Rice Lake MSI-4260 IS User manual

MSI-4260
Port-A-Weigh Crane Scales
Technical Manual
PN 216250 Rev A
February 27, 2023

© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Revision History
© Rice Lake Weighing Systems ● All Rights Reserved 3
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
Revision History
This section tracks and describes manual revisions for awareness of major updates.
Revision Date Description
A February 27, 2023 Initial manual release with product launch
Table i. Revision Letter History

Contents
MSI-4260 Port-A-Weigh
4 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4.1 Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4.2 Annunciators and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.1 Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.2 Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.3 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Communications Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4.1 Remove Front Casting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4.2 Reinstall Front Casting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2 Zero. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.1 View Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3.2 Clear Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4 Function Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4.1 Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4.2 Total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4.3 View Total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4.4 Net / Gross . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4.5 Peak Hold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4.6 Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4.7 High Resolution Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4.8 Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.0 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.1 Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2 Set Function Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.3 Auto-Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4 Sleep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5 Display Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6 Display Color. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.7 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.8 Total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.9 Filter Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.10 Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.11 Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Contents
© Rice Lake Weighing Systems ● All Rights Reserved 5
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
5.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1 Calibration Switch Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.2 Standard Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3 Initial Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.4 Guidelines for Capacity and Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.4.1 Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.4.2 Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.5 C-Cal Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.6 Calibration Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.7 Auto Zero Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.8 Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.9 Gravity Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.9.1 Compensation by Latitudes and Elevations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.9.2 Compensation by Gravity Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.0 Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.1 Communications Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.2 Printer and Serial Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.2.1 Standard Print Strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.2.2 Control Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.2.3 Printer Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.2.4 Custom Print Formatters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.3 RF Network Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.3.1 802.15.4 RF Network Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.3.2 Hold Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.4 Radio Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.4.1 802.15.4 (XBee 3 and XBee 3-PRO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.4.2 802.15.4 (XBee 2SC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.4.3 Wi-Fi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.4.4 Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.4.5 FHSS (Frequency Hopper Spread Spectrum) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.0 Optional Rugged Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.1 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.1.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.1.2 Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.1.3 Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.1.4 Programmable Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.2 Conflict and Jamming Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3 FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.0 Troubleshooting/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 Service Counters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

MSI-4260 Port-A-Weigh
6 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 7
1.0 Introduction
This manual is intended for use by service technicians responsible for installing and servicing the MSI-4260 Port-A-Weigh.
Configurations and calibration of the scale can be accomplished using ScaleCore Connect software, RF remote control, RF
remote displays, or the front panel keys. See Section 4.0 on page 20 and Section 5.0 on page 27 for information about setup
and configuration of the MSI-4260.
Manuals and additional resources are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information can be found at www.ricelake.com/warranties
1.1 Features
• Automatic power off
• Automatic sleep mode
• The buttons are sealed and rated for over 1 million operations
• Precise high resolution (2500 division standard and up to 10,000 possible) 24 bit A/D conversion coupled with advanced
RISC micro controller
• five large, 1.2'' (30 mm) LED digits displayed in red, green or orange
• Full digital calibration
• Can be calibrated without test weights using C-Cal technology
• Selectable for kg/lb unless prohibited by Legal-for-Trade regulations
• Automatic or manual weight totalization
• High speed Peak mode
• Eight setpoints
• ScaleCore technology
• Two service counters
1.2 FCC Compliance
United States
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la Class A prescites dans le Règlement sur le brouillage radioélectrique edicté par le ministère des
Communications du Canada.

