RL-DBS-2
Dual-Range Digital Baby Scale
Technical Manual
Disponible
en Español
Visite ricelake.com/spanish
para ver todos los materiales
RLWS disponibles en Español
February 10, 2020 PN 168522 Rev E

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2.0 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 Display Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Set Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3.1 KG Units Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3.2 LB/OZ Units Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3.3 Unlock Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.4 Weigh With A Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.5 Weigh Without A Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Firmware Version 2016 and After . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.2 Firmware Version Prior to 2016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.0 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.1 Basic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.0 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

RL-DBS-2 Dual-Range Digital Baby Scale
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
The Rice Lake Dual-Range Digital Baby Scale (RL-DBS-2) provides precise weighing of babies for accurate, reliable and
repeatable weighments. Movement compensation technology eliminates errors caused by spontaneous movement of the
baby and the weight can be displayed in pounds/ounces or in kilograms.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com/health
Figure 1-1. RL-DBS-2 Dual-Range Digital Baby Scale
1.1 Safety
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Ensure every individual operating or working with this unit has read and understands the following safety information.
Do not transport the scale with an infant on the weighing tray.
Clean the scale regularly to avoid cross contamination.
Do not allow minors (children) or inexperienced persons to operate this scale.
Do not use in the presence of flammable materials.
Do not use this product if any of the components are loose or cracked.
Do not drop the scale or subject it to violent shocks.
For accurate weighing, the scale must be placed on a level, stable surface.
Weight exceeding the maximum rated scale capacity may damage the scale.
Avoid contact with excessive moisture.
Do not make alterations or modifications to the scale; any alterations void the warranty.
For accurate weighing, verify proper setup is complete prior to first use. See Section 3.2 on page 4.
Operation at voltages and frequencies other than specified could damage the scale.
Utilizing adapters not supplied by Rice Lake Weighing Systems voids all warranties.
DANGER
WARNING
CAUTION
IMPORTANT
WARNING

RL-DBS-2 Dual-Range Digital Baby Scale
2 Visit our website www.RiceLake.com
2.0 Setup
The RL-DBS-2 comes fully assembled and includes the scale and a 120 V or 230 V AC adapter. Immediately after unpacking,
visually inspect the RL-DBS-2 to ensure all components are included and undamaged. If parts were damaged in shipment,
notify Rice Lake Weighing Systems and the shipper immediately.
Use the following instructions for scale setup:
1. Place the scale on a sturdy, level surface.
2. Connect the 120 V or 230 V AC adapter to the back of the scale.
3. Plug the AC adapter into a power source.
Figure 2-1. AC Power Connection Site
The RL-DBS-2 can also be powered by four AA alkaline batteries if an additional power source is not available. A battery
powered scale automatically turns off after two minutes of not being used to save battery life. Replace the batteries or connect
to an AC power source as soon as possible if the low battery indicator (Lo) displays.
Figure 2-2. Low Battery Indicator
AC Power Connection
120 V Adapter 230 V Adapter

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 3
3.0 Operation
The RL-DBS-2 accurately weighs babies up to 44 lb (20 kg) and features a dual-range capacity for increased precision from
0-22 lb (0-10 kg). The weighing surface also includes a ruler for measuring the length of the baby. The built-in ruler can
measure babies up to 22.5 in (57 cm).
If the scale is battery powered and has not been used for two minutes, it automatically turns off to save battery life.
3.1 Display Descriptions
The following section describes the RL-DBS-2 operating keys and their functions.
Figure 3-1. RL-DBS-2 Display
The RL-DBS-2 comes pre-calibrated from the factory.
Item Description Function
1 Motion annunciator Displays when a weight reading is complete
2 Negative/Minus annunciator Indicates a negative weight reading
3 Zero annunciator Indicates the scale is stable and ready for use
4 Memory annunciator Indicates the last weight measurement is displayed after pressing RECALL
5 6-Digit LCD digital display Displays the weight in pounds/ounces or kilograms
6 On/Off Press to turn On
Press and hold to turn Off
Tare With weight on the scale, short press to tare off the weight, 0 displays
7 LB/KG Selects pounds/ounces or kilograms
8 RECALL Recalls the last weight measurement
Example: Weigh a baby on the scale and then remove the baby
Press RECALL and the baby’s weight displays again
9 LB/OZ annunciator Indicates the scale is weighing in pounds/ounces
KG annunciator Indicates the scale is weighing in kilograms
Table 3-1. Front Panel with Annunciators Displayed
Note
ON/TARE
LB/KG
RECALL
zero mem lb oz
1
2
34
6
7
8
5
9
Note

