DESIGN & TECHNICAL MANUAL
INDOOR
OUTDOOR
ROSH09AFCJ
ROSH12AFCJ
ROSH18AFCJ
RIDH09AVFJ
RIDH12AVFJ
RIDH18AVFJ
AIR CONDITIONER
Duct type

1. INDOOR UNIT
DUCT TYPE :
RIDH09AVFJ
RIDH12AVFJ
RIDH18AVFJ

CONTENTS
1. INDOOR UNIT
1. FEATURES.............................................................................................................. 01 - 01
2. WIRED REMOTE CONTROLLER......................................................... 01 - 02
3. SPECIFICATIONS.............................................................................................. 01 - 04
4. DIMENSIONS........................................................................................................ 01 - 05
5. WIRING DIAGRAMS........................................................................................ 01 - 09
6. CAPACITY TABLE............................................................................................ 01 - 10
6-1. COOLING CAPACITY ....................................................................................... 01 - 10
6-2. HEATING CAPACITY ........................................................................................ 01 - 13
7. FAN PERFORMANCE.................................................................................... 01 - 15
7-1. FAN PERFORMANCE CURVE........................................................................ 01 - 15
7-2. AIRFLOW ............................................................................................................ 01 - 21
8. OPERATION NOISE (SOUND PRESSURE)................................. 01 - 24
8-1. NOISE LEVEL CURVE...................................................................................... 01 - 24
8-2. SOUND LEVEL CHECK POINT ...................................................................... 01 - 26
9. ELECTRICAL CHARACTERISTICS................................................... 01 - 27
10. SAFETY DEVICES............................................................................................ 01 - 28
11. EXTERNAL INPUT & OUTPUT............................................................... 01 - 29
11-1. EXTERNAL INPUT............................................................................................. 01 - 29
11-2. EXTERNAL OUTPUT........................................................................................ 01 - 30
12. FUNCTION SETTINGS.................................................................................. 01 - 33
12-1. INDOOR UNIT..................................................................................................... 01 - 33
12-2. INDOOR UNIT (Setting by remote controller)............................................ 01 - 35
12-3. WIRED REMOTE CONTROLLER................................................................... 01 - 41
13. OPTIONAL PARTS........................................................................................... 01 - 44
13-1. CONTROLLERS................................................................................................. 01 - 44
13-2. OTHERS .............................................................................................................. 01 - 44

-
(
01 - 01
)
-
FEATURES1.MODELS

RIDH09AVFJ / ROSH09AFCJ
RIDH12AVFJ / ROSH12AFCJ
RIDH18AVFJ / ROSH18AFCJ
FEATURES

Energy saving

High energy saving was realized by converting indoor unit/outdoor unit fan motors and
compressor to all DC, and also by optimal design of the refrigerant cycle.
Slim design

The slim design allows installations where
ceilings are narrow.
Height
Drain pump built-in
7-25/32 in.
(198 mm)
Drain port
Drain pump
Compact design

Condensate lift-up to 33-15/32 in. (850 mm).
Max.
33-15/32 in.
(850mm)
Drain hose is standard accessory
Selectable with a wide range of
static pressure
By using DC fan motor, it is possible to
change the static pressure range from
0 to 0.36 in. WG (0 to 90 Pa).
The change of static pressure range is
possible by remote controller.
0
[in.WG (Pa)]
Airflowrate
Static pressure range
[CFM (m
3
/h)]
0.36(90)
Air-intake

Air intake direction can be selected to
match the installation site.
Bottom side Back side
Flexible installation

Ceiling concealed
Wall concealed
Filter (Accessory)

Filter: 2 pcs.
RIDH09AVFJ
RIDH12AVFJ
RIDH18AVFJ

-
(
01 - 02
)
-
WIRED REMOTE CONTROLLER2.FEATURES

High performance and compact size

Thermo
sensor
Individual
control
Weekly
timer
Setback
timer
Wired
remote
controller
Sensor part
Thermo sensor
indicator
Control part for
changing the
thermo sensor
Accurate and comfortable

Indoor temperature can be detected accurately by the inclusion of a
thermo sensor in the body of the wired controller.
Our system can correspond to various scenes.
This wired remote controller and the optional remote sensor allows
flexibility in sensor location, and suitable for all requirements.
Built-in timers

Weekly timer Setback timer
Possible to set ON/OFF time to operate twice each day of the
week.
Possible to set temperature for two time spans and for each
day of the week.
At "Weekly timer" + "Set back timer" setup
76 °F (24 °C)
036912151821O'clock
1236912369
time
AM PM
Easy-to-understand time bar display
Example: setup screen
(Set to Wednesday: 8:00 to 20:00.)
Screen
after setup
84 °F (28 °C)
036912151821 O'clock
1236912369
time
AM PM
Example: setup screen
(Set from Sunday to Saturday: 12:00 to 15:00, 28 °C.)
76 °F 84 °F 76 °F 036912151821O'clock
1236912369
time
AM PM
76°F (24 °C) 84 °F (28 °C)
24 °C 28 °C 24 °C
Easy-to-understand operation

[Variable timer control]
The operation/display sections are zoned according
to time and operation, enabling variable programming
to match application.
Simple installation

Components are compatible with standard switch
boxes. Flat back surface allows equipment to be
installed wherever it is needed.
Timer
area
Operation
area
European
switch box
JIS box
Various timer setup available (ON/OFF/WEEKLY).●
Equipped with weekly timer as standard function.●
(Start/Stop function is twice per day for a week)
When setting up the timer, start/stop and temperature setup can●
be changed.
When a failure occurs, the error code is displayed.●
Error history. (Last 16 error codes can be accessed.)●
The room temperature can be controlled by detecting the●
temperature accurately with Built-in thermo sensor.

