Ricoh Pro C5300S Manual

For safe and correct use, be sure to read Safety Information before
using the machine.
For information not found in this manual,
see the online manuals available on our
web site (https://www.ricoh.com/) or via the
control panel.
Legal and Contact Information
Specifications for The Machine
Troubleshooting
Adjustment Settings for Operators
Paper Settings
Paper Specifications and Adding Paper
Web Image Monitor
Document Server
Scan
Print
Fax
Copy
Getting Started
Operator's Guide

How to Read the Manuals
Symbols Used in the Manuals
This manual uses the following symbols:
Indicates points to pay attention to when using functions. This symbol indicates points that may result in
the product or service becoming unusable or result in the loss of data if the instructions are not obeyed.
Be sure to read these explanations.
Indicates supplementary explanations of the machine's functions, and instructions on resolving user
errors.
[ ]
Indicates the names of keys or buttons on the product or display.
Notes
Contents of this manual are subject to change without prior notice.
The manufacturer shall not be responsible for any damage or expense that might result from the use of
parts other than genuine parts from the manufacturer with your office products.
For good output quality, the manufacturer recommends that you use genuine toner from the
manufacturer.
Some illustrations in this manual might be slightly different from the machine.
1

TABLE OF CONTENTS
How to Read the Manuals.................................................................................................................................1
Symbols Used in the Manuals.......................................................................................................................1
Notes...............................................................................................................................................................1
1. Getting Started
Abbreviated Names of Options......................................................................................................................15
Classic Applications.........................................................................................................................................18
Turning On and Off the Power........................................................................................................................19
Turning On the Main Power........................................................................................................................19
Turning Off the Main Power........................................................................................................................20
Energy Saving Mode...................................................................................................................................20
Guide to Names and Functions of Components............................................................................................23
Front and Left View...................................................................................................................................... 23
Front and Right View....................................................................................................................................24
Rear and Left View.......................................................................................................................................26
Guide to Functions of the Attention Light....................................................................................................26
Machine Options............................................................................................................................................. 28
Guide to Functions of the Machine’s External Options............................................................................ 28
Guide to Functions of the Machine’s Internal Options............................................................................. 35
Special Notes When Using External Options................................................................................................37
Precautions for Using the Finisher...............................................................................................................37
Removing Prints from Finisher SR5090/Booklet Finisher SR5100 during Printing................................ 38
Removing Prints from Finisher SR5110/Booklet Finisher SR5120 during Printing or When in Standby
State.............................................................................................................................................................. 38
When Using the Z-fold Function.................................................................................................................40
When Using the Letter Fold-out Function................................................................................................... 43
When Ejecting Thin Paper to Finisher SR5110/Booklet Finisher SR5120.............................................44
When Ejecting Carbonless Paper Weighing 63 g/m2 or Less to Finisher SR5110/Booklet Finisher
SR5120........................................................................................................................................................ 45
When Ejecting Banner Sheets to Finisher SR5110/Booklet Finisher SR5120.......................................46
When Ejecting a Large Number of Booklets to the Booklet Tray of Booklet Finisher SR5120............. 46
When Using the Staple Function of Finisher SR5110/Booklet Finisher SR5120 on Thin Coated Paper
Weighing 80 g/m2 or Less........................................................................................................................ 47
When Using the High Capacity Stacker....................................................................................................49
When Ejecting Thick Paper or Envelopes to the Upper Tray of the High Capacity Stacker..................53
2

