Rice Lake iDimension Plus Manual instruction

iDimension® Plus
Static Dimensioning System
Setup and Operation Manual
PN 195439November 4, 2019

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.0 Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Access Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.1 Time Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1.2 Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1.3 Zero Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.4 Scan Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.5 Certified Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Next Steps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.0 Touchscreen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Touch Screen Display Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.1 Live Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.2 Out of Bounds Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.3 Shape Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.4 Status Indication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.5 Help Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.6 Zero Height Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.0 Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Access Configuration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.1 Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.2 View EULA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.3 Data Extract . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.4 Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.5 Enable Flats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.6 Upgrade Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1.7 IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2 Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2.1 Device Information Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2.2 Weights and Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.0 Use and Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Measurement Capabilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1.1 Flats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.2 Object Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.0 Performing A Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1 Automatic Package Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.2 Network Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.1 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.3 Admin Tools Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.3.1 Edit/Cancel/Save Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

iDimension Plus
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
7.0 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.1 Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2 General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.2.1 General Settings Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.2.2 Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2.3 Measurement Settings – Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.3.1 Network Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.1 Calibration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.1.1 Zone of Interest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.1.2 Zone of Interest Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.2 Camera Calibration from QubeVu Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.2.1 Camera Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
9.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.1 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.1.1 Diagnostics Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.1.2 Component Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
9.1.3 Scale Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
9.1.4 System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.1.5 Debug Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.2 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.2.1 iDimension Plus Does Not Return to Ready State. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.2.2 iDimension Plus Display is Off or Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
9.2.3 iDimension Plus Display is Green . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
9.2.4 iDimension Plus Display is Locked and Will Not Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
This manual provides an overview of the iDimension Plus setup and operation instructions.
Ensure the iDimension Plus unit is fully assembled by following the instructions of the iDimension Plus Assembly Instructions
(PN 197164).
When interfacing this device to third parties software, please reference the software manufacturer’s documentation for setup
and configuration parameters as necessary.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
Additional Manual Resources
• iDimension Plus Assembly Instructions (PN 197164). The iDimension Plus Assembly Instructions describes how to
assemble the iDimension Plus.
• iDimension Plus QubeVu Managers Guide (PN 195441). The iDimension Plus QubeVu Managers Guide is a detailed
overview of the QubeVu Manager, the embedded firmware of the iDimension Plus.
1.1 Regulatory Information
This product is a Class 1 Laser Product according to IEC 60825-1:2007 Ed. 2.0 and complies with 21 CFR 1040.1 pursuant to
Laser Notice No. 50. A laser source with a diffraction optical element is embedded in the product, which produces a maximum
output power of 1.1 mW at the aperture with a maximum wavelength of 825 nm.
FCC
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense. Changes or modifications not expressly approved by Postea, Inc. could void the user’s FCC
granted authority to operate the equipment.

iDimension Plus
2 Visit our website www.RiceLake.com
1.2 Safety
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Electric shock hazard!
There are no user serviceable parts. Refer to qualified service personnel for service.
The unit has no power switch, to completely remove power from the unit, disconnect the power source at the AC outlet.
For pluggable equipment the socket outlet must be installed near the equipment and must be easily accessible.
When cycling power, use the in-line power cord at a power outlet, do not power at the base.
Always disconnect from main power before performing work on the device.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without all shields and guards in place.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not use near water, avoid contact with excessive moisture.
Keep the unit dry.
Retain packaging. When transporting the unit, always disassemble and pack it in its original packaging.
Use only supplied power adapter. Never short-circuit the power adapter or the device.
Never remove the iDimension Plus head cover or the electrical connection panels at the base of the pole assembly.
Never modify or attempt to repair the unit. Service must be performed by Rice Lake Weighing Systems only.
Handle cables and cable connectors with care.
Never use damaged power cords, plugs or loose electrical sockets.
Never touch the power cord with wet hands.
Ensure that the base plate, pole assembly and head unit are all securely attached before attempting to move the unit.
Never lift the unit by grasping only the pole assembly.
Always ensure that both sections of the pole assembly and the base plate are supported.
Never drop or allow an impact to the head.
Mount on a flat surface.
Never use product for anything other than its intended purpose.
DANGER
WARNING
CAUTION
IMPORTANT
WARNING