-
(
01 - 03
)
-
FUNCTIONS

Display panel
DIMENSION

SPECIFICATION

15
11
10
9
8
21
3
5
14
4
12
13
6
7
17
16 18
19 20
21
4-23/32 (120)
4-23/32 (120)
4-23/32 (120)
23/32 (18)
Side ViewFront View
SIZE [H × W × D]: in.(mm) 4-23/32 × 4-23/32 × 23/32
(120 × 120 × 18)
WEIGHT oz. (g) 5.6 (160)
CABLE LENGTH ft. (m) 33 (10)
POWER (V) 12
1START/STOP button
Pressed to start and stop operation.
2SET TEMP. button
Selects the setting temperature.
3MODE button
Selects the operating mode (AUTO, HEAT, FAN, COOL, DRY).
4FAN button
Selects the fan speed (AUTO, QUIET, LOW, MED, HIGH).
5ECONOMY (THERMO SENSOR) button
Turns the economy efficient mode on and off.
6TIMER MODE (CLOCK ADJUST) button
Selects the timer mode (OFF TIMER, ON TIMER, WEEKLY
TIMER). Sets the current time.
7DAY (DAY OFF) button
Temporarily cancels one day timer.
8SET BACK button
Pressed to select the set back timer.
9Set time button
Pressed to set time.
10 TIMER DELETE button
Deletes the weekly timer schedule.
11 TIMER SET button
Sets the date, hour, minute and on-off time.
12 Vertical airflow direction and swing button
Push for two seconds to change the swing mode.
13 Horizontal airflow direction and swing button
Push for two seconds to change the swing mode.
14 FILTER RESET button
15 Operation lamp
Lights during operation and when the timer is on.
16 Timer and clock indicator
17 Operation mode indicator
18 Fan speed indicator
19 Operation lock indicator
20 Temperature indicator
21 Function indicators
Defrost indicator
Thermo sensor indicator
Economy indicator
Vertical swing indicator
Horizontal swing indicator
Filter display
Functions will be different due to type of indoor unit.
For details, refer to the operation manual.
WIRING SPECIFICATIONS

Use Cable size Wire type Remarks
Remote controller cable 22AWG
(0.33 mm2)Polar 3 core Use sheathed PVC cable
[Unit: in. (mm)]

-
(
01 - 04
)
-
SPECIFICATIONS3.
NOTES:
Specifications are based on the following conditions:

•
Cooling: Indoor temperature of 80 °F (26.67 °C) DB / 67 °F (19.44 °C) WB and outdoor temperature of 95 °F (35 °C) DB / 75 °F (23.9 °C) WB
Heating: Indoor temperature of 70 °F (21.11 °C) DB / 59 °F (15 °C) WB and outdoor temperature of 47 °F (8.33 °C) DB / 43 °F (6.11 °C) WB
Standard static pressure: 0.10 in.WG (25 Pa)
Pipe length: 24 ft. 7 in. (7.5 m), Height difference: 0 m (Outdoor unit–Indoor unit)
The protective function might work when using it in environment out of the temperature range mentioned above.

