Rheem RIWH18ASJ Service manual

INDOOR
OUTDOOR
DESIGN & TECHNICAL MANUAL
RIWH18ASJ
RIWH24ASJ
RIWH30AXJ
RIWH36AXJ
ROSH30AXJ
ROSH36AXJ
ROSH18ASJ
ROSH24ASJ
AIR CONDITIONER
Wall Mounted type
REFRIGERANT R410A
INVERTER

1. INDOOR UNIT
WALL MOUNTED TYPE :
RIWH18ASJ
RIWH24ASJ
RIWH30AXJ
RIWH36AXJ
DTR_AS125E_01
2017.01.27

WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
CONTENTS
1. INDOOR UNIT
1. SPECIFICATIONS.............................................................................................. 01 - 01
2. DIMENSIONS ........................................................................................................ 01 - 02
3. WIRING DIAGRAMS........................................................................................ 01 - 04
4. CAPACITY TABLE ............................................................................................ 01 - 05
4-1. COOLING CAPACITY...................................................................................... 01 - 05
4-2. HEATING CAPACITY....................................................................................... 01 - 09
5. FAN PERFORMANCE.....................................................................................01 - 11
5-1. AIR VELOCITY DISTRIBUTION......................................................................01 - 11
5-2. AIR FLOW.......................................................................................................... 01 - 15
6. OPERATION NOISE......................................................................................... 01 - 19
6-1. NOISE LEVEL CURVE .................................................................................... 01 - 19
6-2. SOUND LEVEL CHECK POINT..................................................................... 01 - 21
7. SAFETY DEVICES ............................................................................................ 01 - 22
8. EXTERNAL INPUT & OUTPUT............................................................... 01 - 23
8-1. EXTERNAL INPUT ........................................................................................... 01 - 23
8-2. EXTERNAL OUTPUT....................................................................................... 01 - 25
9. WIRELESS REMOTE CONTROLLER............................................... 01 - 26
10. FUNCTION SETTING...................................................................................... 01 - 27
10-1. INDOOR UNIT (Setting by remote controller)........................................... 01 - 27
11. OPTIONAL PARTS ........................................................................................... 01 - 32

- (01 - 01) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
1. SPECIFICATIONS
Type WALL MOUNTED
INVERTER HEAT PUMP
Model name RIWH18ASJ RIWH24ASJ RIWH30AXJ RIWH36AXJ
Power source 208/230V ~ 60Hz
Available voltage range 187-253V
Capacity
Cooling
Rated kW 5.28 7. 03 8.79 9.70
Btu/h 18,000 24,000 30,000 33,000
