Rice Lake 120 User manual

76699
120
Digital Weight Indicator
Version 1.0
Installation Manual

© 2006 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America.
Specifications subject to change without notice.
Version 1.0, September 2006
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com or obtained
by calling 715-234-9171 and asking for the training department
Contents
About This Manual ................................................................................................................................... 1
1.0 Introduction.................................................................................................................................. 1
1.1 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Front Panel Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 LED Annunciators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 Indicator Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4.1 Weighing Mode Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4.2 Panel Mode Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.0 Installation ................................................................................................................................... 5
2.1 Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Enclosure and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2.1 Serial Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2.2 Load Cells. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Enclosure Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.0 Configuration ............................................................................................................................... 7
3.1 Configuration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1.1 Revolution Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1.2 EDP Command Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1.3 Front Panel Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Menu Structures and Parameter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.1 Configuration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.2 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.3 Calibration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.4 Serial Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.5 Program Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2.6 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.2.7 Time Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.8 Date Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.9 Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.0 Calibration ................................................................................................................................. 21
4.1 Front Panel Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.2 EDP Command Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.0 EDP Commands.......................................................................................................................... 23
5.1 The EDP Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.1 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.2 Reporting Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.3 The RS Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.4 Parameter Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.2 Saving and Transferring Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.2.1 Saving Indicator Data to a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.2.2 Downloading Configuration Data from PC to Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

ii 120 Installation Manual
6.0 Print Formatting ......................................................................................................................... 27
6.1 Print Formatting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2 Customizing Print Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.1 Using the EDP Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.2 Using the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.0 Appendix .................................................................................................................................... 29
7.1 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.2 Continuous Output (Stream) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.3 Front Panel Display Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.4 ASCII Character Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.5 Conversion Factors for Secondary Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.6 Digital Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.6.1 DIGFLxParameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.6.2 DFSENS and DFTHRH Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.6.3 Setting the Digital Filter Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.7 Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.8 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
120 Limited Warranty............................................................................................................................. 37

Introduction 1
About This Manual
This manual is intended for use by service technicians
responsible for installing and servicing 120 digital
weight indicators. This manual applies to indicators
using Version 1.0 of the 120 software.
Configuration and calibration of the indicator can be
accomplished using the indicator front panel keys, the
EDP command set, or Version 3.0 or later of the
Revolution™configuration utility. See Section 3.1 on
page 7 for information about configuration methods.
Some procedures described in this
manual require work inside the indicator
enclosure. These procedures are to be
performed by qualified service personnel
only.
Authorized distributors and their employees
can view or download this manual from the
Rice Lake Weighing Systems distributor
site at www.ricelake.com.
The Operator Card included with this manual
provides basic operating instructions for users of the
120. Please leave the Operator Card with the indicator
when installation and configuration are complete.
1.0 Introduction
The 120 is a single-channel digital weight indicator housed in a durable plastic enclosure. The indicator front
panel consists of a large (.8 in, 20 mm), six-digit, seven-segment LED display and five-button keypad. Features
include:
• Drives up to four 350Ω or eight 700Ωload cells
• Supports 4- and 6-wire load cell connections
• Electronic data processing (EDP) port for full duplex, RS-232 communications at up to 38400 bps
• Printer port for output-only RS-232 and 20 mA current loop communications at up to 9600 bps
The 120 is NTEP-certified for Classes III and III L at 6,000 divisions. See Section 7.8 on page 36 for detailed
specifications.
1.1 Operating Modes
The 120 supports the following modes of operation:
Normal (weighing) mode
Normal mode is the “production” mode of the indicator. The indicator displays gross or net weights as
required, using the LED annunciators described in Section 1.3 on page 2 to indicate scale status and the type
of weight value displayed. Once configuration is complete and a legal seal is affixed to the back of the
indicator, this is the only mode in which the 120 can operate. See Section 1.4.1 on page 3 for more
information about normal mode operations.
Panel mode
Panel mode allows the time, date, consecutive number, and consecutive number start-up value to be set
without entering configuration mode. To enter panel mode, press and hold the GROSS/NET key until the TIME
menu is shown. See Section 1.4.2 on page 4 for more information about panel mode.
Configuration mode
Most of the procedures described in this manual require the indicator to be in configuration mode, including
configuration and calibration.
To enter configuration mode, remove the large fillister head screw from the enclosure backplate. Insert a
screwdriver or a similar tool into the access hole and press the setup switch once. The indicator display
changes to show the word CONFIG.
Test mode
Test mode provides a number of diagnostic functions for the 120 indicator. Like setup mode, test mode is
entered using the setup switch. See Section 7.7 on page 35 for more information about entering and using
test mode.
7ARNING

