-stimulation
•Aer a long period of immobility or inactivity – use a low intensity and shorter
time to avoid over-stimulation or muscle fatigue
When using TENS:
• It is possible Revitive may reduce the sensation of pain that would normally act
as a warning of an underlying problem
•If your pain does not improve, gets worse or continues for more than 5 days, stop
using the device and seek advice from your doctor
• TENS is not eective in treating the original source or cause of pain
Additional Cautions:
• The long term eects of electrical stimulation are unknown
• Electrical stimulation may not work for every user, please seek advice from
your doctor
Important safeguards EN
5839_IFU04_18244309.indd 12-13
5839_IFU04_18244309.indd 12-13
06/10/2021 16:44
06/10/2021 16:44

14 15
Adverse Reactions
• If you experience adverse reactions, stop using Revitive and consult with your
doctor immediately
Important safeguards Instructions for use
Before you use Revitive for the first time, read the Important Safeguards on
pages 9-14. If in doubt, consult your doctor before using the product.
Step 1: Setting up Revitive for use
aRemove all parts from the box:
• AC/DC power adaptor
• Revitive Medic device
• Remote control
• AAA batteries x 2
• Electrode Body Pads
• Electrode cord
See “What’s in the box?” on page 4 to help identify the parts.
bLocate the remote control and insert the batteries.
cLocate the AC/DC power adaptor.
Plug the small end of the power cord into the socket
on the side of the Revitive.
dPlug the power adaptor into the nearest electrical
socket.
EN
5839_IFU04_18244309.indd 14-15
5839_IFU04_18244309.indd 14-15
06/10/2021 16:44
06/10/2021 16:44

16 17
Sit with
both bare feet
on the foot-pads
bGet into a comfortable seated position.
For best results sit with your knees at a 90 degree angle
(right angle).
cPlace Revitive on the floor in front of you.
Revitive is designed to be used while seated.
Never stand on the Revitive unit.
dPlace both bare feet on the foot-pads.
Make sure you remove all footwear, including socks/
stockings.
ePress the power button on the device or on the remote
control to turn Revitive on.
You will hear a beep and the display will light up.
The Time will read 30 minutes and Intensity will
read 00.
To turn o Revitive at any time during operation,
press the power button on the device or on the remote
control.
fPress the (+) Intensity Control one time to
start stimulation.
You can use the buttons on the control panel or remote
control.
Press the (+) button to increase the level.
Press the (–) button to decrease the level.
Instructions for use
Step 2: Using the foot-pads
The foot-pads will only deliver , Electrical Muscle Stimulation (EMS) with clinically proven
and patented waveforms, to your feet and legs. You can use the Body Pads to receive EMS
or TENS, see pages 19-23 for details.
aIt is important that you are well hydrated. We recommend that you apply a
moisturizer to the soles of the feet to help hydrate the skin and improve the
delivery of electrical stimulation.
We also recommend drinking a glass of water before using Revitive.
For best results:
• Use Revitive foot-pads for at least 30 to 60 minutes each day, 7 days a week.
If you have varicose veins, use Revitive foot-pads for 60 minutes per day.
• It is important to use Revitive at a high enough intensity to give you a strong
comfortable muscle contraction. Most people achieve a strong muscle
contraction over intensity level 40 (intensity range 1-99).
• If you are diagnosed with a long term medical condition such as Diabetes,
Osteoarthritis, Varicose Veins, Poor Circulation or COPD, it can take up to 8
weeks to help reduce symptoms associated with these chronic conditions.
Do not use Revitive, using EMS stimulation, for more than 6 sessions of 30 minutes
(or the equivalent) per day. Seek medical diagnoses from your doctor if you have
leg symptoms combined with high blood pressure, high cholesterol, diabetes or
smoking.
EN
5839_IFU04_18244309.indd 16-17
5839_IFU04_18244309.indd 16-17
06/10/2021 16:44
06/10/2021 16:44

