This section explains Adjustment Settings for Operators and how to specify them.
How to Use the [Adjustment Settings for
Operators] Screen
This section explains how to use the Adjustment Settings for Operators.
1.
Press this key to collapse the hierarchical display of the adjustment items, and display only the group
names of those items.
2. [Reset]
Press this key to reset the settings/modifications being currently configured. The settings/
modifications cannot be reset after you press [Apply].
3. [Apply]
Press this key to apply the settings/modifications.
4. [To Print Screen]
Press this key to display the print screen. You can use this screen to view the changes you have
made.
5. Adjustment items
Adjustment items are displayed in this area. When you select an item, its configuration screen will
then open.
6. Configuration screen
Configure or modify the settings of the adjustment item that you have selected.
209
•All items in Adjustment Settings for Operators appear regardless of which of the machine's
optional components are installed. If you change the settings of options that are not installed, the
changes will have no effect.
5
41 32
EAR301
6

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
6. Adjustment Settings for Operators
Accessing the Adjustment Settings for Operators
Features of the Displayed Items and Setting Operations
The following operations are available for each adjustment item:
•Value setting
•Item setting
•Executing
•Display only
1. Press [Adjustment Settings for Operators] on the Home screen.
2. Select and change adjustment settings.
The method for changing the selected adjustment setting depends on the setting that
you want to change. For details, see "Features of the Displayed Items and Setting
Operations".
3. Press [Apply].
4. Press [Home] ( ) at the bottom of the screen in the center.
Value setting
Press [+] to increase the value, or [-] to decrease or use the numeric keypad to enter the
value.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
A numeric keypad appears to the left when you press the input box. Use the
keypad to enter a value.
•[×]: Press to delete the entered value character by character.
•[Clear]: Clear the entered value.
•[+/-]: Change the sign of the entered value from + (positive) to - (negative)
and vice versa.
•[Enter]: Confirm the entered value.
For some items, you can select a value from the pull-down list that appears
when you press the input box. Select a value from the list.
For some settings, move the slider right or left to increase or decrease the setting value.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Executing
Press [Execute] to perform a selected function.
Display Only
You can check the setting of the selected item.
Item setting
Select the item you require.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Printing with Adjusted Settings
To print with the settings you have adjusted, be sure to select the paper tray and paper size to
which the settings apply.
•Settings adjustable for each paper tray
•Settings adjustable for each paper size
Settings adjustable for each paper tray
•These are settings adjustable for each paper tray.
•Print jobs are processed with the adjusted settings when printing from a tray with the
applied settings.
Settings adjustable for each paper size
•These are settings adjustable for each paper size.
•Print jobs are processed with the adjusted settings when printing with a paper size that has
the applied settings.
•For details about selecting the paper tray and paper size for printing, see the manuals
for the related functions.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Menu Items and Function
All items in Adjustment Settings for Operators appear regardless of which of the machine's
optional components are installed. If you change the settings of options that are not installed, the
changes will have no effect.
01: Machine: Image Position
0101 Image Position: With Feed
Adjust the horizontal position of the print image.
You cannot individually adjust the image position on sides 1 and 2.
Side 1
DGH005
Right
(Trailing Edge)
Left
(Leading Edge)
Top
Bottom
Paper feed direction
Press [+] to shift the image to the right (trailing edge).
Press [−] to shift the image the left (leading edge).
Side 2
Paper feed direction
Top
Bottom
Left
(Leading Edge)
Right
(Trailing Edge)
CWY006
Press [+] to shift the image to the left (trailing edge).
Press [−] to shift the image to the right (leading edge).

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
•If sheets are delivered face down, turn them over horizontally and check the image
position.
•If the leading-edge margin on Side 1 of the paper is too narrow, paper jams may occur.
•If the trailing-edge margin on Side 1 of the paper is too narrow, paper jams may occur
when printing on the back side of paper during duplex printing.
Paper feed direction
Leading-edge margin Trailing-edge margin
CWY015
•This setting is not effective for paper fed from paper trays with custom paper
presets. For such paper, the value specified in [Image Position: Side1] in
[Advanced Settings] takes precedence.
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
Paper Weight 0
Paper Weight 1
Paper Weight 2
Paper Weight 3
Paper Weight 4
Paper Weight 5
Paper Weight 6
Paper Weight 7
Paper Weight 8
0.0 3.0 -3.0 0.1 mm

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
0106 Select Test Pattern for Image Position Adjustment
Select the test image for adjusting the image position.
If [Copy Image] is selected, the image scanned using the Auto Document Feeder (ADF) or
exposure glass is printed.
If [Frame Image] is selected, stripe test patterns are printed.
Setting Items Values Default Value
Test Pattern Copy Image
Frame Image
Copy Image
0108 ADF Double Feed Detection
Specify whether or not to detect multiple feeding of originals loaded in the Auto Document
Feeder (ADF).
If [On] is selected, the machine stops printing and displays a message reporting a paper jam
when it detects multiple feeding. The machine may erroneously detect double feeding when
you use creased, scratched or torn originals, originals with holes, perforated originals, or
originals with sticky notes or tape affixed. In such a case, select [Off] to prevent erroneous
detection.
Setting Items Values Default Value
Setting [On]
[Off]
[On]

