Ricoh PRO C7200S Operating instructions

Copier Models:
Pro C7200S/C7200SL/C7200SX/C7210S/C7210SX
Machine Codes:
D0A5/D0BG/D0AL/D0AK/D0AM
Printer Models:
Pro C7200/C7200X/C7210/C7210X
Machine Codes:
M0BH/M0BK/M0BJ/M0BL
Troubleshooting
Ver 1.0
Latest Release: Feb, 2018
Initial Release: Feb, 2018
(c) 2018 Ricoh Co.,Ltd.

Symbols, Abbreviations
This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations
are as follows:
Symbol
What it means
Clip ring
Blue screw
Screw
Black screw (heavy, fusing unit, TCRU)
Shoulder screw
Pivot screw
Connector
Clamp
E-ring
C-ring
Flat Flexible Cable
Timing Belt
Spring
SEF
Short Edge Feed
LEF
Long Edge Feed
K
Black
C
Cyan
M
Magenta
Y
Yellow
S
Special color for 5th Station
B/W, BW
Black and White
FC
Full color
TE
Trailing Edge
LE
Leading Edge
[A] Short Edge Feed (SEF)
[B] Long Edge Feed (LEF)

1
Table of Contents
1. SC Codes............................................................................................................................................ 7
Self-Diagnostic Mode ............................................................................................................................. 7
Service Call Conditions ...................................................................................................................... 7
SC Logging ......................................................................................................................................... 8
SC Automatic Reboot ......................................................................................................................... 8
SC Manual Reboot ........................................................................................................................... 10
Service Call 101-195(Scanning)........................................................................................................... 12
SC100 (Engine) ................................................................................................................................ 12
Service Call 202-286 (Image Writing) .................................................................................................. 23
SC200 (Engine) ................................................................................................................................ 23
Service Call 300-398 ............................................................................................................................ 31
SC300 (Engine: Charge, Development)........................................................................................... 31
Service Call 400-498 ............................................................................................................................ 51
SC400 (Engine: Around the Drum) .................................................................................................. 51
Service Call 501-595 ............................................................................................................................ 64
SC500 (Engine: Paper transport 1: Paper Feed, Duplex, and Transport)....................................... 64
Service Call 600-672 (Controller)....................................................................................................... 119
SC632 to SC653, SC670 to SC672 ............................................................................................... 119
Service Call 603-689 (Engine) ........................................................................................................... 122
SC600 (Engine: Communication and Others)................................................................................ 122
Service Call 700-740 .......................................................................................................................... 148
SC700 (Engine: Peripherals).......................................................................................................... 148
Service Call 750-790 .......................................................................................................................... 193
SC700 (Engine: Peripherals).......................................................................................................... 193
Service Call 816-899 .......................................................................................................................... 373
SC816 to SC899............................................................................................................................. 373
Service Call 900-998 (Controller)....................................................................................................... 377
SC900 to SC998............................................................................................................................. 377
Service Call 995 (Engine)................................................................................................................... 386
SC995 (Engine: Others) ................................................................................................................. 386
2. JAM Codes ..................................................................................................................................... 387
Jam Detection..................................................................................................................................... 387
Jam Displays................................................................................................................................... 387
Jam Removal.................................................................................................................................. 387
Printer Engine Jam History............................................................................................................. 388
Jam Code Descriptions .................................................................................................................. 388
3. Troubleshooting: Paper Delivery Problems.................................................................................... 403

