Rice Lake 880 Performance Series User manual

880 Performance ™ Series
Controller/Indicator
Version 4.01
Operation Manual
PN 152240 Rev DMarch 10, 2021

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or registered
trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product updates
can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction ................................................................................ 1
1.1 FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.1 Weigh Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.2 Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.3 User Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Front Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Menu Structures and Parameter Descriptions. . . . . . . . . . . . . . . . . . . . . . 7
1.6.1 Navigating Through Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.2 Edit Parameter Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.3 Alphanumeric Entry Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.4 Numeric Values Editing Procedure (880 Plus Only). . . . . . . . . . . . . . . 8
1.7 Indicator Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.1 Toggle Gross/Net Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.2 Toggle Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.3 Zero Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.4 Acquire Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.5 Remove Stored Tare Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7.6 Preset Tare (Keyed Tare). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.7 Print Ticket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.8 Front Panel User Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.9 Displaying Audit Trail Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7.10 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7.11 Display or Edit Setpoint Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.7.12 Turn Setpoint On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.7.13 Set Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.7.14 Display Accumulator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.7.15 Clear the Accumulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.7.16 Display Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.0 Configuration............................................................................ 15
2.1 Configuration Methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.1 Revolution Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.2 EDP Command Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.3 Front Panel Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2 Menu Structures and Parameter Descriptions. . . . . . . . . . . . . . . . . . . . . 18
2.2.1 Audit Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2.2 Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

880 Performance Series Controller/Indicator
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars.
2.2.3 Scale Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.2.4 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.2.5 Calibration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.2.6 Feature Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.2.7 Region Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.2.8 Ports Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.2.9 COM and USBCOM Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.2.10 Ethernet Communications Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.2.11 USB Host and Fieldbus Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.2.12 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.2.13 Setpoint Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.2.14 Digital Input/Output Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.2.15 Analog Output Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.2.16 Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.0 Troubleshooting ....................................................................... 31
3.1 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.0 Compliance ............................................................................... 32
5.0 Specifications ........................................................................... 33

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
This manual is intended for operators who use the 880 digital weight indicators.
This 880 Performance Series Operation Manual (PN 152240) is included with the indicator and
provides basic operating instructions for users of the 880, please leave it with the indicator
when installation and configuration are complete.
Information contained within this manual is exclusively for units with CPU
board, PN 175109 (blue in color).
The 880 Performance Series Technical Manual (PN 158387) is referred to in this manual is
available online.
Manuals and additional resources are available on the Rice Lake Weighing Systems
website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 FCC Compliance
United States
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la Class A prescites dans le Règlement sur le
brouillage radioélectrique edicté par le ministère des Communications du Canada.
IMPORTANT

880 Performance Series Controller/Indicator
2 Visit our website www.RiceLake.com
1.2 Safety
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in
death or serious injury. Includes hazards that are exposed when guards are
removed.
Indicates a potentially hazardous situation that, if not avoided could result in
serious injury or death. Includes hazards that are exposed when guards are
removed.
Indicates a potentially hazardous situation that, if not avoided, could result in
minor or moderate injury.
Indicates information about procedures that, if not observed, could result in
damage to equipment or corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and
all instructions are understood. Contact any Rice Lake Weighing Systems
dealer for replacement manuals.
Failure to heed may result in serious injury or death.
Some procedures described in this manual require work inside the indicator enclosure.
These procedures are to be performed by qualified service personnel only.
Do not open the indicator, all procedures that require work inside the indicator enclosure are to be
performed by qualified service personnel only.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without the enclosure completely assembled.
Do not use for purposes other than weight taking.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not exceed the rated specification of the unit.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not submerge.
Before opening the unit, ensure the power cord is disconnected from the outlet.
Properly seal cord grips to prevent moisture damage inside of the enclosure.
Cable plugs must be installed in unused cord grips. Cord grip dome nuts,
around a cable or a plug, must be torqued to 22 in-lb. The cord grip nut
against the enclosure must be torqued to 33 in-lb.
DANGER
WARNING
CAUTION
IMPORTANT
WARNING
IMPORTANT