MSI-4260 Port-A-Weigh
8 Visit our website www.RiceLake.com
1.3 Safety
Safety Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
WARNING
Failure to heed could result in serious injury or death.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not stand near the load being lifted as it is a potential falling hazard. Keep a safe distance.
Do not use for purposes other than weight taking or dynamic load monitoring.
Do not use any load bearing component that is worn beyond 5% of the original dimension.
Do not use the scale if any of the components of the load train are cracked, deformed or show signs of fatigue.
Do not exceed the rated load limit of the scale, rigging elements or the lifting structure.
Do not allow multi-point contact with the hook, shackle or lifting eye of the scale.
Do not allow high torque on the scale unless it is specifically designed for high torque.
Do not make alterations or modifications to the scale or associated load bearing devices.
Do not use improperly rated or sized shackles. Use only Rice Lake Weighing Systems’ recommended shackles.
Do not remove or obscure warning labels.
Do not submerge to clean.
For guidelines on safe rigging and loading of overhead scales and dynameters, read the MSI Crane Scale Safety and Periodic
Maintenance Manual (available at www.ricelake.com).
Keep hands, feet and loose clothing away from moving parts.
There are no user serviceable parts within the MSI-4260. Any repairs are to be performed by qualified service personnel only.
The MSI-4260 Port-A-Weigh scale has a safe mechanical overload of 200% and an ultimate overload of 500%. Overloads greater
than 500% could result in structural failure and dropped loads. Dropped loads could cause serious personal injury or death.

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 9
1.4 Display
The keys and display of the MSI-4260 front panel is described below.
Figure 1-1. MSI-4260 Front Panel
1.4.1 Keypad Functions
The functions of the push buttons vary based on the current MSI-4260 mode.
Example of numeric entry: Enter 2500 kg on a 5000 kg capacity scale.
• Press two times for the leftmost blinking digit, press to save that digit selection.
• Press five times for the next blinking digit, press to save that digit selection.
• Press to save that digit selection.
• Press to save the next digit selection.
 displays.
Key Weigh Mode Setup Menu Navigation Numeric Entry
Power Key Turns the MSI-4260 On and Off Exits setup without saving changes; 
displays momentarily and unit enters Weigh mode
Enters decimal point to the left of
the blinking digit
Zero Key Zeros out residual weight on the scale Saves and drops back one menu level; At the root
menu level the Zero key stores the changes and
returns to Weigh mode  displays briefly
Steps back one digit to change or
correct the digit to the left
Tare Key Removes the weight of containers, trucks
or carriers and places the scale in the Net
Weigh mode
Functions as the Enter/Select key Confirms blinking digit and move
to the digit to the right
User Key Programmable to user selectable
functions (Section 4.0 on page 20); This
key is defaulted to the Test function
Functions as the Scroll key Cycles blinking digit through
numbers 0-9
Table 1-1. Key Functions
st
ZERO TARE USER
es
POWER
TF
Sealed calibration switch
Section 5.1 on page 27
RS-232 serial port
Section 6.2 on page 36
IP-68 rated push buttons
es
POWER
st
ZERO
TARE
T
USER
F
USER
F
TARE
T
USER
F
TARE
T
TARE
T
TARE
T

MSI-4260 Port-A-Weigh
10 Visit our website www.RiceLake.com
1.4.2 Annunciators and LEDs
Figure 1-2. Front Panel
WARNING: Wear appropriate hearing protection when any audible alarm is active. Not wearing appropriate hearing
protection may result in hearing loss.
Annunciator Name Description
Center of Zero Indicates that the scale is zeroed and the weight is within 1/4d of zero
Stable Indicates that the weight has settled within the motion window (usually ±1d);
When this symbol is off, the scale will not zero, tare or totalize
BT Low Battery Displays when 10% of battery life remains; LED blinks indicating automatic shutdown will occur
Setpoints Eight user programmable setpoints for early overload warnings;
Red LED = Setpoint 1, Yellow LED = Setpoint 2, Green LED = Setpoint 3
TTL Total Blue LED indicates the total weight displays for five seconds or less
NET Net Indicates the scale is in Net mode; Tare weight has been subtracted from the gross weight
PK Peak Indicates the scale is in Peak Hold mode
lb LB Red LED indicates weight display is in pounds
kg KG Red LED indicates weight display is in kilograms
x1K x1000 Indicates weight display or accumulation beyond the 5 digit display limit by a multiplier of 1000; If 1K is
illuminated, read the total as the displayed value multiplied by 1000
Acknowledge Green LED provides feedback to the operator that incoming remote commands have been received
Display The main display digits include five, 1.2'' (30 mm) brightness LED load display; Main display may be red,
orange, or green depending on the color setting
Table 1-2. Annunciators and LEDs
0

