Ricoh Aficio SP C431DN-HS
Color HotSpot Printer
Simply print any document
from anywhere at any time

Ricoh Aficio SP C431DN-HS Color HotSpot Printer
Ricoh places the power of driverless mobile
printing in the hands of every user.
That’s right—high-resolution, full-color 42-ppm laser printing from
anywhere. All you need is Internet access because the RICOH®
Aficio® SP C431DN–HS comes bundled with a one year subscription
to PrinterOn Mobile Printing Service*. Ricoh’s HotSpot technology
is the only customizable mobile printing solution completely
embedded inside a desktop printer. The SP C431DN-HS Color
HotSpot Printer offers a fast and easy means for corporate guests,
clients, traveling executives and mobile employees to print e-mails
and attachments, documents and Web pages using virtually any
Internet-enabled device…without the need for IT support,
to install drivers, apps, cables or authenticate users.
* Additional one year or multi-year Subscription
Extensions are available for an additional fee.

A Multitasking Printer
The Ricoh Aficio SP C431DN-HS Color HotSpot
Printer delivers the added value of serving
networked users—in addition to meeting the
need for efficient mobile printing—all in a
single space-saving device.
• Allow mobile professionals and field-based sales reps and techs to print
across the Web using any Internet-enabled laptop, iPad®, handheld device,
or smartphone including BlackBerry®, iPhone® and Android® products
quickly, conveniently and securely.
• Leverage the SP C431DN-HS’s powerful 600 MHz controller and generous
memory capacity to serve the everyday printing needs of authorized users.
• Lower your total cost of ownership with a single solution that enables
networked employees as well as temporary users to easily print with
increased productivity while reducing IT support requirements across your
organization.
A Secure, Embedded Solution
The SP C431DN-HS provides access to brilliant
full-color network printing without giving
unmonitored access to your network.
• Web-based PrinterOn Mobile Printing Service operates totally
independently from your company network. All mobile print jobs are
processed outside your company firewall.
• Install a completely embedded solution. All hardware and software are
pre-loaded inside the printer. That means no external appliances, keypads
or servers at the installation site.
• Mitigate the risk that sensitive documents will be seen in the printer tray
by an unauthorized party. Files can only be printed after the job owner
enters a private release code for each job at the machine.
Easily Fits Into Any Environment
or Workflow
Public or private network, paid service or free
amenity, the SP C431DN-HS fits anywhere
convenient mobile printing is required.
• Install HotSpot printing as a free public service to attract new customers or
boost loyalty among hotel and convention center guests.
• Set up the SP C431DN-HS as a chargeable service to recover printing costs
or generate new revenues. The HotSpot mobile printing solution integrates
seamlessly with PayPal™, the global leader in online payment solutions.
• Use HotSpot as a productivity-enhancing tool for executives on the go,
who can be sure their job will not be printed until they enter their unique
private release code at the machine.
• Change the design of the customizable PrintSpots™ Web page to reflect
your business identity. Add services, print job options, job confirmation/
approval steps, additional printers, links to other Websites and more
to present HotSpot printing as a value-added service exclusive to your
establishment.
MobileConvenientColorPrint
Build your brand. Take ownership of the
mobile printing service by customizing the
HotSpot printer’s Web page with your
company’s logo, colors, targeted messages
and links to other services.
Offer convenient printing to corporate
guests and visitors without having to
access your company’s network.
The Total
Green Office
Solution
Ricoh continues its long-
standing commitment to
developing office solutions
with environmentally friendly
and superior energy- and
supply-saving features,
without compromising
productivity.