Precautions Taking Booklets from the Trimmer.......................................................................................... 54
Functions Requiring Optional Configurations................................................................................................ 55
Copy Function.............................................................................................................................................. 55
Facsimile Functions...................................................................................................................................... 56
Printer Function.............................................................................................................................................57
Scanner Function..........................................................................................................................................58
Interface........................................................................................................................................................59
Others........................................................................................................................................................... 59
Names and Functions of the Control Panel....................................................................................................60
Touch Panel/Interface.................................................................................................................................60
LED Indicators...............................................................................................................................................61
How to Use the Home Screen.........................................................................................................................63
Intuitive Screen Operation Using Fingertips.............................................................................................. 65
How to Use the Machine Status Screen.........................................................................................................68
How to Use the "Settings"................................................................................................................................69
How to Use the Copy (Classic) Screen.......................................................................................................... 72
Switching screen patterns............................................................................................................................74
[Connect Copy] Screen...............................................................................................................................74
How to Use the Fax (Classic) Screen............................................................................................................. 76
Switching screen patterns............................................................................................................................78
How to Use the Scan (Classic) Screen...........................................................................................................80
Switching screen patterns............................................................................................................................82
How to Use the Printer (Classic) Screen.........................................................................................................83
Switching screen patterns............................................................................................................................84
Logging In from the Control Panel.................................................................................................................. 86
Logging In by Entering the User Name and Password.............................................................................87
Logging In Using an IC Card......................................................................................................................88
Logging In Using a Mobile Device.............................................................................................................88
Authenticating Using the User Code.......................................................................................................... 90
Changing the Login Password.................................................................................................................... 90
2. Copy
Basic Procedure................................................................................................................................................93
Auto Reduce / Enlarge....................................................................................................................................95
3

Duplex Copying............................................................................................................................................... 97
Specifying the Original and Copy Orientation.........................................................................................99
Combined Copying.......................................................................................................................................101
One-Sided Combine.................................................................................................................................103
Two-Sided Combine................................................................................................................................. 105
Copying onto Envelopes...............................................................................................................................107
Copying onto envelopes from the bypass tray....................................................................................... 107
Copying onto envelopes from the paper tray or the wide LCT............................................................. 108
Sort..................................................................................................................................................................109
3. Fax
Basic Procedure for Fax Transmissions (Memory Transmission)................................................................113
Sending Originals Using the Exposure Glass......................................................................................... 115
Registering Fax Numbers in the Address Book........................................................................................... 117
Registering a Fax Number and Send Conditions................................................................................... 117
Changing/Deleting the Registered Data Such as Fax Number............................................................118
Displaying Confirmation of Transmission.....................................................................................................120
Viewing the Fax Transmission Result............................................................................................................ 121
Printing the Fax Transmission Result......................................................................................................... 121
Sending the Fax Transmission Result........................................................................................................122
Printing the Fax Transmission Result and Sending It by E-Mail..............................................................122
Communication Result Report (Memory Transmission).......................................................................... 123
Immediate TX Result Report (Immediate Transmission)...........................................................................123
Communication Failure Report.................................................................................................................123
4. Print
Installing the Printer Driver by Using Device Software Manager Installer................................................ 125
Installing Device Software Manager from the CD-ROM.......................................................................125
Installing Device Software Manager from the Downloaded File..........................................................128
Installing the Printer Driver for Network Connection (Windows)...............................................................131
Installing the PCL 6 Printer Driver from the CD-ROM.............................................................................131
Installing the PostScript 3 Printer Driver from the CD-ROM...................................................................134
Installing the PCL 6/PostScript 3 Printer Driver from the Downloaded File..........................................136
Installing the Printer Driver for Windows................................................................................................. 137
If the Machine Cannot Be Found............................................................................................................. 138
4