Min-Max kW 0.90 -5.28 0.90 - 7.30 2.90 - 9.50 2.90 - 10.00
Btu/h 3,100 - 19,000 3,100 - 25,000 9,900-32,400 9,900-34,100
Heating
Rated kW 5.28 7. 03 8.79 9.96
Btu/h 18,000 24,000 30,000 34,000
Min-Max kW 2.05 - 5.86 2.20 - 7.91 2.34 - 9.70 2.99 - 10.26
Btu/h 7,000 - 20,000 7,500-27,000 8,000 - 33,000 10,200-35,000
Input power
Cooling Rated
kW
1.44 2.40 3.16 3.88
Max 1.63 2.50 3.42 4.01
Heating Rated 1.285 1.925 2.80 3.39
Max 2.06 2.54 3.28 3.50
Current Cooling Rated A6.4 10.5 13.8 17.0
Heating 5.8 8.5 12.3 14.8
EER Cooling kW/kW 3.67 2.93 2.78 2.50
Btu/hW 12.5 10.0 9.5 8.5
COP Heating kW/kW 4.11 3.65 3.14 2.94
Btu/hW 14.0 12.5 10.7 10.0
SEER Cooling Btu/hW 19.0 18.0 16.5 15.5
HSPF Heating Btu/hW 10.6 10.6 9.0 9.0
POWER FACTOR Cooling %98 99 99 99
Heating 96 98 99 99
Moisture removal pints/h (l/h) 4.0 (1.9) 6.3 (3.0) 9.7 (4.6) 10.1 (4. 8)
Maximum operating current *1 Cooling A8.3 11.8 16.8 18.0
Heating 11.8 13.8 18.8 18.8
Fan
Airow
rate
Cooling
High
CFM
(m3/h)
541 (920) 659 (1,120) 659 (1,120) 69 4 (1,180)
Med 435 (740) 530 (900) 530 (900) 530 (900)
Low 365 (620) 435 (740) 435 (740) 435 (740)
Quiet 306 (520) 365 (620) 365 (620) 365 (620)
Heating
High 541 (920) 647 (1,100) 677 (1,15 0) 69 4 (1,180)
Med 435 (740) 530 (900) 530 (900) 530 (900)
Low 365 (620) 435 (740) 435 (740) 435 (740)
Quiet 318 (540) 365 (620) 365 (620) 365 (620)
Type × Q'ty Cross ow fan × 1
Motor output W 42 42 42 65
Sound pressure level *2
Cooling
High
dB(A)
42 47 47 50
Med 35 41 42 42
Low 31 35 37 37
Quiet 26 31 32 32
Heating
High 43 47 49 50
Med 36 42 42 42
Low 33 36 37 37
Quiet 28 33 33 33
Heat exchanger type
Dimensions
(H × W × D) in. (mm) Main:14-14/16 x 32-12/16 x 1-1/16 (378×832×26.6) Sub: 3-5/16 x 32-12/16 x 8/16 (84×832×13.3)
Fin pitch FPI Main:21, Sub:18
Rows x Stages Main:2×18, Sub1:1×4, Sub2:1×4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color WHITE
Approximate color of MUNSELL N9.25/
Dimensions
( H×W×D )
Net mm 320 × 998 × 238
inch 12-10/16 × 39-5/16 × 9-6/16
Gross mm 329 × 1090 × 420
inch 12-15/16 × 42-15/16 × 16-9/16
Weight Net lbs. (kg) 31 (14)
Gross 40 (18)
Connection pipe Size Liquid in. (mm) Ø 1/4 (Ø 6.35) Ø 3/8 (Ø 9.52) Gas Ø 1/2 (Ø 12.70) Ø 5/8 (Ø 15.88)
Method Flare
Operation range Cooling °F (°C) 64 to 90 (18 to 32) %RH 80 or less
Heating °F (°C) 88 (30) or less
Remote controller type Wireless
Drain pipe
Material PVC
Size mm
(Reference in.)
Ø12 (15/32) (I.D.)
Ø16 (5/8) (O.D.)
NOTE :
• Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C) DB / 67°F (19.44°C) WB, and outdoor temperature of 95°F (35°C) DB / 75°F (23.9°C) WB.
Heating : Indoor temperature of 70°F (21.11°C) DB / 59°F (15°C) WB, and outdoor temperature of 47°F (8.33°C) DB / 43°F (6.11°C) WB.
Pipe length : 24ft.7in (7.5m), Height difference:0 m. (Outdoor unit-Indoor unit)
• The protective function might work when using it outside the operation range.
*1: The maximum current is the maximum value when operated within the operation range.
*2: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specied values here.

