Rhino-Rack RLRM User manual

Page 1 of 14
RLRM Rubber Ladder Mount
Important: Please read these instructions carefully prior to installation.
Please refer to your fitting instruction to ensure that the Roof Rack System is installed in the
correct location.
Check the contents of kit before commencing fitment and report any discrepancies.
Place these instructions in the vehicle’s glove box after installation is complete.
1. Check Part No./Kit is correct
3. Fit roof rack accessory 2. Read through instruction before installing
4. Check and recheck all fasteners are secure
Parts List:
Item Components Qty Part No.
1 M8 x 25mm Hex Bolt 4 B101
2 M8 x 35 Hex Bolt 2 B102
3 M8 Spring Washer 2 W019
4 M8 x 17mm Flat Washer 6 W020
5 M8 Channel Nut 2 N003
6 M8 Nyloc Nut 4 N028
7 Flexible Crossbar Mount Top Plate 2 CA1583
8 Multi-slide Flexible Crossbar Mount 2 M826
9 Flexible Crossbar Mount Bottom Plate 2 CA1582
10 Flexible Crossbar Mount Oval Plate 4 CA1581
11 Instructions 1 R1083
Tools Required:
1. 13mm Socket Wrench.
1.
Note:
For use with the Rhino Multi-slide & CSL Kits. Kits are sold as separate.
2.
3.
4.
Instructions
5. 6.
8. 7.
10.
9.
10.
1Assemble the Rubber Mounts as shown. Finger tighten
only at this stage.
2.
3.
4.
1.
1.
8. 10.
9. 6.
5.
4.
10.
6.
4.
7.
2Slide the Rubber Mount
Assembly into either side of
the front of the side of the
Slide Ladder Rack. Do not
tighten in place at this stage.
Side View: The M8 x
25mm Hex Bolts will slide
into the Slide Ladder Rack
Extrusion as shown.
M8 x 25mm Hex
Bolt.
Side View: The M8 x
25mm Hex Bolts will slide
into the CSL Ladder Rack
Extrusion as shown.
CONTROLLED
Page 2 of 2
RLRM Rubber Ladder Mount
3Place the Ladder Rack onto the Roof Racks. Use the Locking Tabs to secure the rear and middle of the Rack to the Cross-
bars as per the Slide Ladder Rack instructions. Install the front of the Rack to the vehicles front Crossbar as shown below.
Place the installed Rubber Mounts into the
front Crossbar. Angle the Channel Nut so that
it will sit inside the Crossbar.
Side View: The Ladder Rack
must sit on the Rubber Strip
in the Crossbar.
Rubber Strip
must be
installed to
sit under the
Ladder Rack
at the front of
the vehicle.
Rubber Strip. Crossbar.
Slide Ladder Rack. Rubber
Mount.
Note:
Locking
Tabs are
not used
on the
inside of
the front
Crossbar.
Fix the Ladder Rack to the rear and middle
Crossbar as per Slide Ladder Rack
instructions.
4Be sure the Channel Nut is located correctly across the
Crossbar. Tighten with a 13mm Socket Wrench.
5Tighten the Rubber Mount to the Slide Ladder with a
13mm Socket Wrench. Be sure all fixtures on the Rack
System are secure before use.
Rhino-Rack
3 Pike Street, Rydalmere, Document No: R1083 Fit Time: 15min
NSW 2116, Australia. Prepared By: Kayle Everett Issue No: 01
(Ph) (02) 9638 4744 Authorised By: Chris Murty Issue Date: 19/07/16
(Fax) (02) 9638 4822
These instructions remain the property of Rhino-Rack Australia Pty. Ltd. and may not be used or changed for any other purpose than intended.
