Rice Lake DIGI DSX-1000 User manual

DIGI DSX-1000
Checkweigher
Version 1
Operation Manual
PN 174290

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems®is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete
and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to
make changes to the technology, features, specifications and design of the equipment
without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents i
© Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America.
Specifications subject to change without notice.
Rice Lake Weighing Systems is an ISO 9001 registered company.
March 23, 2017
Contents
1.0 Introduction.................................................................................................................................. 1
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.1 Capacity/Minimum Graduation/Tare range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3.2 Keys and Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.0 Setup ............................................................................................................................................ 7
2.1 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Date and Time Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Communication Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Weight and Measurement Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.0 Communication.......................................................................................................................... 11
3.1 RS-232C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.1 Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.2 Pin Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Control Code and Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 Data Format (Type A, Type W, Type B) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Communication Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.1 Type A (Standard Stream). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.2 Type W (Standard Manual) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.3 Type B (Standard Command) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5 Setpoint Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5.1 Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5.2 Pin Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5.3 Setpoint Signal ON Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5.4 Setpoint Output Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.0 Operation.................................................................................................................................... 17
4.1 Zero Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Tare Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2.1 Manual Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2.2 Digital Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2.3 Clearing a Digital Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3 Print in Weigh Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.4 Setting Weight Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.4.1 Setting Minimum and Maximum Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.4.2 Setting Minimum and Maximum Limits Within a Percentage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4.3 Setting Minimum and Maximum Limits with Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.4 Clearing Minimum and Maximum Weight Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.5 LED Indicator for Weight Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.5 Weight Accumulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6 Internal Count Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.

ii DIGI DSX-1000 Operation Manual
5.0 Maintenance and Troubleshooting............................................................................................ 23
5.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.2 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.3 Software Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.0 Specifications............................................................................................................................ 28
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction 1
1.0 Introduction
The DIGI DSX-1000 is an economical, high resolution checkweigher that quickly responds to changes in applied
weight and utilizes a splash-proof housing.
Manuals can be viewed and downloaded from the Rice Lake Weighing Systems website at
www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Safety
Important
CAUTION
WARNING
DANGER
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in serious injury or
death. Includes hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided could result in serious injury or
death. Includes hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or
moderate injury.
Indicates information about procedures that, if not observed, could result in damage to
equipment or corruption to and loss of data.
General Safety
WARNING
Do not operate or work on this equipment unless this manual has been read and all instructions are
understood. Failure to follow the instructions or heed the warnings could result in injury or death.
Contact any Rice Lake Weighing Systems dealer for replacement manuals.
Failure to heed may result in serious injury or death.
Ensure every individual who operates or works with this unit has read and understands the following safely information.
Important
Do not allow minors (children) or inexperienced persons to operate this scale.
Prior to cleaning, make sure the scale is disconnected from the power source.
Do not use near water.
Do not drop the scale or subject it to violent shocks.
Do not use this product if any of the components are loose or cracked.
Do not use in the presence of flammable materials.
For accurate weighing, the scale must be placed on a flat, level surface.
Operating at voltages and frequencies other than specified could damage the equipment.
Avoid contact with excessive moisture.
Do not make alterations or modifications to the scale.

2DIGI DSX-1000 Operation Manual
1.2 Dimensions
11.5'' (291 mm)
10.7'' (270.9 mm)
13.9'' (351.9 mm)
7.8'' (198.4 mm)
3.8'' (97.1 mm)
Figure 1-1. Dimensions DIGI DSX-1000

Introduction 3
1.3 Electrical Connections
Switch
Power
Power
Selector
A/D
Convertor
LCD
Load Cell
Set Point
Interface
RS-232
Interface
Micro Controller
R5F100G
Figure 1-2. Electrical Connections
CN1
LCD
CN4
Printer
CN5
RS-232
CN3
Set Point
A/D
Convertor
CN6
Load Cell
Power
CN7
AC DC
BOARD
Figure 1-3. Electrical Connections Layout

