Ricoh PJ WU6181 N User manual

Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use,
be sure to read the Important Information in this manual before using the machine.
User’s Manual
RICOH PJ WU6181N/WX6181N/X6181N

• Macintosh, Mac OS X and PowerBook are trademarks of Apple Inc. registered in the U.S. and other countries.
• Microsoft, Windows, Windows Vista, Internet Explorer, .NET Framework and PowerPoint are either a registered trademark
or trademark of Microsoft Corporation in the United States and/or other countries.
• MicroSaver is a registered trademark of Kensington Computer Products Group, a division of ACCO Brands.
• Adobe, Adobe PDF, Adobe Reader, and Acrobat are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
• HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
• DisplayPort, DisplayPort Certified Logo, VESA, and VESA logo are trademarks of the Video Electronics Standards As-
sociation, registered in the U.S. and other countries.
• Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and other countries
and areas.
• Wi-Fi®, Wi-Fi Alliance®, and Wi-Fi Protected Access (WPA, WPA2)®are registered trademarks of the Wi-Fi Alliance.
• Blu-ray is a trademark of Blu-ray Disc Association
• Crestron, Crestron Control, and Crestron RoomView are trademarks or registered trademarks of Crestron Electronics,
Inc.
• Other product and company names mentioned in this user’s manual may be the trademarks or registered trademarks
of their respective holders.
NOTES
(1) The contents of this user’s manual may not be reprinted in part or whole without permission.
(2) The contents of this user’s manual are subject to change without notice.
(3) Great care has been taken in the preparation of this user’s manual; however, should you notice any questionable
points, errors or omissions, please contact us.
(4) Notwithstanding article (3), Ricoh will not be responsible for any claims on loss of profit or other matters deemed to
result from using the Projector.

i
User Information on Electrical and Electronic Equipment
Users in the countries where this symbol shown in this section has been specified in national
law on collection and treatment of E-waste
Our Products contain high quality components and are designed to facilitate recycling.
Our products or product packaging are marked with the symbol below.
This product contains substances which are harmful to humans and the environment.
• The lamp contains mercury.
Please dispose of this product or used lamps in accordance with local regulations.
CAUTION
Avoid displaying stationary images for a prolonged period of time.
Doing so can result in these images being temporarily sustained on the surface of the LCD panel.
If this should happen, continue to use your projector. The static background from previous images will
disappear.
Important Information
Safety Cautions
Precautions
Please read this manual carefully before using your Ricoh projector and keep the manual handy for future reference.
CAUTION
To turn off main power, be sure to remove the plug from power outlet.
The power outlet socket should be installed as near to the equipment as possible, and should be easily
accessible.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET.
THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the unit may be sufficient to cause electrical shock.
Therefore, it is dangerous to make any kind of contact with any part inside of the unit.
This symbol alerts the user that important information concerning the operation and maintenance of this unit
has been provided.
The information should be read carefully to avoid problems.
WARNING: TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THE PRONGS CAN
BE FULLY INSERTED.
DOC Compliance Notice (for Canada only)
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Machine Noise Information Regulation - 3. GPSGV,
The highest sound pressure level is less than 70 dB (A) in accordance with EN ISO 7779.

ii
Important Information
RF Interference (for USA only)
WARNING
The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those
specified by Ricoh Americas Corporation in this manual. Failure to comply with this government regulation could
void your right to operate this equipment. This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turn-
ing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio / TV technician for help.
For UK only: In UK, a BS approved power cord with moulded plug has a Black (five Amps) fuse installed for use with this
equipment. If a power cord is not supplied with this equipment please contact your supplier.
WARNING TO CALIFORNIA RESIDENTS:
Handling the cables supplied with this product will expose you to lead, a chemical known to the State of California to
cause birth defects or other reproductive harm. WASH HANDS AFTER HANDLING.
The symbol indicates that the product must not be treated as municipal waste. It must be disposed of separately via the
appropriate return and collection systems available. By following these instructions you ensure that this product is treated
correctly and help to reduce potential impacts on the environment and human health, which could otherwise result from
inappropriate handling. Recycling of products helps to conserve natural resources and protect the environment.
For more detailed information on collection and recycling systems for this product, please contact the shop where you
purchased it, your local dealer or sales/service representatives.
Note for the Battery and/or Accumulator Symbol (For EU countries only)
In accordance with the Battery Directive 2006/66/EC Article 20 Information for end-users Annex II, the above symbol is
printed on batteries and accumulators.
This symbol means that in the European Union, used batteries and accumulators should be disposed of separately from
your household waste.
In the EU, there are separate collection systems for not only used electrical and electronic products but also batteries
and accumulators.
Please dispose of them correctly at your local community waste collection/recycling centre.
CE Marking Traceability Information
Manufacturer: Ricoh Co., Ltd.
3-6 Nakamagome 1-chome, Ohta-ku, Tokyo. 143-8555, Japan
Importer: Ricoh Europe PLC
20 Triton Street, London. NW1 3BF, United Kingdom
Declaration of Conformity for EU countries
•EMC Directive 2004/108/EC (including amendments)
•Low Voltage Directive 2006/95/EC