18 19
gEnsure you familiarise yourself with the feeling of OxyWave therapy. Use on a low
intensity for 30-60 minutes once per day for a few days.
Set the intensity at a level where you can feel the stimulation in your feet which
creates a calf muscle contraction.
It is normal to feel tingling or varying sensations in your feet and calf muscles.
Revitive does not vibrate.
hAer a few days of familiarization, use a higher intensity that provides you with
strong but comfortable calf muscle contractions.
Most people experience a strong contraction at intensity level 40 or over.
The IsoRocker® enables Revitive to rock up and down once muscle contractions are
nearing the desired level. The rocking is caused by muscle contractions in the leg,
and the resulting ankle movement allowed by the IsoRocker is a good indicator
that the intensity level is suicient to provide the therapy. Increasing the intensity
above this level will enhance the therapy, but should not be allowed to become
uncomfortable.
You can set the intensity between 1-99.
Please note that the intensity required may vary from day to day.
iThe Time Display will start to count down in minutes as Revitive cycles
through its program.
jWhen Revitive times out, the Time Display reads 00 and you will hear
three beeps.
kRevitive switches itself o automatically.
Instructions for use
If you feel pain or discomfort:
• Remove one or both feet from the foot-pads to stop the stimulation
• Lower the intensity of the foot-pads using the (–) Intensity Control on
the control panel, or remote control, before replacing your feet on Revitive
Use Revitive Body Pads in EMS
mode for muscle strengthening and
rehabilitation when required, from 30
minutes per day.
Do not use Revitive in EMS mode for
more than 6 sessions of 30 minutes (or
the equivalent) per day. This may result
in muscle fatigue.
Use at an intensity that provides you
with strong but comfortable muscle
contractions.
It is recommended to use Revitive
in TENS mode for temporary
pain relief from chronic joint,
muscular, nerve or arthritic pain.
Use for 20-30 minutes per session
as and when required.
Use at an intensity that provides a
strong but comfortable tingling
sensation without causing you
pain.
Do NOT use the Body Pads on your head, face, neck or chest.
The Body Pads cannot be used at the same time as the foot-pads.
Using the Body Pads will automatically turn the foot-pads o.
1. EMS Mode 2. TENS Mode
Step 3: Using the Dual Mode Body Pads
Electrode Body Pads are for single person use only. Do not share Body Pads with others.
Targeted Pain Management is achieved with the use of Electrode Body Pads, by selecting
from two proven therapies EMS and TENS.
EN
5839_IFU04_18244309.indd 18-19
5839_IFU04_18244309.indd 18-19
06/10/2021 16:44
06/10/2021 16:44

20 21
Instructions for use
✔
Inside of
Ankle/foot
✔
✔
Caf
Lower back
✔
✔
Elbow
✔
aSelect the area you wish to apply electrical stimulation to.
Recommended Body Pad placements are shown below:
Thigh
EMS & TENS
✔
TENS only
Knee
TENS only
Back of
Shoulder
EMS & TENS
EMS & TENS
Outside of
Ankle/foot
If using TENS for pain relief, position the Body Pads on either side of the area causing
you pain.
bClean and dry the area where you will place the Body Pads.
cMake sure Revitive is switched o. If the control panel is still illuminated, press the
power button and turn Revitive o.
TENS only
EMS & TENS
✔
EMS & TENS
✔
dAttach the ends of the Body Pads to the Electrode cord.
Press connectors until there is no gap between them.
Leaving a gap may cause discomfort or no stimulation.
ePlug the other end of the Electrode cord into the
socket on the side of Revitive.
Plugging in the Electrode cord will automatically
turn the foot-pads o.
fRemove the plastic liner from the Body Pads, by peeling it
o carefully. Replace the Body Pads onto the plastic liner
aer use.
gPress the Body Pads on the area you wish to apply
electrical stimulation to, as shown on page 20, gently
pressing the adhesive side against the skin.
EN
5839_IFU04_18244309.indd 20-21
5839_IFU04_18244309.indd 20-21
06/10/2021 16:44
06/10/2021 16:44

