User’s Manual
RICOH PJ KU12000 Series

2
Safety Information
This chapter describes safety information for this machine.
Information
Introduction
This manual contains detailed instructions and notes on the operation and use of
this machine. For your safety and benet, read this manual carefully before using
the machine. Keep this manual in a handy place for quick reference.
Important
Contents of this manual are subject to change without prior notice.
In no event will the company be liable for direct, indirect, special, incidental, or
consequential damages as a result of handling or operating the machine.
Some illustrations in this manual might be slightly different from the machine.
Please ask the specialists to replace the lamp.
The description of the lamp replacement is for the specialists.
Caution
The manufacturer shall not be responsible for any damage or expense that might
result from the use of parts other than genuine parts from the manufacturer with
your ofce products.

3
Safety Information
When using this machine, the following safety precautions should always be fol-
lowed.
Safety During Operation
In this manual, the following important symbols are used:
WARNING
Indicates a potentially hazardous situation which, if instructions are not followed,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if instructions are not followed,
may result in minor or moderate injury or damage to property.
Safety Precautions to Be Followed
This section explains safety precautions that should always be followed when using
this machine.
Environments where the machine can be used
This section explains safety precautions about environments where the machine
can be used.
WARNING
Do not place vases, plant pots, cups, toiletries, medicines, small metal
objects, or containers holding water or any other liquids, on or close to this
machine. Fire or electric shock could result from spillage or if such objects or
substances fall inside this machine.
WARNING
Keep the product and attachments out of the reach of children. If the product
is near children, it might fall over and cause an injury.

4
CAUTION
Keep the machine away from humidity and dust. Otherwise a re or an elec-
tric shock might occur.
CAUTION
Do not place any objects on the machine. Doing so may cause the machine
to topple over, possibly resulting in injury.
CAUTION
Do not place the machine on an unstable or tilted surface. If it topples over,
an injury might occur.
CAUTION
Do not place the product or use it in an environment where it might get wet
such as from snow, rain, or being near water. Doing so could result in re or
electric shock.
CAUTION
Do not put your face or hand near the exhaust vents. Doing so could result in
burns or an accident due to hot air coming from the exhaust vents.
CAUTION
Do not use the product on soft material such as paper or cloth that might get
sucked into the intake vents. Doing so may cause heat buildup inside the
product, resulting in malfunction, burns, or re.
CAUTION
Do not place the power cord and connection cable in a way that might cause
someone to trip and fall. The product might fall over and cause an injury.
CAUTION
Do not place the product in a location where air ow is poor. Doing so may
cause re due to internal components becoming overheated.

5
CAUTION
Do not place or store the product in a location where direct sunlight or heat
generation might occur. The heat may deform or wear out the exterior parts
or negatively affect internal parts. Doing so could result in re.
CAUTION
Do not place low heat resistant material near the exhaust vents. Hot air may
come from the exhaust vents, resulting in damage to the product or an ac-
cident.
CAUTION
Do not expose the product to salt air or corrosive gas. Also, do not place the
product in a laboratory or other location where a chemical reaction might oc-
cur. Doing so may cause the product to malfunction.
CAUTION
Do not obstruct the machine’s vents. Doing so risks re caused by overheat-
ed internal components.
Handling power cords and power cord plugs
This section explains safety precautions about handling power cords and power
cord plugs.
WARNING
Do not use any power sources other than those that match the specications
shown. Doing so could result in re or electric shock.
WARNING
Do not use any frequencies other than those that match the specications
shown. Doing so could result in re or electric shock.
WARNING
Do not damage, break, or modify the power cord. Also, do not place heavy
objects on the power cord, or pull the cord or bend it severely. Doing so could
result in re or electric shock.

6
WARNING
Touching the prongs of the power cable’s plug with anything metallic consti-
tutes a re and electric shock hazard.
WARNING
The supplied power cord is for use with this machine only. Do not use it with
other appliances. Doing so could result in re or electric shock.
WARNING
It is dangerous to handle the power cord plug with wet hands. Doing so could
result in electric shock.
WARNING
Be sure to disconnect the plug from the wall outlet at least once a year.
There are burn marks on the plug.
The prongs on the plug are deformed.
If any of the above conditions exist, do not use the plug and consult your
dealer or service representative. Use of the plug could result in re or electric
shock.
WARNING
Be sure to disconnect the power cord from the wall outlet at least once a
year.
The power cord’s inner wires are exposed, broken, etc.
The power cord’s coating has a crack or dent.
When bending the power cord, the power turns off and on.
Part of the power cord becomes hot.
The power cord is damaged.
If any of the above conditions exist, do not use the power cord and consult
your dealer or service representative. Use of the power cord could result in
re or electric shock.