- (01 - 02) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
2. DIMENSIONS
 MODEL: RIWH18ASJ, RIWH24ASJ, RIWH30AXJ, RIWH36AXJ
Unit : in (mm)
39-5/16 (998)
9 (238)
12-5/8 (320)
39-5/16 (998)
Outline of unit
18-9/16 (471) 2-5/8 (67)
1-1/8 (28)
1-13/16 (46)
17-1/4 (438)2-3/8 (61) 4 (102)15-5/8 (397)
17 (432)
2-3/16 (56)
2-3/16 (56)
3/8 (10)
12-5/8 (320)
11/16 (17)
Ø 3-1/8 (80) hole
Piping inlet
Ø 3-1/8 (80) hole
Piping inlet

- (01 - 03) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 INSTALLATION PLACE
Unit : in (mm)
3 (63) or more
4 (80) or more
3 (52) or more 3 (53) or more
4 (80) or more
Outline of unit
5 (120) or more
60 (1500) or more
71 (1800) or more

- (01 - 04) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
3. WIRING DIAGRAMS
 MODEL: RIWH18ASJ, RIWH24ASJ, RIWH30AXJ, RIWH36AXJ

- (01 - 05) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
4. CAPACITY TABLE
4-1. COOLING CAPACITY
 MODEL: RIWH18ASJ
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
SHC : Sensible Heat capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 541
Indoor temperature
64°FDB 70°FDB 75°FDB 80°FDB 85°FDB 90°FDB
54°FWB 60°FWB 63°FWB 67°FWB 71°FWB 73°FWB
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 15.8 11.8 0.50 17.6 13.1 0.50 19.4 14.5 0.53 20.0 14.9 0.51 21.2 15.8 0.51 22.4 16.7 0.53
23 15.5 11.6 0.54 17.3 12.9 0.54 19.1 14.2 0.57 19.7 14.6 0.56 20.8 15.5 0.56 22.0 16.4 0.58
32 15.3 11.4 0.56 17.0 12.7 0.56 18.8 14.0 0.59 19.4 14.4 0.58 20.5 15.3 0.58 21.7 16.2 0.59
41 15.1 11.2 0.57 16.8 12.5 0.57 18.5 13.8 0.60 19.1 14.2 0.59 20.2 15.1 0.59 21.3 15.9 0.61
50 14.8 11.0 0.58 16.5 12.3 0.59 18.2 13.5 0.62 18.7 14.0 0.60 19.9 14.8 0.60 21.0 15.6 0.62
59 14.6 10.8 0.62 16.2 12.1 0.62 17.9 13.3 0.66 18.4 13.7 0.64 19.5 14.5 0.64 20.7 15.4 0.66
67 16.7 13.3 1.00 18.6 13.4 1.02 20.5 14.6 1.04 21.2 15.8 1.04 22.4 15.7 1.05 23.7 16.8 1.06
77 16.0 12.7 1.13 17.8 12.8 1.14 19.6 13.9 1.17 20.2 15.0 1.17 21.4 15.0 1.18 22.6 16.0 1.19
87 15.2 12.0 1.26 17.0 12.1 1.27 18.7 13.2 1.30 19.3 14.3 1.31 20.5 14.2 1.32 21.6 15.2 1.33
95 14.2 11.3 1.39 15.8 11.4 1.42 17.4 12.4 1.43 18.0 13.4 1.44 19.1 13.3 1.45 20.2 14.2 1.46
104 12.9 9.9 1.37 14.4 10.0 1.39 15.8 10.9 1.42 16.3 11.8 1.42 17.3 11.7 1.43 18.3 12.5 1.45
115 12.0 9.1 1.34 13.4 9.1 1.37 14.8 9.9 1.39 15.2 10.7 1.39 16.1 10.7 1.42 17.0 11.4 1.43
AFR 920
Indoor temperature
17.8°CDB 21.1°CDB 23.9°CDB 26.7°CDB 29.4°CDB 32.2°CDB
12.2°CWB 15.6°CWB 17.2°CWB 19.4°CWB 21.7°CWB 22.8°CWB
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 4.63 3.45 0.50 5.16 3.85 0.50 5.69 4.24 0.53 5.86 4.37 0.51 6.20 4.62 0.51 6.56 4.89 0.53
-5.0 4.56 3.39 0.54 5.08 3.78 0.54 5.60 4.16 0.57 5.77 4.29 0.56 6.11 4.54 0.56 6.46 4.80 0.58
0.0 4.49 3.34 0.56 5.00 3.72 0.56 5.51 4.10 0.59 5.68 4.23 0.58 6.01 4.48 0.58 6.36 4.74 0.59
5.0 4.41 3.29 0.57 4.92 3.67 0.57 5.42 4.04 0.60 5.59 4.16 0.59 5.92 4.41 0.59 6.25 4.66 0.61
10.0 4.34 3.23 0.58 4.84 3.60 0.59 5.33 3.97 0.62 5.49 4.09 0.60 5.82 4.34 0.60 6.15 4.58 0.62
15.0 4.27 3.18 0.62 4.76 3.54 0.62 5.24 3.90 0.66 5.40 4.02 0.64 5.73 4.26 0.64 6.05 4.50 0.66
19.4 4.90 3.91 1.00 5.46 3.93 1.02 6.02 4.28 1.04 6.21 4.63 1.04 6.58 4.60 1.05 6.95 4.91 1.06
25.0 4.68 3.72 1.13 5.21 3.75 1.14 5.75 4.08 1.17 5.92 4.40 1.17 6.27 4.39 1.18 6.63 4.68 1.19
30.6 4.47 3.52 1.26 4.98 3.55 1.27 5.49 3.87 1.30 5.66 4.18 1.31 5.99 4.17 1.32 6.34 4.44 1.33
35.0 4.17 3.31 1.39 4.64 3.34 1.42 5.11 3.64 1.43 5.28 3.93 1.44 5.59 3.91 1.45 5.91 4.17 1.46
40.0 3.78 2.92 1.37 4.21 2.93 1.39 4.64 3.20 1.42 4.78 3.45 1.42 5.07 3.44 1.43 5.35 3.66 1.45
46.1 3.52 2.66 1.34 3.92 2.67 1.37 4.32 2.92 1.39 4.45 3.14 1.39 4.73 3.13 1.42 4.99 3.34 1.43