iii
Important Information
Important Safeguards
These safety instructions are to ensure the long life of your projector and to prevent fire and shock. Please read them
carefully and heed all warnings.
Installation
• Do not place the projector in the following conditions:
- on an unstable cart, stand, or table.
- near water, baths, or damp rooms.
- in direct sunlight, near heaters, or heat radiating appliances.
- in a dusty, smoky or steamy environment.
- on a sheet of paper or cloth, rugs or carpets.
• If you wish to have the projector installed on the ceiling:
- Do not attempt to install the projector yourself.
- The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of
bodily injury.
- In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance
with any local building codes.
- Please consult your dealer for more information.
• For sales or service representatives:
- Use brackets that are strong enough to support the projector. (PJ WU6181N Series weighs about 8.4kg.(18.5lbs))
(Not including lens)
- The projector must be installed in a location that is sturdy enough to support the full weight of the projector and
brackets.
- Use only the screws (four M4~16 screws) provided with the projector to attach the brackets to the projector.
- Use all four of the projector’s screw holes to attach the brackets. The locations of the screw holes are shown in the
illustration below.(→page 242)Make sure that the screws are tightened firmly.
WARNING
• Do not cover the lens with the lens cap or equivalent while the projector is on. Doing so can lead to melting of the
cap due to the heat emitted from the light output.
• Do not place any objects, which are easily affected by heat, in front of the projector lens. Doing so could lead to
the object melting from the heat that is emitted from the light output.
Do not use the projector with it leaning to the left and right. This may result in a malfunction. However, portrait installation is
possible* (when a custom-designed stand is made). For portrait installation, install the projector with the intake vent at the bot-
tom and leave a space of at least 130 mm below the intake vent.

iv
Important Information
Fire and Shock Precautions
• Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside your
projector. Allow at least 4 inches (10cm) of space between your projector and a wall.
• Do not try to touch the ventilation outlet on the left front (when seen from the front) as it can become heated while the
projector is turned on and immediately after the projector is turned off. Parts of the projector may become temporarily
heated if the projector is turned off with the Power button or if the AC power supply is disconnected during normal
projector operation.
Use caution when picking up the projector.
• Prevent foreign objects such as paper clips and bits of paper from falling into your projector. Do not attempt to retrieve
any objects that might fall into your projector. Do not insert any metal objects such as a wire or screwdriver into your
projector. If something should fall into your projector, disconnect it immediately and have the object removed by a
qualified service personnel.
• Do not place any objects on top of the projector.
• Do not touch the power plug during a thunderstorm. Doing so can cause electrical shock or fire.
• The projector is designed to operate on a power supply of 100-240V AC 50/60 Hz. Ensure that your power supply fits
this requirement before attempting to use your projector.
• Do not look into the lens while the projector is on. Serious damage to your eyes could result.
• Keep any items (magnifying glass etc.) out of the light path of the projector. The light path being projected from the
lens is extensive, therefore any kind of abnormal objects that can redirect light coming out of the lens, can cause an
unpredictable outcome such as a fire or injury to the eyes.
• Do not place any objects, which are easily affected by heat, in front of a projector exhaust vent.
Doing so could lead to the object melting or getting your hands burned from the heat that is emitted from the exhaust.
• Handle the power cord carefully. A damaged or frayed power cord can cause electric shock or fire.
- Do not use any power cord other than the one supplied with the projector.
- Do not bend or tug the power cord excessively.
- Do not place the power cord under the projector, or any heavy object.
- Do not cover the power cord with other soft materials such as rugs.
- Do not heat the power cord.
- Do not handle the power plug with wet hands.
• Turn off the projector, unplug the power cord and have the projector serviced by a qualified service personnel under
the following conditions:
- When the power cord or plug is damaged or frayed.
- If liquid has been spilled into the projector, or if it has been exposed to rain or water.
- If the projector does not operate normally when you follow the instructions described in this user’s manual.
- If the projector has been dropped or the cabinet has been damaged.
- If the projector exhibits a distinct change in performance, indicating a need for service.
• Disconnect the power cord and any other cables before carrying the projector.
• Turn off the projector and unplug the power cord before cleaning the cabinet or replacing the lamp.
• Turn off the projector and unplug the power cord if the projector is not to be used for an extended period of time.
• When using a LAN cable:
For safety, do not connect to the connector for peripheral device wiring that might have excessive voltage.