4DIGI DSX-1000 Operation Manual
1.3.1 Capacity/Minimum Graduation/Tare range
Note
IR is the Internal Resolution. e is the Division (Minimal Increment)
Internal count (full capacity = 300000IR)
Capacity Minimum Graduation Tare Rang e
Table 1-1. Single Interval
Table 1-2. Multi-Interval
Capacity Minimum Graduation Tare Ran g
600 g (1.5 lb) 0.2 g (0.0005 lb) (1e = 100IR) 299.8 g (0.75 lb)
600 g (1.5 lb) 0.1 g (0.0002 lb) (1e = 50IR) 299.9 g (0.75 lb)
600 g (1.5 lb) 0.05 g (0.0001 lb) ( 1e = 25IR) 299.95 g (0.75 lb)
6 kg (15 lb) 2 g (0.005 lb) (1e = 100IR) 2998 g (7.5 lb)
6 kg (15 lb) 1 g (0.002 lb) (1e = 50IR) 2999 g (7.5 lb)
6 kg (15 lb) 0.5 g (0.001 lb) (1e = 25IR) 2999.5 g (7.5 lb)
15 kg (30 lb) 5 g (0.01 lb) (1e = 100IR) 7.495 kg (15 lb)
15 kg (30 lb) 2 g (0.005 lb) (1e = 40IR) 7.498 kg (15 lb)
15 kg (30 lb) 1 g (0.005 lb) (1e = 20IR) 7.499 kg (15 lb)
30 kg (60 lb) 5 g (0.01 lb) (1e = 50IR) 14.995 kg (30 lb)
30 kg (60 lb) 2 g (0.005 lb) (1e = 20IR) 14.998 kg (30 lb)
600 g (1.5 lb) (0-300 g)-0.1 g (1e=50IR) (300g-600 g)-0.2g (1e=100IR) 0 – 299.9 g (0 - 0.75 lb)
6 kg (15 lb) (0-3 kg)-1 g (1e=50IR) (3-6 kg)-2 g (1e=100IR) 0 - 2999 g (0-7.5 lb)
15 kg (30 lb) (0-6 kg)-2 g (1e=40IR) (6-15 kg)-5 g (1e=100IR) 0 - 5.998 kg (0-15 lb)

Introduction 5
1.3.2 Keys and Symbols
lb
lb
HIGH
LOW
lb
lb
Figure 1-4. DIGI DSX-1000 Weigh Mode Display
Table 1-3. Symbols
Symbol Description
Six-digit weight display
Six-digit tare weight display
Six-digit maximum weight display — See Section 4.4 on page 19
Six-digit minimum weight display — See Section 4.4 on page 19
Center of zero — displays when the current zero point is at or within 0.25 d of true zero;
See Section 4.1 on page 17
NET — displays when a tare weight is set. See Section 4.2 on page 17
Tilde — displays when the weight on the scale is stable
This annunciator illuminates from left to right as the weight increases on the scale if
weight limits have been set. The symbol illuminates yellow for weights below the 
minimum limit set, blue for weights between the minimum and maximum limits set, and
red for weights above the maximum limit set. See Section 4.4 on page 19.

Table 1-4. Keys
Key Function
Zero the scale — See Section 4.1 on page 17
Set a tare weight — See Section 4.2 on page 17
Add weight in accumulation — See Section 4.5 on page 22
Not used at this time
Prints numeric weight data only — See Section 4.3 on page 18
Enter mode selection
Set a digital tare weight — See Section 4.2.2 on page 17
Set upper and lower weight limit data — See Section Table 2-2. on page 10
Go back one level
6DIGI DSX-1000 Operation Manual

Setup 7
2.0 Setup
2.1 Calibration
Use the following steps to perform a weight (span) calibration.
1. Power on the scale.
2. Insert a non-conductive tool into the access hole on the bottom of the scale and press the configuration
switch to turn on the SPAN SW.
Access Hole
Front of Scale
Power Switch
Figure 2-1. Bottom View of Scale
3. Press to enter mode selection.
4. Press to enter the calibration mode. A/D COUNT and FULL WEIGHT data are displayed.
5. Ensure there is no weight on the scale.
6. Press . If the zero calibration is good, SUCCESS is displayed. If FAILED is displayed, repeat the
procedure. Contact Rice Lake Weighing Systems Technical Support if unable to obtain a successful zero
calibration.
7. Place test weight equal to full capacity on the scale.
8. Press . If the full scale calibration is good, SUCCESS is displayed. If FAILED is displayed, repeat the
procedure. Contact Rice Lake Weighing Systems Technical Support if unable to obtain a successful full
calibration.
9. Press twice to return to weigh mode.