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 11
2.0 Installation
The MSI-4260 cast aluminum enclosure is rated at NEMA Type 4 IP 66. It hangs from a crane using properly sized shackles.
WARNING: Refer to the Crane Scale Safety and Periodic Maintenance Manual (PN 153105) for safe loading and rigging
guidelines when installing the model MSI-4260.
Regular maintenance inspections of the lifting system should be performed to ensure safety. Pay particular attention for
signs of stress on any element in the load train.
Use the appropriate interface hardware for the capacity of the scale.
• If the interface hardware does not fit properly, Rice Lake Weighing Systems can supply the MSI-4260 with oversized
lifting eyes or shackle interfaces.
• If the crane hook is too large to fit in the lifting eye with single point interface, then install the scale using adaptive rigging.
• If multiple attachments are needed, use a shackle or ring to attach multiple lines to keep a single point attachment to the
scale.
IMPORTANT: Using an oversized shackle or hook to interface with the MSI-4260 can cause off center loading and stress
points that will reduce the life of the lifting eye or hook.
Single point attachments are necessary to ensure the safety and accuracy of the scale system.
2.1 Unpacking
When unpacking the MSI-4260, ensure that all assembly parts are accounted for. Check the MSI-4260 for any visible damage.
If any parts were damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately. If the MSI-4260 must
be returned, it must be properly packed with sufficient packing materials. Whenever possible, use the original carton when
shipping the unit back.
2.2 Battery Pack
The MSI-4260 is powered by a 12V Sealed Lead Acid (SLA) rechargeable battery. This battery operates for up to 100 hours
(depending on LED brightness setting) before requiring recharging. Charging time for a completely discharged battery is up to
eight hours. A spare battery pack is recommended to keep the MSI-4260 in continuous operation.
IMPORTANT: To obtain maximum service life from batteries, store between -4°F and 122°F (-20°C and +50°C).
Stored batteries should be recharged every three months. The battery is fully charged when the status indicator on the
battery charger flashes.
2.2.1 Battery Life
The battery life of the MSI-4260 depends on several factors:
• LED display brightness and number of segments lit
• RF activity
• Battery age
• SLA battery condition
The MSI-4260 includes the following power saving features:
• Automatic Power Off mode — Senses no activity after the set amount of minutes and turns the scale off
• Automatic Sleep mode — Dims the display after a set amount of minutes of no scale activity
The MSI-4260 automatically turns off when the SLA battery drops to approximately 10.5V. Recharge the battery when this
happens, SLA batteries benefit from frequent recharging and can be recharged when it still has available life.
Due to the maintenance discharge imposed on the battery by the MSI-4260 electronics, do not store the MSI-4260 with the
battery inside. Remove the battery if it will not be used for more than two weeks.
IMPORTANT: Leaving a discharged battery in the scale, which has a maintenance battery drain, can result in a deep
discharged battery which will shorten its service life.