22 23
hPress the power button on the device or on the remote
control to turn Revitive on.
You will hear a beep and the display lights will light up.
The time will read 30 minutes, the Intensity will
read 00 and the EMS symbol will be displayed.
iRevitive Body Pads will automatically provide
stimulation in EMS mode.
If you wish to use Revitive Body Pads in TENS Mode
press the TENS button on the remote control.
You will then see the TENS symbol on the display.
See page 24 for further instructions on how to switch
between EMS and TENS mode.
j Press the (+) Intensity Control one time to
start stimulation.
You can use the buttons on the control panel or remote
control.
Press the (+) button to increase the level.
Press the (–) button to decrease the level.
It is normal to feel tingling or varying sensations in
the muscles you are treating.
Please note that the intensity required may vary from
day to day.
Instructions for use
kThe Time display will start to count down in minutes
as Revitive cycles through its program.
When Revitive times out, you will hear three beeps,
and the device will switch itself o automatically.
lEnsuring that the device is switched o, gently peel the
Body Pads from the skin.
Do not pull the Body Pads o the skin using the
Electrode cords as this may damage the cords.
mReplace the Body Pads onto their plastic liner aer use.
nUnplug the Electrode cord from the socket on Revitive.
If you feel pain or discomfort:
• Lower the intensity of the Body Pads using the (–) Intensity Control on
the device or remote control.
• You can also choose to stop therapy before the end of the 30 minute session
to avoid skin irritation and/or muscle fatigue. You can do this by pressing the
power button on the device or on the remote control.
EN
5839_IFU04_18244309.indd 22-23
5839_IFU04_18244309.indd 22-23
06/10/2021 16:44
06/10/2021 16:44

24 25
Step 3.1:
Switching between EMS and TENS mode
To change between EMS and TENS mode, press the button of the stimulation mode
you require on the remote control.
You will see the mode selected highlighted on the display.
During use, switching from EMS to TENS mode (or vice versa), will reset the timer
back to the relevant default time. The Intensity will also be reset to zero.
Instructions for use
Step 4: Cleaning and storing Revitive
aEnsure Revitive is switched o.
bWipe down the foot-pads with a so damp cloth.
Do not clean with chemicals.
Do not immerse Revitive in water.
cStore Revitive in a cool, dry and dust-free location.
Store out of direct sunlight.
dPlace Body Pads onto the plastic liner.
eStore the Body Pads in a dry and ventilated location.
Store out of direct sunlight.
You do not have to detach the Body Pads from the Electrode cords to store them.
Replacing the Batteries
The remote control requires two AAA 1.5V batteries to operate.
Replacing the Body Pads
The Body Pads are reusable up to 20-30 applications. If the Body Pads start to lose
their adhesiveness, rub a few drops of water into the surface. Replacement Body Pads
can be obtained via www.revitive.com
EN
5839_IFU04_18244309.indd 24-25
5839_IFU04_18244309.indd 24-25
06/10/2021 16:44
06/10/2021 16:44