•
*1: The maximum current is the maximum value when operated within the operation range.
*2: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
Type DUCT
INVERTER HEAT PUMP
Model name RIDH09AVFJ RIDH12AVFJ RIDH18AVFJ
Power source 208/230V ~ 60 Hz
Available boltage range 187–253 V
Capacity
Cooling
Rated kW 2.64 3.52 5.28
Btu/h 9,000 12,000 18,000
Min.–Max. kW 0.90–3.60 0.90–4.00 0.90–5.90
Bt u/ h 3,1 00 –12 ,0 0 0 3,1 00 –13 ,6 0 0 3 ,10 0 –2 0,10 0
Heating
Rated kW 3.52 4.69 6.33
Btu/h 12,000 16,000 21,600
Min.–Max. kW 0.90–5.28 0.90–5.70 0.90–7.50
Btu/h 3,100–18,000 3,100–19,400 3,100–25,600
Input power
Cooling Rated
kW
0.62 0.94 1.50
Max. 1.40 1.45 2.15
Heating Rated 0.85 1.30 1.67
Max. 1.80 2.00 2.60
Current Cooling Rated A 3.0 4.4 6.6
Heating 3.9 6.0 7.3
EER Cooling kW/kW 4.25 3.74 3.52
Btu/hW 14.5 12.8 12.0
COP Heating kW/kW 4.14 3.60 3.79
Btu/hW 14.1 12.3 12.9
SEER Cooling Btu/hW 21.5 20.0 19.7
HSPF Heating Btu/hW 12.2 11.5 11.3
Power factor Cooling %90 94 98
Heating 94 94 99
Moisture removal pints/h (l/h) 1.5 (0.7) 2.7 (1.3) 4.2 (2.0)
Maximum operating current *1 Cooling A9.3 9.4 10.0
Heating 10.8 10.9 14.0
Fan
Airflow rate
Cooling
High
CFM
(m3/h)
353 (600) 383 (650) 554 (940)
Med 324 (550) 353 (600) 518 (880)
Low 294 (500) 324 (550) 483 (820)
Quiet 265 (450) 283 (480) 442 (750)
Heating
High 353 (600) 383 (650) 554 (940)
Med 324 (550) 353 (600) 518 (880)
Low 294 (500) 324 (550) 483 (820)
Quiet 265 (450) 283 (480) 442 (750)
Type × Q'ty Sirocco fan × 2 Sirocco fan × 3
Motor Output W 81 96
Recommended static pressure in.WG (Pa) 0 to 0.36 (0 to 90)
Sound pressure level *2
Cooling
High
dB (A)
28 29 32
Med 27 28 30
Low 26 27 29
Quiet 25 26 27
Heating
High 28 29 32
Med 26 28 30
Low 25 27 29
Quiet 24 24 27
Heat exchanger
Dimension
(H × W × D) in. (mm) 11-9/16 × 19-11/16 × 1-9/16
(294 × 500 × 39.9)
11-9/16 × 27-9/16 × 1-9/16
(294 × 700 × 39.9)
Fin pitch FPI 20
Rows × Stages 3 × 14
Pipe type Copper tube
Fin type Aluminum
Enclosure Material GALVANIZED STEEL SHEET
Color -
Dimensions
(H × W × D)
Net
in. (mm)
7-25/32 × 27-9/16 × 24-13/32
(198 × 700 × 620)
7-25/32 × 35-7/16 × 24-13/32
(198 × 900 × 620)
Gross 10-7/8 × 38-1/8 × 30-13/32
(276 × 968 × 772)
10-7/8 × 46 × 30-13/32
(276 × 1168 × 772)
Weight Net lb. (kg) 41 (19) 50 (23)
Gross 58 (26) 59 (27)
Connection pipe Size Liquid in. (mm) Ø 1/4 (Ø6.35)
Gas Ø 3/8 (Ø 9.52) Ø 1/2 (Ø 12.7)
Method Flare
Operation range Cooling °F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 88 (16 to 30)
Remote controller type Wired [Wireless (option)]
Drain hose
Material HARD PVC
Size in. (mm) Ø 3/4 (Ø 20.7) (I.D.)
Ø 1-1/16 (Ø 26.6) (O.D.)

-
(
01 - 05
)
-
4.DIMENSIONS
MODELS: RIDH09AVFJ, RIDH12AVFJ
Unit : in. (mm)
Rear view View A
Top view Side view
Front view Bottom view
(Drain hose)
Drain port
2 (51)
22-19/32 (574)
6-27/32 (174)
2-25/32 (71)
6 (152)
3-15/16 (100) x 6 = 23-5/8 (600)
3-7/32 (82)
1-7/8 (48)
25-19/32 (650)
28-29/32 (734)
1-3/16 (30)
14-27/32 (377)
6-9/16 (167)
4-11/16 (119)
3-1/2 (89) 3-1/16 (78)
2-5/32 (55)
1-27/32 (47)
13/32 (10)
24-13/32 (620)
14-19/32 (371)
10-13/32 (264)
5-21/32 (144)
2-23/32 (69)
25-19/32 (650)
26-5/32 (664)
27-9/16 (700)
1-11/16 (43)
25/32 (20)
7-25/32 (198)
6-5/8 (168)
5-15/16 (151)
3-1/16 (78) 2-5/32 (55)
9, 12
Refrigerant pipe flare
connection
Liquid Ø 1/4 in. (Ø 6.35 mm)
Gas Ø 3/8 in. (Ø 9.52 mm)
Drain hose connection Drain hose I.D. Ø 3/4 in., O.D. Ø 1-1/16 in.

-
(
01 - 06
)
-
MODEL : RIDH18AVFJ
Rear view View A
Top view Side view
Front view
Bottom view
(Drain hose)
Drain port
2 (51)
30-15/32 (774)
6-27/32 (174)
2-25/32 (71)
6 (152)
3-7/16 (87)
2-7/32 (56)
33-15/32 (850)
36-25/32 (934)
3-15/16 (100) x 8 = 31-1/2 (800)
1-3/16 (30)
14-27/32 (377)
6-9/16 (167)
4-11/16 (119)
3-1/2 (89)
3-1/16 (78)
2-5/32 (55)
1-27/32 (47)
13/32 (10)
24-13/32 (620)
14-19/32 (371)
10-13/32 (264)
5-21/32 (144)
2-23/32 (69)
33-15/32 (850)
34-1/32 (864)
35-7/16 (900)
1-11/16 (43)
25/32
(20)
7-25/32 (198)
6-5/8 (168)
5-15/16 (151)
3-1/16 (78) 2-5/32 (55)
Unit : in. (mm)
18
Refrigerant pipe flare
connection
Liquid Ø 1/4 in. (Ø 6.35 mm)
Gas Ø 1/2 in. (Ø 12.70 mm)
Drain hose connection Drain hose I.D. Ø 3/4 in., O.D. Ø 1-1/16 in.