MSI-4260 Port-A-Weigh
12 Visit our website www.RiceLake.com
NOTE: If the scale is in continuous use, a fully charged spare battery is recommended. Replace the drained battery as close
as possible to the low battery warning.
SLA batteries that have not been deep discharged should withstand 500 to 1500 charging cycles.
Low battery warning annunciator indicates about two to four hours of use before MSI-4260 powers off.
If the MSI-4260 is not going to be used again soon, remove SLA battery to prevent deep discharge while unit is in storage.
Recycle the battery at an authorized recycling center when the average life drops to 20 hours or less.
2.2.2 Battery Charger
The MSI-4260 is shipped with a battery charger designed to charge and maintain the battery. Exact charging time depends on
the degree of battery discharge. A battery removed when the low battery warning first appears should take about four hours to
fully charge.
DANGER: Charger is for indoor use only and should not be used in wet locations.
NOTE: When the battery is new, it might take significantly longer for the initial charge. It is recommended to charge a new
battery for 24 hours. It might take several charge/discharge cycles before full capacity is reached. Deep discharged
batteries also take significantly longer to charge.
Figure 2-1. Battery Charger Connected to Battery
The battery charger illuminates annunciators as the battery charges.To charge the battery:
1. Remove the battery from the MSI-4260 (Figure 2-2 on page 13).
2. Connect the charger assembly to the AC power supply (86-260 VAC). The power annunciator displays red.
NOTE: If the power status light fails to illuminate, check the AC power connection to ensure the jack is fully seated. AC
power cords suitable for any world location are available from Rice Lake Weighing Systems.
3. Plug the polarized connector into the jacks on the battery. Charging annunciators illuminate to represent charge
percentage.
4. Charge until all status annunciators fully illuminate.
When the charge cycle is complete, the battery can be left on the charger until it is needed. The charger keeps a maintenance
float charge on the battery to ensure the best possible operation times.
IMPORTANT: For maximum service life from batteries, the manufacturer suggests recharging after each 20 hours of use.
Continuous deep discharging reduces maximum battery life cycle.
100%
POWER
CHARGING
80%
50%
20%

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 13
2.2.3 Battery Replacement
1. Turn the MSI-4260 off.
2. Secure the battery cover.
3. Release the latches holding the battery cover.
4. Slowly lower the cover while holding the battery in place.
5. Remove the battery by pulling straight back.
6. Install a fully charged battery by plugging it into the exposed battery jacks.
7. Close the battery cover.
8. Reset the latches. Ensure the latches are secured and the cover is firmly in place.
Figure 2-2. Remove Battery
IMPORTANT: Periodically, inspect the battery latches for fit. Adjust the screw latch by rotating the catch on its threads to
maintain a tight seat on the battery O-ring.
CAUTION: The 12V Sealed Lead Acid battery can be a dangerous falling hazard. When opening the battery hatch, be sure to
hold the battery to prevent it from falling. The batteries contain lead and should be recycled when it has reached its end of
life.

MSI-4260 Port-A-Weigh
14 Visit our website www.RiceLake.com
2.3 Communications Port
The MSI-4260 has a single communications port allowing access to the embedded ScaleCore through the terminal access
mode or ScaleCore Connect. The terminal access mode is used for updating scale firmware while ScaleCore Connect can be
used for calibration and configuration, backup and adjusting scale settings. This communications port is not intended for output
use.
The MSI-4260 comes standard with one communications port cable wired for RS-232 following the AT standard for 9-pin serial
cables (DCE). An un-terminated cable is also available for wiring the serial cable for RS-232.
Table 2-1 shows the wiring color code.
Figure 2-3. Comm Port Cable Assignments Examples
Signal Wire Color
TxD (transmitted data) Brown
RxD (received data) Black
CTS (clear to send) Gray
RTS (request to send) White
GND (ground) Blue
PG (protective ground) Drain Wire
Table 2-1. RS-232 Wiring Code
1
2
3
4
5
6
7
8
(NC) 9
Brown (TD)
Black (RD)
Blue (GND)
Gray (CTS)
White (RTS)
Jumper 1-6-4
RS-232 DCE
9-Pin Female ‘D’
Solder Cup View
Standard wiring for direct
4260 to Computer connection
RS-232 DTE
9-Pin Male ‘D’
Solder Cup View
Brown (TD)
Black (RD)
Blue (GND)
Gray (CTS)
White (RTS)
Jumper 1-6-4
1
2
3
4
5
6
7
8
9 (NC)
Wiring for direct 4260 to
Printer/Scoreboard connection

