RevJams REV-200 LITE User manual
USERS GUIDE
REVJAMS LITE
BLUETOOTH 4.1 STEREO EARBUDS
REV-200
Welcome
Thank you for choosing RevJams
LITE Bluetooth 4.1 Stereo Earbuds
The RevJams LITE Bluetooth Stereo Earbuds are the
perfect choice for people on the go. No wires. No
cables. It uses Bluetooth 4.1 technology to connect
to your Tablet, Smartphone, Computer or MP3 and
are perfect for listening to music while on the go,
watching movies, playing video games. All the while
being ready to accept incoming calls.
Built-in Li-ion battery works for up to 5 hours of
listening playtime or 140 hours of standby time. With
the RevJams LITE Bluetooth Stereo Earbuds you are
always ready to go.
Included in the Package
• RevJams LITE Bluetooth Stereo Earbuds
• 3 Sets of Earbud Tips (S,M,L)
• Micro USB Charging Cable
• Users Guide
Description of Parts
Control Unit:
• Microphone
• Micro USB Charging port
• Pairing/Power LED Indicator
• Volume +/ Next Track
• Multi-Function Button
Power/Play/Pause/Pair
• Volume – / Previous Track
MICRO USB
CHARGING
PORT
MULTI-FUNCTION BUTTON
MICROPHONE
VOLUME UP / NEXT
VOLUME DOWN / PREVIOUS
LED INDICATOR
LED Indicator Guide
Power On
Power O
Charging
Charging Complete
Pairing Mode
Blue light
Red light then turns o
Red light
Blue light
Red and blue light ash
alternately
Status Indicator
How to Use
Getting Started
To start using your RevJams LITE Bluetooth Stereo
Earbuds, please follow the steps below:
1. Ensure your Bluetooth headset is fully charged.
2. Pair your Bluetooth headset to a Bluetooth-
enabled device prior to use. (See Pairing your
Headset instructions).
Charging Your Headset
Your RevJams headset comes with a built-in
rechargeable battery and a Micro USB charging
cable.
Your RevJams headset can be charged either directly
from an AC power supply (not included) or through
your PC via a micro USB cable (included). Charge
fully before use. The battery indicator will turn red
when charging and turn blue once charging is
complete. Initial charging time is approximately 2
hours.
Pairing Your Headset
In order to use your RevJams LITE Bluetooth Stereo
Earbuds with a Bluetooth-enabled device, you will
rst need to pair the two.
1. Place the headset and the mobile phone where
they are easily viewable and no more than 3 ft. apart.
2. Ensure that the headset is fully charged
3. Ensure that the headset is turned off (Very
important)
4. Press the Multi-Function button for approximately
8-10 seconds until the RED AND BLUE LIGHT FLASH
ALTERNATELY which indicates that you are in Pairing
Mode. The voice prompt will conrm “pairing” once
the pairing is successful
5. Activate your mobile phone's Bluetooth pairing
function.
6. Set the mobile phone to search for Bluetooth
devices within range and select “RevJams Lite” from
the list of devices shown.
7. If you are prompted for a Passcode enter “0000”
and press “ok” to pair the headset with your mobile
phone. (Note: If the Bluetooth version of your phone
is 2.1, there is no need to enter the passcode when
pairing.)
8. Now you can use your Bluetooth headset to listen
to music, and make and receive phone calls. Some
mobile phones will connect automatically to the
RevJams LITE Bluetooth Stereo Earbuds when
powered on.
Pairing Your Headset
In order to use your RevJams LITE Bluetooth Stereo
Earbuds with a Bluetooth-enabled device, you will
rst need to pair the two.
1. Place the headset and the mobile phone where
they are easily viewable and no more than 3 ft. apart.
2. Ensure that the headset is fully charged
3. Ensure that the headset is turned off (Very
important)
4. Press the Multi-Function button for approximately
8-10 seconds until the RED AND BLUE LIGHT FLASH
ALTERNATELY which indicates that you are in Pairing
Mode. The voice prompt will conrm “pairing” once
the pairing is successful
5. Activate your mobile phone's Bluetooth pairing
function.
6. Set the mobile phone to search for Bluetooth
devices within range and select “RevJams Lite” from
the list of devices shown.
7. If you are prompted for a Passcode enter “0000”
and press “ok” to pair the headset with your mobile
phone. (Note: If the Bluetooth version of your phone
is 2.1, there is no need to enter the passcode when
pairing.)
8. Now you can use your Bluetooth headset to listen
to music, and make and receive phone calls. Some
mobile phones will connect automatically to the
RevJams LITE Bluetooth Stereo Earbuds when
powered on.
