Ricoh SP 8400DN User manual

Read this manual carefully before you use this machine and keep
it handy for future reference. For safe and correct use, be sure to
read the Safety Information in this manual before using the
machine.
For information not found in paper
manuals, see the online manuals available
on our web site
(http://www.ricoh.com/).
Other Information for This Machine
Safety Labels of This Machine
Safety Information for This Machine
Information
4.
3.
2.
1.
Read This First
English

English

1
1. Information
Introduction
This manual contains detailed instructions and notes on the operation and use
of this machine. For your safety and benefit, read this manual carefully before
using the machine. Keep this manual in a handy place for quick reference.
Manuals for This Machine
The operating instructions of this machine are provided in the following
formats:
Format Manuals
Printed manuals • Read This First
• Quick Installation Guide
• Start Guide
CD-ROM • Driver Installation Guide
Manuals displayed on the control panel • Operating Instructions (HTML)
Web page • Read This First
• Quick Installation Guide
• Start Guide
• User Guide
• Driver Installation Guide
• Operating Instructions (HTML)
Read This First
Before using the machine, be sure to read the section of this manual entitled
Safety Information. It also describes each regulation and environmental
conformance.
Quick Installation Guide
Describes procedures for unpacking and setting up the machine, which
include loading paper and installing print cartridge, etc.
Start Guide
Describes how to read manuals on the control panel. It also describes how
to log in to the machine.
User Guide
Regarding the basic usage of this machine, frequently used functions,
troubleshooting when an error message appears, etc., summaries are
provided for each user manual.
User Guide is provided in different formats depending on the language:
• English, German, French, Italian, Spanish, Dutch, and Russian: in PDF
• Other languages: in HTML

2
Operating Instructions (HTML)
Describes the setup for using the machine, how to use functions to print or
for maintenance and specifications, troubleshooting, system settings, and
security functions.
Manuals are available in English, German, French, Italian, Spanish, Dutch,
and Russian.
User Guide and Security Guide are available in the seven languages above
and other languages.
For details about how to use the HTML manuals, see "How to Use the
Operating Instructions", Operating Instructions.
Driver Installation Guide
Describes how to install and configure each driver. This manual is included
in the drivers CD.
• Before you configure the extended security and authentication settings,
refer to "Before Using This Machine" in the Security Guide.
• You can see the following manuals on the Web page.
• Appendix
• DHCP Option 204

3
2. Safety Information for This Machine
Safety Symbols for This Machine
The meanings of the safety symbols for this machine are as follows:
Caution
Do not touch
Do not throw into the fire
Do not use the cleaner
Keep out of reach of children
Caution, hot surface
Caution, risk of having hands or arms caught

4
Safety Information
In this manual, the following important symbols are used:
RWARNING:
Indicates a potentially hazardous situation which, if instructions are not
followed, could result in death or serious injury.
RCAUTION:
Indicates a potentially hazardous situation which, if instructions are not
followed, may result in minor or moderate injury or damage to property.
EnvironmentsWhere the Machine Can be Used
RWARNING:
• Do not use flammable sprays or solvents in the vicinity of this machine.
Also, avoid placing these items in the vicinity of this machine. Doing so
could result in fire or electric shock.
• Do not place vases, plant pots, cups, toiletries, medicines, small metal
objects, or containers holding water or any other liquids, on or close to this
machine. Fire or electric shock could result from spillage or if such objects
or substances fall inside this machine.
RCAUTION:
• Keep the machine away from humidity and dust. Otherwise a fire or an
electric shock might occur.
• Do not place the machine on an unstable or tilted surface. If it topples over,
an injury might occur.
• Do not place heavy objects on the machine. Doing so can cause the
machine to topple over, possibly resulting in injury.
• Make sure the room where you are using the machine is well ventilated
and spacious. Good ventilation is especially important when the machine is
used heavily.
• Do not obstruct the machine’s vents. Doing so risks fire caused by
overheated internal components.