2120 Installation Manual
1.2 Front Panel Keypad
Figure 1-1 shows the 120 keypad and LED annunciators.
The symbols shown under the keys (representing up, down, enter, left, right) describe the key functions assigned
in configuration and panel modes. In these modes, the keys are used to navigate through menus, select digits
within numeric values, and increment/decrement values. See Section 3.1.3 on page 8 for information about using
the front panel keys in configuration mode.
Figure 1-1. 120 Front Panel
1.3 LED Annunciators
The 120 display uses a set of eight LED annunciators to provide additional information about the value being
displayed:
•Gr (gross) and Nt (net) annunciators are lit to show whether the displayed weight is a gross or net weight.
• Center of zero ( ): Gross weight is within ±0.25 graduations of zero. This annunciator lights when the
scale is zeroed.
• Standstill ( ): Scale is at standstill or within the specified motion band. Some operations, including
tare functions and printing, can only be done when the standstill symbol is shown.
•lb, kg, oz, and g annunciators indicate the units associated with the displayed value: lb=pounds,
kg=kilograms, oz=ounces, g=grams.
The displayed units can also be set to short tons (tn), metric tons (t), or NONE (no units information
displayed). The lb and kg LEDs function as primary and secondary units annunciators for some
combinations of primary and secondary units. If neither primary nor secondary units are lb, kg, oz, or g, the
lb annunciator is lit for primary units, kg for secondary units.
Table 1-1 on page 3 shows which annunciators are used for all combinations of configured primary and
secondary units. For example:
• If the primary unit is pounds (lb) and the secondary unit is kilograms (kg), the lb LED is lit for primary
units, kg for secondary units.
• If the primary unit is pounds (lb) and the secondary unit is short tons (tn), the lb LED is lit for primary
units, kg for secondary units. There is no LED for short tons, so the kg LED is used as the secondary units
annunciator.
• If the primary unit is short tons (tn) and the secondary unit is pounds (lb), the lb LED is lit for primary
units (tn), and kg is lit for secondary units (lb). Because there is no LED for short tons, the lb and kg LEDs
are used as primary and secondary units annunciators.
LH
MC H
P[ (S /U
;&30
(3044
/&5
#/
5"3&
4
6/*54
6OJUT
13*/5