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 3
1.3 Overview
The 880 is a programmable single-channel digital weight indicator, available in a panel mount
or universal enclosure.
The front panel can be sealed to a NEMA Type 4X/IP69K rating. The front panel consists of a
six-button keypad and a six-digit,
14-segment LED display. The Universal front panel includes a numeric key pad.
Features include:
• LED display, 0.56'' (14 mm), six-digit, 14-segment
• RS-232 or RS-485 serial port
• USB device port connects directly to a PC
• Ethernet TCP/IP polled or continuous - supporting both a server and client connection
• AC or DC models
• Built-in DIN-rail clips on controller box (panel mount)
• Display and controller can be separated up to 250' (panel mount)
• Expansion slot for one option card
• Operator functions through menu key for audit trail, preset tare, accumulator, time & date,
Ethernet MAC ID and setpoints
• Audit trail tracking for configuration and calibration changes; password protection for user
and configuration changes
• 20 setpoints with latched batch engine or unlatched outputs
• Four onboard digital I/O channels
• Programmable ticket formats up to 1,000 characters for header text, gross, net,
accumulator and setpoints
• Local/remote operation
• Multi-range or multi-interval weighing
• Filter settings for light, medium and heavy noise
Options/Accessories:
• Metrological hardware sealing kit
• Adapter plate for converting 310 A and 520 panel mounts
• Panel mount kit for universal enclosure
Network Cards:
• 179158 Indicator Option, EtherCat Model 880 Indicator
• 179159 Indicator Option, Ethernet/IP Model 880 Indicator
• 179160 Indicator Option, Profinet Model 880 Indicator
• 179161 Indicator Option, Modbus TCP Model 880 Indicator
• 179162 Indicator Option, Devicenet Model 880 Indicator
• 179163 Indicator Option, Profibus Model 880 Indicator

880 Performance Series Controller/Indicator
4 Visit our website www.RiceLake.com
1.4 Operating Modes
The three modes of operation for the 880 are described in the following sections.
1.4.1 Weigh Mode
In this mode, the indicator displays gross or net weights to indicate the type of weight value
displayed and annunciators to indicate scale status.
1.4.2 Configuration Mode
Most of the procedures described in this manual, including configuration and calibration,
require the indicator to be in Configuration mode.
To enter Configuration mode, remove the fillister head screw from the enclosure backplate.
Insert a non-conductive tool into the access hole and press the setup switch once.
SCALE displays.
Breaking the seal to enter Configuration mode voids a Legal for Trade unit.
1.4.3 User Setup Mode
User Setup mode (accessed by pressing MENU) is used to:
• View the audit trail
• Set the time and date
• View or clear the accumulator value
• Change setpoint values
• View the current tare value
• Enter Setup mode (if audit trail is enabled)
See 880 Performance Series Technical Manual (PN 158387) for more information.
IMPORTANT

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 5
1.5 Front Panel Display
The front panel consists of a six-button keypad and a six-digit, 14-segment LED display.
The Universal front panel includes a numeric key pad.
The numeric display consists of six, 14-segment LED digits. If a negative number is displayed,
the first LED is used to display -, reducing the number of available digits to five.
The symbols on the keys in Figure 1-1 (representing up, down, enter, left, right) describe the
key functions assigned in Setup mode. The keys are used to navigate through menus, select
digits within numeric values, and increment/decrement values.
Figure 1-1. 880 Front Panel Display (Universal Model)
MENU
TARE
UNITS
ZERO
PRINT
GROSS
NET
B/N
Gross
Brutto
Net
lb
kg
T
PT
R1 R2 R3
10 1
2
3
4
5
6
7
8
9
11
12
13 15
16
14