RL-DBS-2 Dual-Range Digital Baby Scale
4 Visit our website www.RiceLake.com
3.2 Initial Setup
Use the following steps to set up and verify the RL-DBS-2 upon initial power up and periodically thereafter.
1. Plug AC adapter cable into the back of the scale (Figure 2-1 on page 2) and the AC adapter plug into a power source.
2. Turn on the scale. A self test runs and 0.00.0 lb or 0.00 kg displays when complete.
3. Place a weight, not exceeding 40 lb, on the scale. The weight measurement is complete when Ο displays.
4. Press to select unit of measure, lb/oz or kg.
5. Remove the weight from the scale. To display the weight again, press .
If setup procedure fails, see Section 5.3 on page 8. If the problem is not resolved, refer to a qualified service provider.
3.3 Set Units
The RL-DBS-2 can be set to display weights in lb/oz only, kg only, or to toggle between lb/oz and kg units on the scale.
3.3.1 KG Units Only
Lock the weight units to display in kg only.
1. Ensure the scale is turned on.
2. Press to change the displayed units to kg.
3. Press and hold for five seconds until kg flashes.
4. Release . The weight units are now locked in kg. Pressing does not switch units to lb/oz.
3.3.2 LB/OZ Units Only
Lock the weight units to display in lb/oz only.
1. Ensure the scale is turned on.
2. Press to change the displayed units to lb/oz.
3. Press and hold for five seconds until lb oz flashes.
4. Release . The weight units are locked in lb/oz. Pressing does not switch units to kg.
3.3.3 Unlock Units
Unlock the weight units to toggle between lb/oz and kg.
1. Ensure the scale is turned on.
2. Press and hold for five seconds until kg or lb oz flashes.
3. Release . Pressing toggles units between lb/oz and kg.
LB/KG
RECALL
Note
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG
LB/KG

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 5
3.4 Weigh With A Tare
The tare function removes the weight of additional items on the scale, such as a pad or blanket, at the time the baby is weighed.
1. Turn on the scale. 0:0.0 lb oz or 0.00 kg displays.
2. Place a pad on the weighing tray, ensuring the edges of the pad are not touching the stand. Ο displays when the
weight reading is complete.
3. Press to remove the weight of the pad or any other accessory on the weighing tray.
4. Place a baby on the scale. Ο displays when the weight reading is complete.
5. Remove the baby from the scale.
6. Press to display the weight again, if necessary.
3.5 Weigh Without A Tare
Use this procedure when there are no additional items on the scale at the time the baby is weighed.
1. Turn on the scale. 0:0.0 lb oz or 0.00 kg displays.
2. Place a baby on the scale. Ο displays when the weight reading is complete.
3. Remove the baby from the scale.
4. Press to display the weight again, if necessary.
ON/TARE
RECALL
RECALL

RL-DBS-2 Dual-Range Digital Baby Scale
6 Visit our website www.RiceLake.com
4.0 Calibration
This section contains procedures on how to calibrate the RL-DBS-2 based on the year of the firmware version.
4.1 Firmware Version 2016 and After
Use the following instructions to calibrate the RL-DBS-2 with a newer version of firmware.
1. Ensure the scale is installed on a level surface.
The scale needs to be off at the start of the calibration procedure.
2. If using kg weights, the scale needs to be set up using the following instructions (skip to step 3 if using lb weights).
• Press and hold and (at the same time) until CAL displays.
• Release the keys. The scale displays the raw A/D counts.
• Press . CAL displays and lb lights.
• Press to switch to kg. CAL displays and kg lights.
• Press and hold to turn the scale off.
3. Press and hold and (at the same time) until CAL displays.
4. Release the keys. The raw A/D counts display.
5. Press again. C20 briefly displays and lb is lit, then 0.00 displays. (If calibrating in kg, C10 displays and kg is
lit, then 0.00 displays.)
6. Load the scale with a 20 lb (10 kg) test weight.
7. Press . C40 briefly displays and lb is lit, then 0.00 displays. (If calibrating in kg, C20 displays and kg is lit,
then 0.00 displays.)
8. Load the scale with a 40 lb (20 kg) test weight.
9. Press . End displays and the scale turns off automatically.
10. Remove test weight from the scale.
11. Turn on the scale.
12. Place a known weight onto the scale to confirm the correct calibration. If it is not correct, repeat the calibration
procedure.