26 27
Troubleshooting
Problem Possible Cause Solution
Revitive is on (lights
illuminated on the
LED display) but
I cannot feel the
electrical stimulation
through the foot-
pads.
Not placing both bare feet
on the foot-pads at the
same time.
Ensure that your feet are bare and each
foot is placed on each of the foot-pads
at the same time. Keep increasing the
intensity up to a maximum of 99 until
you feel the stimulation.
Your feet may be dry. Moisturize the soles of your feet to
improve conductivity and stimulation
and try the procedure again. You may
also have to increase the intensity
level.
You may be dehydrated. Drink plenty of water before and aer
using the device. The device uses your
body to create the electrical circuit.
Water is an excellent conductor of
electricity and if your body is less
hydrated (below 60%) then the
stimulation may be less, therefore it
is important to always remain well
hydrated.
The intensity level may
be on too low a setting.
This is a very safe device. Keep
increasing the intensity level towards
99 until you feel the stimulation. You
may find that you have to increase the
intensity level as you get used to the
therapy. The aim is not to get to 99 but
to find a setting that produces strong
muscle contractions in your calves and
is comfortable for you.
Electrode cord is connected
to device.
Disconnect the Electrode cord - the foot-
pads will not work while the Electrode
cord is plugged in.
If, having tried the solutions
above, you still cannot feel
the stimulation:
Test the device by placing one hand
across both foot-pads at the same time
(The heel end of the foot-pads is easiest).
With your other hand, and starting from
zero, increase the intensity level until
you can feel the stimulation. If you can
feel the stimulation through your hand
then the device is working. If on 99 you
still cannot feel the stimulation then
please contact your authorised dealer.
Problem Possible Cause Solution
No power or lights
to Revitive when it is
switched on.
AC Adaptor not switched on
at the electrical socket or AC
Adaptor not plugged into device
properly.
Check electrical socket power
is switched on and the AC Adaptor
is plugged into the device correctly.
If still not working – contact your
authorised dealer.
Revitive is not
vibrating. REVITIVE IS NOT DESIGNED TO VIBRATE.
The IsoRocker® is not
"rocking". It is the muscles in your legs
that cause the "rocking", the
IsoRocker® is a pivot.
The IsoRocker® will only rock
when increased to an intensity
which causes suicient calf muscle
contraction. It may be that you
cannot comfortably increase the
intensity high enough until you
get used to the sensation. It is
important that intensity is adjusted
to a level that is comfortable.
The device is too far in front
of you.
Sit with your knees at a 90 degree
angle.
When using the
IsoRocker® on a
hard floor it makes a
tapping noise.
Incorrect positioning of the
device or too high an intensity
level.
Adjust the positioning of the
device or lower the intensity level
to reduce the device tapping.
Alternatively use a floor mat under
the device to cushion the sound.
My legs are aching
aer treatment. You may have the
intensity
on too high a setting and your
muscles are being overworked.
Leave adequate time aer each
treatment to allow the muscles
to recover (just like aer vigorous
exercise!). On your next session
start on a lower setting (where
you can feel the mild electrical
stimulation and it is comfortable)
and reduce the duration until your
muscles have acclimatized to the
stimulation.
I have placed my feet
on the device but
am unable to see the
TENS symbol on the
control panel
TENS is only available through
the Electrode Pads.
EN
5839_IFU04_18244309.indd 26-27
5839_IFU04_18244309.indd 26-27
06/10/2021 16:44
06/10/2021 16:44

28 29
Troubleshooting
Problem Possible Cause Solution
When using the Body
Pads, the stimulation
feels uncomfortable.
The level of stimulation you
are using may be too high or
you may have broken skin.
Decrease the stimulation level using
the (–) intensity control on the
device or remote control. You may
need to discontinue use until skin
has healed.
I am unsure of which
therapy mode I am
using when using the
Body Pads.
Look at the display on the device. If
the Body Pads are in EMS mode,
you will see the EMS symbol. If
the Body Pads are in TENS mode,
you will see the TENS symbol.
I suddenly can’t feel
stimulation when using
the Body Pads.
You may have pressed the
other stimulation mode
button by accident.
Pressing the opposite stimulation
mode button (i.e. pressing the
TENS button when already in EMS
mode or vice versa), will reset the
timer back to 30 minutes. The inten-
sity will also be reset to zero. The
mode, intensity and time settings
will need to be re-made.
For more information, including Frequently Asked Questions,
please visit support.revitive.com
Technical Specications
The Remote Control replicates the controls found on the device
Operating Frequencies KH
Operating Range Distance
0 to 25m at horizontal
0 to 18m at +/- 30 degree angle
from the horizontal.
Name of product Revitive Medic
Model 2837AB
Frequency (+/- 10%) EMS: 20Hz – 53Hz
TENS: 80Hz - 130Hz
Output current EMS: Max 15mA
TENS: Max 19mA
Weight
(+/- 0.5kg) 1.5kg
Dimensions 357(W) x 357(H) x 84(D) mm
Power consumption 5W
AC adaptor
CE Approved
Power source
Input (adaptor used)
Output
100-240V AC ( ), 50/60Hz, 0.18A
5V ( ) DC ,1.0A
Applied parts
Parts of Revitive that in normal use come into
physical contact with the user.
Foot-pads - 135.5 cm2
Electrode Body Pads - 5cm x 5cm = 25cm2
Durable period (Service Life) of Device
and remote control
4 Years
EN
5839_IFU04_18244309.indd 28-29
5839_IFU04_18244309.indd 28-29
06/10/2021 16:44
06/10/2021 16:44