8DIGI DSX-1000
2.2 Date and Time Setting
Use the following steps to set the date and time on the DIGI DSX-1000.
1. Power on the scale.
2. Press to enter mode selection.
3. Press .
4. Press to display the digital keypad.
5. Enter date and time in order of YY-MM-DD HH:MM:SS.
Figure 2-2. Enter Date and Time
6. Press to accept or press to cancel.
7. Press twice to return to the weigh mode.

Setup 9
2.3 Communication Settings
Use the following steps to configure communication settings on the DIGI DSX-1000.
1. Press to enter mode selection.
2. Press to enter specification settings.
3. Press or to access each specification.
4. Press the option desired for each specification. See Table 2-1.
5. Press
Table 2-1. Specifications (SPEC 141)
Spec. No. Bit 3 Bit 2 Bit 1 Bit 0
0RS-232C PC Protocol (Bit 3,2,1,0)
0000 - Inhibit 0001 - stream type
0010 - manual type 0011 - command type
0100 - DS470 manual 1 0101 - DS470 manual 2
1RTS/CTS handshaking (Bit 3)
0 - On
1 - Off
Baud Rate of RS-232C (Bit 2,1,0)
000 - 4800 bps 001 - 9600 bps
010 - 19200 bps 011 - 38400 bps
2Stop bit of RS-232C (Bit 3)
0 - 1 bit
1 - 2 bit
Data length of RS-232C (Bit 2)
0 - 7 bit
1 - 8 bit
Parity of RS-232C (Bit 1,0)
00 - None
01 - Odd
10 - Even
3Interval of Time out error of RS232C (Bit 3,2)
00 - 1 second
01 - 3 second
10 - 5 second
11 - 10 second
Transmission
condition of RS232-C
(Bit 1)
0 - Weight Stable
1 - Unconditional
Additional parity
code in text of RS-
232C (Bit 0)
0 - No
1 - Yes
4Tare Weight in text of RS-
232C (Bit 3)
0 - No
1 - Yes
Weight unit RS-232C (Bit 2)
0 - Allow
1 - Inhibit
Header Code in text of
RS-232C (Bit 1)
0 - No
1 - Yes
STATUS data in
text of RS-232C
(Bit 0)
0 - No
1 - Yes
5One touch tare printing (Bit 3)
0 - No
1 - Yes
Set Point Type (Bit 2)
0 - Act low
1 - Act high
Sequence number
print (Bit 1)
(not available)
0 - No
1 - Yes
Use Internal Printer
(Bit 0)
(not available)
0 - No
1 - Yes
6Buzzer (Bit 3)
0 - On
1 - Off
Set Point Alarm (Bit 2,1)
00 - On (Under/Over)
10 - Off
Set Point Output (Bit 0)
0 - On
1 - Off
7Print the status against the
target range (Bit 3)
(not available)
0 - No
1 - Yes
When stable and weight
change >= 10 e, RS-232 stream
type output once (Bit 2)
0 - On
1 - Off
RS232C data length of output

weight data (Bit 1)
0 - 7 byte fixed
1 - actual length
8Weight check bar display when negative weight (Bit 3)
0 - Allow
1 - Inhibit
twice to return to the weigh mode.