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 15
2.4 Servicing
Rice Lake Weighing System’s dealer network provides both on-site and depot servicing of MSI-4260 crane scales. Please
contact a local dealer or Rice Lake Weighing Systems to obtain a return material authorization (RMA). Due to the weight and
size of many products, it is not always necessary to return the whole scale. Lower swivel hook assemblies and upper lifting
shackles on 50k capacity models and above do not need to be returned for service or recalibration. There are no user
serviceable parts inside the MSI-4260. Depot repair is performed with module and harness swaps. If the electronics are at fault,
often the front casting section is all that needs to be returned.
Figure 2-4. Remove Front Casting
2.4.1 Remove Front Casting
See the following procedure to remove the front casting:
1. Remove the cap screws (x4).
2. Unplug connectors.
3. Package the front casting well for safe shipping.
2.4.2 Reinstall Front Casting
See the following procedure to reinstall the front casting:
1. Clean the front casting and bulkhead o-ring grooves with isopropyl alcohol.
2. Reconnect the load cell cables and power cables then tighten the cables.
3. While securing the o-ring, ensure the o-ring is flush with the o-ring grooves.
WARNING: Replace damaged o-rings when necessary. Damaged o-rings may break the unit seal, allowing water
penetration.
4. Insert the bolts (x4) into the front casting then torque the bolts to 20–25 ft-lbs.
NOTE: Apply anti-seize compound as necessary.

MSI-4260 Port-A-Weigh
16 Visit our website www.RiceLake.com
3.0 Operation
The following sections describe the Weigh mode operation of the MSI-4260.
3.1 Power
The power key turns the MSI-4260 power on. While in Weigh mode, it also turns the power off.
Press to turn on the power. The following sequence displays:
1. All LED segments light at full brightness as a display test.
2.  displays, followed by the software version number.
3.  followed by the weighing standard.
4.  displays, followed by the battery voltage.
5.  displays, followed by the display counting from 00000 to 99999.
6.  displays, followed by the C-CAL value.
7. MSI-4260 enters Weigh mode.
While in Weigh mode, press to turn off the power.
IMPORTANT: The scale has a maintenance battery drain. Always remove the battery if the scale will be off for an extended period
of time. Leaving a discharged battery in the scale can result in a deep discharged battery which will shorten its service life.
3.2 Zero
The zero key sets the zero reading of the scale.
Press to remove small deviations in zero when the scale is unloaded. For zeroing (taring) package or pallet weights,
see Section 3.3. The zero key can be used in GROSS or NET mode.
NOTE: The backup memory in the unit stores the zero reading and retains it even if the power fails.
Zeroing while in NET mode will zero the GROSS weight causing the display to show a negative tare value.
The scale must be stable within the stable window.
The unit will only zero if is on and there has been no activity for two seconds. If a motion ceases within the motion
window in that time, the scale will zero.
The scale will accept a zero setting over the full range of the scale (NTEP and other Legal for Trade models may have a
limited zero range).
Zero settings above 4% of full scale will subtract from the overall capacity of the unit.
Example: If 100 lb on a 1,000 lb scale is zeroed, the overall capacity of the scale will reduce to 900 lb, plus the
allowed over-range amount.
3.3 Tare
Tare is used to zero out a known weight, such as a packing container or pallet, and display a NET weight. The TARE function is
defined as a Tare-In or Tare-Out operation.
To tare the scale:
1. Hang the empty container from the scale.
2. Press to enter a tare value. The MSI-4260 stores the current weight as a tare value and subtracts the value of
the container from the GROSS weight.  displays and the Weigh mode changes to NET.
3. Add the product to the packing container. The NET weight displays.
NOTE: To set a new tare, the existing tare must first be cleared. The MSI-4260 will not set a new tare over an old tare.
es
POWER
es
POWER
st
ZERO
TARE
T