Using Your Headset
Powering On the Headset
Press and hold down the Multi-Function button for
5-6 seconds until a blue light appears
Powering O the Headset
Once powered on, Press and hold down the
Multi-Function button for 5-6 seconds until a
ashing red light appears.
Wearing Your Headset
The Left / Right indicator is located on the inside of
the Earbuds.
Using Your Headset
Answering a Call
When you receive a call, the ring tone will be heard
through the headset. Press the Multi-Function
button once to accept the call, or answer the call
normally via your mobile phone.
Rejecting a Call
Briey press the Multi-Function button twice to
reject the incoming call.
Ending a Call
Press the Multi-Function button once to end the call
or hang up on your mobile phone.
Redialing a Call
Briey press the Multi-Function button twice to
redial the last dialed phone number on your mobile
phone.
Adjusting the Volume
Briey Press the Volume + to increase volume or
Volume – to decrease volume. You can also adjust
the volume on your handset or device.
NOTE: To reach maximum volume BOTH the headset
and phone volume must be turned up!
Play/Pause Music
When the Bluetooth headset is connected with your
mobile phone, press the Multi-Function button once
to play music, press again to Pause the music.
(Attention: your mobile phone must support A2DP
prole.)
Next Track
Press and hold down the "Volume -" key to select the
Next track.
Previous Track
Press and hold down the "Volume +" key to select
the Previous track.
Using Your Headset
Powering On the Headset
Press and hold down the Multi-Function button for
5-6 seconds until a blue light appears
Powering O the Headset
Once powered on, Press and hold down the
Multi-Function button for 5-6 seconds until a
ashing red light appears.
Wearing Your Headset
The Left / Right indicator is located on the inside of
the Earbuds.
Using Your Headset
Answering a Call
When you receive a call, the ring tone will be heard
through the headset. Press the Multi-Function
button once to accept the call, or answer the call
normally via your mobile phone.
Rejecting a Call
Briey press the Multi-Function button twice to
reject the incoming call.
Ending a Call
Press the Multi-Function button once to end the call
or hang up on your mobile phone.
Redialing a Call
Briey press the Multi-Function button twice to
redial the last dialed phone number on your mobile
phone.
Adjusting the Volume
Briey Press the Volume + to increase volume or
Volume – to decrease volume. You can also adjust
the volume on your handset or device.
NOTE: To reach maximum volume BOTH the headset
and phone volume must be turned up!
Play/Pause Music
When the Bluetooth headset is connected with your
mobile phone, press the Multi-Function button once
to play music, press again to Pause the music.
(Attention: your mobile phone must support A2DP
prole.)
Next Track
Press and hold down the "Volume -" key to select the
Next track.
Previous Track
Press and hold down the "Volume +" key to select
the Previous track.
Using Your Headset
Powering On the Headset
Press and hold down the Multi-Function button for
5-6 seconds until a blue light appears
Powering O the Headset
Once powered on, Press and hold down the
Multi-Function button for 5-6 seconds until a
ashing red light appears.
Wearing Your Headset
The Left / Right indicator is located on the inside of
the Earbuds.
Using Your Headset
Answering a Call
When you receive a call, the ring tone will be heard
through the headset. Press the Multi-Function
button once to accept the call, or answer the call
normally via your mobile phone.
Rejecting a Call
Briey press the Multi-Function button twice to
reject the incoming call.
Ending a Call
Press the Multi-Function button once to end the call
or hang up on your mobile phone.
Redialing a Call
Briey press the Multi-Function button twice to
redial the last dialed phone number on your mobile
phone.
Adjusting the Volume
Briey Press the Volume + to increase volume or
Volume – to decrease volume. You can also adjust
the volume on your handset or device.
NOTE: To reach maximum volume BOTH the headset
and phone volume must be turned up!
Play/Pause Music
When the Bluetooth headset is connected with your
mobile phone, press the Multi-Function button once
to play music, press again to Pause the music.
(Attention: your mobile phone must support A2DP
prole.)
Next Track
Press and hold down the "Volume -" key to select the
Next track.
Previous Track
Press and hold down the "Volume +" key to select
the Previous track.
Care and Maintenance of Your
Headset
Maintenance of your Headset
Your headset may require periodic cleaning:
• Ear tips: First, remove them from the headset and
wash the tips with a mild detergent and water. Make
sure you thoroughly rinse and dry them before
putting them back on the headset.