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 3
1.3 Installation Requirements
Avoid installation of the unit near direct sunlight or near bright lights. Direct sunlight and overhead lighting
causes void pixels and noise that will affect the system from performing a dimension.
Protect the iDimension Plus from static electricity and connect to a clean AC power outlet.
Install the iDimension Plus on a table or sturdy level work surface large enough for the base plate and scale.
Ensure the location provides a large enough work surface clear from other objects in the measurement area.
Measurement Area Background
The background of the measurement area should provide a color contrast between the objects being measured in the standard
dimensioning configuration. Platforms that create a glare from overhead lights will affect the measurements. Use a flat black
paint to the surface to reduce glare and provide contrast. Adjustment of the Zone of Interest to approximately a 3'' x 3'' size can
help eliminate noise created by glare from shiny surfaces. A depth only mode is available.
Scale Placement
If using a scale, place the scale on the base plate, centered on the marks (Figure 1-1). Secure the scale into position.
Continuous movement of the scale may provide inaccurate measurements. If the scale moves from the original position placed
after a zero height or reset function, results may be inaccurate.
Figure 1-1. Scale Placement
IMPORTANT
Scale Guide
Scale Guide
Flat Detection Circle

iDimension Plus
4 Visit our website www.RiceLake.com
2.0 Setup Wizard
This section provides an overview of how to setup the iDimension Plus.
The Setup Wizard displays during the initial power-up. Skip to Step 3 if Setup Wizard displays.
Figure 2-1. Setup Wizard Prompt
2.1 Access Setup Wizard
If Setup Wizard does not display, see the following procedure:
1. From the display (Figure 3-1 on page 10), select the Device Information button
(Figure 4.1 on page 15) at the bottom of the display.
2. Select the Configuration Menu button (Section 4.1 on page 15). Configuration Menu displays
(Figure 3-7 on page 14).
Figure 2-2. Configuration Menu
3. Select Setup Wizard.
Figure 2-3. Initial Setup Wizard

Setup Wizard
© Rice Lake Weighing Systems ● All Rights Reserved 5
2.1.1 Time Zone
The Time Zone button displays the current time zone.
Figure 2-4. Time Zone
Use the following instructions to edit the time zone.
1. Select Time Zone, the current time zone displays.
2. Select by selecting or to highlight the desired time zone.
3. Select to continue.
2.1.2 Date and Time
The Date and Time button allows the adjustment of date or time if necessary.
Figure 2-5. Date and Time
Use the following instructions to adjust the date or time.
1. Select Time & Date.
2. Select or to enter the current time and date.
3. Select to continue.

iDimension Plus
6 Visit our website www.RiceLake.com
2.1.3 Zero Height
1. Select the base type of the iDimension Plus.
Figure 2-6. Zero Height Base Selection Display (NEED IMAGE OF SCALE)
• If the base is a smooth top scale or no scale, only using the iDimension Plus base, select the and
proceed to Step 3
• If the base has an uneven surface (roller balls or conveyor), not using the iDimension Plus base, select the
then continue to Step 2
2. Place the calibration object on top of the scale then select .
Figure 2-7. Place Calibration Box Display
3. Ensure the platform is clear of other objects then select .
Figure 2-8. Ensure Base is Clear Display
It is important to keep the scale or iDimension Plus base clear and unobstructed during the zero height calibration to
set the zero height accurately.
Note

Setup Wizard
© Rice Lake Weighing Systems ● All Rights Reserved 7
4. Stand clear of the unit before the countdown completes.
Figure 2-9. Stand Clear Display
5. Upon successful zero height calibration then select (Figure 3-1 on page 10).
6. Remove the calibration object, if used when the base has an uneven surface (roller balls or conveyor). The base is
selected within Step 1 on page 6.
If the zero height fails, ensure the dimensioning area is clear, the scale is level and repeat the zero height function.
If unable to perform a successful zero height, calibration may be required (Section 2.0 on page 4).
2.1.4 Scan Zone
The scan zone is the area the system uses to dimension an item. When configuring consider the area that needs to be clear
from all other objects and is used to identify motion detected by an operator placing an item on the platform. Before the unit will
attempt to perform a dimension, the scan area is required to be free from motion by the operator or objects near the device.
If the application has enabled flats, items than are less than 1.2'' (3 cm) in height, the scan zone is required to be as large in
length and width as the object.
1. Adjust the scan area by adjusting each of the four dots (touch points) on screen.
Figure 2-10. Scan Zone
2. Select when scan zone is configured.
Note

iDimension Plus
8 Visit our website www.RiceLake.com
2.1.5 Certified Settings
1. Select or to select between US Customary and NTEP 19-040A1 to configure for inches and accept.
The recommended setting is US Customary (pole mount) (in) and requires additional configuration in the QubeVu
Manager, see Section 7.0 on page 30 for additional QubeVu Manager configuration information.
For additional QubeVu Manager information, see the iDimension Plus QubeVu Managers Guide (PN 195441).
Figure 2-11. Certification Settings – US Customary
Figure 2-12. Certification Settings – NTEP 19-040A1
• If Metric (pole mount) (m/cm/mm) is selected, select the measurement increment that will be used: mm, cm or
meters.
Figure 2-13. Certification Settings – Metric
Note