Installing the Printer Driver for Network Connection (macOS)..................................................................142
Installing the PPD file................................................................................................................................. 142
Registering the Machine in [Print & Scan] or [Printers & Scanners]...................................................... 143
Specifying the Option Settings................................................................................................................. 146
Basic Procedure for Printing Documents...................................................................................................... 148
Printing a Document in Windows.............................................................................................................148
Printing a Document in macOS................................................................................................................ 150
Printing on Both Sides of Paper.................................................................................................................... 153
Specifying 2-sided Print (Windows)........................................................................................................ 153
Specifying 2-sided Print (macOS)............................................................................................................153
Combining and Printing Multiple Pages on a Single Sheet of Paper........................................................ 155
Specifying the Combine 2 Originals Function (Windows).................................................................... 155
Specifying the Combine 2 Originals Function (macOS)........................................................................155
Printing on Envelopes.................................................................................................................................... 157
5. Scan
Basic Procedure for Sending Scan Files by E-mail......................................................................................159
Procedure for Sending Files to the Shared Folder Registered in the Address Book.................................163
Procedure for Specifying Scan Settings.......................................................................................................165
Original Type.............................................................................................................................................165
Resolution...................................................................................................................................................166
Scan Size................................................................................................................................................... 167
Edit..............................................................................................................................................................171
Specifying the File Type and File Name......................................................................................................173
Specifying the File Type............................................................................................................................173
Specifying the File Name..........................................................................................................................175
6. Document Server
Storing Documents in Document Server.......................................................................................................179
Printing Documents in Document Server...................................................................................................... 181
Printing a Document with the Settings Specified When Scanned..........................................................181
Changing the Print Settings to Print a Document.....................................................................................182
Specifying a Page to Print.........................................................................................................................183
7. Web Image Monitor
Using Web Image Monitor...........................................................................................................................185
5

What You Can Do on the Web Image Monitor..................................................................................... 186
Web Image Monitor Screen.................................................................................................................... 188
Specifying Web Image Monitor Help.....................................................................................................188
8. Paper Specifications and Adding Paper
Placing an Original on the Exposure Glass.................................................................................................191
Placing an Original in the Auto Document Feeder (ADF).......................................................................... 193
Loading Paper into the Paper Tray...............................................................................................................197
Fanning the Paper..................................................................................................................................... 198
Loading Paper into Tray 1........................................................................................................................ 200
Loading Paper into the A3/11 × 17 Tray Unit.......................................................................................202
Loading Paper into Trays 2 and 3........................................................................................................... 203
Loading Tab Stock into Trays 2 and 3.....................................................................................................206
Loading Paper into the Bypass Tray........................................................................................................ 207
Loading Tab Stock into the Bypass Tray..................................................................................................210
Loading Paper into the Multi Bypass Banner Sheet Tray....................................................................... 210
Loading Paper into the Banner Sheet Guide Tray.................................................................................. 213
Loading Paper into the Multi Bypass Tray (Tray A)................................................................................214
Loading tab stock into the multi bypass tray (Tray A).............................................................................216
Loading Paper into the Large Capacity Tray (LCT)................................................................................ 217
Loading Paper into the Wide LCT............................................................................................................ 218
Loading Tab Stock into the Wide LCT..................................................................................................... 222
Loading Paper with a Vertical Size of 100.0 mm to 139.2 mm in Wide LCT..................................... 223
Loading B5 Vertical or Larger Paper in Wide LCT................................................................................. 225
Loading Paper into the Two-tray Wide LCT............................................................................................ 228
Loading Tab Stock into the Two-tray Wide LCT..................................................................................... 233
Attaching the small tab end fence to the two-tray wide LCT..................................................................234
Loading Paper into the Interposer............................................................................................................235
Loading Paper into the Twin Interposer................................................................................................... 237
Specifying the Paper Size That Is Not Automatically Detected.............................................................238
Specifying a Custom Size Paper..............................................................................................................239
Recommended Paper Sizes and Types........................................................................................................241
Tray 1......................................................................................................................................................... 241
Tray 1 (A3/11 × 17 tray unit)................................................................................................................. 241
6