880 Performance Series Controller/Indicator
6 Visit our website www.RiceLake.com
Item No. Function
1 Sets the current gross weight to zero; Used to navigate to other menus or to select another
digit when editing a value
2 Sends an on-demand print format to a communications port, provided the conditions for
standstill are met; If enabled in configuration, Print may display while the unit is printing;
Used to navigate to other menus or select another digit when editing a value
3 Performs several predetermined tare functions dependent on the mode of operation selected
in the TAREFN; Acts as enter for numeric or parameter entry
4 Toggles displayed weight between Gross and Net mode; If a tare value has been entered or
acquired, the net value is the gross weight minus the tare; Gross mode is indicated by the
Gross/Brutto annunciator; Net mode is indicated by the Net annunciator; Used to navigate
to different menus or to select another digit when editing a value
5 Allows access to the user setup menu; Also acts as the cancel key when editing parameter
values, or Exit key when in the configuration or user setup menus
6 Switches the weight display to an alternate unit, defined in the format menu
(Section 2.2.4 on page 20); Units available: lb, kg, oz, metric ton, ton, gram; Used to navigate
to different menus or to select another digit when editing a value
7 Clears a numeric entry from the LCD (not available with the panel mount)
8 Inserts a decimal point where necessary (not available with the panel mount)
9 The numeric keypad can be used to enter values; Values may also be entered by scrolling
through values with the arrow keys (not available with the panel mount)
10 Indicates the current range when configured for multi-range or multi-interval; R1, R2, R3
11 Scale is at standstill or within the specified motion band; Some operations, including
Zero, Tare and Printing, can only be completed LED is lit
12 Indicates current gross weight reading is within ±0.25 display divisions of the acquired zero,
or is within the center of zero band; A display division is the resolution of the displayed weight
value, or the smallest incremental increase or decrease which can be displayed or printed
13 Gross Weight mode (or Brutto in OIML mode);
Net Weight mode
14 Indicator display area
15 lb/kg LED – lb and kg annunciators indicate units associated with the displayed value;
If the displayed value is pounds, lb lights; If displayed value is kilograms, kg lights;
Primary or secondary – If the other units value is neither lb or kg then lb lights for the units
assigned as primary, and kg lights for the units assigned as secondary;
lb/tn, t, oz, g, or none – Alternate conversions which can be displayed include short tons (tn),
metric tons (t), ounces (oz), grams (g), or NONE (no units); If the displayed units is one of
these alternate conversions, and the other unit value is lb then kg lights;
tn, t, oz, g, or none – Alternate conversions which can be displayed include short tons (tn),
metric tons (t), ounces (oz), grams (g), or NONE (no units); If the displayed units is one of
these alternate conversions, and the other unit value is kg then lb lights
16 T LED – Indicates a tare has been acquired and stored by the system;
PT LED – Indicates a preset tare weight has been keyed in or entered via the EDP
serial port
Table 1-1. Key Functions

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 7
1.6 Menu Structures and Parameter Descriptions
The front panel keys are used to navigate through the menus in Setup mode (Figure 1-2).
• and move left and right (horizontally) in a menu level
• and move up and down (vertically) to different menu levels
• serves as an enter key for selecting parameter values within the menus
1.6.1 Navigating Through Levels
Figure 1-2. Setup Mode Menu Navigation
To select a parameter, press or to scroll left or right until the desired
menu group displays then press to move down to the sub-menu or parameter to be
edited. When moving through the menu parameters, the current selected value displays.
1.6.2 Edit Parameter Values
To change a parameter value, scroll left or right to view the values for a parameter.
When the desired value displays, press to select the value and move back up one
level. To edit numerical values, use the navigation keys to select the digit and to increment or
decrement the value. Alternatively, use the numeric keypad to enter the digits. The decimal
point begins flashing if a decimal value is allowed. Use the navigation keys to move the
decimal point left or right. Press when done.
See the 880 Performance Series Technical Manual (PN 158387) for more information.
UNITS
PRINT
ZERO
GROSS
NET
B/N
TARE
Level 1
Parameter
Default value
Level 2
Parameter
Value Value Value
Level 1
Parameter
Level 2
Parameter
When moving through values below the first menu level, press to return to the level
above. Press or to move to the next parameter on that level.
UNITS
PRINT
GROSS
NET
B/N
TARE
TARE