7
WARNING
Do not use the connection cable if it is deformed, cracked, or damaged.
Doing so could result in re or electric shock. If the connection cable is de-
formed, cracked, or damaged, contact your service representative to request
a replacement cable.
WARNING
When using an extension cord or power strip, only connect equipment whose
total power consumption is within the power rating for the extension cord or
power strip. If the power rating is exceeded, it may cause heat buildup and
result in re.
WARNING
Do not place the power cord and connection cable in front of the lens or ex-
haust vents when the product is turned on. Doing so may result in re.
CAUTION
Push the power plug all the way into the power outlet. Do not use a power
outlet with a loose connection. Doing so may result in heat buildup. Plug the
power cord in the correct direction into the base. If they are not plugged in
correctly, it could result in smoke, re, or electric shock.
CAUTION
If this machine is not going to be used for several days or longer at a time,
disconnect its power cord from the wall outlet.
CAUTION
When disconnecting the power cord from the wall outlet, always pull the plug,
not the cord. Pulling the cord can damage the power cord. Use of damaged
power cords could result in re or electric shock.
CAUTION
Be sure to disconnect the plug from the wall outlet and clean the prongs and
the area around the prongs at least once a year. Allowing dust to build up on
the plug constitutes a re hazard.

8
CAUTION
When performing maintenance on the machine, always disconnect the power
cord from the wall outlet.
Handling the main machine
This section explains safety precautions about handling the main machine.
WARNING
If the machine emits smoke or odours, or if it behaves unusually, you must
turn off its power immediately. After turning off the power, be sure to discon-
nect the power cord plug from the wall outlet. Then contact your service rep-
resentative and report the problem. Do not use the machine. Doing so could
result in re or electric shock.
WARNING
If metal objects, or water or other uids fall inside this machine, you must turn
off its power immediately. After turning off the power, be sure to disconnect
the power cord plug from the wall outlet. Then contact your service represen-
tative and report the problem. Do not use the machine. Doing so could result
in re or electric shock.
WARNING
Do not touch this machine if a lightning strike occurs in the immediate vicinity.
Doing so could result in electric shock.
WARNING
The following explains the warning messages on the plastic bag used in this
product’s packaging.
Keep the polythene materials (bags, etc.) supplied with this machine
away from babies and small children at all times. Suffocation can result if
polythene materials are brought into contact with the mouth or nose.

9
WARNING
If the machine topples, or if a cover or other part gets broken, you must turn
off its power immediately. After turning off the power, be sure to disconnect
the power cord plug from the wall outlet. Then contact your service
representative and report the problem. Do not use the machine. Doing so
could result in re or electric shock.
WARNING
Contact your sales or service representative to clean or replace parts for a
projector that is installed on a wall or ceiling.
Do not attempt to clean or replace parts for a projector that is installed in
a high location on a wall or ceiling. Doing so may cause it to fall down,
resulting in an injury.
Do not open the lamp cover of a projector that is installed on a wall or
ceiling. Doing so may cause the lamp cover to fall down. If the lamp is
broken, pieces of glass may fall and cause an injury.
WARNING
If a projector is incorrectly installed on a wall or ceiling, it may fall down and
cause an injury. Contact your sales or service representative if you want to
install a projector on a wall or ceiling.
Use brackets that are strong enough to support the projector. The
projector weighs about 23.8kg (52.5lbs) (Projector weight without lens).
The projector must be installed in a location that is sturdy enough to
support the full weight of the projector and brackets.
CAUTION
The machine may be very hot after it is turned off, especially the vents and
the lower part of the unit where the lamp is located. Avoid touching these
areas. Doing so may result in burns.
CAUTION
Do not place the product on other equipment or vice versa. Doing so may
cause heat buildup inside the product or cause the other equipment to
malfunction.

10
CAUTION
Do not increase the volume unless you are listening while increasing the
volume. Also, lower the volume before turning off the power, because a loud
sound may be emitted when the power is turned on and cause hearing dam-
age.
Handling the machine’s interior
This section explains safety precautions about handling the machine’s interior.
WARNING
Do not remove any covers or screws that are not mentioned in this manual.
There are high voltage components inside the product that may cause elec-
tric shock. Contact your service representative if any of the product’s internal
components require maintenance, adjustment, or repair.
Do not disassemble or modify the product. Doing so may cause injury or
malfunction.
CAUTION
If the machine’s interior is not cleaned regularly, dust will accumulate. Fire
and breakdown can result from heavy accumulation of dust inside this
machine. Contact your sales or service representative for details about and
charges for cleaning the machine’s interior.