10 DIGI DSX-1000
2.4 Weight and Measurement Settings
Use the following steps to configure weight and measure settings on the DIGI DSX-1000.
1. Insert a non-conductive tool into the access hole on the bottom of the scale and press the configuration
switch to access the weight and measure settings.
2. Press to enter mode selection.
3. Press to enter specification settings.
4. Press or to access each specification.
5. Press the option desired for each specification. See Table 2-2.
6. Press twice to return to the weigh mode.
Spec. No. Bit3 Bit 2 Bit 1 Bit 0
20 Selection of resolution (Bit 3,2,1,0)
1/1000 1/1500 1/2000 1/2500 1/3000
1/5000 1/6000 1/7500 1/10000 1/12000
1/15000 1/20000 1/25000 1/30000
21 Minimum display (Bit 3,2,1)
000-1 001-2
010-5 011-10
100-20 101-50
110-100
Weight reset when tare (Bit 0)
0 - Allow
1 - Inhibit
22 Decimal point position on weight display (Bit 3,2,1)
000 - No point 001 - 0.0
010 - 0.00 011 - 0.000
100 - 0.0000 101 - 0.00000
Type of Decimal point (Bit 0)
0 - Standard (.)
1 - Europe (,)
23 Manual Tare
Cancellation (Bit 3)
0 - Allow
1 - Inhibit
Tare Subtraction (Bit 2)
0 - Allow
1 - Inhibit
Tare Accumulation 
(Bit 1)
0 - Allow
1 - Inhibit
AUTO tare clear when rezero
(Bit 0)
0 - Allow
1 - Inhibit
24 Zero Tracking when
Tare (Bit 3)
0 - Allow
1 - Inhibit
Digital tare (Bit 2)
0 - Allow
1 - Inhibit
Negative weight dis-
play mask (Bit 1)
0 - Minus (gross) > 9e
1 - Minus (gross) weight
IR mode protected (Bit 0)
0 - No
1 - Yes
25 Re-Zero range (Bit 3,2)
00 - ±2% F.S.
01 - ±4% F.S.
10 - ±10% F.S.
11 - ±100% F.S.
Start range (Bit 1,0)
00 - ±2% F.S.
01 - ±3% F.S.
10 - ±5% F.S.
11 - ±10% F.S.
26 System Base Weight Unit (Bit 3,2)
00 - kg
01 - g
10 - lb
11 - oz
Weight single interval or multi-interval (Bit 1,0)
0 - Single Interval
1 - Multi-interval
27 Weight Range of Data Output (Bit 3)
0 - Always
1 - Over 20e
Tare Range (Bit 2)
0 - 50%
1 - 100%
Digital Tare Print (Bit 1)
(not available)
0 - No
1 - Yes
28 Weight Data Print (Bit 3)
0 - Net, Tare
0 - Net
Header code of digital and preset tare in text of RS-232C (Bit 2) (not available)
0 - “9”
1 - “4”
Table 2-2. Specifications (SPEC142)

Communication 11
3.0 Communication
3.1 RS-232C Interface
3.1.1 Specification
Baud Rate: 4800, 9600, 19200, 38400 bps
Start Bit: 1 Bit
Stop Bit: 1,2 Bit
Data Bit: 7,8 Bit
Parity Bit: Even, Odd, None
3.1.2 Pin Assignment
Table 3-1. Pin Assignment
Inside DSX-1000
CNI (5 pins)
DSX-1000 SIDE
DB9 PC Side
1RXD 2RXD
2RTS 7RTS
3TXD 3TXD
4CTS 8CTS
5GND 5GND
If handshaking is not necessary for the RS-232 equipment being connected to the scale, RTS and CTS do not need
to be connected (Spec. 1). See Section 2.3 on page 9.
3.2 Control Code and Characters
Table 3-2. Control Code and Characters
Control Code Character Description Hex Values
Termination
Code
CR Carriage return 0x0d
LF Line feed 0x0a
Date
0 - 9 Numeric date 0x30 - 0x39
- (minus) Minus sign 0x2d
. (decimal) Decimal 0x2e
(space) Data error or empty 0x20
OF Overflow 0x4f 0x46
UF Underflow 0x55 0x46
Header Code
0Net Weight 0x30
4Ta r e W e i g h t 0x34
BStatus and Weight condition 0x42
VScale Number 0x56
Command
ENQ Enquiry 0x05
ACK Acknowledge 0x06
NAK Not Acknowledged 0x15
TXD
RXD
GND

12 DIGI DSX-1000
3.3 Data Format (Type A, Type W, Type B)
Without additional parity (Total 32 bytes)
Header
Code
Status
Flag
Weight
Condition
Flag CR
Header
Code
Net
Weight
Weight
Unit
1 Byte 1 Byte 1 Byte 1 Byte 1 Byte 7 Bytes 2 Bytes
CR
Header
Code
Tare
Weight
Weight
Unit Cr LF
1 Byte 1 Byte 7 Bytes 2 Bytes 1 Byte 1 Byte
With additional parity (Total 33 bytes)
Header
Code
Status
Flag
Weight
Condition
Flag CR
Header
Code
Net
Weight
Weight
Unit
1 Byte 1 Byte 1 Byte 1 Byte 1 Byte 7 Bytes 2 Bytes
CR
Header
Code
Tare
Weight
Weight
Unit CR
Additional
Parity LF
1 Byte 1 Byte 7 Bytes 2 Bytes 1 Byte 1 Byte 1 Byte
Table 3-3. Status Flags
Status Flag Bit Data Description
Not Used Bit 7 Not Used, always 0
Fixed to 1 Bit 6 Fixed to 1
Not Used Bit 5 Not Used
Not Used Bit 4 Not Used
Not Used Bit 3 Not Used
Weight Overflow Bit 2 1 when weight overflow, 0 when not
Net Bit 1 1 when tare subtraction is used, 0 when not
Additional Parity Bit 0 1 when additional parity code is added in text, 0 when not
Note
If the additional parity is 0x0d, 0x0a or 0x00, it will be changed to 0x1d or 0x10 respectively.
If it is the type A with high speed, the data should be less than 30 bytes.