• Headset nozzles, Microphone, Answer/End button:
Clean only with a dry, soft cotton swab or equiva-
lent. Never insert any cleaning tool into the nozzle or
microphone opening.
i. Consider turning your headset o before placing it
in your pocket or bag. If the Power button is
accidentally activated, your mobile phone may place
an unintended call.
ii. Do not expose the headset to liquid, moisture or
humidity, as it is not waterproof.
iii. Do not use abrasive cleaning solvents to clean the
headset.
iv. Do not expose the headset to extreme tempera-
tures. The best storage temperature range is from
40-80F, otherwise, the life of the headset will be
aected.
v. Do not dispose of the headset in re as it this may
result in an explosion.
vi. Do not bring your headset into contact with sharp
objects as this will cause scratches and can damage
the headset.
vii. Do not attempt to disassemble the headset, as it
does not contain serviceable components.
viii. If you do not use the headset for long periods,
be sure to store it in a dry place, free from extreme
temperature conditions and dust.
Troubleshooting
If you are unable to connect your headset and
mobile phone, please try the following:
Ensure that your headset is fully charged and
powered on.
Ensure that the headset is paired with your mobile
phone.
Ensure that your mobile phone's Bluetooth feature is
activated. Please refer to your mobile phone user’s
guide for specic instructions.
Ensure that the headset is within a 10 meter (30 ft.)
range of your mobile phone and that there are no
obstructions, such as walls or other electronic
devices, between the two.
If your device is already paired, try deleting from the
Bluetooth paired devices and re-pairing it. If the
above steps do not solve your problem, please
remove your mobile phone battery for a short time
and recharge the headset. Repeat the troubleshoot-
ing sequence.
Warranty
At RevJams, we are dedicated to making the best
quality product we can. To back this up, your
RevJams LITE Bluetooth Stereo Earbuds are warran-
tied for One (1) full year from the date of purchase.
Should you require additional information or have
any questions about your product or its warranty,
please contact us via email at:
Customer Service:
customerservice@revjams.com
Care and Maintenance of Your
Headset
Maintenance of your Headset
Your headset may require periodic cleaning:
• Ear tips: First, remove them from the headset and
wash the tips with a mild detergent and water. Make
sure you thoroughly rinse and dry them before
putting them back on the headset.
• Headset nozzles, Microphone, Answer/End button:
Clean only with a dry, soft cotton swab or equiva-
lent. Never insert any cleaning tool into the nozzle or
microphone opening.
i. Consider turning your headset o before placing it
in your pocket or bag. If the Power button is
accidentally activated, your mobile phone may place
an unintended call.
ii. Do not expose the headset to liquid, moisture or
humidity, as it is not waterproof.
iii. Do not use abrasive cleaning solvents to clean the
headset.
iv. Do not expose the headset to extreme tempera-
tures. The best storage temperature range is from
40-80F, otherwise, the life of the headset will be
aected.
v. Do not dispose of the headset in re as it this may
result in an explosion.
vi. Do not bring your headset into contact with sharp
objects as this will cause scratches and can damage
the headset.
vii. Do not attempt to disassemble the headset, as it
does not contain serviceable components.
viii. If you do not use the headset for long periods,
be sure to store it in a dry place, free from extreme
temperature conditions and dust.
Troubleshooting
If you are unable to connect your headset and
mobile phone, please try the following:
Ensure that your headset is fully charged and
powered on.
Ensure that the headset is paired with your mobile
phone.
Ensure that your mobile phone's Bluetooth feature is
activated. Please refer to your mobile phone user’s
guide for specic instructions.
Ensure that the headset is within a 10 meter (30 ft.)
range of your mobile phone and that there are no
obstructions, such as walls or other electronic
devices, between the two.
If your device is already paired, try deleting from the
Bluetooth paired devices and re-pairing it. If the
above steps do not solve your problem, please
remove your mobile phone battery for a short time
and recharge the headset. Repeat the troubleshoot-
ing sequence.
Warranty
At RevJams, we are dedicated to making the best
quality product we can. To back this up, your
RevJams LITE Bluetooth Stereo Earbuds are warran-
tied for One (1) full year from the date of purchase.
Should you require additional information or have
any questions about your product or its warranty,
please contact us via email at:
Customer Service:
customerservice@revjams.com
Care and Maintenance of Your
Headset
Maintenance of your Headset
Your headset may require periodic cleaning:
• Ear tips: First, remove them from the headset and
wash the tips with a mild detergent and water. Make
sure you thoroughly rinse and dry them before
putting them back on the headset.