v
Important Information
CAUTION
• Do not use the tilt-foot for purposes other than originally intended. Misuses such as gripping the tilt-foot or hang-
ing on the wall can cause damage to the projector.
• Do not send the projector in the soft case by parcel delivery service or cargo shipment. The projector inside the
soft case could be damaged.
• Select [HIGH] in Fan mode if you continue to use the projector for consecutive days. (From the menu, select
[SETUP] →[OPTIONS(1)] →[FAN MODE] →[MODE] →[HIGH].)
• Before using Direct Power Off, be sure to allow at least 20 minutes immediately after turning on the projector and
starting to display an image.
• Do not unplug the power cable from the wall outlet or projector when the projector is powered on. Doing so can
cause damage to the AC IN connector of the projector and (or) the prong plug of the power cable.
To turn off the AC power supply when the projector is powered on, use a power strip equipped with a switch and
a breaker.
• Do not turn off the AC power for 60 seconds after the lamp is turned on and while the Power indicator is blinking
blue. Doing so could cause premature lamp failure.
Caution on Handling the Optional Lens
When shipping the projector with the lens, remove the lens before shipping the projector. Always attach the dust cap
to the lens whenever it is not mounted on the projector. The lens and the lens shift mechanism may encounter damage
caused by improper handling during transportation.
Do not hold the lens part when carrying the projector.
Doing so could cause the Focus ring to rotate, resulting in accidental dropping of the projector.
Remote Control Precautions
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• Do not short, heat, or take apart batteries.
• Do not throw batteries into fire.
• If you will not be using the remote control for a long time, remove the batteries.
• Ensurethatyouhavethebatteries’polarity(+/−)alignedcorrectly.
• Do not use new and old batteries together, or use different types of batteries together.
• Dispose of used batteries according to your local regulations.
Note for US Residents
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL,
STATE OR FEDERAL LAWS.
Notes to Users in the State of California
Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
WARNING: Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause
cancer, and birth defects or other reproductive harm. Wash hands after handling.
Lamp Replacement
• Use the specified lamp for safety and performance.
• To replace the lamp, follow all instructions provided on page 176.
• Be sure to replace the lamp and filter when the message [THE LAMP HAS REACHED THE END OF ITS USABLE LIFE. PLEASE
REPLACE THE LAMP AND FILTER. USE THE SPECIFIED LAMP FOR SAFETY AND PERFORMANCE.] appears. If you continue
to use the lamp after the lamp has reached the end of its usable life, the lamp bulb may shatter, and pieces of glass
may be scattered in the lamp case. Do not touch them as the pieces of glass may cause injury.
If this happens, contact your dealer for lamp replacement.