Trays 2 and 3............................................................................................................................................ 242
Bypass Tray................................................................................................................................................245
Large Capacity Tray..................................................................................................................................250
Extension Unit (for LCT).............................................................................................................................250
Wide LCT .................................................................................................................................................. 251
Two-Tray Wide LCT (Tray T1/T2)*1*13................................................................................................. 256
Multi Bypass Tray (Tray A)....................................................................................................................... 264
Interposer................................................................................................................................................... 267
Twin Interposer.......................................................................................................................................... 268
Notes on Special Paper............................................................................................................................271
Paper Thickness for Each Paper Weight..................................................................................................272
Unusable Paper......................................................................................................................................... 273
Paper Storage............................................................................................................................................274
Saving Printouts......................................................................................................................................... 274
Thick Paper Orientation and Recommended Status................................................................................... 276
Envelope Orientation and Recommended Status....................................................................................... 277
Using the Copy Function...........................................................................................................................278
Using the Printer Function..........................................................................................................................279
Loading Orientation-fixed Paper or Two-sided Paper............................................................................... 281
Copying onto Letterhead Paper...............................................................................................................281
Printing onto Letterhead Paper Using the Printer Driver..........................................................................282
Recommended Original Size and Weight.................................................................................................. 284
Sizes Detectable with Auto Paper Select.....................................................................................................286
9. Paper Settings
Registering Custom Paper............................................................................................................................. 289
Overview of Paper Settings...................................................................................................................... 289
How to Use the [Edit Custom Paper] Screen...........................................................................................292
How to Use the [Import from Master Library] Screen............................................................................ 293
Registering a Custom Paper..................................................................................................................... 294
Registering a Custom Paper with the Media Identification Unit............................................................ 299
Modifying a Custom Paper.......................................................................................................................305
Custom Paper Settings.............................................................................................................................. 306
Adjusting the Image Position of the Either Side of the Paper................................................................. 309
7

Searching for a Paper by Specifying the Conditions............................................................................. 311
Printing the Parameters of Custom Paper Settings.................................................................................. 312
Deleting a Custom Paper..........................................................................................................................313
Backing Up and Restoring Custom Paper Profiles.................................................................................. 314
Changing Tray Paper Settings...................................................................................................................... 316
Specifying a Custom Paper...................................................................................................................... 316
Manually Specifying a Paper's Size and Type.......................................................................................317
Feed Speed Auto Adjustment...................................................................................................................317
10. Adjustment Settings for Operators
How to Use the [Adjustment Settings for Operators] Screen..................................................................... 319
Opening and Closing Adjustment Settings for Operators..................................................................... 320
Features of the Displayed Items and Setting Operations.......................................................................320
Printing with Adjusted Settings..................................................................................................................322
02: Machine: Image Quality........................................................................................................................324
0209: Photoconductor Special Mode.................................................................................................... 324
0210: Smooth Fusing Belt........................................................................................................................ 324
0211: Fusing Ability by Feed Speed.......................................................................................................324
0214: Fusing Belt Smoothing Setting: Uneven Gloss.............................................................................325
03: Machine: Paper Feed/ Output..............................................................................................................326
0303: Criteria for Paper Weight............................................................................................................. 326
0308: Connection Unit: Registration Gate Home Position.................................................................... 327
05: Machine: Maintenance..........................................................................................................................328
0509: Execute Developer Refreshing......................................................................................................328
0511: Temperature / Humidity outside the Machine............................................................................328
0512: Back Up / Restore Custom Paper Data.......................................................................................328
0513: Switch Print Screen........................................................................................................................ 329
07: Finishing: Finisher.................................................................................................................................... 330
0701: Punch Position: With Feed.............................................................................................................330
0702: Punch Position: Across Feed......................................................................................................... 330
0703: Staple Position............................................................................................................................... 331
0704: Staple Position for Booklet............................................................................................................332
0705: Folding Position for Booklet.......................................................................................................... 333
0706: Folding Speed for Booklet............................................................................................................336
8

