RevJams PLAY3 User manual

REV-BTH100
USERS MANUAL

• Wireless technology using Bluetooth 4.2
• Sound isolating in-ear stereo earbuds with in line
mic
• Fashionable metallic nish and accents to add style
and air
• Comfortable lightweight design with ear stabilizers
for a secure and stable t
• Premium High Denition Stereo Sound
• Rechargeable battery with Up to 4 Hours of
Talk/Music time
• Streams Audio from any Bluetooth Device
• On Board Controls for music and call functionalities
• Tangle Free cable
FEATURES:
2

• RevJams Play 3 Premium Metallic In-Ear
Bluetooth Stereo Earbuds
• Micro USB Charging Cable
• 3 sets of ear bud tips (S, M, L)
• Users Guide
PACKAGE CONTENTS
3

1. Volume – / Previous Track
2. Multi-Function Button - Power/Play/Pause/Pair
3. Volume +/Next Track
4. LED Indicator
5. Micro USB Charging port
6. Microphone
HEADSET CONTROLS
3
2
5
1
6
4
4

LED INDICATOR GUIDE
STATUS INDICATOR
Power On Flashing Blue Light
Power Off Red Light and the device
powers off
Charging Red Light
Charging Complete Blue light
Pairing Mode Red and Blue Light ash
alternately. Once Paired, Blue
light will ash slowly.
5

GETTING STARTED
To use your RevJams Play 3 In-Ear Bluetooth Stereo
Earbuds, please follow the steps below:
1. Ensure your Bluetooth headset is fully charged.
2. Pair your Bluetooth headset to a
Bluetooth-enabled device prior to use. (See Pairing
your Headset instructions)
CHARGING YOUR HEADSET
CHARGE FULLY BEFORE USE.
To charge your headset, use the supplied micro-USB
charging cable, the battery indicator will turn red
when charging and turn blue once charging is
complete (the device might power off once
charging is complete to save battery).
Initial charging time is approximately 2 hours.
6

In order to use your RevJams Play 3 In-Ear Bluetooth
Stereo Earbuds with a Bluetooth-enabled device, you
will rst need to pair the two.
1. Place the headset and the mobile phone where
they are easily viewable and no more than one meter
apart.
2. Ensure that the headset is fully charged and
powered off.
3. Press the Multi-Function button for approxi-
mately 3-4 seconds until the red and blue light ash
alternately which indicates that you are in Pairing
Mode. (Note: A blue light will turn on at rst but keep
pressing down the pairing button until it changes to
a ashing blue/red light which indicates that you are
in pairing mode.)
PAIRING YOUR HEADSET
100%
PRESS & HOLD
Settings
Bluetooth
Bluetooth
REV-BTH100
3-4
sec
1 2 3
4. Activate your mobile phone's Bluetooth pairing
function.
5. Set the mobile phone to search for Bluetooth
devices within range and select “REV-BTH100” from
the list of devices shown.
6. If you are prompted for a Passcode enter “0000”
and press “ok” to pair the headset with your mobile
phone. (Note: If the Bluetooth version of your phone
is 2.1, there is no need to enter the passcode when
pairing.)
7. Now you can use your Bluetooth headset to listen
to music and make and receive phone calls.
7

In order to use your RevJams Play 3 In-Ear Bluetooth
Stereo Earbuds with a Bluetooth-enabled device, you
will rst need to pair the two.
1. Place the headset and the mobile phone where
they are easily viewable and no more than one meter
apart.
2. Ensure that the headset is fully charged and
powered off.
3. Press the Multi-Function button for approxi-
mately 3-4 seconds until the red and blue light ash
alternately which indicates that you are in Pairing
Mode. (Note: A blue light will turn on at rst but keep
pressing down the pairing button until it changes to
a ashing blue/red light which indicates that you are
in pairing mode.)
For Customer Service / Technical Assistance
Call or Email Us!
Email: [e-mail]
Toll free number: 855-206-6634
4. Activate your mobile phone's Bluetooth pairing
function.
5. Set the mobile phone to search for Bluetooth
devices within range and select “REV-BTH100” from
the list of devices shown.
6. If you are prompted for a Passcode enter “0000”
and press “ok” to pair the headset with your mobile
phone. (Note: If the Bluetooth version of your phone
is 2.1, there is no need to enter the passcode when
pairing.)
7. Now you can use your Bluetooth headset to listen
to music and make and receive phone calls.
8

Powering On the Headset
Press and hold down the Multi-Function button for 2
seconds until a blue light appears.
Powering O the Headset
Once powered on, Press and hold down the
Multi-Function button for 4-5 seconds until a red
light appears to power off the device.
Wearing your headset
The Left “L” and Right “R” indicator is located on the
inside of the ear stabilizers.
GENERAL INSTRUCTIONS FOR USE
9

CALL MODE
Answering a Call When you receive a call, the ring tone
will be heard through the headset.
Short Press the Multi-Function button
once to accept the call or answer the
call normally via your mobile phone.
Short Press the Multi-Function button
to end the call or end the call directly
from your mobile phone.
Press the Multi-Function button twice
to redial the last dialed phone
number on your mobile phone.
Press and hold the Multi-Function
button for 2 seconds to reject the
incoming call.
Rejecting a Call
Ending a Call
Redialing a Call
10