vi
Important Information
A Lamp Characteristic
The projector has a high-pressure mercury lamp as a light source.
A lamp has a characteristic that its brightness gradually decreases with age. Also repeatedly turning the lamp on and
off will increase the possibility of its lower brightness.
CAUTION:
• DO NOT TOUCH THE LAMP immediately after it has been used. It will be extremely hot. Turn the projector off and
then disconnect the power cord. Allow at least one hour for the lamp to cool before handling.
• When removing the lamp from a ceiling-mounted projector, make sure that no one is under the projector. Glass
fragments could fall if the lamp has been burned out.
About High Altitude mode
• Set [FAN MODE] to [HIGH ALTITUDE] when using the projector at altitudes approximately 5500 feet/1700 meters or higher.
Using the projector at altitudes approximately 5500 feet/1700 meters or higher without setting to [HIGH ALTITUDE]
can cause the projector to overheat and the protector could shut down. If this happens, wait a couple minutes and
turn on the projector.
• Using the projector at altitudes less than approximately 5500 feet/1700 meters and setting to [HIGH ALTITUDE] can
cause the lamp to overcool, causing the image to flicker. Switch [FAN MODE] to [AUTO].
• Using the projector at altitudes approximately 5500 feet/1700 meters or higher can shorten the life of optical compo-
nents such as the lamp.
About Copyright of original projected pictures:
Please note that using this projector for the purpose of commercial gain or the attraction of public attention in a venue
such as a coffee shop or hotel and employing compression or expansion of the screen image with the following functions
may raise concern about the infringement of copyrights which are protected by copyright law.
[ASPECT], [KEYSTONE], Magnifying feature and other similar features.
Notice: Users in Turkey
Notice: Users in Taiwan
All Other Users
If you wish to discard this product, please contact your local authorities, the shop where you bought this product, your
local dealer or sales/service representatives.
This device is not intended for use in the direct field of view at visual display workplaces. To avoid incommoding reflec-
tions at visual display workplaces this device must not be placed in the direct field of view.

vii
Important Information
Safety Labels of This Machine
1 Do not look into the lens while the projector is on. Serious damage to your eyes could result. Do not cover the lens
with the lens cap or equivalent while the projector is on. Doing so can lead to melting of the cap due to the heat emit-
ted from the light output. Do not place any objects, which are easily affected by heat, in front of the projector lens.
Doing so could lead to the object melting from the heat that is emitted from the light output.
2 Do not try to touch the ventilation outlet on the left front (when seen from the front) as it can become heated while the
projector is turned on and immediately after the projector is turned off. Parts of the projector may become temporarily
heated if the projector is turned off with the Power button or if the AC power supply is disconnected during normal
projector operation.
Use caution when picking up the projector.
3 Do not remove any screws except the lamp cover screws. Do not block or cover the vents.
4 To replace the lamp, first unplug the power cord then wait for more than 1 hour.
The lamp might be broken. Be careful of pieces of broken glass.
*The label changes depending on the destination.
3
2
1
4
21
21

viii
Important Information
Health precautions to users viewing 3D images
Before viewing, be sure to read health care precautions that may be found in the user’s manual included with your 3D eyeglasses
or your 3D compatible content such as Blu-ray Discs, video games, computer’s video files and the like.
To avoid any adverse symptoms, heed the following:
• Do not use 3D eyeglasses for viewing any material other than 3D images.
• Allow a distance of 2 m/7 feet or greater between the screen and a user. Viewing 3D images from too close a distance can
strain your eyes.
• Avoid viewing 3D images for a prolonged period of time. Take a break of 15 minutes or longer after every hour of viewing.
• If you or any member of your family has a history of light-sensitive seizures, consult a doctor before viewing 3D images.
• While viewing 3D images, if you get sick such as nausea, dizziness, queasiness, headache, eyestrain, blurry vision, convulsions,
and numbness, stop viewing them. If symptoms still persist, consult a doctor.
• View 3D images from the front of the screen. Viewing from an angle may cause fatigue or eyestrain.
Power management function
In order to keep power consumption low, the following power management functions (1) and (2) have been set when shipped from
the factory. Please display the on-screen menu and change the settings (1) and (2) according to the aim of using the projector.
1. STANDBY MODE (Factory preset: NORMAL)
• When [NORMAL] is selected for [STANDBY MODE], the following connectors and functions will not work:
HDMI OUT connector, AUDIO OUT connector, Ethernet Port* USB-A Port, LAN functions, Mail Alert function
(→page 127)
2. AUTO POWER OFF (Factory preset: 60 minutes)
• When [1:00] is selected for [AUTO POWER OFF], you can enable the projector to automatically turn off in 1 hour if there
is no signal received by any input or if no operation is performed.
(→page 128)