30 31
Output Specifications for Electrical Muscle Stimulation (EMS):
Waveform Biphasic
Shape Square symmetrical with polarity reversal
Maximum Output Voltage (+/-15%) @500 Foot: 35V Body: 19V
Pulse Duration (+/-10%) Foot: 450-970s Body: 450s
Net Charge @ 500 [0.001]mC
Maximum Power Density @ 500 Foot: 0.79 mW/cm Body: 1.66 mW/cm
ON Time (+/- 10%) Foot: 1.90 - 8.30s Body: 1.90 - 6.50s
OFF Time (+/- 10%) Foot: 1.00 - 1.50s Body: 1.00s
The values of PULSE DURATIONS, PULSE repetition frequencies and amplitudes,
including any d.c. component, shall not deviate by more than ± 20 % when measured
with a load resistance within the range specified.
If confirmation is required that the Revitive works within its Essential Performance aer a
certain period of time, contact the manufacturer
Output Specifications for Transcutaneous Electrical Nerve Stimulation (TENS):
Waveform Biphasic
Shape Rectangular
Maximum Output Voltage: @ 500 50 V
Pulse Duration: 100s
Net Charge (per pulse @ 500) 0μC
Maximum Average Power Density @ 500 @ 500 4.19 mW/cm2
Technical Specications
Complies with European Medical Devices Directive (93/42/EEC)
UK Conformity Assessed
Product conforms to all applicable U.K. legislative requirements.
Device Lot number including year (YYYY) and month (MM) of
manufacture can be found on the box and back of unit
Item number
Contraindications, Warnings and Cautions
Make sure you understand these before using Revitive
Power
Time Remaining
Intensity Level
EMS Mode
TENS Mode
Center Positive Polarity
Class II medical electrical equipment double insulated
Type BF medical electrical equipment
Legal manufacturer of the device
EU/EC European Authorised Representative
#YYYYMMXXXXX
LOT
REF
EN
Symbols
5839_IFU04_18244309.indd 30-31
5839_IFU04_18244309.indd 30-31
06/10/2021 16:44
06/10/2021 16:44