2
Paper Feed Problems on Main Machine............................................................................................ 403
Frequent Paper Misfeeds ............................................................................................................... 403
No Feeding (Poor-Quality Paper): Main Machine Paper Feed ...................................................... 404
J032 Appears.................................................................................................................................. 406
J033/J082 Appears (Small size paper, Metallic Paper, and Paper Weight 7 or larger) ................ 407
J080 Appears (Paper Delay in Specific Papers) ............................................................................ 411
J099 Appears (Main Machine Tray) ............................................................................................... 411
Wrong Detection of Double Feeding .............................................................................................. 413
Paper Skew..................................................................................................................................... 415
J097 (Overskew)/ J098 (Shift Over) Appears ................................................................................ 419
Efficient SP for Paper Jam Analyzing............................................................................................. 425
Paper Transport Problems on Main Machine..................................................................................... 426
Fan on Optional Buffer Pass Unit Generates Noise....................................................................... 426
White Spots/Scratches Due to Paper Dusts .................................................................................. 426
Roller Marks on Paper Edges (Merge)........................................................................................... 439
Disturbed Images, Scratches, Streaks, Waves and Creases (Line Speed Fine-tuning) ............... 444
Scratches, Streaks, Waves or Creases (Decurl Unit Line Speed Adjustment) ............................. 454
Roller Marks by Paper Exit Inverter Roller ..................................................................................... 456
Roller Marks on Coated Paper (after Continuous Large-volume Printing) .................................... 457
Fusing Jam When Printing with High Coverage (J033/J034/J083) ............................................... 458
Jams Related to insufficient Separation on Thin Paper ................................................................. 460
Jams Related to Duplex/Invert in Short Grain and Thickest Paper ............................................... 462
Roller Marks on Buffer Pass Unit ................................................................................................... 462
Paper Feed/Transport Problems on Peripherals ............................................................................... 465
Common: A3LCIT /Bypass Tray /Cover Interposer Tray ............................................................... 465
No Feeding (Envelope)................................................................................................................... 466
No Feeding 1 .................................................................................................................................. 466
No Feeding 2 .................................................................................................................................. 469
No Feeding 3 .................................................................................................................................. 477
No Feeding 4 .................................................................................................................................. 482
No Feeding 4 (Cover Interposer Tray) ........................................................................................... 486
No Feeding (Poor-Quality Paper): 3-Tray A3LCIT......................................................................... 488
4. Troubleshooting: Post-Processing Option...................................................................................... 490
Finishing Problems: Finisher/Booklet Finisher................................................................................... 490
Large Paper Not Stacked Properly................................................................................................. 490
When bundle to be bound is poorly aligned ................................................................................... 493
Trailing Edge of Stapled Sheets Close to the Paper Exit............................................................... 495
Leading edge 4mm pitch edges getting dirty ................................................................................. 496
Paper edges get dirty caused by dirt of paper transfer rollers ....................................................... 498

3
Only the Cover Is Discharged During Saddle Stitching (JAM129)................................................. 499
Thin, Coated Paper Eject Error (Stapled Sheets) .......................................................................... 500
Cleaning the Rollers and Guide Boards in the Finisher................................................................. 503
Finishing Problems: Multi-Folding Unit............................................................................................... 507
Folded Sheets Are Not Stacked Properly....................................................................................... 507
Z-Folding Is Not Performed Correctly............................................................................................. 507
Matte Paper Scratched During Folding .......................................................................................... 508
Folds Soiled by Multi-Sheet Folding............................................................................................... 511
Edges of Letter Fold Bent............................................................................................................... 512
Poor Folding.................................................................................................................................... 513
Folding Deviation ............................................................................................................................ 514
Finishing Problems: High Capacity Stacker....................................................................................... 520
Premature Detection of Full When Paper Discharged to Shift Tray .............................................. 520
Marks Left by the Paper Holder...................................................................................................... 521
Prevent Loosening of Screws to the Cart's Handle........................................................................ 522
Finishing Problems: Ring Binder........................................................................................................ 524
SC756-48 (Ring Binder Is Not Detected) ....................................................................................... 524
5. Troubleshooting for the Operation Panel ....................................................................................... 525
Factory Reset ..................................................................................................................................... 525
Factory Reset Procedure................................................................................................................ 525
Restoring after the Factory Reset .................................................................................................. 526
Software Update Errors...................................................................................................................... 528
Errors that occur during application update from an SD card........................................................ 528
Errors that occur during update from the eDC Server ................................................................... 529
Errors That Occur When the Operation Panel Downloads Data from the Controller at Startup ....... 531
6. Improving Throughput..................................................................................................................... 532
Improving Throughput ........................................................................................................................ 532
Reducing the Waiting Time ............................................................................................................ 532
Improving Fusing Capability ........................................................................................................... 533
Improving Productivity when Loading the Different Types/Thicknesses of paper ......................... 534
7. Detailed Procedures of SC Occur .................................................................................................. 536
Detailed Procedures of SC Occur ...................................................................................................... 536
Recovering SC499-03, Preventive Maintenance of Intermediate Transfer Scale ......................... 536
SC441: ITB Drive Motor Error Measure Flow ................................................................................ 540
Recovering from SC756-48 ............................................................................................................ 541
Recovering from SC486 ................................................................................................................. 542
8. Troubleshooting: Image Quality Problems ..................................................................................... 543
Image Index........................................................................................................................................ 543
Large classification: Lines/Streaks ................................................................................................. 543