880 Performance Series Controller/Indicator
8 Visit our website www.RiceLake.com
1.6.3 Alphanumeric Entry Procedure
Use the following scheme for alphanumeric entry when using the five-button keypad.
Figure 1-3. Editing Procedure for Numeric Values
1.6.4 Numeric Values Editing Procedure (880 Plus Only)
When using the numeric keypad option, the method for editing numeric values relies on the
numbers which are embossed on the keypad (as opposed to using the arrows).
Figure 1-4. Numeric Keypad
1. Using the numeric keypad, insert the required value.
• Press to clear the currently selected digit
• Press to enter a decimal point
2. Press to save the value entered and return to the level above.
When editing fractional numeric values, the decimal point must be positioned in
accordance with the primary units formatting, otherwise the keyed number may be
rejected by the software.
Display first 6
characters of format
Display and edit
active character and
ASCII value
Delete active
character
Scroll right in format string.
Scroll left in format string.
Increment ASCII value of active character
Decrement ASCII value
of active character.
Press to insert a space
before the active character.
Press to accept the changes
and return to the level above.
Level 2
Parameter
Level 1
Parameter
Level 2
Parameter
Level 1
Parameter
Press to accept the changes
and return to the level above.
TARE
Note

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 9
1.7 Indicator Operations
Basic 880 operations are summarized below.
1.7.1 Toggle Gross/Net Mode
1. Press to toggle the display mode between gross and net.
Net mode is available when a tare value has been entered or acquired (Net = Gross
minus Tare). If tare has not been entered or acquired, the display remains in Gross
mode. The LEDs next to Gross or Net indicate the current mode.
1.7.2 Toggle Units
Press to switch between primary and secondary units. The current units LED lights.
1.7.3 Zero Scale
1. In Gross mode, remove all weight from the scale and wait for the LED to light.
2. Press . The LED lights to indicate the scale is zeroed.
The scale must be stable and within the configured zero range for the scale to be
zeroed. If the scale cannot be zeroed, Nozero displays.
1.7.4 Acquire Tare
1. Place a container on the scale and wait for the LED to light.
2. Press to acquire the tare weight of the container. The Net weight displays and
the T LED lights to display the tare value was entered.
1.7.5 Remove Stored Tare Value
1. Remove all weight from the scale and wait for the LED to light. The display
should read zero and the LED should be lit.
2. Press to zero the scale if needed.
3. Press (or in OIML mode). Display shifts to gross weight and the
Gross LED is lit.
If keyed tares are allowed, press to open the keyed tare prompt.
To clear the tare, press again.
GROSS
NET
B/N
Note
UNITS
ZERO
0
Note
TARE
0
ZERO
TARE
ZERO
Note
TARE
TARE

880 Performance Series Controller/Indicator
10 Visit our website www.RiceLake.com
1.7.6 Preset Tare (Keyed Tare)
Tare mode must be set to keyed or both for the preset tare feature to function.
1. With the scale empty and zero weight on the display, press . 000000 displays
with the focused digit flashing.
2. Edit the value using the keypad on the 880Plus or use the following method for the panel
mount.
• Press or to select the digit
• Press or to increment or decrement the value
• Press to move to the decimal point entry
• Press or to adjust the decimal point placement
• Press when the value is correct
The display changes to the Net mode and the PT LED lights to display the preset tare was
entered.
Entering a keyed tare of zero removes the stored tare value.
1.7.7 Print Ticket
1. Wait for the LED to light.
2. Press to send data to the configured communications port.
1.7.8 Front Panel User Setup
Press to enter User Setup mode. Use User Setup to:
• View audit trail information
• Enter Configuration mode if audit trail is enabled
• View or set time and date
• View or clear the accumulator
• Change setpoint values and enable/disable setpoints
• View the current tare value
Note
TARE
TARE
TARE
Note
PRINT
MENU