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 17
3.3.1 View Tare
To view the GROSS weight without clearing the tare value:
1. Program to the NET/GROSS function (Section 4.2 on page 21).
2. Press to toggle between NET and GROSS values. This will only work if a tare value has been established.
NOTE: The backup memory in the MSI-4260 stores the Tare reading and can restore it even if power fails.
Only positive GROSS weight readings can be tared. The STABLE annunciator must be on, indicating weight reading is
stable. Setting or changing the tare has no effect on the GROSS zero setting. Taring will reduce the apparent over range of
the scale. The RF Remote Control has NET/GROSS permanently available.
Example: Taring a 100 lb container on a 1,000 lb scale, the scale will overload at a NET weight of 900 lb (1,000-
100) plus any additional allowed overload (usually 4% or 9d).
3.3.2 Clear Tare
To clear a saved tare value, press . The GROSS weight displays.
NOTE: Only positive gross weight readings can be tared.
The must be off indicating weight reading is stable.
Setting or changing the tare has no effect on the gross zero setting.
Taring will reduce the apparent over-range of the scale.
The scale stores the tare value in non-volatile memory and is restored when power is cycled.
Example: Taring a 100 lb container on a 1000 lb scale, the scale will overload at a net weight of 900 lb (1000-100)
plus any additional allowed overload (usually ~4% or 9d).
3.4 Function Key
The key can be programmed in the setup menu (Section 4.2 on page 21) to one of the following functions. Some
functions require additional programming in the setup menu to work correctly.
3.4.1 Test
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to scroll through
the following sequence and returns to Weigh mode:
1. All LED lights display momentarily at once.
2.  displays, followed by the software version number.
3.  followed by the weighing standard
4.  displays, followed by the battery voltage.
5.  displays, followed by the display counting from 00000 to 99999.
6.  displays, followed by the C-CAL value.
NOTE: Other internal tests are performed and if any test fails, an error code displays. See Section 8.0 on page 45 for
information on the troubleshooting guide.
Automatic Scroll Test
• Press to start the test
The unit automatically scrolls through the test sequence and returns to Weigh mode
USER
F
USER
F
TARE
T
USER
F
USER
F
USER
F

MSI-4260 Port-A-Weigh
18 Visit our website www.RiceLake.com
Single Step Test Mode
To stop the automatic scroll of the test procedure, begin the automatic scroll test and press again within two seconds to
enable a single step test mode.
1. Press to scroll through the available test functions.
2. Press to start or display the individual tests.
3. Press to exit individual tests.
4. Press to exit from the test function.
3.4.2 Total
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to perform the
total function that has been be set in the setup menu. That can be, , , , , or For more
information on these parameters and setup see Section 4.8 on page 24. If nothing has been set, nothing will happen when
is pressed.
• Press to start the complete the total function
NOTE: The Total mode must be programmed from the Setup menus before the USER key will function.
3.4.3 View Total
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to display total
weight followed by the number of samples that have been saved.
1. Press to display the total weight.
2. With the Total weight displayed, press to clear.
3.4.4 Net / Gross
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to switch the
display between NET and GROSS modes. This will only work if a tare value has been established.
• Press to toggle between NET and GROSS modes
NET weight is defined as GROSS weight minus a tare weight.
The operator can switch back to GROSS from NET without clearing the tare value. Only clearing or setting a new tare will
change the tare value held before switching into GROSS mode.
NOTE: OIML Legal for Trade units only: The NET/GROSS key is a temporary action only. The GROSS weight displays for
two seconds and then the display returns to the NET mode. The only way to return to permanent GROSS readings is to
clear the tare (Section 3.3.2 on page 17).
USER
F
USER
F
TARE
T
st
ZERO
st
ZERO
USER
F
USER
F
USER
F
USER
F
USER
F
st
ZERO
USER
F
USER
F

