This training course provides service technician training for the PE-MF4/PE-
P4 series.
The differences between this series and the previous PE-MF3/PE-P2 series
are also explained.
Revision History
- Version1.2 (Revised 9th Apr. 2014)
Slide 12:
Updated MonthlyAverage Print Volume
MF4a:0.7K prints
MF4c:0.8K prints
P4a:0.4K prints
P4c:0.5K prints
- Version1.1 (Revised 17th Feb. 2014)
Slide 10: Long (High Yield) AIO will be available for NA, EU, AP, CN models.

2
This section provides an overview of the machine, and the options that can
be installed.

3
Pe-MF3a was 16 ppm.
Pe-MF3a/P2a were GDI models.
Memory specs are changed from PE-MF3/P2.
Built-in Wireless LAN is a new feature. It was not available in previous
models.

4
No additional notes

5
Duplex can be used for printing and copying. In some earlier models in this series,
duplex could not be used for copying.

6
No additional notes

7
No additional notes

8
No additional notes

9
No additional notes

10
Based on ISO 19798
Revised 17th Feb. 2014
-Long (High Yield) AIO will be available for NA, EU, AP,CN models.

11
The waste toner tank is the same as the one that is used for previous models in this
series.
Waste toner tank yield measurement based on 5%, 3P/J, 50% color ratio
Color ratio: 50% means that half the jobs are black-and white, and half are
color
Compatible with Pe-P1, Pe-MF1, Pe-MF2, Pe-P2, and Pe-MF3

12
Same as the PE-MF3/P2 series.
Revised 9th Apr. 2014
-Updated version
MF4a:0.7K prints
MF4c:0.8K prints
P4a:0.4K prints
P4c:0.5K prints
-Previous version
MonthlyAverage Print Volume
MF4a, P4a: 0.65K prints
MF4c: 1.1K prints
P4c: 0.8K prints

13
This section provides an overview of the main specifications and explains
improvements over the previous models in the PE series.

14
No additional notes

15
Same as PE-MF3, except where mentioned.
Why is 1st copy time so much slower than the 1st print time?
Scanner initialization and movement to the start position takes more time.
Duplex printing cannot be done for thick paper (more than 90 g/m2).
Printing on OHP transparencies is not possible.

16
PDL for PE-MF3a: DDST (GDI)

17
These specs are the same as PE-P2, except where mentioned.

18
PDL for PE-P2a: DDST (GDI)

19
No additional notes

20