0801: Staple Position: Across Feed 1..................................................................................................... 337
0802: Staple Position: Across Feed 2..................................................................................................... 338
0803: Staple Position: With Feed............................................................................................................339
0813: Punch Position: Across Feed......................................................................................................... 340
0814: Punch Position: With Feed.............................................................................................................341
0825: Staple Position for Booklet............................................................................................................342
0826: Folding Position for Booklet.......................................................................................................... 343
0828: Set Number of Folds for Booklet..................................................................................................345
0838: Accuracy Priority for Stapling.......................................................................................................345
0839: Accuracy Priority for Booklet........................................................................................................345
0840: Staple Tray: Rib Installed Mode to Strengthen Paper................................................................ 346
09: Finishing: Fold......................................................................................................................................... 347
0901: Z-fold Position 1............................................................................................................................ 347
0902: Z-fold Position 2............................................................................................................................ 347
0903: Half Fold Position: 1 sheet Fold....................................................................................................348
0904: Half Fold Position: Multi-sheet Fold............................................................................................. 349
0905: Letter Fold-out Position 1: 1 sheet Fold........................................................................................350
0906: Letter Fold-out Position 1: Multi-sheet Fold..................................................................................351
0907: Letter Fold-out Position 2: 1 sheet Fold........................................................................................352
0908: Letter Fold-out Position 2: Multi-sheet Fold..................................................................................353
0909: Letter Fold-in Position 1: 1 sheet Fold.......................................................................................... 354
0910: Letter Fold-in Position 1: Multi-sheet Fold....................................................................................355
0911: Letter Fold-in Position 2: 1 sheet Fold.......................................................................................... 355
0912: Letter Fold-in Position 2: Multi-sheet Fold....................................................................................356
0913: Double Parallel Fold Position 1.................................................................................................... 357
0914: Double Parallel Fold Position 2.................................................................................................... 358
0915: Gate Fold Position 1......................................................................................................................359
0916: Gate Fold Position 2......................................................................................................................359
0917: Gate Fold Position 3......................................................................................................................360
10: Finishing: Stacker.................................................................................................................................... 361
1004: Maximum Stack Quantity in Stacker Tray...................................................................................361
21: Finishing: Interposer................................................................................................................................362
2102: Interposer: Fan Setting.................................................................................................................. 362
9

2103: Interposer: Fan Level..................................................................................................................... 362
11. Troubleshooting
Alert Sounds...................................................................................................................................................363
Checking the Indicators, Icons, and Messages on the Control Panel.......................................................365
When an Icon Is Displayed with a Message.......................................................................................... 365
When the [Check Status] Indicator Is Lit or Flashing.............................................................................. 367
When the Machine Cannot Be Operated...................................................................................................369
When the Machine Does Not Respond Correctly to an Operation on the Control Panel..................369
When the Machine Does Not Respond Correctly to an Operation from a Computer....................... 372
When a Message Appears and the Machine Cannot Be Operated........................................................374
When a Message Appears While Using the Copy Function.....................................................................377
When a Message Appears While Using Document Server...................................................................... 379
When a Message Appears While Using the Fax Function........................................................................381
Messages that Appear During Operation or When Sending/Receiving a Fax Cannot Be Performed....
.................................................................................................................................................................... 381
Messages that Appear When the Machine Cannot Connect to the Network.....................................383
When a Message Appears While Using the Printer Function....................................................................392
Messages that Appear without Error Codes...........................................................................................392
Messages that Appear with Error Codes................................................................................................ 405
When a Message Appears While Using the Scanner Function................................................................ 409
Messages that Appear on the Control Panel..........................................................................................409
When documents cannot be scanned properly......................................................................................417
When documents cannot be scanned because the memory is full....................................................... 417
When data transmission fails....................................................................................................................418
When data cannot be sent because a currently used file is selected................................................... 418
When data cannot be sent because there are too many documents or pages................................... 419
When the WSD scanner function cannot be used..................................................................................419
When Stored Files Cannot Be Accessed.................................................................................................420
When Stored Files Cannot Be Edited...................................................................................................... 421
When You Cannot Send Scan Files Using WSD....................................................................................421
Messages that Appear on the Computer................................................................................................ 421
When Other Messages Appear...................................................................................................................428
Messages that Appear When Machine Login Fails............................................................................... 430
10