Introduction 3
See Section 3.2.2 on page 12 for more information about configuring primary and secondary display units.
1.4 Indicator Operations
1.4.1 Weighing Mode Operations
Basic 120 operations are summarized below:
Toggle Gross/Net Mode
Press the GROSS/NET key to switch the display mode from gross to net, or from net to gross. If a tare value has
been entered or acquired, the net value is the gross weight minus the tare.
Gross mode is shown by the Gross annunciator; net mode is shown by the Net annunciator.
Toggle Units
Press the UNITS key to switch between primary and secondary units. The units LED to the right of the display is
lit.
Zero Scale
1. In gross mode, remove all weight from the scale and wait for the standstill annunciator ( ).
2. Press the ZERO key. The center of zero ( ) annunciator lights to indicate the scale is zeroed.
Acquire Tare
1. Place container on scale and wait for the standstill annunciator ( ).
2. Press the TARE key to acquire the tare weight of the container. The indicator switches to net mode.
Remove Stored Tare Value
1. Remove all weight from the scale and wait for the standstill annunciator ( ).
2. Press the TARE key. The indicator switches to gross mode, indicating the tare value has been removed.
Print Ticket
1. Wait for the standstill annunciator ( ).
2. Press the PRINT key to send data to the serial port.
Primary Unit
Secondary Unit
lb kg oz gtn tnone
lb lb / lb lb / kg lb / oz lb / g lb / kg
kg kg / lb kg / kg kg / oz kg / g lb / kg
oz oz / lb oz / kg oz / oz oz / g oz / kg
g g / lb g / kg g / oz g / g g / kg
tn lb / kg lb / kg lb / oz lb / g lb / lb lb / kg lb / kg
tlb / kg lb / lb lb / kg
none lb / kg lb / kg lb / lb
Table 1-1. Units Annunciators, Showing Primary / Secondary LEDs Used for All Configurations

4120 Installation Manual
1.4.2 Panel Mode Operations
The following operations are available by placing the indicator in panel mode:
•Settime
•Setdate
• Set consecutive number
• Set consecutive number start-up value
To enter panel mode, press and hold the GROSS/NET key until the TIME menu is displayed. Use the navigation
keys to move around the menu; to change a value, use the navigation keys to select the digit and increment or
decrement its value. Press the Enter (TARE) key to set the value and return to the menu level above. Figure 1-2
shows the structure of the panel mode menu.
Note: To enter a 2 digit month, the lower digit must be a “1” then the upper digit is incremented to “1”. The lower digit can then
be changed to 0, 1 or 2 as required.
Figure 1-2. Panel Mode Menu Structure
TIME
SHOW
hh.mm.ss
HOUR
hh
MINUTE
mm
SECOND
ss
DATE
SHOW
yy.mm.dd
YEAR
yy
MONTH
mm
DAY
dd
CONSNU
number
CONSTU
number

Installation 5
2.0 Installation
This section provides information for connecting load cell and serial communications cables to the 120 indicator.
2.1 Unpacking and Assembly
Immediately after unpacking, visually inspect the 120 to ensure all components are included and undamaged. The
shipping carton should contain the indicator with attached tilt stand, this manual, and a parts kit. If any parts were
damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately.
The parts kit contains the items listed below:
• Capacity and identification labels
• Load cell connector (PN 82505)
• 9V power supply adapter (PN 78611 for 115 VAC units, PN 78612 for 230 VAC units)
2.2 Enclosure and Connectors
The back of the 120 enclosure provides a 3-pin power connection, 9-pin D-sub connector for communications,
and an available 6-pin connector or load cell cord grip connector for load cell connection (see Figure 2-1).
The setup switch, used for placing the indicator into configuration mode, is located in the recess on the underside
of the enclosure. The setup switch is protected by a cover plate and secured with a fillister head screw (not shown
in Figure 2-1).
Figure 2-1. Back View of 120 Enclosure, Showing Load Cell DB-9 Connector, Communications Connectors and Setup
Switch Location
2.2.1 Serial Communications
The serial communications cable attaches to the male
D-Sub connector, Port 1 (see Figure 2-1 on page 5).
Port 1 provides connections for the EDP (Electronic
Data Processing) port and the printer port. Table 2-1.
shows the pin assignments for Port 1.
The EDP port supports RS-232 communications only;
the printer port provides either active 20 mA output or
RS-232 transmission. Both ports are configured using
the SERIAL menu. See Section 3.0 on page 7 for
configuration information.
SETUP
PORT 1 PORT 2
COMMUNICATIONS LOAD CELL
9VDC ADAPTER
SWITCH
DB-9
Connector
Load Cell
Connection
shown with
6-pin
Connector
(Port 2)
Load Cell
Cord Grip
Available
Communications Port 1
Setup Switch
Port 1
Pin Port Function
1 Printer RS-232 TxD
2 EDP RS-232 TxD
3 RS-232 RxD
4— not used
5 EDP/Printer RS-232 Ground / –20 mA OUT
6N/C not used
7
8
9 Printer +20 mA OUT
Table 2-1. Serial Connector (Port 1) Pin Assignments