ix
Important Information
Clearance for Installing the Projector
Allow ample clearance between the projector and its surroundings as shown below.
The high temperature exhaust coming out of the device may be sucked into the device again.
Avoid installing the projector in a place where air movement from the HVAC is directed at the projector.
Heated air from the HVAC can be taken in by the projector's intake vent. If this happens, the temperature inside the projector will
rise too high causing the over-temperature protector to automatically turn off the projectors power.
Example 1 – If there are walls on both sides of the projector.
20 cm/7.9" or greater 13 cm/5.1" or greater
Filter cover
(Intake vent)
Lamp cover
NOTE:
The drawing shows the proper clearance required for the front, back and top of the projector.
Example 2 – If there is a wall behind the projector.
10 cm/3.9" or greater
Exhaust vent
NOTE:
The drawing shows the proper clearance required for the back, sides and top of the projector.
Example 3 – In the case of portrait projection.
Filter cover
(Intake vent)
13 cm/5.1" or greater
NOTE:
• The drawing shows the proper clearance required for the front, back and top of the projector.
• See page 163 for an installation example on portrait projection.

x
Table of Contents
Important Information................................................................................................................................. i
1. Introduction ......................................................................................................................................................... 1
❶What’s in the Box? ...............................................................................................................1
❷Introduction to the Projector ................................................................................................2
Congratulations on Your Purchase of the Projector.......................................................2
Installation ......................................................................................................................2
Videos ............................................................................................................................2
Network ..........................................................................................................................3
Energy-saving ................................................................................................................3
Maintenance...................................................................................................................4
About this user’s manual ...............................................................................................5
About the Projector’s [NETWORK SETTINGS] ..............................................................6
❸Part Names of the Projector.................................................................................................7
Front/Top ........................................................................................................................7
Rear................................................................................................................................8
Controls/Indicator Panel.................................................................................................9
Terminals ......................................................................................................................10
❹Part Names of the Remote Control....................................................................................11
Battery Installation........................................................................................................12
Remote Control Precautions........................................................................................12
Operating Range for Wireless Remote Control ...........................................................13
2. Projecting an Image (Basic Operation) ............................................................ 14
❶Flow of Projecting an Image ..............................................................................................14
❷Connecting Your Computer/Connecting the Power Cord..................................................15
❸Turning on the Projector.....................................................................................................16
Note on Startup screen (Menu Language Select screen) ...........................................17
❹Selecting a Source.............................................................................................................18
Selecting the computer or video source......................................................................18
❺Adjusting the Picture Size and Position .............................................................................20
Adjusting the vertical position of a projected image (Lens shift).................................21
Focus ...........................................................................................................................22
Applicable lens: Replacement Lens Type8..................................................................23
Applicable lens: Replacement Lens Type1..................................................................24
Zoom ............................................................................................................................25
Adjusting the Tilt Feet...................................................................................................25
❻Optimizing Computer Signal Automatically.......................................................................26
Adjusting the Image Using Auto Adjust.......................................................................26
❼Turning Up or Down Volume ..............................................................................................26
❽Turning off the Projector .....................................................................................................27
❾After Use ............................................................................................................................28
3. Convenient Features..........................................................................................................................29
❶Turning off the Image and Sound ......................................................................................29
❷Freezing a Picture ..............................................................................................................30
❸Enlarging a Picture.............................................................................................................30

xi
Table of Contents
❹Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [ECO MODE] ...31
Checking Energy-Saving Effect [CARBON METER] ...................................................32
❺Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE] ......................33
6Preventing the Unauthorized Use of the Projector [SECURITY]........................................36
7Projecting 3D videos..........................................................................................................39
Procedure to watch 3D videos using this projector.....................................................39
When videos cannot be viewed in 3D..........................................................................41
8Controlling the Projector by Using an HTTP Browser........................................................42
9Projecting Your Computer’s Screen Image from the Projector via a Network
[NETWORK PROJECTOR] ..........................................................................................52
❿Using the Projector to Operate Your Computer via a Network [REMOTE DESKTOP] .....56
Prepare a commercially available wireless keyboard .................................................56
Setting the password to the user account of Windows 7 ............................................57
Setting the Remote Access..........................................................................................57
Checking the IP address on Windows 7......................................................................57
Starting the Remote Desktop.......................................................................................58
4. Multi-Screen Projection.................................................................................................................61
❶Things that can be done using multi-screen projection ....................................................61
Case 1. Using a single projector to project two types of videos [PIP/PICTURE BY
PICTURE] .........................................................................................................61
Case 2. Using four projectors (liquid crystal panel: XGA) to project videos with a
resolution of 1920 × 1080 pixels [TILING]..................................................................62
Things to note when installing projectors ....................................................................64
❷Displaying Two Pictures at the Same Time........................................................................65
Projecting two screens.................................................................................................66
Switching the main display with the sub-display and vice versa.................................67
Restrictions...................................................................................................................68
❸Displaying a Picture Using [EDGE BLENDING]................................................................69
Setting the overlap of projection screens ....................................................................70
Black Level Adjustment................................................................................................73
5. Using On-Screen Menu .................................................................................................................. 75
❶Using the Menus................................................................................................................75
❷Menu Elements ..................................................................................................................76
❸List of Menu Items..............................................................................................................77
❹Menu Descriptions & Functions [INPUT] ..........................................................................83
❺Menu Descriptions & Functions [ADJUST] .......................................................................87
[PICTURE] ....................................................................................................................87
[IMAGE OPTIONS]......................................................................................................91
[VIDEO] .......................................................................................................................95
[3D SETTINGS]............................................................................................................97
❻Menu Descriptions & Functions [DISPLAY] ......................................................................98
[PIP/PICTURE BY PICTURE] ........................................................................................98
[GEOMETRIC CORRECTION] ...................................................................................100
[EDGE BLENDING] ...................................................................................................104
[MULTI SCREEN] .......................................................................................................105
❼Menu Descriptions & Functions [SETUP]........................................................................107
[MENU]......................................................................................................................107