- (01 - 06) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH24ASJ
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
SHC : Sensible Heat capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 659
Indoor temperature
64°FDB 70°FDB 75°FDB 80°FDB 85°FDB 90°FDB
54°FWB 60°FWB 63°FWB 67°FWB 71°FWB 73°FWB
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 21.1 14.9 0.83 23.5 16.6 0.84 25.9 18.3 0.88 26.6 18.9 0.86 28.2 20.0 0.86 29.8 21.2 0.89
23 20.7 14.7 0.90 23.1 16.3 0.90 25.5 18.0 0.95 26.2 18.6 0.93 27.8 19.7 0.93 29.4 20.8 0.96
32 20.4 14.5 0.93 22.7 16.1 0.94 25.1 17.8 0.99 25.8 18.3 0.96 27.3 19.4 0.96 28.9 20.5 0.99
41 20.1 14.2 0.95 22.4 15.9 0.95 24.7 17.5 1.00 25.4 18.0 0.98 26.9 19.1 0.98 28.5 20.2 1.01
50 19.7 14.0 0.97 22.0 15.6 0.98 24.3 17.2 1.03 25.0 17.7 1.00 26.5 18.8 1.01 28.0 19.8 1.04
59 19.7 13.7 1.04 21.9 15.3 1.04 24.2 16.9 1.10 24.9 17.4 1.07 26.4 18.4 1.07 27.9 19.5 1.10
67 22.3 16.9 1.67 24.8 17.0 1.71 27.4 18.5 1.73 28.2 20.0 1.73 29.9 19.9 1.75 31.6 21.3 1.77
77 21.3 16.1 1.88 23.7 16.2 1.90 26.1 17.7 1.94 26.9 19.1 1.94 28.5 19.0 1.96 30.2 20.2 1.98
87 20.2 15.3 2.10 22.5 15.4 2.12 24.8 16.8 2.16 25.5 18.1 2.18 27.0 18.0 2.20 28.6 19.2 2.22
95 19.0 14.3 2.32 21.1 14.4 2.36 23.3 15.7 2.38 24.0 17.0 2.40 25.4 16.9 2.42 26.9 18.0 2.44
104 17.1 12.6 2.28 19.1 12.7 2.32 21.0 13.9 2.36 21.6 14.9 2.36 22.9 14.9 2.38 24.2 15.8 2.42
115 16.1 11.5 2.24 17.9 11.5 2.28 19.7 12.6 2.32 20.3 13.6 2.32 21.6 13.5 2.36 22.7 14.4 2.38
AFR 1,120
Indoor temperature
17.8°CDB 21.1°CDB 23.9°CDB 26.7°CDB 29.4°CDB 32.2°CDB
12.2°CWB 15.6°CWB 17.2°CWB 19.4°CWB 21.7°CWB 22.8°CWB
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 6.17 4.38 0.83 6.88 4.88 0.84 7.58 5.38 0.88 7.81 5.54 0.86 8.27 5.87 0.86 8.74 6.20 0.89
-5.0 6.08 4.30 0.90 6.77 4.79 0.90 7.46 5.28 0.95 7.69 5.44 0.93 8.14 5.76 0.93 8.61 6.09 0.96
0.0 5.98 4.24 0.93 6.66 4.72 0.94 7.34 5.21 0.99 7.57 5.37 0.96 8.02 5.68 0.96 8.47 6.01 0.99
5.0 5.88 4.17 0.95 6.55 4.65 0.95 7.23 5.12 1.00 7.45 5.28 0.98 7.89 5.60 0.98 8.34 5.91 1.01
10.0 5.79 4.10 0.97 6.45 4.57 0.98 7.11 5.04 1.03 7.33 5.19 1.00 7.76 5.50 1.01 8.20 5.81 1.04
15.0 5.77 4.03 1.04 6.43 4.49 1.04 7.09 4.95 1.10 7.31 5.10 1.07 7.75 5.40 1.07 8.19 5.71 1.10
19.4 6.54 4.96 1.67 7.28 4.99 1.71 8.03 5.43 1.73 8.28 5.87 1.73 8.77 5.84 1.75 9.27 6.23 1.77
25.0 6.24 4.72 1.88 6.95 4.75 1.90 7.66 5.18 1.94 7.89 5.59 1.94 8.36 5.57 1.96 8.84 5.93 1.98
30.6 5.91 4.47 2.10 6.59 4.50 2.12 7.27 4.91 2.16 7.48 5.30 2.18 7.93 5.29 2.20 8.39 5.63 2.22
35.0 5.56 4.20 2.32 6.19 4.23 2.36 6.82 4.61 2.38 7.03 4.99 2.40 7.45 4.96 2.42 7.88 5.29 2.44
40.0 5.01 3.70 2.28 5.58 3.71 2.32 6.14 4.06 2.36 6.33 4.38 2.36 6.72 4.36 2.38 7.09 4.64 2.42
46.1 4.71 3.37 2.24 5.23 3.38 2.28 5.77 3.70 2.32 5.95 3.98 2.32 6.32 3.97 2.36 6.67 4.23 2.38