6120 Installation Manual
2.2.2 Load Cells
Load cell wires may be connected externally or internally, depending upon which indicator model is purchased.
Refer to the external 6-pin connector instructions or the load cell cord grip plug instructions below to connect to
the load cell wires.
NOTE: When using 4-wire load cells, sense and excitation pins must be shorted together. See Tables 2-2 and 2-3 for details.
External Load Cell Connector
The load cell or junction box cable attaches to the
round 6-pin connector, Port 2, on the back of the
indicator enclosure (see Figure 2-1 on page 5).
Table 2-2 shows the pin assignments for Port 2.
Load Cell Cord Grip Plug
For models having the load cell cord grip, route load
cell cable through the cord grip and wire the cable to
connector J1 (see Figure 2-2) as shown in Table 2-3.
When wiring is complete, tighten cord grip.
Figure 2-2. CPU Board, Showing Location of J1 Load Cell Connector
Port 2 Pin Function
1 +SIG
2 +EXC
3 +SENSE *
4 –EXC
5 –SENSE *
6 –SIG
* For 4-wire connections, short pin 2 to pin 3, pin 4 to pin 5.
Table 2-2. Load Cell Connector (Port 2) Pin Assignments
J1 Function
1–EXC
2 –SEN *
3 –SIG
4 +SIG
5 +SEN *
6 +EXC
* For 4-wire connections, short pin 1 to pin 2, pin 5 to pin 6.
Table 2-3. J1 Pin Assignments with Load Cell Cord Grip
1
–EXC
–SEN
–SIG
+SIG
+SEN
+EXC
J1
J2
POWER
SERIAL
COMMUNICATIONS
1

Installation 7
2.3 Enclosure Disassembly
Use a wrist strap to ground yourself and
protect components from electrostatic
discharge (ESD) when working inside the
indicator enclosure.
If the indicator enclosure must be opened for
maintenance, do the following:
1. Disconnect power to the unit. Remove tilt stand.
2. Remove two fillister head screws and the setup
switch cover plate from back of enclosure.
3. Loosen self-tapping screw at top center of back
of enclosure.
4. Lift up the forward edge of the rubber feet on
bottom of enclosure for access to two additional
self-tapping screws. Loosen both screws.
5. Press down on top of back half of the enclosure
to release tabs. Open enclosure by separating the
housing at the top of the indicator. (CPU board
is mounted to front half of enclosure; power,
communications, and load cell connections all
connect to the bottom of the CPU board.)
6. Reverse steps to reassemble enclosure.
2.4 Replacement Parts
Table 2-4 lists replacement parts for the 120 indicator.
Caution
PN Description
78609 CPU Board
78610 Switch panel membrane
15799 9-pin socket for D-sub communications cable
15774 Shell for D-sub communications cable
83429 Setup switch cover plate
83430 Fillister head screw
83432 Self-tapping screw (enclosure)
83431 Rubber foot
83428 Tilt stand wing knob
78949 Optional wall-mount tilt stand
78611 9V power supply adapter for 115V units
78612 9V power supply adapter for 230V units
Table 2-4. Replacement Parts