4
Large classification: Spots.............................................................................................................. 546
Large classification: Full page ........................................................................................................ 547
Others ............................................................................................................................................. 554
9. Image Quality Problem: Lines ........................................................................................................ 555
Streaks................................................................................................................................................ 555
Horizontal Black Streaks (Image Edge) ......................................................................................... 555
Horizontal White Streaks ................................................................................................................ 556
Whiter at the Trailing Edge ............................................................................................................. 557
Vertical Black Streaks..................................................................................................................... 559
Vertical Black (color) Streaks (1).................................................................................................... 561
Vertical Black (color) Streaks (2).................................................................................................... 565
Vertical White Streaks (1)............................................................................................................... 566
Vertical White Streaks (2)............................................................................................................... 574
Vertical Black Streaks Occur after "10: Exe Image Quality Adj Print: Acr Fd" is Executed........... 575
Bands.................................................................................................................................................. 577
Banding (General) .......................................................................................................................... 577
Banding (63 mm intervals).............................................................................................................. 578
Banding (189 mm intervals)............................................................................................................ 580
10. Image Quality Problem: Spots........................................................................................................ 582
Spots................................................................................................................................................... 582
Black (color) Spots (1) .................................................................................................................... 582
Black (color) Spots (2) .................................................................................................................... 585
White Spots/Toner Blasting ............................................................................................................ 587
Medaka (White Spots) .................................................................................................................... 589
Patchy Image at the Leading Edge ................................................................................................ 590
11. Image Quality Problem: Full Page.................................................................................................. 593
Unprinted ............................................................................................................................................ 593
Fainter Leading Edge ..................................................................................................................... 593
Fainter Trailing Edge ...................................................................................................................... 596
Unprinted: When Using a Transparent Film................................................................................... 599
Unprinted: Around Clear-toner Images .......................................................................................... 601
Worm Holes: Text or Edge of an Image ......................................................................................... 604
Worm Holes: When Using the Clear Toner.................................................................................... 608
Replacing the PTR springs............................................................................................................. 613
Uneven Density .................................................................................................................................. 618
Low Image Density of Black Area .................................................................................................. 618
Horizontal White Streaks: Around Black Text ................................................................................ 618
Uneven Density between Left and Right of an Image: 40 mm Interval.......................................... 622
Uneven Density within 90 mm of the Trailing Edge ....................................................................... 623