11
About the batteries
Explains things that you should follow in regard to the batteries.
WARNING
For safe operation, follow the warnings below regarding the batteries used in
the remote control. If you use the batteries incorrectly, it may result in re or
injury due to batteries leaking or exploding.
Do not use batteries other than the ones specied.
Do not mix and use batteries that are different types or that are new and
old.
Correctly insert batteries according to the polarity (+/-).
Do not charge non-rechargeable batteries.
Do not heat or throw the batteries into re or water.
Do not connect the positive and negative terminals on a battery with a
wire.
Remove the batteries from the remote control that are past their sug-
gested use period or that are depleted.
Remove the batteries when they will not be used for extended periods.
Keep the batteries out of the reach of children. Children may swallow or
choke on the batteries. If this happens, contact a doctor immediately.
WARNING
What to do if a battery has leaked
If leakage from a battery adheres to your skin, rinse it with water immedi-
ately, and then contact a doctor.
Wipe off the leakage with tissue paper while being careful not to touch it.
Soak the tissue paper that you used in water, and then throw it away as
burnable trash.

12
About the lamp
Explains things that you should follow in regard to the lamp.
WARNING
Do not look into the lens or vent when the product is on. The bright light may
damage your eyes. Be especially careful in an environment with children.
WARNING
Before replacing the lamp, turn off the power and wait at least one hour to
allow the product to cool completely. If it is not completely cool, you may burn
or injure yourself due to the inside of the product and lamp unit being hot.
If you replace the lamp without unplugging the power cord from the power
outlet, electric shock or explosion may occur.
Be careful when handling the used lamp so that it does not break. If it breaks,
it may cause injury.
CAUTION
The product’s light uses a mercury vapor lamp that becomes high pressure
when it is turned on. The lamp has the following characteristics, so be sure to
handle it with care after understanding the contents.
Deterioration or shock can cause the lamp’s life span to end or the lamp
to explode. If the lamp explodes, it may make a big noise.
The time that it takes for the lamp to reach its life span or explode de-
pends on each individual lamp and its operating conditions. It is possible
that it might explode the rst time it is used.
If you use the lamp past its replacement period, the possibility of explo-
sion increases.
If the lamp explodes, broken glass pieces may be scattered around the
inside of the product and ejected from the vent or other opening.
If the lamp explodes, a very small amount of mercury vapor in the lamp
tube and broken glass pieces may be ejected from the vents or other
opening.

13
CAUTION
What to do if a lamp has exploded
If the lamp explodes, remove the power cord from the product, leave the
room while making sure it is thoroughly ventilated.
If the lamp explodes and you think that you have gotten glass particles
or mercury vapor in your eyes or have inhaled either, contact a doctor
immediately.
Clean up the area around the product completely while being careful not
to get injured from any broken glass pieces.
Throw away any food that was near the product.
Ask your service representative to replace the lamp and inspect the
product.
CAUTION
Do not block the projection light when it is on. If you do so, the part that is
blocking the projection light may get quite hot and deform, deteriorate or
cause a burn or re. The reected light may make the lens hot and cause a
product failure. To temporarily suspend projection, select the mute function.
To suspend longer, turn off the product.
CAUTION
Be sure to always use a dedicated replacement lamp that is new when
replacing the lamp. If you use a lamp that is not dedicated, it may result in an
explosion and injury.
Moving
This section explains safety precautions about moving the machine.
CAUTION
Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, take care that the power cord is not damaged
under the machine. Failing to take these precautions could result in re or
electric shock.

14
Other Information
Copyrights to Images
When projecting images using the projector, be careful not to infringe the copyright
of protected materials.
The following are examples that may infringe the copyright of protected materials.
• Broadcasting images or movies for commercial purposes
• Modifying images or movies using functions such as freeze, magnify, or zoom to
broadcast images for commercial pur poses or public viewing
• Varying the aspect ratio of images or movies using a function that changes the
screen size to broadcast images for com mercial purposes or public viewing
Note to Users Viewing 3D Images
Pay attention to the following points when viewing images us ing 3D glasses with
projector:
• How 3D images are viewed may vary according to the indi vidual.
• Do not use 3D glasses for viewing any material other than 3D images.
• Before viewing 3D images, make sure to read the manuals provided with your 3D
glasses and 3D compatible content.
• Avoid viewing 3D images for a long period of time. Take a break of 15 minutes or
longer after every hour of viewing.
• If you feel sick while viewing 3D images, stop viewing them. If you continue to
feel sick, consult a doctor.
• When viewing 3D image in a room where on LED lighting system or uorescent
lights are used, you may feel that the light in the room ickers. If this is the case,
dim the lights until you do not notice any ickers, or turn off the lights.
• If you or any member of your family has a history of lightsen sitive seizures, con-
sult a doctor before viewing 3D images.