- (01 - 07) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH30AXJ
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
SHC : Sensible Heat capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 659
Indoor temperature
64°FDB 70°FDB 75°FDB 80°FDB 85°FDB 90°FDB
54°FWB 60°FWB 63°FWB 67°FWB 71°FWB 73°FWB
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 25.7 18.3 0.80 28.6 18.4 0.81 31.5 20.1 0.82 32.5 21.7 0.83 34.5 21.6 0.84 36.4 23.0 0.84
23 25.7 18.7 0.93 28.6 18.8 0.94 31.5 20.5 0.95 32.5 22.1 0.96 34.5 22.0 0.97 36.4 23.5 0.98
32 25.7 19.0 1.05 28.6 19.2 1.07 31.5 20.9 1.08 32.5 22.6 1.09 34.4 22.5 1.10 36.4 23.9 1.11
41 25.7 18.3 1.17 28.6 18.4 1.19 31.5 20.1 1.21 32.5 21.7 1.22 34.4 21.6 1.23 36.4 23.0 1.24
50 25.6 18.7 1.33 28.5 18.8 1.35 31.4 20.5 1.37 32.4 22.1 1.37 34.3 22.0 1.39 36.3 23.5 1.40
59 25.1 18.2 1.47 28.0 18.4 1.49 30.8 20.0 1.51 31.8 21.6 1.52 33.7 21.5 1.53 35.6 22.9 1.55
67 24.4 18.0 1.71 27.2 18.2 1.74 30.0 19.8 1.76 30.9 21.4 1.77 32.8 21.3 1.79 34.7 22.7 1.81
77 26.3 19.1 2.45 29.3 19.2 2.49 32.4 20.9 2.53 33.4 22.6 2.54 35.4 22.5 2.57 37.4 24.0 2.59
87 25.1 18.4 2.74 27.9 18.5 2.79 30.8 20.2 2.83 31.7 21.8 2.84 33.6 21.7 2.87 35.5 23.1 2.90
95 23.7 17.6 3.05 26.4 17.7 3.10 29.1 19.4 3.14 30.0 20.9 3.16 31.8 20.8 3.19 33.6 22.2 3.22
104 22.1 16.8 3.35 24.7 16.9 3.40 27.2 18.4 3.45 28.0 19.9 3.47 29.7 19.8 3.50 31.4 21.1 3.54
115 16.9 14.0 2.80 18.8 14.1 2.84 20.7 15.4 2.88 21.3 16.6 2.90 22.6 16.6 2.93 23.9 17.7 2.96
AFR 1,120
Indoor temperature
17.8°CDB 21.1°CDB 23.9°CDB 26.7°CDB 29.4°CDB 32.2°CDB
12.2°CWB 15.6°CWB 17.2°CWB 19.4°CWB 21.7°CWB 22.8°CWB
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 7.53 5.37 0.80 8.39 5.40 0.81 9.25 5.89 0.82 9.53 6.36 0.83 10.10 6.34 0.84 10.68 6.75 0.84
-5.0 7.53 5.48 0.93 8.38 5.51 0.94 9.24 6.01 0.95 9.53 6.49 0.96 10.10 6.46 0.97 10.67 6.88 0.98
0.0 7.52 5.58 1.05 8.38 5.61 1.07 9.24 6.12 1.08 9.52 6.61 1.09 10.09 6.59 1.10 10.66 7.02 1.11
5.0 7.52 5.36 1.17 8.37 5.40 1.19 9.23 5.88 1.21 9.52 6.35 1.22 10.09 6.33 1.23 10.66 6.74 1.24
10.0 7.50 5.47 1.33 8.35 5.51 1.35 9.21 6.01 1.37 9.49 6.49 1.37 10.06 6.46 1.39 10.63 6.88 1.40
15.0 7.36 5.35 1.47 8.20 5.38 1.49 9.03 5.87 1.51 9.31 6.34 1.52 9.87 6.31 1.53 10.43 6.72 1.55
19.4 7.16 5.29 1.71 7.98 5.32 1.74 8.80 5.80 1.76 9.07 6.27 1.77 9.61 6.24 1.79 10.16 6.65 1.81
25.0 7.72 5.60 2.45 8.60 5.63 2.49 9.48 6.14 2.53 9.77 6.63 2.54 10.36 6.60 2.57 10.95 7.03 2.59
30.6 7.35 5.39 2.74 8.19 5.42 2.79 9.02 5.91 2.83 9.30 6.39 2.84 9.86 6.36 2.87 10.42 6.78 2.90
35.0 6.94 5.17 3.05 7.74 5.20 3.10 8.53 5.67 3.14 8.79 6.12 3.16 9.32 6.10 3.19 9.84 6.50 3.22
40.0 6.49 4.93 3.35 7.23 4.95 3.40 7.97 5.40 3.45 8.22 5.84 3.47 8.71 5.81 3.50 9.20 6.19 3.54
46.1 4.94 4.12 2.80 5.51 4.14 2.84 6.07 4.52 2.88 6.26 4.88 2.90 6.63 4.86 2.93 7.01 5.17 2.96