• Headset nozzles, Microphone, Answer/End button:
Clean only with a dry, soft cotton swab or equiva-
lent. Never insert any cleaning tool into the nozzle or
microphone opening.
i. Consider turning your headset o before placing it
in your pocket or bag. If the Power button is
accidentally activated, your mobile phone may place
an unintended call.
ii. Do not expose the headset to liquid, moisture or
humidity, as it is not waterproof.
iii. Do not use abrasive cleaning solvents to clean the
headset.
iv. Do not expose the headset to extreme tempera-
tures. The best storage temperature range is from
40-80F, otherwise, the life of the headset will be
aected.
v. Do not dispose of the headset in re as it this may
result in an explosion.
vi. Do not bring your headset into contact with sharp
objects as this will cause scratches and can damage
the headset.
vii. Do not attempt to disassemble the headset, as it
does not contain serviceable components.
viii. If you do not use the headset for long periods,
be sure to store it in a dry place, free from extreme
temperature conditions and dust.
Troubleshooting
If you are unable to connect your headset and
mobile phone, please try the following:
Ensure that your headset is fully charged and
powered on.
Ensure that the headset is paired with your mobile
phone.
Ensure that your mobile phone's Bluetooth feature is
activated. Please refer to your mobile phone user’s
guide for specic instructions.
Ensure that the headset is within a 10 meter (30 ft.)
range of your mobile phone and that there are no
obstructions, such as walls or other electronic
devices, between the two.
If your device is already paired, try deleting from the
Bluetooth paired devices and re-pairing it. If the
above steps do not solve your problem, please
remove your mobile phone battery for a short time
and recharge the headset. Repeat the troubleshoot-
ing sequence.
Warranty
At RevJams, we are dedicated to making the best
quality product we can. To back this up, your
RevJams LITE Bluetooth Stereo Earbuds are warran-
tied for One (1) full year from the date of purchase.
Should you require additional information or have
any questions about your product or its warranty,
please contact us via email at:
Customer Service:
customerservice@revjams.com
Product Specications
Model number: REV200
Size: 32 X 1 X 0.1 inches
Weight: 0.6 oz.
Voltage: 3.7V
Charging Jack: Micro USB port
Charging Time: Up to 2 hours
Talk/Music time: Up to 5 hours
Standby time: Up to 140 hours
Bluetooth Version: Bluetooth 4.1 Airoha
Wireless Range: 33Ft (10M)
Digital Volume Control
Built-In Microphone
Battery Specs:
70 mAh *1 Lithium Battery
DC Battery power: Built-in rechargeable lithium
battery
Speaker Specs:
Speaker diameter：Φ10mm
Impedance：16Ω
Rated power：3mW
Frequency response：20Hz〜20KHz
Sensitivity：111dB±3dB /1KHz
Actual performance may vary due to the user's habits,
dierent modes of operation, and mobile phone
settings. This manual is for reference purposes only. The
specications and design of the headset may change
without prior notice. Actual product may dier slightly
from the image on the packaging
Safety Information
Check local laws regarding the use of mobile phones
and headsets while driving. If you use the headset
while driving, ensure that your attention and focus
remains on the road and you drive in a responsible
and safe manner.
Never allow children to play with the headset, as the
small parts may be a choking hazard.
Observe all signs that require an electrical device or
RF radio product to be switched off in designated
areas. These could include hospitals, airplanes,
blasting areas, and potentially explosive environ-
ments.
Never mount or store your headset over an air bag
deployment area, a serious injury may result when
the air bag deploys.
Do not open or mutilate the built-in battery.
Dispose of batteries according to local regulations.
Do not dispose as household waste.
Warning and Precautions
• To prevent re or shock hazard, do not expose this
unit to rain or moisture.
• Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive
nish. As with any rubber compound made with oils,
the feet could cause marks or staining where the
feet reside. We recommend using a protective
barrier such as cloth or a piece of a glass between
the unit and the surface to reduce the risk of damage
and/or staining.
• Lithium batteries, like all rechargeable batteries are
recyclable and should be recycled or disposed of in
normal household waste. Contact your local
government for disposal or recycling practices in
your area. They should be incinerated since they
might explode.
• Long-term exposure to loud music may cause
hearing damage. It is best to avoid high volume
levels when using headphones, especially for
extended periods.
• Use caution when using your headset/headphones
while operating a vehicle or engaging in any activity
that requires your full attention.
• Check and follow local laws regarding mobile
phone and headset/headphones use. Some
jurisdictions impose specic limitations, such as
single earpiece conguration, on the use of such
products while driving
NOTE: This device uses an internal rechargeable
lithium-ion battery that should last the lifetime of
the device. If you suspect your battery may be dead
after several attempts to charge, please visit
www.revjams.com for support.