-
(
01 - 07
)
-
INSTALLATION PLACE

Left
side
Strong and durable ceiling
Indoor unit
Right
side
3-15/16 (100)
or more
11-13/16 (300)
or more Service access Ceiling
98-7/16 (2500) or more
(When no ceiling)
Floor
9-7/16 (240) or more
25/32 (20) or more
25/32 (20) or more
11-13/16 (300) or more
13/32 (10)
or less
13/32 (10)
or less
Left side
Strong and
durable floor
Right side
(PIPE side)
5-29/32
(150)
or more
3-15/16 (100)
or more
11-13/16 (300)
or more
Grille
Inlet air
Strong and
durable floor
25/32 (20)
or more
25/32 (20)
or more
5-29/32 (150)
or more
Left side
Strong and
durable floor
Right side
(PIPE side)
Duct
Grille
Inlet air
Strong and
durable floor
5-29/32
(150)
or more
3-15/16 (100)
or more
11-13/16 (300)
or more
25/32 (20)
or more
25/32 (20)
or more
5-29/32 (150)
or more
Unit : in. (mm)

-
(
01 - 08
)
-
MAINTENANCE SPACE

Provide a service access for inspection purposes as shown below.
Do not place any wiring or illumination in the service space, as they will impede service.
Service access
Unit
Control
box
Service space
11-13/16
(300)
or more
11-13/16
(300)
or more
3-15/16
(100)
or more
Unit : in. (mm)

-
(
01 - 09
)
-
5.WIRING DIAGRAMS
MODELS: RIDH09AVFJ, RIDH12AVFJ, RIDH18AVFJ

-
(
01 - 10
)
-
6.CAPACITYTABLE
6-1.COOLING CAPACITY
MODEL:RIDH09AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
SHC: Sensible Heat Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m3/h)
TC: Total Capacity (kW)
SHC: Sensible Heat Capacity (kW)
IP: Input Power (kW)
AFR 353
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 8.50 6.74 0.22 9.60 7.62 0.22 10.12 8.03 0.23 10.84 8.60 0.23 11.59 9.19 0.23 11.94 9.47 0.23
23 8.32 6.71 0.25 9.40 7.57 0.25 9.90 7.98 0.25 10.60 8.54 0.26 11.33 9.13 0.26 11.67 9.40 0.26
32 8.15 6.68 0.26 9.20 7.54 0.26 9.70 7.94 0.26 10.38 8.51 0.27 11.10 9.09 0.27 11.43 9.37 0.27
41 7.98 6.53 0.27 9.01 7.38 0.28 9.49 7.78 0.28 10.17 8.33 0.28 10.87 8.90 0.28 11.20 9.17 0.29
50 7.80 6.36 0.25 8.82 7.19 0.26 9.29 7.57 0.26 9.95 8.11 0.26 10.64 8.67 0.27 10.96 8.94 0.27
59 7.63 5.70 0.31 8.62 6.44 0.31 9.09 6.79 0.31 9.73 7.27 0.32 10.41 7.77 0.32 10.73 8.01 0.32
67 8.60 6.98 0.50 9.72 6.97 0.50 10.25 7.69 0.51 10.97 8.07 0.51 11.73 8.26 0.52 12.09 9.18 0.52
77 8.17 6.74 0.56 9.23 6.73 0.57 9.73 7.42 0.57 10.42 7.79 0.58 11.14 7.97 0.58 11.49 8.85 0.59
87 7.62 6 .47 0.60 8.61 6. 47 0. 61 9. 0 8 7.13 0.6 2 9.72 7. 49 0. 62 10 .39 7.6 6 0.6 3 10.72 8.51 0. 6 3
95 7.06 6.23 0.60 7. 97 6 . 22 0.61 8 .41 6.86 0. 61 9 .00 7. 2 0 0.6 2 9 .62 7.37 0.6 3 9.92 8.19 0 .63
104 5.93 5.76 0.50 6.70 5.75 0.51 7.07 6.35 0.52 7.57 6.66 0.52 8.09 6.81 0.53 8.34 7.57 0.53
115 5.45 5.38 0.51 6.16 5.38 0.52 6.50 5.93 0.52 6.96 6.22 0.53 7.44 6.37 0.53 7.67 7.08 0.53
AFR 600
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 2.49 1.98 0.22 2.81 2.23 0.22 2.97 2.35 0.23 3.18 2.52 0.23 3.40 2.69 0.23 3.50 2.78 0.23
-5.0 2.44 1.97 0.25 2.75 2.22 0.25 2.90 2.34 0.25 3.11 2.50 0.26 3.32 2.68 0.26 3.42 2.76 0.26
0.0 2.39 1.96 0.26 2.70 2.21 0.26 2.84 2.33 0.26 3.04 2.49 0.27 3.25 2.66 0.27 3.35 2.75 0.27
5.0 2.34 1.92 0.27 2.64 2.16 0.28 2.78 2.28 0.28 2.98 2.44 0.28 3.19 2.61 0.28 3.28 2.69 0.29
10.0 2.29 1.86 0.25 2.58 2.11 0.26 2.72 2.22 0.26 2.92 2.38 0.26 3.12 2.54 0.27 3.21 2.62 0.27
15.0 2.24 1.67 0.31 2.53 1.89 0.31 2.66 1.99 0.31 2.85 2.13 0.32 3.05 2.28 0.32 3.14 2.35 0.32
19.4 2.52 2.05 0.50 2.85 2.04 0.50 3.00 2.25 0.51 3.22 2.37 0.51 3.44 2.42 0.52 3.54 2.69 0.52
25.0 2.39 1.97 0.56 2.71 1.97 0.57 2.85 2.17 0.57 3.05 2.28 0.58 3.27 2.34 0.58 3.37 2.60 0.59
30.6 2.23 1.90 0.60 2.52 1.90 0.61 2.66 2.09 0.62 2.85 2.19 0.62 3.05 2.24 0.63 3.14 2.49 0.63
35.0 2.07 1.83 0.60 2.34 1.82 0.61 2.46 2.01 0.61 2.64 2.11 0.62 2.82 2.16 0.63 2.91 2.40 0.63
40.0 1.74 1.69 0.50 1.97 1.69 0.51 2.07 1.86 0.52 2.22 1.95 0.52 2.37 2.00 0.53 2.44 2.22 0.53
46.0 1.60 1.58 0.51 1.81 1.58 0.52 1.90 1.74 0.52 2.04 1.82 0.53 2.18 1.87 0.53 2.25 2.07 0.53