5
Mottling ........................................................................................................................................... 625
Blurred Image: Around a Clear Image............................................................................................ 631
Residual Gloss (Gloss Ghost) ........................................................................................................ 632
Residual Gloss (Gloss Ghost): Multiple.......................................................................................... 635
Uneven Gloss: Partly...................................................................................................................... 638
Uneven Gloss: Wavy ...................................................................................................................... 638
Uneven Gloss: Side 2..................................................................................................................... 640
Dirtied Printouts .................................................................................................................................. 644
Trailing Edge Dirty at 20 mm Intervals ........................................................................................... 644
Dirty Background ............................................................................................................................ 644
Toner Scattering: Lines .................................................................................................................. 646
Toner Scattering: Trailing Edge...................................................................................................... 648
Toner Scattering: Around a Solid Fill Image .................................................................................. 651
Stained Paper Edges...................................................................................................................... 651
Toner Stains on trailing Edge of think paper .................................................................................. 653
Scratches, Others............................................................................................................................... 656
Narrow Trailing Edge Margin (Image Elongation) .......................................................................... 656
Uneven Gloss Waves at Paper Trailing Edge (When Paper Longer than A4 SEF Is Used)......... 656
Matte Paper Scratched During Folding .......................................................................................... 657
Insufficient Gloss: Clear Image....................................................................................................... 657
Milky Transparency......................................................................................................................... 658
12. Advanced Instructions .................................................................................................................... 662
Shortening the Leading/Trailing Edge Margins.................................................................................. 662
Life Prediction of Developer ............................................................................................................... 663
Capturing the Engine Debug Log....................................................................................................... 664
Overview ......................................................................................................................................... 664
Procedures for Capturing the Engine Debug Log via the Capturing Log Function ....................... 665
Procedures for Capturing the Engine Debug Log via the Service Slot Board (SDCU) ................. 665
Procedures for Capturing the Engine Debug Log via the Debug Cable ........................................ 666
Duct Covers to Reducing Noise Level ............................................................................................... 671
13. Fuses .............................................................................................................................................. 676
Fuses .................................................................................................................................................. 676
Boards Layout................................................................................................................................. 676
PSU1(5V)........................................................................................................................................ 677
PSU2............................................................................................................................................... 677
PSU3............................................................................................................................................... 678
PSU4............................................................................................................................................... 679
PSU5............................................................................................................................................... 679
AC Drive.......................................................................................................................................... 680

6
ACRY .............................................................................................................................................. 680
RYB................................................................................................................................................. 681

1.SC Codes
7
1. SC Codes
Self-Diagnostic Mode
Service Call Conditions
At job end or when the machine is switched off, both sides of the ITB unit are lowered and
separated from the drums.
However, after a power failure or accidental disconnection of the power cord, or after a
machine issues an SC code after a malfunction, both or one side of the ITB may remain up
against the drums.
To avoid damage to the ITB, both sides of the ITB must be checked and lowered before the
ITB unit can be pulled out of the unit.
The ‘SC Table’ section shows the SC codes for controller errors and other errors. The latter are put into
four types. The type is determined by their reset procedures. The table shows the classification of the
SC codes.
Pattern
Display
How to reset
SC call or SC alarm
in customer support
system
A
The SC is immediately displayed on
the operation panel when SC occurs.
The error involves the fusing unit.
The machine operation is disabled.
The user cannot reset the error.
Reset the SC (set SP5-
810-1) and then cycle the
main power off and on.
Occurrence & alarm
count
Immediate alarm
B
When a function is selected, the SC
is displayed on the operation panel.
The machine cannot be used (down-
time mitigation).
Turn the operation switch
off and on..
Occurrence & alarm
count
Power OFF and ON
Alarm count and
alarm only if
recurrence
C
No display on the operation panel.
The machine operates as usual.
Only the SC history is
updated.
Occurrence
Logging count &
alarm count
D
The SC is displayed on the operation
Turn the main power
Occurrence & alarm

1.SC Codes
8
Pattern
Display
How to reset
SC call or SC alarm
in customer support
system
panel.
The machine cannot be used
(machine-error SC).
switch off and on.
count
Power OFF and ON
Alarm count and
alarm only if
recurrence
When an ordinary SC (type D) is generated, an automatic reboot is performed. When an event
is reported by the customer support system, even in the event of an ordinary SC, reboot is not
performed. During automatic reboot, a confirmation screen is displayed after the reboot.
When automatic reboot occurs twice continuously, an SC is displayed without rebooting, and
logging count is performed. Also, when an SMC print is output, an * mark is added alongside
the SC number for clarity.
Automatic reboot can be enabled or disabled with SP5-875-001 (SC automatic reboot setting)
(default value: 0: Manual reboot).
SP descriptions: SP5-875-001 (SC automatic reboot: Reboot Setting)
Enables or disables the automatic reboot function when an SC error occurs.
0: The machine reboots automatically when the machine issues an SC error and logs the SC error
code. If the same SC occurs again, the machine does not reboot.
1: The machine does not reboot when an SC error occurs.
The reboot is not executed for the pattern A or C.
SC Logging
When an SC is generated, the "total count value when the SC is generated" and the "SC code" are
logged. However, if the total count value during the SC is the same as last time, logging is not
performed.
Logged data can be checked by outputting an administrative report (SMC print). The SC history is
logged up to the last 10 entries, and if there are more than 10 entries, data are progressively deleted
starting from the oldest.
SC Automatic Reboot
When an ordinary SC (pattern D) is generated, automatically reboot is performed. Automatic reboot or
reboot by user operation can be set by SP5-875-001 (SC automatic reboot setting out) (default value: 1
"OFF").