5
Handling Power Cords and Power Plugs
RWARNING:
• Do not use any power sources other than those that match the
specifications shown. Doing so could result in fire or electric shock.
• Do not use any frequencies other than those that match the specifications
shown. Doing so could result in fire or electric shock.
• Do not use multi-socket adaptors. Doing so could result in fire or electric shock.
• Do not use extension cords. Doing so could result in fire or electric shock.
• Do not use power cords that are damaged, broken, or modified. Also, do not
use power cords that have been trapped under heavy objects, pulled hard, or
bent severely. Doing so could result in fire or electric shock.
• If the power cord is damaged and its inner wires are exposed or broken,
contact your service representative for a replacement. Use of damaged
power cords could result in fire or electric shock.
Be sure to disconnect the plug from the wall outlet at least once a year and
check for the following:
• There are burn marks on the plug.
• The prongs on the plug are deformed.
If any of the above conditions exist, do not use the plug and consult your dealer
or service representative. Use of the plug could result in fire or electric shock.
Be sure to disconnect the power cord from the wall outlet at least once a year
and check for the following:
• The power cord’s inner wires are exposed, broken, etc.
• The power cord’s coating has a crack or dent.
• When bending the power cord, the power turns off and on.
• Part of the power cord becomes hot.
• The power cord is damaged.
If any of the above conditions exist, do not use the power cord and consult
your dealer or service representative. Use of the power cord could result in
fire or electric shock.
• Touching the prongs of the power cable’s plug with anything metallic
constitutes a fire and electric shock hazard.
• The supplied power cord is for use with this machine only. Do not use it with
other appliances. Doing so could result in fire or electric shock.

6
• It is dangerous to handle the power cord plug with wet hands. Doing so
could result in electric shock.
RCAUTION:
• Be sure to push the plug of the power cord fully into the wall outlet. Partially
inserted plugs create an unstable connection that can result in unsafe
buildup of heat.
• If this machine is not going to be used for several days or longer at a time,
disconnect its power cord from the wall outlet.
• When disconnecting the power cord from the wall outlet, always pull the
plug, not the cord. Pulling the cord can damage the power cord. Use of
damaged power cords could result in fire or electric shock.
• Be sure to disconnect the plug from the wall outlet and clean the prongs
and the area around the prongs at least once a year. Allowing dust to build
up on the plug constitutes a fire hazard.
• When performing maintenance on the machine, always disconnect the
power cord from the wall outlet.
• Power Source
120–127 V, 12 A or more, 60 Hz
Please be sure to connect the power cord to a power source as above.
Handling the Main Machine
RWARNING:
• Be sure to locate the machine as close as possible to a wall outlet. This will
allow easy disconnection of the power cord in the event of an emergency.
• If the machine emits smoke or odours, or if it behaves unusually, you
must turn off its power immediately. After turning off the power, be sure
to disconnect the power cord plug from the wall outlet. Then contact your
service representative and report the problem. Do not use the machine.
Doing so could result in fire or electric shock.
• If metal objects, or water or other fluids fall inside this machine, you must
turn off its power immediately. After turning off the power, be sure to
disconnect the power cord plug from the wall outlet. Then contact your
service representative and report the problem. Do not use the machine.
Doing so could result in fire or electric shock.
• When replacing the Fusing Unit, turn the main power switch off and wait at
least 60 minutes before proceeding with the replacement.

7
• Do not touch this machine if a lightning strike occurs in the immediate
vicinity. Doing so could result in electric shock.
• The following explains the warning messages on the plastic bag used in
this product’s packaging.
• Keep the polythene materials (bags, etc.) supplied with this machine
away from babies and small children at all times. Suffocation can result
if polythene materials are brought into contact with the mouth or nose.
RCAUTION:
• Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, take care that the power cord is not damaged
under the machine. Failing to take these precautions could result in fire or
electric shock.
• If you have to move the machine when the optional paper tray unit is
attached, do not push on the main unit’s top section. Doing so can cause
the optional paper tray unit to detach, possibly resulting in injury.
• The machine weighs approximately 57 kg (125.7 lb.).
• When moving the printer, hold the handles located on both sides, and then
lift it slowly. Lifting it carelessly or dropping it may cause an injury.
• If the lower paper tray is installed, do not pull out more than one tray at a
time when you are changing or replenishing paper or resolving paper jams.
Pressing down forcefully on the machine's upper surfaces can result in
malfunctions and/or user injury.
• Contact your service representative if you need to lift the machine (such
as when relocating it to another floor). Do not attempt to lift the machine
without the assistance of your service representative. The machine will
be damaged if it topples or is dropped, resulting in malfunction and risk of
injury to users.
• Do not look into the lamp. It can damage your eyes.
• Do not hold the control panel while moving the machine. Doing so may
damage the control panel, cause a malfunction, or result in injury.
• Do not pull out paper trays while moving the machine. Doing so may
damage the control panel, cause a malfunction, or result in injury.