-
(
01 - 11
)
-
MODEL:RIDH12AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
SHC: Sensible Heat Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m3/h)
TC: Total Capacity (kW)
SHC: Sensible Heat Capacity (kW)
IP: Input Power (kW)
AFR 383
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 11.32 8.02 0.34 12.81 9.07 0.34 13.48 9.55 0.34 14.44 10.23 0.35 15.44 10.93 0.35 15.93 11.29 0.35
23 11.06 7.98 0.39 12.52 9.03 0.40 13.21 9.53 0.40 14.15 10.20 0.40 15.09 10.88 0.41 15.57 11.23 0.41
32 10.84 7.88 0.43 12.26 8.91 0.43 12.94 9.40 0.44 13.85 10.07 0.44 14.78 10.74 0.45 15.26 11.08 0.45
41 10.62 7.74 0.45 12.01 8.76 0.46 12.67 9.24 0.46 13.56 9.89 0.47 14.47 10.56 0.47 14.94 10.90 0.47
50 10.39 7.55 0.45 11.76 8.54 0.46 12.40 9.01 0.46 13.27 9.64 0.47 14.17 10.29 0.47 14.63 10.63 0.48
59 10.17 6.95 0.46 11.50 7.86 0.47 12.14 8.29 0.48 12.98 8.87 0.48 13.86 9.47 0.49 14.32 9.78 0.49
67 11.46 8.50 0.75 12.97 8.50 0.76 13.68 9.35 0.77 14.64 9.83 0.78 15.63 10.03 0.79 16.14 11.16 0.79
77 10.88 8.19 0.84 12.32 8.19 0.86 12.97 9.04 0.87 13.89 9.49 0.88 14.84 9.69 0.89 15.32 10.78 0.89
87 10.17 7.88 0.91 11.50 7.88 0.93 12.11 8.67 0.93 12.97 9.11 0.94 13.85 9.31 0.95 14.30 10.37 0.96
95 9.42 7.57 0.91 10.65 7.57 0.92 11.19 8.36 0.93 12.01 8.77 0.94 12.83 8.97 0.95 13.24 9.96 0.96
104 7.92 6.99 0.76 8.94 6.99 0.78 9.42 7.71 0.78 10.10 8.09 0.79 10.78 8.29 0.80 11.12 9.21 0.81
115 7.30 6.48 0.77 8.26 6.48 0.78 8.70 7.17 0.79 9.31 7.51 0.80 9.96 7.68 0.81 10.27 8.53 0.81
AFR 650
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 3.32 2.35 0.34 3.75 2.66 0.34 3.95 2.80 0.34 4.23 3.00 0.35 4.52 3.20 0.35 4.67 3.31 0.35
-5.0 3.24 2.34 0.39 3.67 2.65 0.40 3.87 2.79 0.40 4.15 2.99 0.40 4.42 3.19 0.41 4.56 3.29 0.41
0.0 3.18 2.31 0.43 3.59 2.61 0.43 3.79 2.76 0.44 4.06 2.95 0.44 4.33 3.15 0.45 4.47 3.25 0.45
5.0 3.11 2.27 0.45 3.52 2.57 0.46 3.71 2.71 0.46 3.98 2.90 0.47 4.24 3.09 0.47 4.38 3.19 0.47
10.0 3.05 2.21 0.45 3.45 2.50 0.46 3.64 2.64 0.46 3.89 2.83 0.47 4.15 3.02 0.47 4.29 3.12 0.48
15.0 2.98 2.04 0.46 3.37 2.30 0.47 3.56 2.43 0.48 3.81 2.60 0.48 4.06 2.77 0.49 4.20 2.87 0.49
19.4 3.36 2.49 0.75 3.80 2.49 0.76 4.01 2.74 0.77 4.29 2.88 0.78 4.58 2.94 0.79 4.73 3.27 0.79
25.0 3.19 2.40 0.84 3.61 2.40 0.86 3.80 2.65 0.87 4.07 2.78 0.88 4.35 2.84 0.89 4.49 3.16 0.89
30.6 2.98 2.31 0.91 3.37 2.31 0.93 3.55 2.54 0.93 3.80 2.67 0.94 4.06 2.73 0.95 4.19 3.04 0.96
35.0 2.76 2.22 0.91 3.12 2.22 0.92 3.28 2.45 0.93 3.52 2.57 0.94 3.76 2.63 0.95 3.88 2.92 0.96
40.0 2.32 2.05 0.76 2.62 2.05 0.78 2.76 2.26 0.78 2.96 2.37 0.79 3.16 2.43 0.80 3.26 2.70 0.81
46.0 2.14 1.90 0.77 2.42 1.90 0.78 2.55 2.10 0.79 2.73 2.20 0.80 2.92 2.25 0.81 3.01 2.50 0.81