xii
Table of Contents
[INSTALLATION]........................................................................................................109
[CONTROL]................................................................................................................112
[NETWORK SETTINGS].............................................................................................120
[SOURCE OPTIONS] .................................................................................................125
[POWER OPTIONS]...................................................................................................127
Returning to Factory Default [RESET]........................................................................129
❽Menu Descriptions & Functions [INFO.] .........................................................................131
[USAGE TIME]...........................................................................................................131
[SOURCE(1)] .............................................................................................................132
[SOURCE(2)] .............................................................................................................132
[SOURCE(3)] .............................................................................................................132
[SOURCE(4)] .............................................................................................................133
[WIRED LAN].............................................................................................................133
[VERSION(1)] ............................................................................................................133
[VERSION(2)] ............................................................................................................133
[OTHERS]...................................................................................................................134
[CONDITIONS] ..........................................................................................................134
❾Application Menu .............................................................................................................136
ADVANCED NETWORK UTILITY................................................................................136
NETWORK PROJECTOR ...........................................................................................137
REMOTE DESKTOP CONNECTION..........................................................................137
NETWORK SETTINGS(MM).......................................................................................138
6. Connecting to Other Equipment.................................................................................. 153
❶Mounting a lens (sold separately) ...................................................................................153
Mounting the lens.......................................................................................................153
Removing the lens .....................................................................................................154
❷Making Connections ........................................................................................................155
Analog RGB signal connection..................................................................................155
Digital RGB signal connection ...................................................................................156
Connecting an External Monitor.................................................................................159
Connecting Your Blu-ray Player or Other AV Equipment ...........................................160
Connecting Component Input ...................................................................................161
Connecting HDMI Input .............................................................................................162
Portrait projection (vertical orientation) ......................................................................163
Connecting to a Wired LAN .......................................................................................166
Connecting to a Wireless LAN (sold separately) ......................................................167
Mounting a wireless LAN unit ....................................................................................167
To remove the wireless LAN unit................................................................................168
Example of wireless LAN connection ........................................................................170
7. Maintenance...................................................................................................................................................171
❶Cleaning the Filters ..........................................................................................................171
❷Cleaning the Lens ............................................................................................................174
❸Cleaning the Cabinet .......................................................................................................174
❹Replacing the Lamp and the Filters.................................................................................175
8. User Supportware ............................................................................................................................... 180
❶Operating Environment for Software Included on CD-ROM ...........................................180
Names and Features of Bundled Software Programs...............................................180