8
Handling the Machine’s Interior
RWARNING:
• Do not remove any covers or screws other than those explicitly mentioned
in this manual. Inside this machine are high voltage components that are
an electric shock hazard and laser components that could cause blindness.
Contact your sales or service representative if any of the machine’s internal
components require maintenance, adjustment, or repair.
• Do not attempt to disassemble or modify this machine. Doing so risks burns
and electric shock. Note again that exposure to the laser components
inside this machine risks blindness.
RCAUTION:
• Some of this machine's internal components get very hot. For this reason,
take care when removing misfed paper. Not doing so could result in burns.
• Some of the internal components of this machine might be fragile. When
you remove jammed paper, do not touch the sensors, connectors, LEDs, or
other fragile parts that are shown in the Troubleshooting manual. Doing so
may cause malfunctions.
• When removing jammed paper, make sure not to trap or injure your fingers.
• When loading paper, take care not to trap or injure your fingers.
• Keep your hands clear of the booklet finisher tray when removing misfed
paper, pulling out or pushing in the finisher's staple unit. You can trap and
injure your fingers if you do not.
• While safety measures have been installed to prevent accidents, you must
not touch the machine's rollers while it is operating. Doing so could cause
injury.
• If the machine's interior is not cleaned regularly, dust will accumulate. Fire
and breakdown can result from heavy accumulation of dust inside this
machine. Contact your sales or service representative for details about and
charges for cleaning the machine's interior.

9
Handling the Machine’s Supplies
RWARNING:
• Do not incinerate toner (new or used) or toner containers. Doing so risks
burns. Toner will ignite on contact with naked flame.
• Do not store toner (new or used) or toner containers anywhere near naked
flames. Doing so risks fire and burns. Toner will ignite on contact with naked
flame.
• Do not use a vacuum cleaner to remove spilled toner (including used
toner). Absorbed toner may cause a fire or explosion due to electrical
contact flickering inside the vacuum cleaner.
However, it is possible to use a vacuum cleaner that is explosion-proof and
dust ignition-proof. If toner is spilled on the floor, remove the spilled toner
slowly using a wet cloth, so that the toner is not scattered.
RCAUTION:
• Do not crush or squeeze toner containers. Doing so can cause toner spillage,
possibly resulting in dirtying of skin, clothing, and floor, and accidental
ingestion.
• Store toner (new or used), toner containers, and components that have been
in contact with toner out of reach of children.
• If toner or used toner is inhaled, gargle with plenty of water and move into a
fresh air environment. Consult a doctor if necessary.
• If toner or used toner gets into your eyes, flush immediately with large
amounts of water. Consult a doctor if necessary.
• If toner or used toner is swallowed, dilute by drinking a large amount of
water. Consult a doctor if necessary.
• When removing jammed paper or replacing toner, avoid getting toner (new
or used) on your clothing. If toner comes into contact with your clothing,
wash the stained area with cold water. Hot water will set the toner into the
fabric and make removing the stain impossible.
• When removing jammed paper or replacing toner, avoid getting toner (new
or used) on your skin. If toner comes into contact with your skin, wash the
affected area thoroughly with soap and water.
• When replacing a toner or waste toner container or consumables with toner,
make sure that the toner does not splatter. Put the waste consumables in a bag
after they are removed. For consumables with a lid, make sure that the lid is shut.

10
• Do not attempt to print on stapled sheets, aluminum foil, carbon paper, or
any kind of conductive paper. Doing so risks fire.
• Keep SD cards or USB flash memory devices out of reach of children. If
a child accidentally swallows an SD card or USB flash memory device,
consult a doctor immediately.