Setup Wizard
© Rice Lake Weighing Systems ● All Rights Reserved 9
Figure 2-14. Certification Settings – mm
2. Upon completion of the setup wizard, the system restarts. Clear the platform of obstructions to continue.
Figure 2-15. Setup Complete
2.2 Next Steps
The setup wizard is now complete. Additional setup requires connection of the iDimension Plus to a PC from a network
connection to access QubeVu Manager.
1. Connect iDimension to network (Section 8.0 on page 37).
2. Configure general settings (Section 7.2 on page 31).
3. Configure scale settings for connecting to iDimension Plus (Section 7.2.2 on page 33).
4. Configure network (Section 7.3 on page 35).
5. Work area and zone of Interest configuration (Section 8.1.2 on page 38).
6. Camera calibration, if needed (Section 8.2 on page 40).
Models Valid Configuration Profiles
iDimension Plus US Customary (pole mount), Metric (pole mount), NTEP 19-040A1 (pole mount)
iDimension Plus XL US Customary (XL mount), Metric (XL mount)
Table 2-1. Valid Configuration Profiles

iDimension Plus
10 Visit our website www.RiceLake.com
3.0 Touchscreen Display
This section provides an overview of iDimension Plus USB touchscreen display indicators and controls instructions.
The USB touchscreen display combines the weight and dimensions from the iDimension Plus and the optional scale to be
visualized.
The touchscreen display provides the dimensions, a live displayed scale weight and operator access to system level controls.
3.1 Touch Screen Display Operation
A live image provides the user feedback on the placement of the item and conditions that may cause the system to be unable to
dimension, for example out of bounds. The blue line indicates the scan zone defined during initial setup.
The Power button for the USB display is located on the back of the unit. The USB operator display can be configured in
QubeVu Manager, see the iDimension Plus QubeVu Managers Guide (PN 195441).
Figure 3-1. Touchscreen Display
Indicators provide out of bounds and shape information for dimensioning. Function keys allow the iDimension Plus to be
managed via the touchscreen display.
3.1.1 Live Image
The weigh area provides a real-time view of the scanning area from the scanning head onto the USB display. The blue box
within Figure 3-1 is the Scan Zone which indicates the area the iDimension Plus will dimension (Section 8.1 on page 37).
3.1.2 Out of Bounds Indication
The Out of Bounds icon indicates the object is not outside of the Scan Zone. If the object is outside of the Scan Zone,
an exclamation point will appear with arrows indicating the direction the object is not within the Scan Zone.
If all four of the arrows within the Out of Bounds icon are lit , the object being dimensioned is not within the viewing area
or the item is too large. The arrows within the Out of Bounds icon display the direction which the item is outside of the Scan
Zone.

Touchscreen Display
© Rice Lake Weighing Systems ● All Rights Reserved 11
3.1.3 Shape Indication
The Shape Indication icon indicates the type of shape of the object being dimensioned.
• The Regular Shape icon indicates if the item is dimensioned as an regular shape and the dimensions are
displayed in 0.2'' or 0.5 cm increments.
• The Irregular Shape icon indicates if the item is dimensioned as an irregular shape and the dimensions are
displayed in 0.5'' or 0.5 cm increments.
3.1.4 Status Indication
Status indicates the current status of the iDimension Plus unit.
• The Ready status indicates the device is ready to perform a dimensioning transaction
• The Remove status indicates a successful dimensioning transaction is complete
• The Stopped status displays during restart or if the devices requires a restart from the Configuration menu
• The Wait status displays briefly while dimensioning or if user intervention is required; Select the Help function
key to see real time feedback of the system if the device displays the started, stopped or wait condition
3.1.5 Help Key
The Help function key displays the Issue Review menu.
The Help function key provides real time feedback to the operator of the unit. Provides step by step instructions on how to clear
conditions such as started, stopped, wait or remove condition with no object in the scan area.
Figure 3-2. Issue Review
Select the ruler icon at the bottom of the touchscreen display to return to the main screen.