xiii
Table of Contents
Download service.......................................................................................................181
Operating Environment ..............................................................................................181
❷Installing Software Program.............................................................................................183
Installation for Windows software ..............................................................................183
Using on Mac OS.......................................................................................................185
3Projecting Your Computer’s Screen Image or Video from the Projector over a LAN
(Projection Utility) .......................................................................................................186
Starting Projection Utility from a USB Memory or SD Card .......................................191
4Projecting an Image from an Angle (Geometric Correction Tool in Projection Utility) ....193
What you can do with GCT ........................................................................................193
Projecting an Image from an Angle (GCT) ................................................................193
5Projecting Images from the Projector over a LAN (Advanced Network Utility) ...............195
What you can do with Advanced Network Utility .......................................................195
Connecting the projector to a LAN ............................................................................196
Basic Operation of Advanced Network Utility............................................................197
6JPEG Conversion Tool .....................................................................................................206
❼Managing the Projector Using Projector Management Utility .........................................207
9. Using the Viewer...................................................................................................................................208
❶What you can do with the Viewer.....................................................................................208
❷Projecting images stored in a USB memory device........................................................211
Starting the Viewer .....................................................................................................211
Names and functions of Viewer screen .....................................................................214
Viewer option settings................................................................................................219
3Projecting data from shared folder ..................................................................................222
Connecting the projector to the shared folder ..........................................................222
Disconnecting the shared folder from the projector..................................................225
4Projecting data from media server ..................................................................................226
Setting up “Media Sharing” in Windows Media Player 11 .........................................226
Setting up “Media Sharing” in Windows Media Player 12 .........................................228
Connecting the projector to the media server ...........................................................229
Disconnecting the projector from the media server ..................................................230
10. Appendix...........................................................................................................................................................231
❶Throw distance and screen size ......................................................................................231
Lens types and throw distance..................................................................................231
Tables of screen sizes and dimensions .....................................................................234
Lens shifting range.....................................................................................................235
❷Compatible Input Signal List............................................................................................237
❸Specifications...................................................................................................................240
❹Cabinet Dimensions.........................................................................................................242
❺Pin assignments and signal names of main connectors.................................................243
6Troubleshooting ...............................................................................................................245
Indicator Messages....................................................................................................245
Common Problems & Solutions ................................................................................247
If there is no picture, or the picture is not displayed correctly. ..................................249
7PC Control Codes and Cable Connection.......................................................................250

1
1. Introduction
❶What’s in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Please save the original box and packing materials if you ever need to ship your projector.
Projector
Dust cap for lens
* The projector is shipped without a
lens. For the types of lens and throw
distances, see page 231.
Remote control AA alkaline batteries
(x2)
Input selection character
sticker
Power cord Lens theft prevention screw
This screw makes it difficult to
remove the lens mounted on the
projector. (→page 154)
Straps (for preventing lamp cover from falling)
Attaching the straps to the lamp cover prevents them
from falling when the projector is suspended from the
ceiling.
For North America only
Limited warranty
• Important Infomation •
Quick Setup Guide
CD-ROM
User’s manual (PDF) and the utility
software

2
1. Introduction
❷Introduction to the Projector
This section introduces you to your new projector and describes the features and controls.
Congratulations on Your Purchase of the Projector
This projector is one of the very best projectors available today. The projector enables you to project precise images up to 500
inches across (measured diagonally) from your PC or Mac computer (desktop or notebook), VCR, Blu-ray player, or document camera.
You can use the projector on a tabletop or cart, you can use the projector to project images from behind the screen, and the
projector can be permanently mounted on a ceiling*1. The remote control can be used wirelessly.
*1Do not attempt to mount the projector on a ceiling yourself.
The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of bodily
injury.
In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance with any
local building codes. Please consult your dealer for more information.
Installation
• Liquid crystal type high brightness/high resolution projector
Model Brightness Resolution Aspect Ratio
PJ WU6181N 6200 lm WUXGA (1920 × 1200) 16:10
PJ WX6181N 6700 lm WXGA (1280 × 800) 16:10
PJ X6181N 7200 lm XGA (1024 × 768) 4:3
• Wide range of optional lenses selectable according to the place of installation
This projector supports 6 types of optional lenses, providing a selection of lenses adapted to a variety of places of installation
and projection methods.
In addition, the lenses can be mounted and removed in one touch.
Note that no lens is mounted upon shipment from the factory. Please purchase optional lenses separately.
• Lens shift function for easily adjusting the position of the projected image
The position of the projected image is moved by turning the two dials on the projector’s front, one for the vertical direction,
one for the horizontal direction.
• 360° installation angle (tilt-free)
The projector can be installed at any angle (360°).
Note, however, that the “fan mode” setting must be changed according to the angle of installation.
Also, the projector cannot be installed tilted to the left or right.
• Portrait projection is possible
This projector can perform portrait projection with the projection screen turned 90°.
However, the lamp replacement time* is 2000 hours for portrait projection.
* Replacement time not guaranteed.
Videos
• Wide range of input/output connectors (HDMI, DisplayPort, BNC, etc.) and built-in monaural speaker
The projector is equipped with a variety of input/output connectors: HDMI (input × 2, output × 1), DisplayPort, BNC (5-core),
computer (analog), etc.
The projector’s HDMI input/output connectors and DisplayPort input connector.
The projector is also equipped with a built-in 10W monaural speaker.