15
Safety Marks of This Machine
Positions of WARNING and CAUTION marks
This machine has marks for WARNING and CAUTION at the positions shown be-
low. For safety, please follow the instructions and handle the machine as indicated.
Main unit
14
5
3
2
1
The lamp attention is for the specialists only.
2
Do not put your face or hand near the exhaust vents. Doing so could result in burns
or an accident due to hot air coming from the exhaust vents.
3
Do not look into the lens when the product is on. The bright light may damage your
eyes.
Do not place anything in front of the lens. The object may become very hot and
cause a re or burn. To blank the image temporarily, turn on the mute function.

16
4
Do not remove any screws except the lamp cover screws.
Do not block or cover the vents.
5
Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws.
Power Switch Symbols
The meanings of the symbols for the switches on this machine are as follows:
 : STANDBY

17
Laws and Regulations
User Information on Electrical and Electronic Equipment
If you wish to discard this product, please contact your local authorities, the shop where you
bought this product, your local dealer or sales/service representatives.
Regulation & Safety Notices
This appendix lists the general notices of your Projector.
Notice: Users in the United States of America
FCC notice
MODEL NAME: RICOH PJ KU12000
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Caution: Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

18
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to
maintain compliance with FCC regulations.
Caution
Changes or modications not expressly approved by the manufacturer could void the
user’s authority, which is granted by the Federal Communications Commission, to
operate this projector.
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR
DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS.
Notes to Users in the State of California
Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/hazardouswaste/
perchlorate.
WARNING: Handling the cord on this product will expose you to lead, a chemical known to the
State of California to cause cancer, and birth defects or other reproductive harm.
Wash hands after handling.
Notes to Canadian Users
Remarques à l’attention des utilisateurs au Canada
Contains mercury / Contient du mercure
For more information on safe handling
procedures, the measures to be taken
in case of accidental breakage and
safedisposal option visit:
www.ec.gc.ca/mercure-mercury
Dispose of or recycle in accordance with
applicable laws.
Pour plus d’ informations sur les procédures
de manutention sécuritaire, les mesures à
prendre en cas de bris accidentel et option
d’ élimination sécuritaire visitez:
www.ec.gc.ca/mercure-mercury/default.
asp?lang=Fr&n=DB6D2996-1
Éliminez ou les recyclez conformément aux
lois applicables.
Declaration of Conformity for EU countries
`EMC Directive 2004/108/EC (including amendments)
`Low Voltage Directive 2006/95/EC
Warning
This is a Class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures

19
Notice: Users in EU countries
CE Marking Traceability Information (For EU Countries Only)
Manufacturer:
Ricoh Co., Ltd.
3-6 Nakamagome 1-chome, Ohta-ku, Tokyo. 143-8555,
Japan
Importer:
Ricoh Europe PLC
20 Triton Street, London. NW1 3BF, United Kingdom
User Information on Electrical and Electronic Equipment
Users in the countries where this symbol shown in this section has been specied in national
law on collection and treatment of E-waste.
Our Products contain high quality components and are designed to facilitate recycling.
Our products or product packaging are marked with the symbol below.
This product contains substances which are harmful to humans and the environment.
• The lamp contains mercury.
Please dispose of this product or used lamps in accordance with local regulations.
The symbol indicates that the product must not be treated as municipal waste. It must
be disposed of separately via the appropriate return and collection systems available. By
following these instructions you ensure that this product is treated correctly and help to re-
duce potential impacts on the environment and human health, which could otherwise result
from inappropriate handling. Recycling of products helps to conserve natural resources and
protect the environment.
For more detailed information on collection and recycling systems for this product, please
contact the shop where you purchased it, your local dealer or sales/service representa-
tives.
Notice: Users in Turkey
All Other Users
If you wish to discard this product, please contact your local authorities, the shop where you
bought this product, your local dealer or sales/ service representatives.

20
Notice: Users in the EU
Note for the Battery and/or Accumulator Symbol
In accordance with the Battery Directive 2006/66/EC Article 20 Information for end-users
Annex II, the above symbol is printed on batteries and accumulators. This symbol means that
in the European Union, used batteries and accumulators should be disposed of separately
from your household waste. In the EU, there are separate collection systems for not only used
electrical and electronic products but also batteries and accumulators.
Please dispose of them correctly at your local community waste collection/recycling centre.
Notice: Users in Taiwan
⺊暣㰈婳⚆㓞
請勿將電池當作一般垃圾丟棄。這個標
誌表示電池不應視為一般垃圾丟棄。僅
適用於台灣。