32 33
FCC mark
Certification mark employed on electronic products manufactured
or sold in the United States which certifies that the electromagnetic
interference from Revitive is under limits approved by the Federal
Communications Commission. Actegy Ltd complies with all
applicable FCC rules.
Consult instructions for use
The Waste Electrical and Electronic Equipment Directive
(WEEE Directive).
At the end of the product lifecycle, do not throw this product
into normal household garbage, but take it to a collection point for
the recycling of electronic equipment
Ingress Protection Rating
Use-by date YYYY MM DD
Humidity, temperature and air pressure limit for storage
and transport
Humidity, temperature and air pressure limit for operating
conditions
Aer any exposure to hot or cold temperatures outside the specified
operating range of 10 - 40°C allow the product to re-adjust to the
recommended operating temperatures to ensure continued product
performance.
Indoor Use Only
Medical device does not contain natural rubber latex
Do not disassemble
-20°C
20%
70°C
90%
500 hPa
1060 hPa
10°C
30%
40°C
75%
700 hPa
1060 hPa
Technical Specications Your 2-year warranty
To activate your free 2-year warranty please register your
device at: support.revitive.com
It is important to retain the retailer’s receipt
as proof of purchase. Staple your receipt to
this back cover for future reference.
Please quote the following information if the
product develops a fault. These numbers
can be found on the base of the product:
Model no: ......................................................
Lot no: ...........................................................
All Revitive devices are individually tested
before leaving the factory. In the unlikely
event of any device proving to be faulty
within 30 days of purchase, it should be
returned to the place of purchase for it to be
replaced.
If the fault develops aer 30 days and within
24 months of original purchase, you should
contact your local distributor quoting model
number and LOT number on the product, or
write to your local distributor at the address
shown.
You will be asked to return the product (in
secure, adequate packaging) to the address
shown with a copy of proof of purchase.
Subject to the exclusions set out below (see
Exclusions) the faulty device will then be
repaired or replaced and dispatched, usually
within 14 working days of receipt.
If, for any reason, this item is replaced during
the 2-year guarantee period, the guarantee
on the new item will be calculated from the
original purchase date. Therefore, it is vital
to retain your original till receipt or invoice to
indicate the date of initial purchase.
To qualify for the 2-year guarantee, the
device must have been used according to the
manufacturer’s instructions supplied.
Exclusions
Actegy, manufacturer of Revitive devices,
shall not be liable to replace the goods under
the terms of the guarantee where:
• The fault has been caused or is
attributable to accidental use, misuse,
negligent use or used contrary to the
manufacturer’s recommendations or
where the fault has been caused by
power surges or damage caused in
transit.
• The device has been used on a voltage
supply other than that stated on the
product or used with a power adaptor
other than the one supplied with the
product.
• Repairs have been attempted by persons
other than our service sta
(or authorised dealer).
• The device has been used for hire
purposes or non-domestic use.
• The device is second hand.
2Actegy are not liable to carry out any type of
servicing work, under the guarantee.
3Accessories such as Electrode Body Pads and
bags are not covered by the guarantee.
4Remote control batteries and any damage
from leakage are not covered by the
guarantee.
5This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is oered as
an additional benefit and does not aect your
statutory rights as a consumer.
EN
Symbols
5839_IFU04_18244309.indd 32-33
5839_IFU04_18244309.indd 32-33
06/10/2021 16:44
06/10/2021 16:44

34 35
Tutoriels vidéo
Pour regarder les vidéos d’installation
et d’utilisation de votre Revitive,
rendez-vous sur:
support.revitive.com
Pour des résultats
optimaux
Utiliser tous les jours
30-60 min
Intensité 40+
pendant
60+ jours
Garantie de 2ans
Pour activer votre garantie gratuite
de 2ans, veuillez enregistrer votre
appareil sur le site:
support.revitive.com
FR
Que contient la boîte? 36
Pièces et commandes 37-38
Introduction à Revitive 39-40
Profil de l'utilisateur 39
Indications thérapeutiques 39-40
Précautions importantes 41-46
Quand NE PAS utiliser le Revitive 41
Avertissements et mises en garde 42-45
Précautions de sécurité 44-46
Eets indésirables 46
Mode d’emploi 47-57
Étape1: Première installation du Revitive 47
Étape2: Utilisation des repose-pieds 48-50
Étape3: Utilisation des électrodes à double mode
51-55
3.1: Passage du mode EMS au mode TENS 56
Étape 4: Nettoyage et rangement de l’appareil 57
Remplacement des piles et des électrodes 57
Dépannage 58-60
Spécifications techniques 61-64
Garantie 65
Sommaire
5839_IFU04_18244309.indd 34-35
5839_IFU04_18244309.indd 34-35
06/10/2021 16:44
06/10/2021 16:44