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 11
1.7.9 Displaying Audit Trail Information
The Audit Trail Configuration and Calibration counters can be viewed through the User Menu.
1. Press . Audit displays.
2. Press to display the Legally Relevant Firmware version.
3. Press to display Calib.
4. Press to view the Calibration Counter.
5. Press to return to Calib.
6. Press to display CFG.
7. Press to view the Configuration Counter.
8. Press to return to CFG.
9. Press to return to the Weigh mode.
1.7.10 Setpoints
Setpoints must be enabled in the Configuration mode to be accessible in the User Setup mode.
Breaking the seal to enter the Configuration mode voids a Legal for Trade unit.
To enter the Configuration mode:
1. Remove the large fillister head screw from the back of the enclosure.
2. Insert a non-conductive tool into the access hole and press the setup switch.
Scale displays.
3. Press or until Setpts displays.
4. Press . SP CFG displays.
5. Press . Press or to desired setpoint number.
6. Press to enter setpoint settings.
7. Select the type by pressing or to desired setting then press to set the value.
For complete list of settings see the 880 Performance Series Technical Manual
(PN 158387) for more information.
8. When all settings have been made, press to return to Weigh mode.
Setpoints are now accessible from the front panel menu.
MENU
MENU
MENU
MENU
IMPORTANT
MENU
Note

880 Performance Series Controller/Indicator
12 Visit our website www.RiceLake.com
1.7.11 Display or Edit Setpoint Value
1. Press . Audit displays.
2. Press or until Setpts displays.
3. Press and the first available setpoint number displays.
4. Press or to toggle through each setpoint which is operator accessible.
5. Press . Value displays.
6. Press again to display or edit the value.
7. Edit the value using the keypad on the 880Plus or use the following method for the panel
mount.
• Press or to increment or decrement the value of the flashing digit
• Press or to select the digit to edit
• Press to move to the decimal point entry
• Press or to adjust the decimal point placement
8. Press to accept the displayed value.
9. Repeat the above steps to set Preact, if enabled.
10.When all settings have been made, press to return to Weigh mode.
Setpoint Value and Preact Value may be accessible from front panel in Weigh mode.
Some indicator configurations may not allow setpoint values to be changed through
the front panel or may require a password to display or change the setpoint value.
1.7.12 Turn Setpoint On or Off
Turn a setpoint off at the front panel.
1. Press . Audit displays.
2. Press or until Setpts displays.
3. Press and the first available setpoint number displays.
4. Press or to toggle through each setpoint which is operator accessible.
5. Press then press or to Enable.
6. Press then press or to turn setpoint On/Off.
7. Press to accept the setting.
8. Press to return to Weigh mode.
Some indicator configurations may not allow setpoints to be turned off through the
front panel or may require a password to turn the setpoint on and off.
MENU
TARE
TARE
MENU
Note
MENU
TARE
MENU
Note

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 13
1.7.13 Set Time and Date
1. Press . Audit displays.
2. Press or until T&D displays.
3. Press . Time displays.
4. Press to enter time.
5. Edit the value using the keypad on the 880Plus or use the following method for the panel
mount.
• Press or to select the digit
• Press or to increment or decrement the value
6. Press when the value is correct. Date displays.
7. Press to enter date.
8. Edit the value in the specified format MMDDYY, DDMMYY, or YYMMDD.
• Press or to select the digit
• Press or to increment or decrement the value
9. Press when the value is correct. Time displays.
10.Press to return to Weigh mode.
1.7.14 Display Accumulator
Enable the accumulator before use in either Weigh mode or setpoint operations.
Once enabled, weight (net weight if a tare is in the system) is accumulated whenever a print
operation is performed using the Print key, digital input, setpoint PSHACC operation or
KPRINT serial command. The scale must return to below the threshold value (except for the
setpoint PSHACC operation) before the next accumulation.
1. Press to enter the User Setup mode, Audit displays.
2. Press or until Accum displays.
Accum is only displayed if the accumulator is enabled. See the 880 Performance
Series Technical Manual (PN 158387) for more information.
3. Press . View displays.
4. Press to view the current accumulator value.
5. While the accumulator value is displayed, press to print the value.
The format of the print output can be configured using the accumulator print
format. See the 880 Performance Series Technical Manual (PN 158387) for more
information.
MENU
TARE
TARE
MENU
MENU
Note
PRINT
Note