Communication 13
Example 1: Transmit all data (without additional parity)
Net Weight = 3.46 Tare Weight = 1.200 Weight Status: stable
Scale No. = 100 Weight Unit = kg
Status Flag: 0x42
Weight Condition Flag: 0x42
01000010
By ASCII Code:
0x42 0x42 0X42 0X0d
0x30 0x30 0x30 0x33 0x2e 0x34 0x35 0x36 06b
0x67 0x0d 0x34 0x30 0x30 0x31 0x2e 0x32 0x30
0x30 0x6b 0x67 0x0d 0x0a
Example 2: Transmit only Net weight (without Header Code)
Net weight = 3.456
Note
Specifications must be set to satisfy this condition. See Section 2.3 on page 9.
Example 3: Weight is overflow data
Net weight = OF
Weight Condition Flag Bit Data Description
Not Used Bit 7 Not Used, always 0
Fixed to 1 Bit 6 Fixed to 1
Not Used Bit 5 Not Used
Weight UF Bit 4 1 when weight underflow, 0 when not
Weight OF Bit 3 1 when weight overflow, 0 when not
Negative Net Weight Bit 2 1 when net weight is negative, 0 when not
Weight Stable Bit 1 1 when weight is stable, 0 when not
Zero Sign Bit 0 1 when weight zero sign is set, 0 when not
Table 3-4. Weight Condition Flags
01000010
0x30 0x30 0x33 0x2e 0x34 0x35 0x36 0x0d 0x0a
0x20 0x20 0x20 0x20 0x4f 0x46

14 DIGI DSX-1000
3.4 Communication Method
Note
The communication method is dependent on specification settings. See Section 2.3 on page 9. 
The data communication methods that can be selected are Stream (continuous), Manual and Command. 
In each type of data transmission the weight stable check is dependent on the Specification 3 setting.
3.4.1 Type A (Standard Stream)
The data is transmitted to the PC continuously.
PC DSX-1000
Figure 3-1. Type A (Standard Stream) Communication
3.4.2 Type W (Standard Manual)
The data is sent by pressing . Data can be transmitted immediately or held until the weight becomes stable,
depending on the Specification 3 setting.
PC DSX-1000
See Section 2.3 on page 9.
Figure 3-2. Type W (Standard Manual) Communication

Communication 15
3.4.3 Type B (Standard Command)
The data transmission starts when a command is received from an external source (PC).
PC DSX-1000
Figure 3-3. Type B (Standard Command) Communication
3.5 Setpoint Interface
3.5.1 Specification
• Interface — Open collector (passive) type
• Max. Rated Input Voltage — 24 VDC
• Max. Rated Current — 50 mA
• External Power (VEXT) — (6-15 VDC) 12 VDC Recommended. Max current draw from external power
supply (VEXT) - VDC 100 mA (2 x 50 mA)
3.5.2 Pin Assignment
Table 3-5. Internal Pin Assignments of DIGI DSX-1000
CN3 (6 pins)
1SP1
2GND
3SP2

16 DIGI DSX-1000
3.5.3 Setpoint Signal ON Timing
When the weight display reaches each programmed value, the setpoint signal turns ON. The following figure
shows an example of the setpoint signal ON timing.
Note
When a programmed setpoint value is zero, the setpoint signal will not be ON.
Figure 3-4. Setpoint Signal ON Timing
3.5.4 Setpoint Output Control
By using additional external circuitry the outputs can be triggered by changes in weight. Figure 3-5 is a sample
circuit diagram, showing how the outputs would be wired to relays to drive additional loads with other voltage or
current requirements, and is for reference only.
Figure 3-5. Setpoint Sample Circuitry