36 37
Que contient la boîte? Pièces et commandes
Lorsque vous ouvrez la boîte, vérifiez que toutes les pièces suivantes sont bien
présentes. Si vous pensez qu’il manque quelque chose, veuillez nous appeler à
l’un des numéros d’assistance téléphonique indiqués au dos de ce livret.
Adaptateur universel
Longueur du câble 180cm
Revitive Medic
Électrodes corporelles
Cordons des électrodes
Longueur des cordons 150cm
Télécommande
Piles AAA x 2
1
2
3
4
5
6
Poignée de transport
Panneau de
commande/
écran
Prise de
l’adaptateur
universel
Prise des électrodes
Repose-pieds
IsoRocker®
Bouton
MARCHE/ARRÊT
EN
5839_IFU04_18244309.indd 36-37
5839_IFU04_18244309.indd 36-37
06/10/2021 16:44
06/10/2021 16:44

38 39
FR
Pièces et commandes Introduction à Revitive
(1) Indications thérapeutiques pour
l’électrostimulation musculaire (EMS)
Lors de l’utilisation des repose-pieds, le Revitive vise à :
• Réduire la douleur et l’inconfort au niveau des jambes, des pieds et/ou des chevilles,
causés par une mauvaise circulation sanguine (maladie artérielle périphérique).
• Améliorer la circulation en cas de problème circulatoire (maladie artérielle
périphérique).
• Améliorer la circulation pour réduire ou prévenir l’accumulation de sang (stase)
causée par un problème circulatoire (insuisance veineuse chronique / varices)
• Augmenter la distance de marche parcourue avant l’apparition de symptômes
de claudication (douleur) causés par une maladie artérielle périphérique
• Soulager les symptômes liés aux varices ou à l’insuisance veineuse
• Contribuer au maintien de la santé des veines des jambes, en augmentant l’apport
en sang oxygéné et en réduisant l’enflure (œdème) des jambes, des pieds et des
chevilles
Lors de l’application d’électrodes aux jambes, le Revitive vise à :
• Réduire la douleur et l’inconfort au niveau des jambes, des chevilles et/ou des pieds,
causés par une neuropathie diabétique périphérique ou par un enflure (œdème)
dû à l’arthrose ou résultant d’une opération
• Réduire l’enflure au niveau des jambes, des chevilles et/ou des pieds, causé par
l’immobilité due à l’arthrose ou à une blessure
Prol de l'utilisateur
Le Revitive est destiné à un usage à domicile par les personnes sourant notamment
d’immobilité, de mauvaise circulation sanguine et de problèmes connexes, dont douleur,
raideur et enflure des jambes, des chevilles et des pieds.
Le Revitive est conçu pour une utilisation hors clinique sans la surveillance ni
l’intervention d’un clinicien.
Un utilisateur typique est un adulte de n’importe quel âge, sans distinction de sexe,
d’ethnicité ou d’éducation.
Niveau
d’intensité
Bouton de
MARCHE/ARRÊT
TENS
EMS
Télécommande
Panneau de commande
Minuterie
Contrôle de l’intensité – /+
Contrôle de
l’intensité – /+
EMS TENS
5839_IFU04_18244309.indd 38-39
5839_IFU04_18244309.indd 38-39
06/10/2021 16:45
06/10/2021 16:45
Table of contents
Languages:
Other Revitive Medical Equipment manuals

Revitive
Revitive Medic Knee User manual

Revitive
Revitive Medic Knee User manual

Revitive
Revitive ProHealth User manual

Revitive
Revitive Advanced Setup guide

Revitive
Revitive Medic Coach User manual

Revitive
Revitive UT1033 User manual

Revitive
Revitive Medic 5573AQ User manual

Revitive
Revitive ProHealth 5572AQ User manual
Popular Medical Equipment manuals by other brands

Posture Pump
Posture Pump Disc Hydrator instructions

Beka Hospitec
Beka Hospitec NORA Pro Original manual

Sizewise
Sizewise Platinum 6000 Quick reference guide

Ring Rescue
Ring Rescue CompressionDevice Technical reference manual

Ergotron
Ergotron StyleView SV42 user guide

Aeonmed
Aeonmed vg70 quick start guide