7120 Installation Manual
3.0 Configuration
To configure the 120 indicator, the indicator must be placed in setup
mode. The setup switch is accessed by removing the left fillister head
screw on underside of the enclosure and removing the rectangular
switch cover plate. Switch position is changed by inserting a
screwdriver into the access hole and pressing the switch.
When the indicator is placed in setup mode, the word CONFIG is shown
on the display. The CONFIG menu is the first of nine main menus
used to configure the indicator. Detailed descriptions of these menus
are given in Section 3.2. When configuration is complete, return to the
CONFIG menu and press the (ZERO) key to exit setup mode, then replace the setup switch access screw.
3.1 Configuration Methods
The 120 indicator can be configured by using the front panel keys to navigate through a series of configuration
menus or by sending commands or configuration data to the EDP port. Configuration using the menus is
described in Section 3.1.3. Configuration using the EDP port can be accomplished using the EDP command set
described in Section 5.0 or by using the Revolution III configuration utility.
3.1.1 Revolution Configuration
The Revolution III configuration utility provides the
preferred method for configuring the 120 indicator.
Revolution runs on a personal computer to set
configuration parameters for the indicator. When
Revolution configuration is complete, configuration
data is downloaded to the indicator.
Figure 3-1. Sample Revolution Configuration Display
Revolution III supports both uploading and
downloading of indicator configuration data. This
capability allows configuration data to be retrieved
from one indicator, edited, then downloaded to
another.
To use Revolution III, do the following:
1. Install Revolution III (Version 3.1 or later) on an
IBM-compatible personal computer running
Windows®98 or later. Minimum system
requirements include a processor speed of at
least 166MHz, 32MB of memory (64MB
recommended, required for NT4, 2000, XP), and
at least 40MB of available hard disk space for
installation.
2. With both indicator and PC powered off,
connect the PC serial port to the RS-232 pins on
the indicator EDP port.
3. Power up the PC and the indicator. Use the setup
switch to place the indicator in setup mode.
4. Start the Revolution III program.
Figure 3-1 shows an example of one of the Revolution
configuration displays.
Revolution III provides online help for each of its
configuration displays. Parameter descriptions
provided in this manual for front panel configuration
can also be used when configuring the indicator using
Revolution: the interface is different, but the
parameters set are the same.
SETUP SWITCH
FILLISTER-HEAD SCREW

Configuration 8
3.1.2 EDP Command Configuration
The EDP command set can be used to configure the 120 indicator using a personal computer, terminal, or remote
keyboard. Like Revolution, EDP command configuration sends commands to the indicator EDP port; unlike
Revolution, EDP commands can be sent using any external device capable of sending ASCII characters over a
serial connection.
EDP commands duplicate the functions available using the indicator front panel and provide some functions not
otherwise available. EDP commands can be used to simulate pressing front panel keys, to configure the
indicator, or to dump lists of parameter settings. See Section 5.0 on page 23 for more information about using the
EDP command set.
3.1.3 Front Panel Configuration
The 120 indicator can be configured using a series of menus accessed through the indicator front panel when the
indicator is in setup mode. Table 3-1 summarizes the functions of each of the main menus.
Four front panel keys are used as directional keys to navigate through the menus in setup mode. The UNITS ()
and PRINT ( ) keys scroll left and right (horizontally) on the same menu level; ZERO ( ) and GROSS/NET ()
move up and down (vertically) to different menu levels. The TARE key ( ) serves as an Enter key for selecting
parameter values within the menus. A label under each of these keys identifies the direction provided by the key
when navigating through the setup menus.
To select a parameter, press or to scroll left or right until the desired menu group appears on the display,
then press to move down to the submenu or parameter you want. When moving through the menu parameters,
the default or previously selected value appears first on the display.
To change a parameter value, scroll left or right to view the values for that parameter. When the desired value
appears on the display, press to select the value and move back up one level.
NOTE: You must press to save the selected value. The 120 does not automatically save the last-displayed value.
To edit numerical values, press (rightmost digit will
flash), then use the navigation keys to select the digit
and to increment or decrement the value (see
Figure 3.2). When done, press again to save the
edited value.
Figure 3-2. Editing Procedure for Numeric Values
Menu Menu Function
CONFIG Configuration Configure load cell sensitivity, grads, zero tracking, zero range, motion band, overload, sample
rate, and digital filtering parameters.
FORMAT Format Set format of primary and secondary units, display rate.
CALIBR Calibration Calibrate indicator. See Section 4.0 on page 21 for calibration procedures.
SERIAL Serial Configure EDP and printer serial ports.
PROGRM Program Set power-up mode, regulatory mode, and consecutive number values.
P FORMT Print Format Set print format used for gross and net tickets. See Section 5.0 for more information.
TIME Time Display and set time
DATE Date Display and set date
VERSION Version Display installed software version number.
Table 3-1. 120 Menu Summary
When editing numeric values, press to allow numeric mode
change entry, then press or to change the digit selected.
Press or to increment or decrement the value of the flashing
selected digit.
Press to save the value entered and return to the level above.