3
1. Introduction
• Simultaneous display of 2 images (PIP/PICTURE BY PICTURE)
Two images can be projected simultaneously with a single projector.
There are two types of layouts for the two images: “picture-in-picture” in which a sub-picture is displayed on the main picture,
and “picture-by-picture” in which the main and sub pictures are displayed next to each other.
• Multi-screen projection using multiple projectors
This projector is equipped with multiple HDMI input & output terminals that can connect multiple projectors in a daisy chain.
A high quality picture is achieved by dividing and projecting high resolution videos among the various projectors.
Furthermore, the boundaries of the screens are smoothed using an edge blending function.
* Both the composite video signal from each input connector as the computer, BNC, and BNC (CV), and the S-video signal
from the BNC (Y/C) Input connector are not output from HDMI OUT Connector of this projector.
• Seamless switch function for smoother screen changes when switching the signal
When the input connector is switched, the image displayed before switching is held so that that the new image can be switched
to without a break due to absence of a signal.
• Supports HDMI 3D format
This projector can be used to watch videos in 3D using commercially-available active shutter-type 3D eyewear and 3D emitters
that support Xpand 3D.
Network
• Supported by wired LAN/wireless LAN (wireless LAN unit sold separately)
Ethernet Port *Video can be transmitted from a computer equipped with a RF-45 port that is connected to a wired LAN to
the projector, and the projector can also be controlled from the computer.
In addition, the all models can also be used over a wireless LAN by using a wireless LAN unit sold separately.
• LAN-compatible Viewer
The projector’s built-in Viewer allows you to view images or movie files in the shared folder of your PC connected to a wired
or wireless LAN.
* The Viewer supports the Media Sharing function of Windows Media Player 11.
• CRESTRON ROOMVIEW compatibility
The projector supports CRESTRON ROOMVIEW, allowing multiple devices connected in the network to be managed and con-
trolled from a computer or controller.
• Convenient utility software (User Supportware) provided as standard
The 2 utility software stored in the attached CD-ROM (Projection Utility (for Windows/Mac OS), Advanced Network Utility
(for Windows), ) may be used. Projection Utility (for Windows) may be started up and used from a USB memory or SD card
available commercially even without installing on a computer.
Projection Utility (for Windows/Mac OS), Advanced Network Utility (for Windows)
Energy-saving
• Energy-saving design with a standby power consumption of 0.11 watts (100-130 V)/0.16 watts (200-240 V)
When the on-screen menu’s standby mode is set to “NORMAL”, the power consumption in the standby mode is 0.11 watts
(100-130 V)/0.16 watts (200-240 V).
• “Eco mode” for low power consumption and “Carbon Meter” display
The projector is equipped with an “eco mode” for reducing power consumption during use. Furthermore, the power-saving
effect when the eco mode is set is converted into the amount of reductions of CO2emissions and this is indicated on the
confirmation message displayed when the power is turned off and at “Information” on the on-screen menu (CARBON METER).

4
1. Introduction
Maintenance
• Maximum lamp replacement time of 4000 hours and no need to clean the filters
When used in the eco mode, the lamp replacement time* is extended to a maximum of 4000 hours.
* This time is not guaranteed.
Furthermore, this projector uses large 2-layer filters. When these filters are replaced with new ones when changing the lamp,
there is no need for regular filter cleaning.
* Actual menus may be different from the menu images in this user’s manual.

5
1. Introduction
About this user’s manual
The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review the
user’s manual. This may save you time later on. At the beginning of each section of the manual you’ll find an overview. If the
section doesn’t apply, you can skip it.
Notation by Resolution
These indicate the descriptions of the model groups according to the resolution of the liquid crystal panels.
WUXGA Type
Applicable to models PJ WU6181N.
WXGA Type
Applicable to models PJ WX6181N.
XGA Type
Applicable to models PJ X6181N.
*The description applies to all models if the type name is not indicated.
