RGBlink VSP268S User manual

VSP 268S Quick Start
User define resolution
EDID Management
Cascade splicing
Seamless switching with Fade
Picture in Picture
Two LED Sender installed
Audio Video Sync
Test Pattern Generator
Wide range Optional input modules

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
1
CONTENT
Product Introduction...................................................................................................................................................2
Packing Configuration................................................................................................................................................. 3
Hardware Info..............................................................................................................................................................4
Front Panel Overview..........................................................................................................................................4
Back Panel Overview........................................................................................................................................... 5
Menu Structure................................................................................................................................................... 6
Product Operations..................................................................................................................................................... 7
Contents.............................................................................................................................................................. 7
Single Picture Switching.............................................................................................................................. 8
Picture in Picture Settings........................................................................................................................... 8
Split Settings................................................................................................................................................9
Select and custom output resolution....................................................................................................... 10
Screen Parameter Setting......................................................................................................................... 10
Input Size Setting & Adjust........................................................................................................................11
VGA Input Auto Adjust.............................................................................................................................. 11
VGA Key Definitation.................................................................................................................................12
Image Scaling Setting................................................................................................................................ 12
Image Freeze............................................................................................................................................. 13
Text Overlay...............................................................................................................................................13
Transition Setting...................................................................................................................................... 14
AUDIO........................................................................................................................................................14
IMAGE SET UP........................................................................................................................................... 15
BLACK OUT................................................................................................................................................ 15
SAVE...........................................................................................................................................................16
LOAD SAVED SETTINGS............................................................................................................................. 16
Contact Information.................................................................................................................................................. 17

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
2
Product Introduction
VSP 268S is an audio and video synchronous switching and hign definition digital input video processor ,
which standard configuration supports CVBS, VGA, HDMI (DVI compatible) input signals and supports a set of
audio input and output to realize audio and video synchronization switching, supports one 3G-SDI input and one
optional input module , supports up to 2 3G-SDI inputs .VSP 268S supports local front panel operation , with
built-in broadcast-level motion adaptive deinterlacing technology, color true reduction technology and dynamic
range adjustment technology, true seamless switching, anti-aliasing and other functions that provides users with
high-quality video display.
System Connection
RGBlink offers solutions to
demanding technical problems.
Any application questions, or
required further information,
please contact with our
customer Support Engineers.
VSP 268S System Connection Diagram

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
3
Packing Configuration
Note:
AC Power Cable supplied as standard according to destination market.
AC Power Cord
USB Cable
DVI to HDMI
Cable

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
4
Hardware Info
Front Panel Overview
FRONT PANEL
OLED
PANEL
Show operation menu items
Menu
Menu and back button
Knob
Confirm and adjust OLED menu
Brightness
Brightness adjustment custom button
OK
Confirm button
CVBS
CVBS signal source button
Save
Save button
VGA
VGA and YPbPr signal source button
Freeze
Screen freeze button
HDMI
HDMI signal source button
SCALE
Scale button
SDI
SDI signal source button
PIP
Single and double picture switch button
MODULE
DVI input signal source button
FS
Screen parameter setting button
TAKE
Effect mode switch button
VOL
Volume control button
0~9
Number Button ,use for scale and custom
resolution setting
LOAD
Load button

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
5
Back Panel Overview
INPUT INTERFACE
2
SDI input and SDI Loop out
3
Audion Input Interface
5
DVI Input module
9
CVBS Input BNC port
10
VGA/YP input DB15 port
11
HDMI input HDMI-A port and Loop out
OUTPUT INTERFACE
4
Audion output port
12
DVI Output DVI-I Port
CONTROL INTERFACE
1
USB Port USB-A
RS232 interface
OTHER INTERFACE
6
Sending card installation slot
POWER CONTROL
7
Power Switch
8
Power input AC 85-264V 50/60HZ,IEC-3

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
6
Menu Structure

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
7
Product Operations
Contents
Single Picture Switching
Picture in Picture Settings
Split Settings
Select and custom output resolution
Screen Parameter Setting
Input Size Setting & Adjust
VGA Input Auto Adjust
VGA Key Definitation
Image Scaling Setting
Image Freeze
Text Overlay
Transition Setting
AUDIO
IMAGE SET UP
BLACK OUT
SAVE
LOAD SAVED SETTINGS

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
8
Single Picture Switching
When powered on, the system default input is HDMI. If other input source is wanted, for example VGA, just
push VGA button. VGA signal will be switched to the output in hard transition, where there will be black screen
or frozen picture. If seamless transition is required, activate seamless transition first. Push [TAKE] button for at
least 3 seconds to activate seamless transition function. Push VGA button to select VGA signal, then push [TAKE]
button, VGA signal will be transited to the screen in seamless cut or other transition effect. [TAKE] button is
defaulted with 1 second fade transition effect. If you want to change the duration of the transition effect, push
[MENU] button, select <Transition> and change the time of duration.
When use [TAKE] button to switch signals, on the LCD display users will be able to see the format and
resolution of the signal to be switched before switching. This will guarantee a safe and accurate operation.
Picture in Picture Settings
Activate PIP:
Push [PIP] button, button light on, PIP activated. Otherwise, PIP settings not available. On the LCD display it
will show the menu for setting PIP.
PIP layout setting:
Select one layout from the 7 layouts built in, push the knob to confirm. 3 examples of PIP layouts as below:
L+T L+R (PBP) T+B
Swap image settings:

Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
9
Select “ON” or “OFF”, to enable the swap of the two images of PIP.
Alpha settings:
The alpha parameter of image B can be set from 0 to 16.
Select setting:
To select “IMAGE A” or “IMAGE B” for settings.
Split Settings
Multiple VSP 268S can be cascaded for seamless splitting. When split, we suggest use distributor to distribute
the signal to the multiple VSP 268S. Users may also use the on board HDMI LOOP for cascade splitting.
Follow below operations of cascade split to access quick splitting:
Push [MENU] button, rotate the knob, select <SPLIT> to split evenly or unevenly.
Menu as below:
ENABLE/DISABLE: ON or OFF split function, system default as OFF, turn it ON to enable split settings.
H TOTAL: to set the total horizontal pixels of the LED screen
V TOTAL: to set the total vertical pixels of the LED screen
H POS: select it and press the number buttons to input the starting horizontal position.
V POS: select it and press the number buttons to input the starting vertical position.
H SIZE: to set the horizontal size of the part responsible.
V SIZE: to set the vertical size of the part responsible.
RESET: When done wrong, use RESET to remove the settings.
For even split, simply set the H SIZE and V SIZE of each VSP 268S to be same. Then set the H POS and V POS
of each VSP 268S accordingly. For uneven split, we have to set the H SIZE and V SIZE of each VSP 268S
individually.
After settings, we can save it to finish the split setting.