11
3. Safety Labels of This Machine
This section explains the machine’s safety information labels.
Positions of RWARNING and RCAUTION labels
This machine has labels for RWARNING and RCAUTION at the positions
shown below. For safety, please follow the instructions and handle the machine
as indicated.
Main unit
DUL801
3
1
2
1 and 2.
The inside of the machine could be very hot. Do not touch the parts which a label
is put on. Otherwise, an injury might occur.
3.
Do not touch the parts a label indicates. The inside of the machine could be very
hot. Caution should be taken when removing misfed paper.

12
Paper trays
DUL802
2
1
1 and 2.
The inside of the machine could be very hot. Do not touch the parts which a label
is put on. Otherwise, an injury might occur.

13
Finisher SR3210
DUL803
4
3
2
1
1.
During operation, rollers for transporting the paper revolve. Take care not to touch
rollers during operation. Otherwise, an injury might occur.
2 and 4.
Keep your hands clear of the booklet finisher tray when pulling out or pushing
in the finisher's staple unit, or removing paper jam.You might trap your fingers
if you do not. Take care not to touch the booklet finisher tray during operation.
Otherwise, an injury might occur.
3.
The machine weighs approximately 44 kg (97 lb.).
When lifting it, lift it slowly with three or more people and be careful not to put a
strain on your body.

14
Finisher SR3230
DUL804
2
1
4
3
1 and 2.
During operation, rollers for transporting the paper revolve. Take care not to touch
rollers during operation. Otherwise, an injury might occur.
3.
The machine weighs approximately 42 kg (93 lb.).
When lifting it, lift it slowly with three or more people and be careful not to put a
strain on your body.
4.
Be careful of the protruding parts when opening the front cover.
Symbols for Power Switch
Symbols for power switch that are used for this machine are as follows:
• : POWER ON
• : STANDBY

15
4. Other Information for This Machine
Legal Prohibition
Do not copy or print any item for which reproduction is prohibited by law.
Copying or printing the following items is generally prohibited by local
law:bank notes, revenue stamps, bonds, stock certificates, bank drafts, checks,
passports, driver's licenses.The preceding list is meant as a guide only and is
not inclusive. We assume no responsibility for its completeness or accuracy. If
you have any questions concerning the legality of copying or printing certain
items, consult with your legal advisor.
Laser Safety
CDRH Regulations
This equipment complies with requirements of 21 CFR Subchapter J for
class I laser product. This equipment contains two AlGaInP laser diodes, 660
nanometer wavelength for each emitter. The beam divergence angle is 15
degrees (minimum) and 25 degrees (maximum) in the vertical direction, and
7 degrees (minimum) and 13 degrees (maximum) in the horizontal direction,
and laser beams are generated in Continuous Wave (CW) mode. The maximum
output power of the light source is 15 milliwatt.
Caution
Use of controls or adjustments or performance of procedures other than those
specified in this manual might result in hazardous radiation exposure.
Notes to Users in the United States of America
FCC Rules
Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:

16
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio /TV technician for help.
Caution:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment should be installed and operated keeping
the radiator at least 20 cm or more away from person’s body (excluding
extremities: hands, wrists, feet and ankles).
Declaration of Conformity
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Responsible party: Ricoh USA, Inc.
Address: 70 Valley Stream Parkway Malvern, Pennsylvania 19355
Telephone number: 610-296-8000
Product Name: Printer
Model Number: SP 8400DN
Using the Shield Cable
Properly shielded and grounded cables and connectors must be used for
connections to a host computer (and/or peripheral) in order to meet FCC
emission limits.

Lea atentamente este manual antes de utilizar la máquina y
guárdelo a mano para consultarlo en el futuro. Para un uso
seguro y correcto, lea "Información de seguridad" antes de
utilizar la máquina.
Para información no contenida en los
manuales en papel, consulte los manuales
online de nuestra página web
(http://www.ricoh.com/).
Más información sobre esta máquina
Etiquetas de seguridad de esta máquina
Información de seguridad de esta
máquina
Información
4.
3.
2.
1.
Leer antes de
empezar
Español

Español