1.SC Codes
9
When a type D occurs, automatic reboot is done or the machine display asks the customer if it can
reboot. However, when the SC occurs twice in a short time, the machine sends a report to the
@Remote server without rebooting. This is because just rebooting may not be a good solution if an SC
occurs twice.
When an automatic reboot is performed, a confirmation screen is displayed after reboot. The
confirmation screen can be cancelled by pressing the [OK] key (display is not cancelled only when the
main power switch is switched OFF to ON).
Screen display during reboot
Status display on the current screen
Post-processing ...... Post-processing during printing, etc.
Automatic reboot .... After operation end
Post-processing
Until automatic reboot
Reset key (Reboot key)
Key to perform reboot
# Cancel key is not displayed.
Turn ON spanner LED (same as when an SC is generated).
Operation during SC reboot
Timing of SC reboot
When @Remote is enabled, and when a NRS alarm*1 is not generated, the corresponding SC is
the object of an automatic reboot.
*1 NRS alarm: Issued when an ordinary SC (type D) is generated twice while the total counter
counts 10 times.
Time to automatic reboot
Reboot is performed 30 seconds after an engine reboot is possible, after the end of post-
processing during printing, etc.
At that time, a reboot is performed even if the MFP is operating. The engine does not start process
control when a reboot is possible.
Automatic reboot
See the flowchart below.

1.SC Codes
10
SC Manual Reboot
When the automatic reboot is disabled in SP5-875-001 (SC automatic reboot setting), the user reboots
the machine manually. See the flowchart below.

1.SC Codes
11

1.SC Codes
12
Service Call 101-195(Scanning)
SC100 (Engine)
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC101-
01
D
Lamp Error (Scanning) (Front)
A part or all of the LED board does not light up when scanning.
This error is detected if the level peak of the white plate or ADF background board
did not reach the prescribed threshold, when the white plate or ADF background
board was scanned.
LED defective
IDB (LED driver) defective
BCU defective
SBU defective
IPU defective
Power/signal harness defective
Condensation in scanner unit
Mirrors or lenses dirty or positioned incorrectly
White plate dirty or installed incorrectly
ADF background board dirty
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
If SC101-02/-05/-06 is occurred, refer to the each SC solution.
1. Clean the ADF background board
2. Reconnect the following connectors:
SBU-IPU/BCU harness connector
SBU-LED harness connector
3. Clean or replace the white plate on the exposure glass.
4. Replace the ADF background board
5. Clean the 1st scanner carriage (1stmirror)/2nd scanner carriage (2nd and 3rd
mirror)
6. Replace the SBU board (lens brock).
7. Replace the IPU board.
8. Replace the BCU board.
9. Replace the following harnesses:
SBU-IPU/BCU harness
SBU-LED harness

1.SC Codes
13
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC101-
02
D
Lamp Error (LED illumination adjustment) (Left and Right Side)
A part or all of the LED board on both left and right sides do not light up.
This error is detected if the white level peak did not reach the prescribed threshold
when the white plate was scanned.
LED board defective on both sides
SBU defective
BCU defective
Power/signal harness defective
Condensation in the scanner unit
Mirrors or lenses dirty or positioned incorrectly
White plate dirty or installed incorrectly
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Reconnect the following connectors:
SBU-IPU/BCU harness connector
SBU-LED harness connector
2. Clean or replace the white plate on the exposure glass.
3. Clean the 1st scanner carriage (1stmirror)/2nd scanner carriage (2nd and 3rd
mirror)
4. Replace the LED board on both sides.
5. Replace the lens brock.
6. Replace the IPU board.
7. Replace the BCU board.
8. Replace the following harnesses:
SBU-IPU/BCU harness
SBU-LED harness.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC101-
05
D
Lamp Error (LED illumination adjustment) (Left Side)
A part or all of the LED board on the left side does not light up.
This error is detected if the white level peak did not reach the prescribed threshold
when the white plate was scanned.
LED board defective on the left side
SBU defective
BCU defective
Power/signal harness defective
Condensation in the scanner unit