- (01 - 08) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH36AXJ
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
SHC : Sensible Heat capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 694
Indoor temperature
64°FDB 70°FDB 75°FDB 80°FDB 85°FDB 90°FDB
54°FWB 60°FWB 63°FWB 67°FWB 71°FWB 73°FWB
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 27.6 19.9 1.01 30.8 20.0 1.03 33.9 21.9 1.04 35.0 23.6 1.05 37.1 23.5 1.06 39.2 25.1 1.07
23 27.6 20.3 1.17 30.8 20.4 1.19 33.9 22.3 1.21 34.9 24.1 1.21 37.0 24.0 1.22 39.1 25.5 1.24
32 27.6 20.7 1.33 30.7 20.8 1.35 33.9 22.7 1.37 34.9 24.5 1.38 37.0 24.4 1.39 39.1 26.0 1.41
41 27.6 19.9 1.48 30.7 20.0 1.51 33.9 21.8 1.53 34.9 23.6 1.54 37.0 23.5 1.55 39.1 25.0 1.57
50 27.5 20.3 1.68 30.6 20.4 1.70 33.8 22.3 1.73 34.8 24.0 1.74 36.9 23.9 1.76 39.0 25.5 1.77
59 27.3 20.2 1.85 30.4 20.3 1.88 33.6 22.1 1.91 34.6 23.9 1.92 36.7 23.8 1.94 38.7 25.4 1.96
67 26.3 19.6 2.16 29.3 19.7 2.20 32.3 21.5 2.23 33.3 23.2 2.24 35.3 23.1 2.27 37.3 24.6 2.29
77 28.3 20.8 3.10 31.6 20.9 3.15 34.8 22.8 3.20 35.9 24.6 3.21 38.0 24.5 3.25 40.2 26.1 3.28
87 27.0 20.0 3.47 30.0 20.1 3.52 33.1 21.9 3.58 34.1 23.7 3.60 36.2 23.6 3.63 38.2 25.1 3.67
95 25.5 19.2 3.86 28.4 19.3 3.92 31.3 21.0 3.98 33.0 21.8 3.88 34.2 22.6 4.04 36.1 24.1 4.08
104 23.8 18.2 4.23 26.5 18.3 4.30 29.2 20.0 4.37 30.1 21.6 4.39 31.9 21.5 4.43 33.8 22.9 4.48
115 18.1 15.2 3.54 20.2 15.3 3.59 22.3 16.7 3.65 22.9 18.0 3.67 24.3 17.9 3.70 25.7 19.1 3.74
AFR 1,180
Indoor temperature
17.8°CDB 21.1°CDB 23.9°CDB 26.7°CDB 29.4°CDB 32.2°CDB
12.2°CWB 15.6°CWB 17.2°CWB 19.4°CWB 21.7°CWB 22.8°CWB
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 8.10 5.84 1.01 9.02 5.88 1.03 9.94 6.41 1.04 10.25 6.92 1.05 10.86 6.89 1.06 11.48 7.34 1.07
-5.0 8.09 5.95 1.17 9.01 5.99 1.19 9.94 6.53 1.21 10.24 7.05 1.21 10.86 7.02 1.22 11.47 7.48 1.24
0.0 8.09 6.06 1.33 9.01 6.10 1.35 9.93 6.65 1.37 10.24 7.18 1.38 10.85 7.15 1.39 11.47 7.62 1.41
5.0 8.08 5.83 1.48 9.00 5.87 1.51 9.92 6.40 1.53 10.23 6.91 1.54 10.84 6.88 1.55 11.46 7.33 1.57
10.0 8.06 5.95 1.68 8.98 5.98 1.70 9.90 6.53 1.73 10.21 7.05 1.74 10.82 7.02 1.76 11.43 7.48 1.77
15.0 8.01 5.92 1.85 8.92 5.95 1.88 9.83 6.49 1.91 10.14 7.01 1.92 10.75 6.98 1.94 11.35 7.44 1.96
19.4 7.70 5.75 2.16 8.58 5.78 2.20 9.46 6.30 2.23 9.75 6.81 2.24 10.33 6.78 2.27 10.92 7.22 2.29
25.0 8.30 6.08 3.10 9.25 6.12 3.15 10.19 6.67 3.20 10.51 7.21 3.21 11.14 7.18 3.25 11.77 7.65 3.28
30.6 7.90 5.86 3.47 8.80 5.89 3.52 9.70 6.43 3.58 10.00 6.94 3.60 10.60 6.91 3.63 11.20 7.36 3.67
35.0 7.47 5.61 3.86 8.32 5.65 3.92 9.17 6.16 3.98 9.70 6.39 3.88 10.02 6.62 4.04 10.58 7.06 4.08
40.0 6.98 5.35 4.23 7.77 5.38 4.30 8.57 5.87 4.37 8.83 6.33 4.39 9.36 6.31 4.43 9.89 6.72 4.48
46.1 5.31 4.45 3.54 5.92 4.48 3.59 6.52 4.89 3.65 6.73 5.28 3.67 7.13 5.26 3.70 7.53 5.60 3.74