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Machine: Image Quality
0202 Execute Image Quality Adjustment
Execute image density control manually.
The machine adjusts the image density. This operation takes about 30 seconds during which
a message appears on the control panel. Do not pull out the drawer while the message is
being displayed.
If the density does not change after applying this function several times, contact your service
representative.
Setting Items Values
Adjust Image Density Press [OK] to apply the setting.
•The machine executes automatic image density adjustment after a set interval or after
printing a specified number of sheets. However, you can also manually initiate automatic
image density adjustment whenever you want.
0208 Avoid Paper Transfer Shock Jitter: Feed Interval
Specify whether or not to enable the mode to reduce the jitter*1 produced when paper
enters the paper transfer roller.
If "1" is selected, the machine adjusts the interval between sheets to reduce jitter.
However, the throughput may be reduced when you use paper larger than A4 or 81/2 × 14.
If this happens, turn this setting off to improve the throughput.
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
Setting 0 1 0 1 –
•Jitter does not occur with A4 or r smaller paper.
•This setting is not effective for paper fed from paper trays with custom paper presets. For
such paper, the value specified in [Avoid Paper Transfer Shock Jitter: Feed Interval] in
"Advanced Settings" takes precedence.
*1 The jitter occurs when the leading or trailing edge of paper that passes through the
paper transfer unit is transmitted to the drum unit via the intermediate transfer belt,
causing banding.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Machine: Paper Feed/ Output
0301 Double Feed Detection
Specify whether or not to detect double feeding of paper.
If [On] is selected, the machine stops when it detects paper double feeding, so as to prevent
mixing of unprinted paper.
The machine may not correctly detect double feeding when using special paper (two-ply
paper such as release paper). In such a case, select [Off].
Setting Items Values Default Value
Tray 1
Tray 2
Tray 3
Tray 4
Tray 5
Tray 6
Tray A
Tray T1
Tray T2
Tray T3
Tray T4
Off
On
On
•This setting is not effective for paper fed from paper trays with custom paper presets.
For such paper, the value specified in [Double Feed Detection] in "Advanced Settings"
takes precedence.
0302 When Double Feed is Detected
Specify how the machine behaves when it detects a double feed.
If [Suspended] is selected, the machine, on detecting a double feed, stops printing and
displays a paper misfeed message.
If [Suspended After Paper Diversion] is selected, the machine stops printing if a double
feed is detected, then delivers the sheets to the paper trap inside the machine at the
bottom left, and displays a paper misfeed message.
This setting is enabled only if [Double Feed Detection] is set to [On].

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Setting Items Values Default Value
Setting Suspended
Suspended After Paper
Diversion
Suspended After Paper
Diversion
0304 Skew Detection
Specify whether or not to detect paper skew.
If the machine detects a paper skew when [On] is selected, the machine will stop printing and
display a message reporting a paper jam.
The machine may erroneously detect paper skew when using dark paper or paper printed to
its edges. In such a case, select [Off].
Setting Items Values Default Value
Tray 1
Tray 2
Tray 3
Tray 4
Tray 5
Tray 6
Tray A
2 Sided
Tray T1
Tray T2
Tray T3
Tray T4
Off
On
On
•This setting is not effective for paper fed from paper trays with custom paper presets. For
such paper, the value specified in [Skew Detection] in "Advanced Settings" takes
precedence.

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
0310 Correct Output Paper Curl
Specify the method for straightening curled sheets.
Select the method according to the direction and degree of curl.
If the paper is curled face up, select "U Curl Correction Level". If it is curled face down, select
"П Curl Correction Level". Depending on how much the paper is curled, specify the degree of
correction by selecting "Weak" or "Strong".
Setting Items Values Default Value
Tray 1
Tray 2
Tray 3
Tray 4
Tray 5
Tray 6
Tray A
Tray T1
Tray T2
Tray T3
Tray T4
U Curl Correction Level: Off
U Curl Correction Level: Small
U Curl Correction Level: Large
П Curl Correction Level: Off
П Curl Correction Level: Small
П Curl Correction Level: Large
U Curl Correction Level: Off
Main Unit: Maintenance
0502 Execute Photoconductor Refreshing
Remove dust on the drum surface.
This operation takes about 4 minutes. Do not open the front covers during the operation.
Setting Items Values
Photoconductor Refreshing Press [OK] to apply the setting(s).