1.SC Codes
14
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
Mirrors or lenses dirty or positioned incorrectly
White plate dirty or installed incorrectly
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Reconnect the following connectors:
SBU-IPU/BCU harness connector
SBU-LED harness connector
2. Clean or replace the white plate on the exposure glass.
3. Clean the 1st scanner carriage (1stmirror)/2nd scanner carriage (2nd and 3rd
mirror)
4. Replace the LED board on the left side.
5. Replace the lens brock.
6. Replace the IPU board.
7. Replace the BCU board.
8. Replace the following harnesses:
SBU-IPU/BCU harness
SBU-LED harness.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC101-
06
D
Lamp Error (LED illumination adjustment) (Right Side)
A part or all of the LED board on the right side does not light up.
This error is detected if the white level peak did not reach the prescribed threshold
when the white plate was scanned.
LED board defective on the right side
SBU defective
BCU defective
Power/signal harness defective
Condensation in the scanner unit
Mirrors or lenses dirty or positioned incorrectly
White plate dirty or installed incorrectly
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Reconnect the following connectors:
SBU-IPU/BCU harness connector
SBU-LED harness connector
2. Clean or replace the white plate on the exposure glass.

1.SC Codes
15
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
3. Clean the 1st scanner carriage (1stmirror)/2nd scanner carriage (2nd and 3rd
mirror)
4. Replace the LED board on the right sides.
5. Replace the lens brock.
6. Replace the IPU board.
7. Replace the BCU board.
8. Replace the following harnesses:
SBU-IPU/BCU harness
SBU-LED harness.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC102-
00
D
LED Illumination Adjustment Error (Front)
The LED illumination cannot be adjusted.
This error is detected if the white level peak reached the prescribed threshold
when the white plate was scanned after a specified number of adjustments.
LED board defective
SBU defective
BCU defective
Power/signal harness defective
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Reconnect the following connectors:
SBU-IPU/BCU harness connector
SBU-LED harness connector
2. Clean or replace the white plate on the exposure glass.
3. Clean the 1st scanner carriage (1stmirror)/2nd scanner carriage (2nd and 3rd
mirror)
4. Replace the LED board on both sides.
5. Replace the lens brock.
6. Replace the IPU board.
7. Replace the BCU board.
8. Replace the following harnesses:
SBU-IPU/BCU harness
SBU-LED harness.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC120-
D
Scanner Home Position Error 1

1.SC Codes
16
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
00
The scanner home position sensor does not go OFF.
Details:
Error detection timing
During homing (when the machine is turned ON or when it returns from
energy save mode)
During an automatic adjustment (when the machine is turned ON or when it
returns from energy save mode)
During a scan from the ADF or exposure glass.
Scanner motor driver defective
Scanner motor defective
Scanner HP sensor defective
Harness defective
Timing belt, pulley, wire, or carriage not installed correctly
Cycle the machine off/on.
Replace the scanner motor.
Replace the HP sensor.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC121-00
D
Scanner Home Position Error 2
The scanner home position sensor does not go ON.
Details:
Error detection timing
During homing
During an automatic adjustment
During a scan from the ADF or exposure glass.
Scanner motor driver defective
Scanner motor defective
Scanner HP sensor defective
Harness defective
Timing belt, pulley, wire, or carriage not installed correctly
Cycle the machine off/on.
Replace the scanner motor.
Replace the HP sensor.
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
SC141-
00
D
Black level detection error (Front)
The black level cannot be adjusted when the initial adjustments of the CMOS