-
(
01 - 12
)
-
MODEL:RIDH18AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
SHC: Sensible Heat Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m3/h)
TC: Total Capacity (kW)
SHC: Sensible Heat Capacity (kW)
IP: Input Power (kW)
AFR 554
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 15.68 11.22 0.52 17.74 12.69 0.53 18.70 13.37 0.53 20.01 14.31 0.54 21.40 15.30 0.54 22.07 15.78 0.55
23 15.44 11.04 0.56 17.45 12.48 0.57 18.42 13.17 0.58 19.70 14.09 0.58 21.03 15.04 0.59 21.72 15.53 0.59
32 15.12 10.81 0.58 17.09 12.22 0.59 18.04 12.90 0.59 19.30 13.80 0.60 20.60 14.73 0.60 21.27 15.21 0.61
41 14.80 10.58 0.58 16.73 11.96 0.59 17.65 12.62 0.60 18.89 13.51 0.61 20.17 14.42 0.61 20.82 14.88 0.62
50 14.48 10.36 0.60 16.37 11.71 0.61 17.27 12.35 0.61 18.48 13.21 0.62 19.74 14.12 0.63 20.36 14.56 0.63
59 14.16 10.13 0.63 16.01 11.45 0.64 16.89 12.08 0.65 18.07 12.92 0.66 19.31 13.81 0.66 19.91 14.24 0.67
67 15.97 12.21 0.96 18.05 12.18 0.98 19.04 13.44 0.99 20.37 14.13 1.00 21.77 14.43 1.01 22.45 16.04 1.02
77 15.08 11.70 1.09 17.06 11.70 1.11 17.98 12.90 1.12 19.24 13.55 1.14 20.57 13.85 1.15 21.22 15.39 1.15
87 14.16 11.19 1.23 16.00 11.19 1.25 16.89 12.35 1.26 18.08 12.93 1.28 19.31 13.24 1.29 19.93 14.74 1.30
95 14.13 11.23 1.45 15.93 11.19 1.47 16.82 12.35 1.48 18.02 12.97 1.50 19.24 13.27 1.52 19.82 14.74 1.53
104 10.30 9.35 1.03 11.67 9.35 1.05 12.28 10.30 1.06 13.17 10.82 1.07 14.06 11.05 1.08 14.50 12.28 1.08
115 9.55 8.63 1.03 10.82 8.63 1.05 11.40 9.52 1.06 12.21 10.00 1.07 13.03 10.20 1.08 13.44 11.36 1.09
AFR 940
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 4.60 3.29 0.52 5.20 3.72 0.53 5.48 3.92 0.53 5.87 4.19 0.54 6.27 4.48 0.54 6.47 4.63 0.55
-5.0 4.53 3.24 0.56 5.11 3.66 0.57 5.40 3.86 0.58 5.78 4.13 0.58 6.16 4.41 0.59 6.36 4.55 0.59
0.0 4.43 3.17 0.58 5.01 3.58 0.59 5.29 3.78 0.59 5.66 4.04 0.60 6.04 4.32 0.60 6.23 4.46 0.61
5.0 4.34 3.10 0.58 4.90 3.51 0.59 5.17 3.70 0.60 5.54 3.96 0.61 5.91 4.23 0.61 6.10 4.36 0.62
10.0 4.24 3.04 0.60 4.80 3.43 0.61 5.06 3.62 0.61 5.42 3.87 0.62 5.79 4.14 0.63 5.97 4.27 0.63
15.0 4.15 2.97 0.63 4.69 3.36 0.64 4.95 3.54 0.65 5.30 3.79 0.66 5.66 4.05 0.66 5.84 4.17 0.67
19.4 4.68 3.58 0.96 5.29 3.57 0.98 5.58 3.94 0.99 5.97 4.14 1.00 6.38 4.23 1.01 6.58 4.70 1.02
25.0 4.42 3.43 1.09 5.00 3.43 1.11 5.27 3.78 1.12 5.64 3.97 1.14 6.03 4.06 1.15 6.22 4.51 1.15
30.6 4.15 3.28 1.23 4.69 3.28 1.25 4.95 3.62 1.26 5.30 3.79 1.28 5.66 3.88 1.29 5.84 4.32 1.30
35.0 4.14 3.29 1.45 4.67 3.28 1.47 4.93 3.62 1.48 5.28 3.80 1.50 5.64 3.89 1.52 5.81 4.32 1.53
40.0 3.02 2.74 1.03 3.42 2.74 1.05 3.60 3.02 1.06 3.86 3.17 1.07 4.12 3.24 1.08 4.25 3.60 1.08
46.0 2.80 2.53 1.03 3.17 2.53 1.05 3.34 2.79 1.06 3.58 2.93 1.07 3.82 2.99 1.08 3.94 3.33 1.09