MUSIC MODE
Adjusting the
Volume
Press and hold the “+” key to increase
volume or “– “key to decrease volume.
You will hear a beep when you reach
the maximum or minimum volume
level. (You can also adjust the volume
on your handset or device)
Short Press the " -" key to select the
Previous track.
Short Press "+" key to select the Next
track.
When the Bluetooth headset is
connected with your mobile phone
and music player, press the
Multi-Function button once to play
music. Short Press the Multi-Function
button while music is playing to
pause music. (Attention: your mobile
phone must support A2DP prole.)
Play/Pause
Music
Previous Track
Next Track
Connection with The Last Paired Device
When powered on, the headset will automatically connect
with the last successfully paired device. If the connection is
successful, it enters standby mode. If the devices fail to
connect within 5 minutes after the pairing has been
initiated, the headset will turn off automatically.
11

TROUBLESHOOTING
Connection issues
• Be sure that your headset is fully charged and
powered on.
• Be sure that the headset is paired with your mobile
phone.
• Be sure that your mobile phone's Bluetooth feature
is activated.
Audio issues
• Wireless devices are susceptible to interference
that may affect audio quality and result in static.
Make sure there is a direct line of sight between your
headset and phone. Avoid placing objects that can
block radio signals, between paired devices. These
include walls, doors, and windows.
• Make sure the distance between your headset and
the paired device does not exceed 33 feet (10m).
• Keep your headset and mobile phone on the same
side of your body.
Note: Low battery capacity in your earbuds and mobile
phone may aect the Bluetooth range.
Bluetooth Connection issues
If you are experiencing Bluetooth connection issues -
Keep the music device at or above waist level on your
right side, the same side as the headphones antenna.
If the above troubleshooting steps do not solve your
problem, please remove your mobile phone battery
or power down and restart your device.
12

WARRANTY
At RevJams, we are dedicated to making the best
quality product. To back this up, your RevJams PLAY 3
Wireless Stereo Earbuds are warrantied for One (1) full
year from the date of purchase.
Please visit our support page at
www.revjams.com/support for helpful tips
such as user’s guide, instructional videos and more!
For Customer Service / Technical Assistance
Call or Email Us!
Email: [e-mail]
Toll free number: 855-206-6634
If the above troubleshooting steps do not solve your
problem, please remove your mobile phone battery
or power down and restart your device.
13

SAFETY INFORMATION
Check local laws regarding the use of mobile
phones and headsets while driving.
If you use the headset while driving, ensure that
your attention and focus remains on the road and
you drive in a responsible and safe manner.
Never allow children to play with the headset, as
the small parts may be a choking hazard.
Observe all signs that require an electrical device
or RF radio product to be switched off in
designated areas. These could include hospitals,
airplanes, blasting areas, and potentially explosive
environments.
Never mount or store your headset over an air bag
deployment area, a serious injury may result when
the air bag deploys.
Do not open or mutilate the built-in battery.
Dispose of batteries according to local regulations.
Do not dispose as household waste.
14

CARE AND MAINTENANCE OF YOUR
HEADSET
i. Consider turning your headset off before placing it
in your pocket or bag. If the Power button is
accidentally activated, your mobile phone may place
an unintended call.
ii. Do not expose the headset to liquid, moisture or
humidity, as it is not waterproof.
iii. Do not use abrasive cleaning solvents to clean the
headset.
iv. Do not expose the headset to extreme tempera-
tures. The best storage temperature range is from
40-80 F, otherwise, the life of the headset will be
affected.
v. Do not dispose of the headset in re as it this may
result in an explosion.
vi. Do not bring your headset into contact with sharp
objects as this will cause scratches and can damage
the headset.
vii. Do not attempt to disassemble the headset, as it
does not contain serviceable components.
viii. If you do not use the headset for long periods, be
sure to store it in a dry place, free from extreme
temperature conditions and dust.
15

PRODUCT SPECIFICATIONS
Model No. REV-BTH100
Product Size: Overall Length: 24” Earbud: 1.2X1X1 in
Product Weight: 0.5 oz.
Power Input: 10mw
Speaker Output: 10mW
Bluetooth Version: 4.2
Working Voltage and Ampere: 3.7V-, 60mAh
Battery Capacity: 60mAh
Driver Size: 10mm
Sensitivity: -80dBm<0.1%BER
Impedance: 32 Ohms
Frequency Range: 2.4 -2.480GHZ
Wireless Prole: HSP, HFP, A2DP and AVRCP
Wireless Range: About 33ft.
Frequency: 2.4GHZ
Battery Charging time: Up to 2 hours
Play Time: Up to 4 hours
Actual performance may vary due to the user's habits,
dierent modes of operation, and mobile phone
settings. This manual is for reference purposes only. The
specications and design of the headset may change
without prior notice. Actual product may dier slightly
from the image on the packaging.
16

WARNING AND PRECAUTIONS
WARNING: To prevent re or shock hazard, do not
expose this unit to rain or moisture.
WARNING: Do not place this unit directly onto
furniture surfaces with any type of soft, porous, or
sensitive nish.
WARNING: Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices
in your area. They should be incinerated since they
might explode.
NOTE: If you suspect your battery may be dead after
several attempts to charge, please visit
www.revjams.com for support.
Never disassemble the unit or attempt to remove the
battery as that could cause leakage of an electrolyte
substance
FCC WARNINGS
Warning: Changes or modications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protections against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
17

WARNING: To prevent re or shock hazard, do not
expose this unit to rain or moisture.
WARNING: Do not place this unit directly onto
furniture surfaces with any type of soft, porous, or
sensitive nish.
WARNING: Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices
in your area. They should be incinerated since they
might explode.
NOTE: If you suspect your battery may be dead after
several attempts to charge, please visit
www.revjams.com for support.
Never disassemble the unit or attempt to remove the
battery as that could cause leakage of an electrolyte
substance
FCC WARNINGS
Warning: Changes or modications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protections against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
18

19