9120 Installation Manual
3.2 Menu Structures and Parameter Descriptions
The following sections provide graphic representations of the 120 menu structures. In the actual menu structure,
the settings you choose under each parameter are arranged horizontally. To save page space, menu choices are
shown in vertical columns. The factory default setting appears at the top of each column.
Most menu diagrams are accompanied by a table that describes all parameters and parameter values associated
with that menu. Default parameter values are shown in bold type.
3.2.1 Configuration Menu
Figure 3-3. Configuration Menu
GRADS
10000 OFF
1D
0.5D
3D
ZTRKBN ZRANGE
1.9%
100%
50D
2D
1D
3D
MOTBAN
10D
5D
20D
FS+2%
FS+9D
FS+1D
FS
OVRLOA
8
4
DIGFL1
64
32
number
DIGFL2 DIGFL3
8OUT
32OUT
16OUT
64OUT
DFSENS DFTHRH
1OUT
128OUT
2OUT
2DD
NONE
5DD
20DD
10DD
50DD
200DD
100DD
250DD
30HZ
7.5HZ
15HZ
3.75HZ
SMPRAT
PGA
2
4
OFF
1
2
4OUT
16
8
4
64
32
1
2
16
128 128
VERSDATETIME
PFORMT
SERIALCALIBRCONFIG FORMATPROGRM
8
4
64
32
1
2
16
128
8
1
0.1DD
0.2DD
1DD
0.5DD

Configuration 10
CONFIG Menu
Parameter Choices Description
Level 2 submenus
PGA 2
4
8
1
Set programmable gain amplifier for load cell sensitivity:
–0.5 mV/V to 4.5 mV/V PGA = 1
–0.2 mV/V to 2.2 mV/V PGA = 2
–0.1 mV/V to 1.1 mV/V PGA = 4
–0.5 mV/V to 0.6 mV/V PGA = 8
GRADS 10000
number
Graduations. Specifies the number of full scale graduations. The value entered must be in
the range 1–100 000 and should be consistent with legal requirements and environmental
limits on system resolution.
To calculate GRADS, use the formula, GRADS = Capacity / Display Divisions.
Display divisions for primary and secondary units are specified on the FORMAT menu.
ZTRKBN OFF
0.5D
1D
3D
Zero track band. Automatically zeroes the scale when within the range specified, as long
as the input is within the configured zero range (ZRANGE parameter). Selections are ±
display divisions. Maximum legal value varies depending on local regulations.
ZRANGE 1.9%
100%
Zero range. Selects the range within which the scale can be zeroed. The 1.9% selection is
± 1.9% around the calibrated zero point, for a total range of 3.8%. Indicator must be at
standstill to zero the scale. Use 1.9% for legal-for-trade applications.
MOTBAN 1D
2D
3D
5D
10D
20D
50D
OFF
Motion band. Sets the level, in display divisions, at which scale motion is detected. If
motion is not detected for 1 second or more, the standstill symbol lights. Some
operations, including print, tare, and zero, require the scale to be at standstill. Maximum
legal value varies depending on local regulations.
If OFF is selected, ZTRKBN should also be set to OFF.
OVRLOA FS+2%
FS+1D
FS+9D
FS
Overload. Determines the point at which the display blanks and an out-of-range error
message is displayed. Maximum legal value varies depending on local regulations.
SMPRAT 15HZ
7.5HZ
3.75HZ
30HZ
Sample rate. Selects measurement rate, in samples per second, of the analog-to-digital
converter. Lower sample rate values provide greater signal noise immunity.
DIGFL1
DIGFL2
DIGFL3
2
4
8
16
32
64
1
Digital filtering. Selects the digital filtering rate used to reduce the effects of mechanical
vibration from the immediate area of the scale.
Choices indicate the number of A/D conversions that are averaged to obtain the
displayed reading. A higher number gives a more accurate display by minimizing the
effect of a few noisy readings, but slows down the settling rate of the indicator. See
Section 7.6 on page 34 for more information on digital filtering.
DFSENS 8OUT
16OUT
32OUT
64OUT
128OUT
2OUT
4OUT
Digital filter cutout sensitivity. Specifies the number of consecutive readings that must fall
outside the filter threshold (DFTHRH parameter) before digital filtering is suspended. If
NONE is selected, the filter is always enabled.
Table 3-2. Configuration Menu Parameters