- (01 - 09) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
4-2. HEATING CAPACITY
 MODEL: RIWH18ASJ
AFR 541
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 16.2 1.98 15.8 2.01 15.4 2.18 14.6 2.14
14 12 17.3 1.87 16.9 1.90 16.5 2.13 15.6 2.02
23 19 18.1 1.81 17.7 1.84 17. 2 2.05 16.3 1.96
32 28 18.2 1.81 17. 8 1.85 17.3 1.95 16.5 1.96
41 37 19.9 1.92 19.4 1.95 19.0 2.00 18.0 2.08
47 43 21.0 1.98 20.5 2.01 20.0 2.06 19.0 2 .14
50 47 23.2 2.01 22.7 2.04 22.1 2.09 21.0 2 .17
59 50 24.0 2.05 23.4 2.09 22.9 2.10 21.8 2.22
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 920
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16 .1 4.73 1.98 4.64 2.01 4.51 2.18 4.29 2.14
-10.0 -11.1 5.08 1.87 4.95 1.90 4.83 2.13 4.59 2.02
-5.0 -7.2 5.30 1.81 5.17 1.84 5.03 2.05 4.78 1.96
0.0 -2.2 5.35 1.81 5.22 1.85 5.08 1.95 4.83 1.96
5.0 2.8 5.84 1.92 5.69 1.95 5.57 2.00 5.27 2.08
8.3 6.1 6.16 1.98 6.01 2.01 5.86 2.06 5.57 2.14
10.0 8.3 6.79 2.01 6.65 2.04 6.47 2.09 6.16 2.17
15.0 10.0 7.04 2.05 6.87 2.09 6.72 2.10 6.38 2.22
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
IP : Input Power (kW)
 MODEL: RIWH24ASJ
AFR 647
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 21.8 2.44 21.4 2.48 20.8 2.69 19.8 2.64
14 12 23.4 2.30 22.8 2.34 22.3 2.62 21.1 2.49
23 19 24.4 2.23 23.8 2.27 23.2 2.53 22.0 2.41
32 28 24.6 2.23 24.1 2.28 23.4 2.40 22.3 2.42
41 37 26.9 2.37 26.2 2.41 25.6 2.46 24.3 2.56
47 43 28.4 2.44 27.7 2.48 27.0 2.54 25.6 2.64
50 47 31.3 2.48 30.6 2.52 29.8 2.58 28.4 2.68
59 50 32.4 2.53 31.6 2.57 31.0 2.59 29.4 2.73
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 1,10 0
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16 .1 6.39 2.44 6.26 2.48 6.09 2.69 5.79 2.64
-10.0 -11.1 6.85 2.30 6.69 2.34 6.52 2.62 6 .19 2.49
-5.0 -7.2 7.15 2.23 6.99 2.27 6.79 2.53 6.46 2.41
0.0 -2.2 7.22 2.23 7.05 2.28 6.85 2.40 6.52 2.42
5.0 2.8 7.88 2.37 7.6 8 2.41 7.5 2 2.46 7.12 2.56
8.3 6.1 8.31 2.44 8.11 2.48 7.91 2.54 7.52 2.64
10.0 8.3 9.17 2.48 8.97 2.52 8.74 2.58 8.31 2.68
15.0 10.0 9.50 2.53 9.27 2.57 9.07 2.59 8.61 2.73
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
IP : Input Power (kW)

- (01 - 10) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH30AXJ
AFR 677
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 23.2 3.78 22.7 3.86 22.1 3.94 21.0 4.10
14 12 25.0 3.78 24.4 3.86 23.8 3.93 22.6 4.09
23 19 28.8 3.79 28.1 3.87 27.5 3.95 26.1 4.11
32 28 31.6 3.76 30.9 3.84 3 0.1 3.91 28.6 4.07
41 37 34.6 3.80 33.8 3.88 32.9 3.96 31.3 4.12
47 43 34.7 3.15 33.8 3.21 33.0 3.28 31.4 3.41
50 47 35.7 3.14 34.8 3.20 34.0 3.27 32.3 3.40
59 50 34.4 2.74 33.6 2.80 32.8 2.86 31.1 2.97
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 1,150
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16 .1 6.81 3.78 6.65 3.86 6.48 3.94 6.16 4.10
-10.0 -11.1 7. 3 3 3.78 7.15 3.86 6.98 3.93 6.63 4.09
-5.0 -7.2 8.45 3.79 8.25 3.87 8.05 3.95 7. 65 4.11
0.0 -2.2 9.27 3.76 9.05 3.84 8.83 3.91 8.38 4.07
5.0 2.8 10.14 3.80 9.90 3.88 9.66 3.96 9.17 4.12
8.3 6.1 10.16 3 .15 9.91 3.21 9.70 3.28 9.19 3.41
10.0 8.3 10.46 3.14 10.21 3.20 9.96 3.27 9.47 3.40
15.0 10.0 10.09 2.74 9.85 2.80 9.61 2.86 9.13 2.97
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
IP : Input Power (kW)
 MODEL: RIWH36AXJ
AFR 694
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 24.6 4.04 24.1 4.12 23.5 4.20 22.3 4.28
14 12 26.5 4.03 25.9 4.11 25.3 4.20 24.0 4.28
23 19 30.6 4.05 29.9 4.13 29.1 4.22 27.7 4.28
32 28 33.5 4.01 32.7 4.09 31.9 4.18 30.3 4.28
41 37 36.7 4.06 35.8 4.14 34.9 4.23 33.2 4.28
47 43 36.8 3.36 35.9 3.43 35.0 3.50 33.3 3.64
50 47 37. 9 3.35 37.0 3.42 3 6.1 3.49 34.3 3.63
59 50 36.5 2.92 35.6 2.99 34.8 3.05 33.0 3.17
AFR : Air ow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 1,180
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16 .1 7. 22 4.04 7.05 4.12 6.88 4.20 6.53 4.28
-10.0 -11.1 7.77 4.03 7. 59 4.11 7. 40 4.20 7.03 4.28
-5.0 -7.2 8.96 4.05 8.75 4.13 8.54 4.22 8.11 4.28
0.0 -2.2 9.83 4.01 9.59 4.09 9.36 4.18 8.89 4.28
5.0 2.8 10.75 4.06 10.50 4.14 10.24 4.23 9.73 4.28
8.3 6.1 10.77 3.36 10.51 3.43 10.26 3.50 9.75 3.64
10.0 8.3 11.10 3.35 10.83 3.42 10.57 3.49 10.04 3.63
15.0 10.0 10.70 2.92 10.45 2.99 10.19 3.05 9.68 3.17
AFR : Air ow rate (m3/h)
TC : Total capacity (kW)
IP : Input Power (kW)