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 19
3.4.5 Peak Hold
When the key is programmed to - (Section 4.2 on page 21), pressing the key clears and re-enbles the scale to
only update the display when a higher weight reading is established. The peak hold function uses a high-speed mode of the
A/D converter allowing it to capture transient weights at a far higher rate than typical scales.
Peak hold is cleared and re-enabled with the , that has been set to -.
Peak hold is not available on NTEP or OIML Legal for Trade certified scales.
3.4.6 Units
When the key is programmed to  (Section 4.2 on page 21), pressing the key changes the displayed units.
• Press to toggle display between available units
NOTE: Unit switching is not available on OIML certified Legal-for-Trade scales.
3.4.7 High Resolution Test Mode
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to toggle
between normal Weigh mode and High Resolution Test mode. High Resolution Test mode displays weight at x10 resolution.
While in High Resolution Test mode, all of the annunciators flash to indicate that the weight display is not set to the approved
legal-for-trade resolution.
• Press to toggle between normal and x10 resolution display
In some cases, the displayed weight in high resolution test mode will require six digits to fully display. In these cases, only the
five least significant digits will be displayed. The full weight can be displayed in normal resolution by pressing the function
button.
Ex: 1000.02 kg displays as 000.02 kg.
NOTE: High resolution test mode is for scale service and diagnostic use only.
Increasing the scale display resolution beyond the calibrated value does not increase scale accuracy.
High resolution test mode is not available in HB-44 and R-76 standards.
3.4.8 Print
When the key is programmed to  (Section 4.2 on page 21), pressing the key prompts the scale to print.
• Press to print
NOTE: The print option must be installed and the print function must be set up in order for the print button to work. See
Section 6.2 on page 36 for print setup information.
USER
F
USER
F
USER
F
USER
F
USER
F
USER
F
USER
F
USER
F

MSI-4260 Port-A-Weigh
20 Visit our website www.RiceLake.com
4.0 Setup
The Setup menu enables configuration of the MSI-4260. This section details settings and parameters that are configured in the
Setup menu. For navigation and numeric entry information, see Section 1.4.1 on page 9.
4.1 Setup Menu
To enter into the MSI-4260 setup menu, press and simultaneously.
Parameters Choices Description
  Function User Key 1 – User definable key that can be programmed to one of several functions
Function User Key 2 – User definable key that can be programmed to one of several functions;
Only available on the RF remote being used with the MSI-4260
 Test Display – Section 3.4.1 on page 17
 Total – Section 3.4.2 on page 18
 View Total – Function always available on the RF Remote (Section 3.4.3 on page 18)
 Net/Gross – Function always available on the RF Remote (Section 3.4.4 on page 18)
 Peak Hold – Section 3.4.5 on page 19;
Function not available or non-functional in OIML R76 or NTEP HB44 modes
 Units – Section 3.4.6 on page 19;
Function not available or non-functional in OIML R76 & 1Unit modes
 High Resolution – x10 display resolution; For testing and maintenance use only; Not a legal Weigh mode; Does not
increase scale resolution or accuracy Section 3.4.7 on page 19
 Print – Section 3.4.8 on page 19
 




Auto Off Time – Prolongs battery life of scale by turning power off after the set time (in minutes) that the scale is not in
use (Section 4.3 on page 21)
 



Sleep – Time (in minutes) before unit will enter the sleep mode (Section 4.4 on page 22)
 




LED Display Intensity – Used to set the display brightness (Section 4.5 on page 22)
  Red
 Orange
 Green
 Color changes based on passing setpoints 1 and 2; when selected, if setpoint 2 trips, the display color changes to
orange; when setpoint 1 trips, the display color changes to red (Section 4.6 on page 23)
 


Setpoint 1 to 8 – Used for warnings or process control (Section 4.7 on page 23)
 




Total Mode – accumulation of multiple weighments (Section 4.8 on page 24)
 


Weight Filter – allows the scale to adjust to situations where there may be movement (Section 4.9 on page 25)
Table 4-1. Function Key Settings
es
POWER
USER
F