www.ricoh-usa.com
R3253
Main Unit Specifications
Configuration Desktop Color Laser Printer
Technology Laser beam scanning &
electrophotographic printing
Dual-component toner development
4 drum tandem method
Keypad Integrated 12-key alphanumeric keypad
Resolution 600 x 600 dpi (1 bit)
600 x 600 dpi (2 bit)
1200 x 1200 dpi (1 bit)
Print Speed (LTR) 42-ppm Full-color & Monochrome
First Print Speed Full-color: 15 seconds
Monochrome: 10 seconds
Warm-up Time 50 seconds or less
Standard Paper Supply 550-sheet Tray + 100-sheet Bypass Tray
= 650 sheets
Optional Paper Supply 550-sheet Paper Feed Unit (Up to 3
may be installed)
Maximum Paper 2,300 sheets
Capacity
Automatic Duplexing Standard (100% productivity)
Acceptable Paper Sizes*:
Std. & Optional Trays 3.9" x 5.8" to 8.5" x 14" (98 mm x
148 mm to 216 mm x 356 mm)
Bypass Tray 2.8" x 5.0" to 8.5" x 49.6" (70 mm x
127 mm to 216 mm x 1260 mm)
* HotSpot print jobs default to either Letter or Legal size. Other paper sizes
and envelope printing are only available when the device is used as a
standard network printer.
Acceptable Paper Weights:
Std. & Optional Trays 14 – 59 lb. Bond / 120 lb. Index
(52 – 220 g/m2)
Bypass Tray 14 – 69 lb. Bond / 140 lb. Index
(52 – 256 g/m2)
When Duplexing 16 – 44 lb. Bond / 90 lb. Index
(60 – 163 g/m2)
Output Capacity 500 sheets, face down
Dimensions (WxDxH) 17.48" x 25.91" x 19.29"
(444 mm x 658 mm x 490 mm)
Weight 126 lb. (57 kg)
Power Requirements 120 – 127V, 60Hz
Power Consumption Maximum: 1520W or less
Operating: 894W or less
Energy Saver: 110W
Sleep: 6W
Print Controller Specifications
CPU 600 MHz
Memory 768 MB RAM standard/maximum
Hard Disk Drive 80 GB (standard)
Standard Interfaces 10/100Base-TX Ethernet
USB 2.0 Host (Type A)
USB 2.0 Hi Speed (Type B)
SD Card slot for JAVA-based device
Optional Interfaces IEEE 802.11a/g Wireless LAN
Gigabit Ethernet
IEEE 1284/ECP Parallel
Printer Languages/ PCL 5c
Drivers* PCL 6
Adobe PostScript 3 + PDF Direct Print
* Page Description Languages are accessible for standard network printing only.
Fonts PCL: 45 fonts + 13 International fonts
PostScript 3: 136 fonts
Network Protocols TCP/IP (IPv4, IPv6)
AppleTalk
IPX/SPX (optional)
Supported Windows 2000, XP, Vista, 7
Environments Server 2003 & 2003R2, Server 2008
Mac OS 8.6 – 9.x, OS X v.10.2+
Novell NetWare v 6.5+, SAP R/3
Citrix Presentation Server
UNIX (Ricoh Filter Phase 11)
Software Utilities Web Image Monitor
Web SmartDeviceMonitor
SmartDeviceMonitor for Admin
@Remote
Security Capabilities Enhanced Locked Print-NX
Administrator Authentication (5 levels)
User Authentication (5 types including
500 User Codes)
SNMP v3 Authentication, IPsec
Communications
128-bit SSL Print Job Data Encryption
User Lockout/Auto Logout
Locked Print
HDD Data Encryption +
DataOverwriteSecurity System (DOSS)
Address Book & Password Encryption
WPA (Wi-Fi Protect Access)
Options & Accessories Part #
IEEE 802.11a/g Wireless LAN (Type L) 403000
Gigabit Ethernet (Type A) 402547
IEEE 1284/ECP Parallel (Type A) 411699
Camera Direct Print Card (Type H) 406676
HDD DataOverwriteSecurity (Type K) 402998
HDD Encryption Unit (Type D) 403113
SD Card for Netware Printing (Type D) 406688
Paper Feed Unit (PB1020)* 406691
Tip-resistant Caster Table (Type C) 406755
1 Year HotSpot Subscription Extension 006174MIU
2 Year HotSpot Subscription Extension 003357MIU
3 Year HotSpot Subscription Extension 004813MIU
4 Year HotSpot Subscription Extension 004814MIU
* Optional Paper Feed Units can only be accessed when the device is used as
a standard network printer.
Consumables & Yields Part #
Black Toner Bottle SP C430A 21,000 pages* 821070
Yellow Toner Bottle SP C430A 24,000 pages* 821071
Magenta Toner Bottle SP C430A 24,000 pages* 821072
Cyan Toner Bottle SP C430A 24,000 pages* 821073
Black Photoconductor Unit SP C430 406662
50,000 pages**
Color Photoconductor Unit SP C430 406663
50,000 pages**
Intermediate Transfer Unit SP C430 406664
100,000 pages**
Waste Toner Bottle SP C430 50,000 pages** 406665
Fusing Unit SP C430 120,000 pages** 406666
* Declared toner yield values in accordance with ISO/IEC 19798. Actual yields
may vary based on types of images printed and other factors.
** Declared imaging component yields based on 5% coverage, 3 pages/job.
Actual yields may vary based on images printed and other factors.
The Ricoh Aficio SP C431DN-HS ships with starter toner bottles yielding 3,000
pages each @ 5% coverage each. All other consumables ship at full yield.
For maximum performance and yield, we recommend using genuine Ricoh
parts and supplies.
HotSpot Specifications
Printing Modes:
Web-based User types the printer’s URL (Web
address) into an Internet browser from
a laptop
E-mail Laptops, PDAs and Internet-enabled
smart phones can print any e-mail
message and/or attachments to the
address assigned to the HotSpot Printer
Supported File Formats Microsoft Word 2.0 > 2007
Microsoft Excel 2.0 > 2007
Microsoft PowerPoint 4.0 > 2007
Microsoft Visio 5 > 2007
OpenOffice.org
Adobe PDF
Web pages (htm, html, mhtml)
Text & TRFT files
JPEG, TIFF, BMP, PNG and GIF files
Languages Supported English, French, Spanish, Dutch, Italian,
and German
Security All jobs submitted through a HotSpot
Web page are transmitted using SSL
encryption.
The transmission of files submitted via
e-mail is not encrypted by default, but
PrinterOn mail servers accept requests
for TLS authentication for all jobs
submitted via e-mail.
Job Release Code Each job is automatically assigned a
private 4 – 10 digit Release Code which
must be entered at the device before
the job can be printed.
Hotline Support If further assistance during the initial
setup and any other aspects of normal
operations of this product is required,
or if the printer requires service, please
contact the Printer/Scanner Help Desk
at Ricoh Americas Corporation by using
the toll-free numbers: 1-800-RICOH38
or 1-800-742-6438
Warranty and Service HotSpot printers ship with a one
year subscription to the PrinterOn
mobile printing service which must be
registered in order to be active.
The Ricoh Aficio SP C431DN-HS is
under warranty against defects for
a period of one year from the date
of purchase. Consumables are under
warranty for a period of 90 days from
the date of purchase or until depleted,
whichever comes first. Please refer to
warranty document shipped with the
product for more details.
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh® and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. The content of this document, and the
appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products are shown with optional features. While care
has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or adequacy of the information contained
herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and factors
affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
Ricoh Aficio SP C431DN-HS
System Specifications
Mobile Printing Made Easy
Once you send a print job from your
Internet-enabled mobile device, it’s
transmitted to the target printer or
MFP where it’s stored in memory
until the release code is entered
and the job prints...it’s that easy!