-
(
01 - 13
)
-
6-2.HEATING CAPACITY
MODEL:RIDH09AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m
3
/h)
TC: Total Capacity (kW)
IP: Input Power (kW)
MODEL:RIDH12AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m
3
/h)
TC: Total Capacity (kW)
IP: Input Power (kW)
AFR 353
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 14.7 1.84 14.3 1.88 14.0 1.92 13.3 1.99
5 3 16.1 1.79 15.7 1.83 15.4 1.87 14.6 1.94
14 12 16.8 1.73 16.4 1.76 16.0 1.80 15.2 1.87
23 19 17.3 1.67 16.9 1.70 16.5 1.74 15.7 1.81
32 28 17.4 1.61 17.0 1.64 16.6 1.68 15.7 1.74
41 37 17.4 1.67 17.0 1.71 16.6 1.74 15.8 1.81
47 43 18.9 1.73 18.5 1.76 18.0 1.80 17.1 1.87
50 47 20.9 1.75 20.4 1.79 19.9 1.83 18.9 1.90
59 50 21.6 1.76 21.1 1.80 20.6 1.84 19.6 1.91
AFR 600
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 4.31 1.84 4.20 1.88 4.10 1.92 3.90 1.99
-15.0 -16.1 4.73 1.79 4.61 1.83 4.50 1.87 4.28 1.94
-10.0 -11.1 4.91 1.73 4.80 1.76 4.68 1.80 4.45 1.87
-5.0 -7.2 5.08 1.67 4.96 1.70 4.84 1.74 4.59 1.81
0.0 -2.2 5.10 1.61 4.98 1.64 4.86 1.68 4.61 1.74
5.0 2.8 5.11 1.67 4.99 1.71 4.87 1.74 4.62 1.81
8.3 6.1 5.54 1.73 5.41 1.76 5.28 1.80 5.01 1.87
10.0 8.3 6.12 1.75 5.98 1.79 5.83 1.83 5.54 1.90
15.0 10.0 6.34 1.76 6.19 1.80 6.04 1.84 5.74 1.91
AFR 383
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 15.8 2.23 15.4 2.27 15.0 2.32 14.3 2.36
5 3 17.6 2.16 17.2 2.21 16.8 2.25 15.9 2.34
14 12 18.3 2.09 17.8 2.13 17.4 2.17 16.5 2.26
23 19 19.2 2.01 18.7 2.05 18.2 2.10 17.3 2.18
32 28 19.5 1.95 19.0 1.99 18.5 2.03 17.6 2.11
41 37 19.7 1.86 19.2 1.90 18.8 1.94 17.8 2.02
47 43 20.4 1.92 19.9 1.96 19.4 2.00 18.4 2.08
50 47 22.5 1.94 22.0 1.98 21.4 2.02 20.4 2.10
59 50 23.3 1.95 22.8 1.99 22.2 2.03 21.1 2.11
AFR 650
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 4.63 2.23 4.52 2.27 4.41 2.32 4.19 2.36
-15.0 -16.1 5.16 2.16 5.03 2.21 4.91 2.25 4.66 2.34
-10.0 -11.1 5.36 2.09 5.23 2.13 5.10 2.17 4.85 2.26
-5.0 -7.2 5.61 2.01 5.48 2.05 5.35 2.10 5.08 2.18
0.0 -2.2 5.70 1.95 5.57 1.99 5.43 2.03 5.16 2.11
5.0 2.8 5.78 1.86 5.64 1.90 5.50 1.94 5.23 2.02
8.3 6.1 5.99 1.92 5.84 1.96 5.70 2.00 5.42 2.08
10.0 8.3 6.60 1.94 6.44 1.98 6.28 2.02 5.97 2.10
15.0 10.0 6.84 1.95 6.67 1.99 6.51 2.03 6.19 2.11