Messages that Appear When Logging in to the Machine Using an IC Card Fails............................. 438
Messages that Appear When the LDAP Server Is Unavailable............................................................ 439
Messages that Appear When There Is a Problem with the Certificate................................................. 440
Messages that Appear When an Application Site Cannot Be Used.................................................... 441
Precautions When Removing Jammed Paper..............................................................................................443
This Machine..............................................................................................................................................443
Finisher SR5110/Booklet Finisher SR5120........................................................................................... 445
Wide LCT................................................................................................................................................... 447
Interposer................................................................................................................................................... 448
Twin Interposer.......................................................................................................................................... 449
Finisher Bridge Unit................................................................................................................................... 450
When Paper or an Original Is Jammed....................................................................................................... 451
If Paper Jams Occur Frequently............................................................................................................... 454
Removing Jammed Banner Sheets............................................................................................................... 457
If the trailing edge of the banner sheet is on the bypass tray................................................................ 457
If the leading edge of the banner sheet is over the finisher tray............................................................459
When a Staple Is Jammed............................................................................................................................ 460
Finisher SR5090........................................................................................................................................460
Booklet Finisher SR5100.......................................................................................................................... 461
Booklet Finisher SR5100 (Saddle Stitch)................................................................................................ 462
Finisher SR5110........................................................................................................................................463
Booklet Finisher SR5120.......................................................................................................................... 464
Booklet Finisher SR5120 (Saddle Stitch)................................................................................................ 465
When the Hole Punch Receptacle Is Full..................................................................................................... 466
Removing Staple Waste................................................................................................................................467
Removing Waste Paper.................................................................................................................................468
When a Deviation in Color Registration Appears...................................................................................... 469
When Printed Colors Appear Differently.....................................................................................................470
12. Specifications for The Machine
Model-Specific Information.......................................................................................................................... 473
List of Specifications for Standard Functions................................................................................................474
Specifications for the Main Unit............................................................................................................... 474
Specifications for the Document Server...................................................................................................483
11

Specifications for Printer........................................................................................................................... 484
Specifications for Scanner........................................................................................................................486
Specifications for Auto Document Feeder...............................................................................................490
List of Specifications for External Options....................................................................................................491
Specifications for Finisher SR5090..........................................................................................................491
Specifications for Booklet Finisher SR5100............................................................................................495
Specifications for Finisher SR5110..........................................................................................................499
Specifications for Booklet Finisher SR5120............................................................................................504
Specifications for Copy Tray.................................................................................................................... 511
Specifications for Punch Unit (Finisher SR5090, Booklet Finisher SR5100)........................................ 512
Specifications for Punch Unit (Finisher SR5110, Booklet Finisher SR5120)........................................ 513
Specifications for Interposer.....................................................................................................................514
Specifications for Twin Interposer............................................................................................................ 514
Specifications for Folding Unit..................................................................................................................515
Specifications for Output Jogger..............................................................................................................516
Specifications for Large Capacity Tray (LCT)..........................................................................................517
Specifications for Wide Large Capacity Tray.........................................................................................517
Specifications for Two-Tray Wide Large Capacity Tray........................................................................518
Specifications for Multi Bypass Tray (Tray A).........................................................................................519
Specifications for Two-Tray Wide LCT Connection Unit........................................................................519
Specifications for Decurler Unit................................................................................................................520
Specifications for Buffer Pass Unit............................................................................................................521
Specifications for Trimmer.........................................................................................................................522
Specifications for High Capacity Stacker................................................................................................523
Specifications for Finisher Bridge Unit..................................................................................................... 525
List of Specifications for Internal Options.....................................................................................................526
Specifications for Facsimile.......................................................................................................................526
Specifications for IEEE 1284 Interface Board........................................................................................ 531
Specifications for Wireless LAN Board................................................................................................... 531
The Setting Values of the Transmission Function..........................................................................................533
Send Email................................................................................................................................................. 533
Send to Folder........................................................................................................................................... 534
Broadcast Transmission.............................................................................................................................535
12

13. Legal and Contact Information
Environmental Regulations............................................................................................................................537
ENERGY STAR Program (mainly North America)............................................................... 537
Energy Saving Functions...........................................................................................................................537
User Information on Electrical and Electronic Equipment (mainly Europe)...................... 539
Note for the Battery and/or Accumulator Symbol (For EU countries only) (mainly Europe)
.................................................................................................................................................................... 540
Environmental Advice for Users (mainly Europe)............................................................... 540
Notes to users in the state of California (Notes to Users in USA) (mainly North America)....
.................................................................................................................................................................... 541
Trademarks.....................................................................................................................................................542
13