- (01 - 11) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
5. FAN PERFORMANCE
5-1. AIR VELOCITY DISTRIBUTION
 MODEL: RIWH18ASJ
Conditions:
Fan speed : High
Operation mode : FAN
Voltage : 230V
2
1
0
1
2
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
1
2
3
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Right & Left
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Down
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
(ft)
714 20 27
7
3
0
3
7
(ft)
(ft)
714 20 27
(ft)
714 20 27
(ft)
714 20 27
10
7
3
0
10
7
3
0
3
7
10
10
7
3
0
(ft)
(ft)
(ft)
7(2)
3(1)
2(0.5)
7(2)
3(1)
2(0.5)
2(0.5)
2(0.5)
3(1)
3(1)
7(2)
7(2)
7(2) 3(1) 2(0.5)

- (01 - 12) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH24ASJ
Conditions:
Fan speed : High
Operation mode : FAN
Voltage : 230V
2
1
0
1
2
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
1
2
3
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Right & Left
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Down
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
(ft)
714 20 27
7
3
0
3
7
(ft)
(ft)
714 20 27
(ft)
714 20 27
(ft)
714 20 27
10
7
3
0
10
7
3
0
3
7
10
10
7
3
0
(ft)
(ft)
(ft)
7(2)
3(1)
2(0.5)
7(2)
3(1)
2(0.5)
2(0.5)
2(0.5)
3(1)
3(1)
7(2)
7(2)
7(2) 3(1)
2(0.5)

- (01 - 13) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH30AXJ
Conditions:
Fan speed : High
Operation mode : FAN
Voltage : 230V
2
1
0
1
2
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
1
2
3
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Right & Left
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Down
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
(ft)
714 20 27
7
3
0
3
7
(ft)
(ft)
714 20 27
(ft)
714 20 27
(ft)
714 20 27
10
7
3
0
10
7
3
0
3
7
10
10
7
3
0
(ft)
(ft)
(ft)
7(2)
3(1)
2(0.5)
7(2)
3(1)
2(0.5)
2(0.5)
2(0.5)
3(1)
3(1)
7(2)
7(2)
7(2) 3(1)
2(0.5)

- (01 - 14) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH36AXJ
Conditions:
Fan speed : High
Operation mode : FAN
Voltage : 230V
2
1
0
1
2
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
1
2
3
(m)
(m)
TOP VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Right & Left
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Down
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical airow direction louver : Up
Horizontal airow direction louver : Center
Unit : ft/s (m/s)
012345678
(ft)
714 20 27
7
3
0
3
7
(ft)
(ft)
714 20 27
(ft)
714 20 27
(ft)
714 20 27
10
7
3
0
10
7
3
0
3
7
10
10
7
3
0
(ft)
(ft)
(ft)
7(2) 3(1)
2(0.5)
7(2)
3(1) 2(0.5)
2(0.5)
2(0.5)
3(1)
3(1)
7(2)
7(2)
7(2)
3(1) 2(0.5)

- (01 - 15) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
5-2. AIR FLOW
 MODEL: RIWH18ASJ
zCooling
zHeating
Fan speed Air ow
HIGH
920 m3/h
256 l/s
541 CFM
MED
740 m3/h
206 l/s
435 CFM
LOW
620 m3/h
172 l/s
365 CFM
QUIET
520 m3/h
144 l/s
306 CFM
Fan speed Air ow
HIGH
920 m3/h
256 l/s
541 CFM
MED
740 m3/h
206 l/s
435 CFM
LOW
620 m3/h
172 l/s
365 CFM
QUIET
540 m3/h
150 l/s
318 CFM

- (01 - 16) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH24ASJ
zCooling
zHeating
Fan speed Air ow
HIGH
1120 m3/h
311 l/s
659 CFM
MED
900 m3/h
250 l/s
530 CFM
LOW
740 m3/h
206 l/s
435 CFM
QUIET
620 m3/h
172 l/s
365 CFM
Fan speed Air ow
HIGH
1100 m3/h
306 l/s
647 CFM
MED
900 m3/h
250 l/s
530 CFM
LOW
740 m3/h
206 l/s
435 CFM
QUIET
620 m3/h
172 l/s
365 CFM

- (01 - 17) -
WALL MOUNTED TYPE RIWH18-36A WALL MOUNTED TYPE RIWH18-36A
 MODEL: RIWH30AXJ
zCooling
zHeating
Fan speed Air ow
HIGH
1120 m3/h
311 l/s
659 CFM
MED
900 m3/h
250 l/s
530 CFM
LOW
740 m3/h
206 l/s
435 CFM
QUIET
620 m3/h
172 l/s
365 CFM
Fan speed Air ow
HIGH
1150 m3/h
319 l/s
677 CFM
MED
900 m3/h
250 l/s
530 CFM
LOW
740 m3/h
206 l/s
435 CFM
QUIET
620 m3/h
172 l/s
365 CFM