11 120 Installation Manual
DFTHRH NONE
0.1DD
0.2DD
0.5DD
1DD
2DD
5DD
10DD
20DD
50DD
100DD
200DD
250DD
Digital filter cutout threshold. Specifies the filter threshold, in display divisions. When a
specified number of consecutive scale readings (DFSENS parameter) fall outside of this
threshold, digital filtering is suspended. If NONE is selected, the filter is always enabled.
CONFIG Menu
Parameter Choices Description
Table 3-2. Configuration Menu Parameters (Continued)

Configuration 12
3.2.2 Format Menu
Figure 3-4. Format Menu
FORMAT Menu
Parameter Choices Description
Level 2 submenus
PRIMAR DECPNT
DSPDIV
UNITS
Specifies the decimal position, display divisions, and units used for the primary units. See
Level 3 submenu parameter descriptions.
SECNDR DECPNT
DSPDIV
UNITS
MULT
MULEXP
Specifies the decimal position, display divisions, units, and conversion multiplier used for
the secondary units. See Level 3 submenu parameter descriptions.
DSPRAT 250MS
500MS
750MS
1SEC
1500MS
2SEC
2500MS
3SEC
4SEC
6SEC
8SEC
Display rate. Sets the update rate for displayed values. Values are in milliseconds (MS) or
seconds (SEC).
Table 3-3. Format Menu Parameters
DSPDIV MULTUNITSDECPNT
0.45359
1D
5D
2D
number
PRIMAR SECNDR
6SEC
4SEC
3SEC
2500MS
2SEC
1500MS
750MS
500MS
250MS
8SEC
DSPRAT
DSPDIV UNITSDECPNT
T
KG
1D
5D
2D
LB
8.88888
888888
88888.8
8888.88
888.888
88.8888
OZ
TN
NONE
G
KG
LB
MULEXP
1SEC
8.88888
888888
88888.8
8888.88
888.888
88.8888
dec_position
VERSDATETIME
PFORMT
SERIALCALIBRCONFIG FORMAT PROGRM
20D
10D
50D
20D
10D
50D T
OZ
TN
NONE
G