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
0517 Temperature / Humidity Inside
Display the internal temperature and humidity.
If your service representative requests it, report this information.
Setting Items Values
Temperature
Humidity
Value display only.
0518 Temperature / Humidity Outside
Display the external temperature and humidity.
If your service representative requests it, report this information.
Setting Items Values
Temperature
Humidity
Value display only.
0519 Display Banner for Conditions Outside Optimal Range
Specify whether or not to display the banner to indicate conditions outside the recommended
operating environment.
Specify whether or not to display the banner when using the machine in conditions outside
the recommended operating environment.
Setting Items Values Default Value
High Temperature/Humidity
Low Temperature/Humidity
Off
On
On
0522 Execute Charger Cleaning
Clean the charge unit.
If the printed copies have vertical creases, clean the charge unit. This may reduce the problem.
Do not open any covers during the operation.
Setting Items Values
Charger Cleaning Press [OK].

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
0523 Switch Print Screen
Set the function displayed when pressing [To Print Screen].
Setting Items Values Default Value
Setting Copier
Printer
Copier
Finishing: Finisher
0601 Staple Position: Across Feed 1
Adjust the vertical position of the staple (applied at an edge) when using Finisher SR5120.
Press [ + ] to move the stapling position left or [ - ] to move it right on the open
booklet.
Paper feed direction
CWY016

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
A3 SEF
B4 JIS SEF
A4 SEF
B5 JIS SEF
SRA3 SEF
SRA4 SEF
310 × 432mm SEF
226 × 310mm SEF
13 × 191/5 SEF
13 × 19 SEF
13 × 18 SEF
123/5 × 191/5 SEF
123/5 × 181/2 SEF
12 × 18 SEF
11 × 17 SEF
81/2 × 14 SEF
81/2 × 132/5 SEF
81/2 × 131/2 SEF
81/2 × 11 SEF
Other Paper Sizes
0.0 1.0 -1.0 0.1 mm
0602 Folding Position for Booklet
Adjust the horizontal position of the folding when using Booklet Finisher SR5120. Press
[ + ] to move the position left or press [ - ] to move it right on the open booklet.
Folding position
Paper feed direction
CWY017

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
A3 SEF
B4 JIS SEF
A4 SEF
B5 JIS SEF
SRA3 SEF
SRA4 SEF
310 × 432mm SEF
226 × 310mm SEF
13 × 191/5 SEF
13 × 19 SEF
13 × 18 SEF
123/5 × 191/5 SEF
123/5 × 181/2 SEF
12 × 18 SEF
11 × 17 SEF
81/2 × 14 SEF
81/2 × 132/5 SEF
81/2 × 131/2 SEF
81/2 × 11 SEF
Other Paper Sizes
0.0 1.0 -1.0 0.1 mm
0603 Staple Position: Across Feed 1
Adjust the vertical position of the staple (applied at an edge) when using Finisher
SR5110 or Booklet Finisher SR5120.
Press [ + ] to move the stapling position away from the side edge of the sheet or [ - ]
to move it toward the edge.
Leading
edge edge
Paper feed direction
Trailing
DFZ001

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
A3 SEF
B4 JIS SEF
A4 LEF
A4 SEF
B5 JIS LEF
B5 JIS SEF
11 × 17 SEF
81/2 × 14 SEF
81/2 × 132/5 SEF
81/2 × 131/2 SEF
81/2 × 11 LEF
81/2 × 11 SEF
8K SEF
16K LEF
16K SEF
Other Paper Sizes
0.0 2.0 -2.0 0.1 mm
0604 Staple Position: Across Feed 2
Adjust the vertical distance (up and down) between the staples (dual) when using
Finisher SR5110 or Booklet Finisher SR5120.
Press [ + ] to move the two stapling positions away from the center and each other or
[ - ] to move it toward each other.
Leading
edge
Trailing
edge
Paper feed direction
DFZ002

CIP Training Pro 8300 series
Adjustment Settings for Operators
CIP Training C7200 series
Adjustment Settings for Operators
Setting Items Default
Value
Max.
Value
Min.
Value Step Unit
A3 SEF 0.0 115 -14.5 0.5 mm
B4 JIS SEF 75
A4 LEF 115
A4 SEF 28
B5 JIS LEF 75
B5 JIS SEF 0
11 × 17 SEF 98
81/2 × 14 SEF
81/2 × 132/5 SEF
81/2 × 131/2 SEF
34
81/2 × 11 LEF 98
81/2 × 11 SEF 34
8K SEF
16K LEF
85
16K SEF 12
Other Paper Sizes 115
0605 Staple Position: With Feed
Adjust the horizontal position of the staples when using Finisher SR5110 or Booklet
Finisher SR5120.
Press [ + ] to move the stapling position away from the trailing edge of the sheet or
[ - ] to move it toward the edge.
edge
Paper feed direction
TrailingLeading
edge
DFZ003