880 Performance Series Controller/Indicator
14 Visit our website www.RiceLake.com
1.7.15 Clear the Accumulator
1. Press to enter the User Setup mode. Audit displays.
2. Press or until Accum displays.
3. Press then press or until CLR Y displays.
4. Press to clear the accumulator. Clear displays briefly and returns to CLR Y.
5. Press to return to the Weigh mode.
The Print key only performs one accumulation, and only if the weight is above the
accumulator threshold. Weight must return to below the accumulator threshold
value before another accumulation is allowed.
Accumulator threshold is configured in the setup menu. See the 880 Performance
Series Technical Manual (PN 158387) for more information.
1.7.16 Display Tare
When a stored Tare value displays, the Gross and Net LEDs turn off then lights.
To display a stored tare:
1. Press .
2. Press to Tare then press to view the current tare value.
3. Press twice to return to Weigh mode.
If there is no tare in the system, the value displayed is zero and the Gross and Net LED turn off.
See the 880 Performance Series Technical Manual (PN 158387) for more information.
MENU
TARE
MENU
Note
0
MENU
MENU

Configuration
© Rice Lake Weighing Systems ● All Rights Reserved 15
2.0 Configuration
To configure the 880 indicator, the indicator must be placed in Configuration mode.
The setup switch is accessed through a small hole on the enclosure (Figure 2-1).
The setup switch access hole is located on the backplate for the panel mount, and from the
bottom of the enclosure on the universal model. Insert a non-conductive tool into the access
hole and press the setup switch.
Use caution when inserting the non-conductive tool into the backplate, press
the tool in about 3/4'', using the board as a guide, until the switch is engaged.
Do not use excessive force that may damage the switch.
If audit trail is enabled, press to access Setup mode. Press or until
SETUP displays then press to Scale. See the 880 Performance Series Technical
Manual (PN 158387) for more information.
Figure 2-1. Back View – Setup Switch Access
Setup switch access for the 880 Universal Mount is located at the bottom of the
enclosure next to the cord grips.
When the indicator is placed in Configuration mode, SCALE displays. The SCALE menu is
the first of eight top-level menus used for configuring the indicator. Detailed descriptions of
these menus are given in the 880 Performance Series Technical Manual (PN 158387).
When configuration is complete, return to the SCALE menu and press the (ZERO) key to
exit Setup mode.
When configuration is complete, press to return to the Weigh mode.
IMPORTANT
Note
MENU
J1 J2 J3 J4 J5 J6
Setup Switch Access
(880 Panel Mount)
Note
MENU

880 Performance Series Controller/Indicator
16 Visit our website www.RiceLake.com
2.1 Configuration Methods
The 880 indicator can be configured by using the front panel keys to navigate through a series
of configuration menus or by sending commands or configuration data to the EDP port.
Configuration using the menus is described in the 880 Performance Series Technical Manual
(PN 158387).
Configuration using the EDP port can be accomplished using either the EDP command set
described in the 880 Performance Series Technical Manual (PN 158387) or Version 3.0 or later
of the Revolution® configuration utility.
2.1.1 Revolution Configuration
The Revolution configuration utility provides the preferred method for configuring the 880
indicator. When Revolution configuration is complete, configuration data is downloaded to the
indicator.
See the 880 Performance Series Technical Manual (PN 158387) for more information.
2.1.2 EDP Command Configuration
The EDP command set can be used to configure the 880 indicator using either a computer or
terminal. Like Revolution, EDP command configuration sends commands to the indicator EDP
port; unlike Revolution, EDP commands can be sent using an external device capable of
sending ASCII characters over a serial connection.
EDP commands duplicate the functions available using the indicator front panel and provide
some functions not otherwise available. EDP commands can be used to simulate pressing
front panel keys, to configure the indicator, or to dump lists of parameter settings. See the 880
Performance Series Technical Manual (PN 158387) for more information about using the EDP
command set.
Note