13 120 Installation Manual
Level 3 submenus
Primary Units (PRIMAR Parameter)
DECPNT 888888
8.88888
88.8888
888.888
8888.88
88888.8
Decimal point location. Specifies the location of the decimal point or dummy zeroes in the
primary unit display. Value should be consistent with local legal requirements.
DSPDIV 1D
2D
5D
10D
20D
50D
Display divisions. Selects the minimum division size for the primary units displayed weight.
UNITS LB
KG
OZ
TN
T
G
NONE
Specifies primary units for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; TN=short ton; T=metric ton; G=gram.
Secondary Units (SECNDR Parameter)
DECPNT 88888.8
888888
8.88888
88.8888
888.888
8888.88
Decimal point location. Determines the location of the decimal point or dummy zeros in
the secondary unit display.
DSPDIV 5D
10D
20D
50D
1D
2D
Display divisions. Selects the value of minimum division size of the displayed weight.
UNITS KG
OZ
TN
T
G
LB
NONE
Specifies secondary units for displayed and printed weight. Values are: KG=kilogram;
OZ=ounce; TN=short ton; T=metric ton; G=gram; LB=pound.
MULT 0.45359
number
Multiplier. Specifies the conversion factor by which the primary units are multiplied to
obtain the secondary units. The default is 0.45359, which is the conversion factor for
changing pounds to kilograms. Use the MULEXP parameter to shift the decimal position
of the multiplier. See Section 7.5 on page 33 for a list of multipliers.
To toggle between primary and secondary units, press the UNITS key.
MULEXP dec_position Multiplier decimal shift. Specifies a divisor used to shift the decimal position in the
secondary units multiplier value. Use the left and right arrow keys to shift the decimal point
within the displayed MULT value.
FORMAT Menu
Parameter Choices Description
Table 3-3. Format Menu Parameters (Continued)

Configuration 14
3.2.3 Calibration Menu
See Section 4.0 on page 21 for calibration procedures.
Figure 3-5. Calibration Menu
CALIBR Menu
Parameter Choices Description
Level 2 submenus
WZERO — Display and edit the zero calibration A/D count value.
DO NOT adjust this value after WSPAN has been set!
WVAL 10000
test_weight
Display and edit the test weight value.
WSPAN — Display and edit the span calibration A/D count value.
REZERO — Press Enter to remove an offset value from the zero and span calibrations.
Use this parameter only after WZERO and WSPAN have been set. See Section 4.1 on
page 21 for more information about using this parameter.
Table 3-4. Calibration Menu Parameters
WZERO
*CAL*
Display and edit
zero calibration
A/D count value Display and edit
test weight value
WVAL
*CAL*
Display and edit
span calibration
A/D count value
WSPAN
*CAL*
Press Enter to
remove offset from
zero and span
calibrations
REZERO
VERSDATETIME
PFORMT
SERIALCALIBRCONFIG FORMATPROGRM
10000

15 120 Installation Manual
3.2.4 Serial Menu
See Section 7.2 on page 29 for information about the 120 serial data format.
Figure 3-6. Serial Menu
EDP PRINT
PRN
EDP
PRNDES
BITS TERMBAUD
CR
9600
7SPACE
7ODD
8NONE CR/LF
1200
38400
19200
EDP
OFF
STREAM
PRN
VERSDATETIME
PFORMT
SERIALCALIBRCONFIG FORMAT
DISABLE
ENABLE
PROTCT
2SEC
1SEC
STMDLY
4SEC
4800
2400
7EVEN
BITS TERMBAUD
CR
9600
7SPACE
7ODD
8NONE CR/LF
1200
4800
2400
7EVEN
PROGRM
15SEC
8SEC
NONE
250MS
500MS
ECHO
OFF
ON
SERIAL Menu
Parameter Choices Description
Level 2 submenus
EDP BAUD
BITS
TERM
Specifies settings for baud rate, data bits, termination characters, and end-of-line delay used by
the EDP port.
PRINT BAUD
BITS
TERM
Specifies settings for baud rate, data bits, termination characters, and end-of-line delay used by
the printer port.
STREAM OFF
EDP
PRN
Selects the serial port used for continuous transmission. See Section 7.2 on page 29 for
information about the 120 continuous data format.
Table 3-5. Serial Menu Parameters