Never disassemble the unit or attempt to remove the
battery as that could cause leakage of an electrolyte
substance
Actual performance may vary due to the user's habits,
dierent modes of operation, and mobile phone
settings. This manual is for reference purposes only. The
specications and design of the headset may change
without prior notice. Actual product may dier slightly
from the image on the packaging
Safety Information
Check local laws regarding the use of mobile phones
and headsets while driving. If you use the headset
while driving, ensure that your attention and focus
remains on the road and you drive in a responsible
and safe manner.
Never allow children to play with the headset, as the
small parts may be a choking hazard.
Observe all signs that require an electrical device or
RF radio product to be switched off in designated
areas. These could include hospitals, airplanes,
blasting areas, and potentially explosive environ-
ments.
Never mount or store your headset over an air bag
deployment area, a serious injury may result when
the air bag deploys.
Do not open or mutilate the built-in battery.
Dispose of batteries according to local regulations.
Do not dispose as household waste.
Warning and Precautions
• To prevent re or shock hazard, do not expose this
unit to rain or moisture.
• Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive
nish. As with any rubber compound made with oils,
the feet could cause marks or staining where the
feet reside. We recommend using a protective
barrier such as cloth or a piece of a glass between
the unit and the surface to reduce the risk of damage
and/or staining.
• Lithium batteries, like all rechargeable batteries are
recyclable and should be recycled or disposed of in
normal household waste. Contact your local
government for disposal or recycling practices in
your area. They should be incinerated since they
might explode.
• Long-term exposure to loud music may cause
hearing damage. It is best to avoid high volume
levels when using headphones, especially for
extended periods.
• Use caution when using your headset/headphones
while operating a vehicle or engaging in any activity
that requires your full attention.
• Check and follow local laws regarding mobile
phone and headset/headphones use. Some
jurisdictions impose specic limitations, such as
single earpiece conguration, on the use of such
products while driving
NOTE: This device uses an internal rechargeable
lithium-ion battery that should last the lifetime of
the device. If you suspect your battery may be dead
after several attempts to charge, please visit
www.revjams.com for support.
Never disassemble the unit or attempt to remove the
battery as that could cause leakage of an electrolyte
substance
Actual performance may vary due to the user's habits,
dierent modes of operation, and mobile phone
settings. This manual is for reference purposes only. The
specications and design of the headset may change
without prior notice. Actual product may dier slightly
from the image on the packaging
Safety Information
Check local laws regarding the use of mobile phones
and headsets while driving. If you use the headset
while driving, ensure that your attention and focus
remains on the road and you drive in a responsible
and safe manner.
Never allow children to play with the headset, as the
small parts may be a choking hazard.
Observe all signs that require an electrical device or
RF radio product to be switched off in designated
areas. These could include hospitals, airplanes,
blasting areas, and potentially explosive environ-
ments.
Never mount or store your headset over an air bag
deployment area, a serious injury may result when
the air bag deploys.
Do not open or mutilate the built-in battery.
Dispose of batteries according to local regulations.
Do not dispose as household waste.
Warning and Precautions
• To prevent re or shock hazard, do not expose this
unit to rain or moisture.
• Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive
nish. As with any rubber compound made with oils,
the feet could cause marks or staining where the
feet reside. We recommend using a protective
barrier such as cloth or a piece of a glass between
the unit and the surface to reduce the risk of damage
and/or staining.
• Lithium batteries, like all rechargeable batteries are
recyclable and should be recycled or disposed of in
normal household waste. Contact your local
government for disposal or recycling practices in
your area. They should be incinerated since they
might explode.
• Long-term exposure to loud music may cause
hearing damage. It is best to avoid high volume
levels when using headphones, especially for
extended periods.
• Use caution when using your headset/headphones
while operating a vehicle or engaging in any activity
that requires your full attention.
• Check and follow local laws regarding mobile
phone and headset/headphones use. Some
jurisdictions impose specic limitations, such as
single earpiece conguration, on the use of such
products while driving
NOTE: This device uses an internal rechargeable
lithium-ion battery that should last the lifetime of
the device. If you suspect your battery may be dead
after several attempts to charge, please visit
www.revjams.com for support.
Never disassemble the unit or attempt to remove the
battery as that could cause leakage of an electrolyte
substance
Table of contents
Other RevJams Headphones manuals
RevJams
RevJams REV-400 User manual
RevJams
RevJams REV-BTH150 User manual
RevJams
RevJams PLAY3 User manual
RevJams
RevJams Play2 User manual
RevJams
RevJams STUDIO TWS User manual
RevJams
RevJams Xec User manual
RevJams
RevJams STUDIO TWS User manual
RevJams
RevJams Disco LED User manual
RevJams
RevJams StudioLite REV100-BLK User manual