14

1. Getting Started
Abbreviated Names of Options
In the manuals, the abbreviated names of options are used. The abbreviated names and corresponding
product names are as follows:
Abbreviated names of externally attached options
Abbreviated name Product name
ADF double-feed detection kit Page Keeper Type M37
Multi bypass banner sheet tray Multi Bypass Banner Sheet Tray Type S6
Banner sheet guide tray Banner Sheet Guide Tray for A3/11"×17"
LCIT Type S13
Wide LCT LCIT RT5140
Large capacity tray (LCT) LCIT RT4060
Extension unit of LCT 81/2" × 14" PAPER SIZE TRAY TYPE M2
Multi bypass tray (Tray A) Multi Bypass Tray BY5020
Banner sheet tray of multi bypass tray (Tray A) Multi Bypass Banner Sheet Tray Type S9
Multi bypass attachment kit Multi Bypass Attachment Kit for Vacuum Feed
LCIT Type S9
Two-tray wide LCT Vacuum Feed LCIT RT5120
Banner sheet tray of two-tray wide LCT Vacuum Feed Banner Sheet Tray Type S9
Two-tray wide LCT connection unit Bridge Unit BU5030
Copy tray Copy Tray Type M42
Decurler unit Decurl Unit DU5080
Buffer pass unit Buffer Pass Unit Type S9
Twin interposer Cover Interposer Tray CI5040
Folding unit Multi-Folding Unit FD5020
15

Abbreviated name Product name
SR4000 series output tray for banner sheet SR4000 series Output Tray for Banner Sheet
Type6
Output jogger Output Jogger Unit Type M25
Finisher SR5090 Finisher SR5090
Booklet Finisher SR5100 Booklet Finisher SR5100
Interposer Cover Interposer Tray CI5050
SR5000 series output tray for banner sheet SR5000 series Output Tray for Banner Sheet
Type S6
Finisher SR5110 Finisher SR5110
Booklet Finisher SR5120 Booklet Finisher SR5120
Trimmer unit Trimmer Unit TR5050
Finisher bridge unit Bridge Unit BU5020
High capacity stacker High Capacity Stacker SK5040
A3/11 × 17 tray unit A3/11"×17" Tray Unit Type M26
Optional feed roller unit Optional Feed Roller Unit Type S13
Carbonless paper unit Carbonless Paper Unit Type S13
Tab sheet holder Tab Sheet Holder Type M2
Card reader NFC Card Reader Type S6
Media Identification Unit Media Identification Unit Type S3
Abbreviated names of internal options
Abbreviated name Product name
Fax unit Fax Option Type M42
Extra G3 interface unit G3 Interface Unit Type M42
Expansion Memory FAX Memory Unit Type M26 64MB
PostScript 3 unit PostScript3 Unit Type M42
1. Getting Started
16

Abbreviated name Product name
OCR unit OCR Unit Type M13
IPDS unit IPDS Unit Type M42
XPS card XPS Direct Print Option Type M42
IEEE 1284 interface board IEEE 1284 Interface Board Type M19
Wireless LAN board IEEE 802.11a/g/n Interface Unit Type M19
File format converter File Format Converter Type M19
VM card VM CARD Type M37
Copy connector Copy Connector Type M25
Color controller
Abbreviated name Product name
Color controller Color Controller E-27B
Color controller Color Controller E-47B
Abbreviated Names of Options
17

Classic Applications
On this machine, standard functions are provided as classic applications. The classic applications are
displayed with "(Classic)" appended to their names, for instance, "Copier (Classic)".
The classic applications can be launched from the Home screen.
Displayed icons Names in this manual
D0CPPC8420
• Copier (Classic) or Copy (Classic)
• Scanner (Classic) or Scan (Classic)
• Fax (Classic)
• Printer (Classic)
• Document Server
Applications other than the classic ones are also available on this machine.
See "Application/Widget List", User Guide.
1. Getting Started
18