iDimension Plus
12 Visit our website www.RiceLake.com
3.1.6 Zero Height Key
The Zero Height function key allows the iDimension Plus to calculate the distance between the scan head and the base.
Zeroing the height after initial setup is only necessary if the distance between the scan head and the measuring platform
changes.
Example: When a scale is added or removed.
To perform the Zero Height function, refer to the following procedure:
1. Select the base type of the iDimension Plus.
Figure 3-3. Zero Height Base Selection Display
• If the base is a smooth top scale or no scale, only using the iDimension Plus base, select the scale type and
proceed to Step 3 on page 13
• If the base has an uneven surface (roller balls or conveyor), not using the iDimension Plus base, select the
then continue to Step 2
2. Place the calibration object on top of the scale then select .
Figure 3-4. Place Calibration Box Display

Touchscreen Display
© Rice Lake Weighing Systems ● All Rights Reserved 13
3. Ensure the platform is clear of other objects then select .
Figure 3-5. Ensure Base is Clear Display
It is important to keep the scale or iDimension Plus base clear and unobstructed during the zero height calibration to
set the zero height accurately.
4. Stand clear of the unit before the countdown completes.
Figure 3-6. Stand Clear Display
5. Upon successful zero height calibration then select . The display returns to the Touchscreen Display
(Figure 3-1 on page 10).
6. Remove the calibration object.
If the zero height fails, ensure the dimensioning area is clear, the scale is level and repeat the zero height function.
If unable to perform a successful zero height, calibration may be required (Section 2.0 on page 4).
Note
Note

iDimension Plus
14 Visit our website www.RiceLake.com
Configuration Menu Key
The Configuration Menu function key displays the Configuration Menu. The Configuration Menu provides more
configuration options when accessed through touchscreen display than when accessed through a PC.
The options accommodate stand-alone deployments. All options are available from the Admin Tools menu, see the iDimension
Plus Managers Guide (PN 195441) for additional Admin Tools information.
Figure 3-7. Configuration Menu
Inspection Menu Key
The Inspection Menu function key provides access to Weight and Measures Inspector menu.
Figure 3-8. Inspection Menu

Configuration Menu
© Rice Lake Weighing Systems ● All Rights Reserved 15
4.0 Configuration Menu
This section provides an overview of iDimension Plus configuration menu instructions.
4.1 Access Configuration Menu
To access the Configuration Menu, see the following procedure:
1. Select the Device Information function key located at the bottom of the screen (Figure 3-1 on page 10).
2. The Device Info menu displays. For Device Info information (Section 4.2 on page 20).
Figure 4-1. Device Information
3. Select the Configuration function key from the Device Info menu.
4. The Configuration Menu displays. For additional Configuration Menu information (Section 4.2.1 on page 20).
Figure 4-2. Configuration Menu
Item Description Reference
Setup Wizard Steps through initial configuration to allow unit operation Section 4.1.1 on page 16
View EULA Displays the Software End User License Agreement information Section 4.1.2 on page 16
Time Zone Displays the current time zone and allows for time zone configuration Section 4.1.3 on page 17
Date & Time Allows the adjustment of date and time Section 2.1.2 on page 5
Data Extract View the configuration settings and the current and previous status;
Must be configuration in administration mode Section 4.1.3 on page 17
Scan Zone Allows for configuration of the Zone of Interest Section 2.1.3 on page 6
Restart Select to restart the iDimension Plus unit Section 4.1.4 on page 18
Enable Flats Select to configure flat detection settings Section 4.1.5 on page 18
Upgrade Firmware Allows for a connected USB drive to update the current device firmware Section 4.1.6 on page 19
IP Address Select to view the current IP address of the iDimension Plus unit Section 4.1.7 on page 20
Table 4-1. Configuration Menu Keys

iDimension Plus
16 Visit our website www.RiceLake.com
4.1.1 Setup Wizard
The Setup Wizard displays during initial assembly and power-up. If Setup Wizard does not display, see Section 2.1 on page 4.
Select the Setup Wizard to automatically step through the following information.
Figure 4-3. Begin Setup Wizard
4.1.2 View EULA
The View EULA button displays the Software End User License Agreement.
Figure 4-4. End User License Agreement