-
(
01 - 14
)
-
MODEL:RIDH18AVFJ
AFR: Airflow Rate (CFM)
TC: Total Capacity (kBtu/h)
IP: Input Power (kW)
AFR: Airflow Rate (m
3
/h)
TC: Total Capacity (kW)
IP: Input Power (kW)
AFR 554
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 19.3 2.42 18.9 2.47 18.4 2.52 17.5 2.63
5 3 20.7 2.63 20.2 2.68 19.7 2.74 18.8 2.85
14 12 22.2 2.68 21.6 2.73 21.1 2.79 20.1 2.90
23 19 23.1 2.79 22.6 2.85 22.0 2.91 20.9 3.03
32 28 23.3 3.02 22.8 3.08 22.2 3.14 21.1 3.19
41 37 25.5 2.67 24.9 2.73 24.3 2.78 23.1 2.90
47 43 26.9 2.50 26.2 2.55 25.6 2.60 24.3 2.70
50 47 29.7 2.23 29.0 2.28 28.3 2.32 26.9 2.42
59 50 30.8 2.24 30.1 2.29 29.3 2.34 27.9 2.43
AFR 940
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 5.67 2.42 5.53 2.47 5.40 2.52 5.13 2.63
-15.0 -16.1 6.08 2.63 5.93 2.68 5.79 2.74 5.50 2.85
-10.0 -11.1 6.50 2.68 6.34 2.73 6.19 2.79 5.88 2.90
-5.0 -7.2 6.78 2.79 6.62 2.85 6.45 2.91 6.13 3.03
0.0 -2.2 6.84 3.02 6.68 3.08 6.51 3.14 6.19 3.19
5 .0 2 .8 7. 4 7 2 .6 7 7. 2 9 2 .7 3 7.12 2 .7 8 6 .7 6 2. 9 0
8.3 6.1 7. 8 8 2 .50 7.6 9 2 . 5 5 7.50 2. 6 0 7.13 2 .7 0
10.0 8.3 8.71 2.23 8.50 2.28 8.29 2.32 7.88 2.42
15.0 10.0 9.02 2.24 8.81 2.29 8.59 2.34 8.16 2.43

-
(
01 - 15
)
-
7. FANPERFORMANCE
7-1. FAN PERFORMANCE CURVE
MODEL: RIDH09AVFJ
SP mode09
upper limit
Normal SP
upper limit
SP mode00
upper limit
SP mode09
lower limit
HI (SP mode09)
HI (Normal SP)
HI (SP mode00)
QUIET
(Normal SP)
QUIET (SP mode00)
QUIET (SP mode09)
0.24 (60)
0.40 (100)
0.20 (50)
0.36 (90)
0.16 (40)
0.32 (80)
0.08 (20)
0.04 (10)
0.12 (30)
0.28 (70)
0 (0)
0.44 (110)
External Static Pressure [in.WG (Pa)]
(700)(600)
(300) (400) (500) (800)
412353
177 235 294 471
Airflow [CFM (m3/h)]
HI (Normal SP)
Available airflow rate range (High level)
HI (SP mode03)
HI (SP mode04)
HI (SP mode00)
HI (SP mode05)
HI (SP mode01)
HI (SP mode06)
HI (SP mode02)
HI (SP mode07)
HI (SP mode08)
HI (SP mode09)
(700)(600)
(300) (400) (500) (800)
412353
177 235 294 471
Airflow [CFM (m3/h)]
0.24 (60)
0.40 (100)
0.20 (50)
0.36 (90)
0.16 (40)
0.32 (80)
0.08 (20)
0.04 (10)
0.12 (30)
0.28 (70)
0 (0)
0.44 (110)
External Static Pressure [in.WG (Pa)]

-
(
01 - 16
)
-
Cooling

(700)
412
(600)
353
(400)
235
(500)
294
(800)
471
Airflow [CFM (m3/h)]
100
120
80
60
40
20
0
Capacity (%)
Capacity
Heating

100
120
80
60
40
20
0
Capacity (%)
Capacity
(700)
412
(600)
353
(500)
294
(800)
471
Airflow [CFM (m3/h)]
(400)
235

-
(
01 - 17
)
-
MODEL : RIDH12AVFJ
SP mode09
upper limit
Normal SP
upper limit
SP mode00
upper limit
SP mode09
lower limit
HI (SP mode09)
HI (Normal SP)
HI (SP mode00)
QUIET
(Normal SP)
QUIET (SP mode00)
QUIET (SP mode09)
(700)(600)
(300) (400) (500) (800)
412353
177 235 294 471
Airflow [CFM (m3/h)]
0.24 (60)
0.40 (100)
0.20 (50)
0.36 (90)
0.16 (40)
0.32 (80)
0.08 (20)
0.04 (10)
0.12 (30)
0.28 (70)
0 (0)
0.44 (110)
External Static Pressure [in.WG (Pa)]
HI (Normal SP)
Available airflow rate range (High level)
HI (SP mode03)
HI (SP mode04)
HI (SP mode00)
HI (SP mode05)
HI (SP mode01)
HI (SP mode06)
HI (SP mode02)
HI (SP mode07)
HI (SP mode08)
HI (SP mode09)
(700)(600)
(300) (400) (500) (800)
412353
177 235 294 471
Airflow [CFM (m3/h)]
0.24 (60)
0.40 (100)
0.20 (50)
0.36 (90)
0.16 (40)
0.32 (80)
0.08 (20)
0.04 (10)
0.12 (30)
0.28 (70)
0 (0)
0.44 (110)
External Static Pressure [in.WG (Pa)]
