Revopoint MINI User manual

MINI 3D SCANNER
Quick Start Guide
V 2.0

©2023 REVOPOINT 3D ALL RIGHTS RESERVED 1
Table of Content
Read Before Your First Scan.............................................................................2
Software Download...................................................................................2
Scanning Dark, Transparent, or Reflective Objects...........................2
Scanning Objects with Plain Surfaces ..................................................3
Color Scanning ...........................................................................................3
About the Scanner..............................................................................................4
What’s in the Box?...............................................................................................5
MINI on a Windows or Mac Device.................................................................5
System Requirements ..............................................................................6
Connection Methods ................................................................................6
Connect the MINI to a PC Via USB.........................................................6
Connect the MINI to a PC Via Wi-Fi .......................................................7
MINI on Smartphones .......................................................................................8
System Requirements ..............................................................................9
Connection Methods ................................................................................9
Connect the MINI to an Android Phone via USB ...............................9
Connect the MINI to a Phone Via Wi-Fi ..............................................10
Appendix .............................................................................................................12
Specifications............................................................................................12
LED Indicators ..........................................................................................14
Update the Firmware..............................................................................14
Scanner Calibration.................................................................................14
Safety Maintenance Instructions.........................................................14
Troubleshooting ......................................................................................15
Customer Service.....................................................................................16

MINI Quick Start Guide
2 ©2023 REVOPOINT 3D ALL RIGHTS RESERVED
Read Before Your First Scan
Software Download
To use your Revopoint MINI 3D Scanner, you must download the Revo
Scansoftware. It can be found on Revopoint’s website for Windows and
macOS systems, and for Android or iOS smartphones, it can be found
by searching for “Revo Scan” in the Google Play or Apple App Store.
For the detailed functions of Revo Scan, please refer to the how-to-use
guide in Revo Scan.
ScanningDark, Transparent, or Reflective
Objects
Like most 3D scanners, the MINI will struggle to scan transparent,
reflective, or black objects without first treating the object's surface
with scanning spray, baby powder, or dry shampoo.
Surface Features
Possible Solutions
Black or very dark objects
Apply Scanning Spray / powder
materials
Shiny or reflective objects
Apply Scanning Spray / powder
materials
Metal / Electroplating surfaces
Apply Scanning Spray / powder
materials
Transparent objects
(Glass, certain kinds of plastic,
etc.)
Apply Scanning Spray / powder
materials
Few Geometric features
Stick markers on or around the
object;

MINI Quick Start Guide
©2023 REVOPOINT 3D ALL RIGHTS RESERVED 3
Scanning Objects with Plain Surfaces
Scanning objects with simple geometric features, like a football or wine
bottle, requires using Marker stickers or marker points and scanning in
Marker Mode.
1. Place markers at random distributions on the surface of objects, and
it is recommended to place them at a distance of 2~4 cm. Refer to the
image below:
2.Place the Marker stickers on the objects’ surface irregularly and
ensure that there are at least 5 Marker stickers in the frame for the
entire scan, or the scanner will lose track.
3. Alternatively, reference objects (these are any objects with distinct
features that can be easily tracked) can be used. Place 1 to 3 reference
objects around the item you are scanning for the 3D scanner to track.
If doing this, you can use the scanner in Feature tracking mode for the
scan.
Color Scanning
If you want to accurately capture an object’s color during a scan, please
ensure that the object is evenly lit with soft light and that there are no
dark or hard shadows.

MINI Quick Start Guide
4 ©2023 REVOPOINT 3D ALL RIGHTS RESERVED
About the Scanner
The Revopoint MINI uses binocular blue light technology to project
ultra-high-resolution structured light. The high-resolution dual-camera
system and intelligent algorithm produce an extremely precise and
detailed scanned model, helping professionals quickly achieve
accurate 3D data reconstruction. The MINI 3D scanner can output
models with a point distance of up to 0.05mm and a single-frame
precision of up to 0.02mm.
The MINI is a necessary modeling tool for professionals such as
designers, engineers, makers, and medical and scientific research
workers, and dramatically lowers the threshold for 3D creative
production, allowing you to quickly build a 3D digital world while
improving modeling efficiency by more than ten times.
1. Depth Camera
2. Projector
3. RGB Camera
4. Depth Camera
5. Micro-B USB Port
6. LED Indicator
7. Start/Pause Scan Button
8. Quick Setup Board

MINI Quick Start Guide
©2023 REVOPOINT 3D ALL RIGHTS RESERVED 5
What’s in the Box?
1. MINI 3D Scanner
2. Tripod
3. Phone Holder
4. 2-in-1 Mobile Cable
5. Type-C Adapter
6. USB Cable(Micro-B to Type-A)
7. Gifts (Markers, Glue Tack,
Black Sheet)
Note:
Except the parts listed above, there is a turntable added in the
MINI Standard Package. Refer to sales page for the MINI
Premium Package and others.
MINI on a Windows or Mac Device
Both Windows and macOS computers are compatible.

MINI Quick Start Guide
6 ©2023 REVOPOINT 3D ALL RIGHTS RESERVED
System Requirements
Windows: Win 8/10/11 (64-bit)
Windows 7 is not supported.
Memory: ≥ 8GB
Processor: Intel Core i5 or better
Mac with Intel × 86 chip: Mac OS 10.15 and models after
Mac with Apple M1 chip: Mac OS 11.0 and models after
Memory: ≥ 8GB
* Minimum PC Display Screen Resolution: 1344×768 (1920×1080 is
recommended.)
Connection Methods
Windows
macOS
USB Mode
√
√
Wi-Fi Mode
√
√
Connect the MINI to a PC Via USB
Step 1: Clip the MINI to the top.

MINI Quick Start Guide
©2023 REVOPOINT 3D ALL RIGHTS RESERVED 7
Step 2: Connect the Micro-B end of the cable to the back of your MINI.
Step 3: Plug the Type-A end into your computer.
Step 4: Open Revo Scan on your computer.
Note: 1) Connect the MINI to a USB 3.0 port or above, as USB 2.0 will
not supply sufficient operating power. Ensure your USB 3.0 port is not
damaged or worn out.
2) If there is no Type-A port on your laptop, use the Type-A-to-C adapter.
Step 5: Open Revo Scan on your computer.
Connect the MINI to a PC Via Wi-Fi
Step 1: Power the MINI on with a Power Bank Handle or an AC adapter.
(Note: Don‘t plug it into your PC, or it will be in USB mode by default.)
Windows or macOS

MINI Quick Start Guide
8 ©2023 REVOPOINT 3D ALL RIGHTS RESERVED
Step 2: Connect the PC to the MINI.
1) Go to your Wi-Fi setting, search for a network called MINI-XXXXXX
and connect. (No password is required.)
2) Wait a few seconds for the scanner to be connected.
Step 3: Open Revo Scan on your computer.
MINI on Smartphones
Android devices can connect via either USB or Wi-Fi. However, iOS
devices only support Wi-Fi mode.
Windows or macOS

MINI Quick Start Guide
©2023 REVOPOINT 3D ALL RIGHTS RESERVED 9
System Requirements
Android: ≥ Android 9.0
Harmony OS is supported.
RAM: ≥ 6GB
iPhone: iPhone 8 Plus or models after
iPad: 6th generation iPad and models after
System Version: ≥ iOS 13.0
Connection Methods
Android
iOS/iPadOS
USB Mode
√
×
Wi-Fi Mode
√
√
Connect the MINI to an Android Phone via
USB
Step 1: Screw the Phone Holder onto the Power Bank Handle.
Step 2: Clip the MINI to the top of the Phone Holder.
