1
Sirius-PJ1Training
Slide 1
Y013/Y014
Service Training
Sirius-PJ1
Version 1.01
This training course provides service technician training for the Sirius-PJ1 series.
This course will cover information related to service. To understand the features
of the machine, the correct ways to turn the projector on or off, about power
saving modes, and other matters that are related to operation, please study the
user guide.
Version 1.01: The file sizes of some inserted photos were reduced.

2
Sirius-PJ1Training
Slide 2
Y013/Y014
Service Training
Product Overview
This section provides an overview of the machine, and the options that can be
installed.

3
Sirius-PJ1Training
Slide 3
What Models are there in the Series?
Sirius-PJ1 nx (Y013): PJ X6180N
6000 lumens, XGA resolution
Sirius-PJ1 nw (Y014): PJ WX6170N
5500 lumens, WXGA resolution
These are high power, high image quality
projectors for auditoriums and large lecture halls
(30- 100 persons).
These models can be used over a network.
Advanced networking features can connect
quickly to a LAN
Can project from a PC with wired or wireless
network
Management and control using PJLink software
No additional notes

4
Sirius-PJ1Training
Slide 4
Main Specifications
330W mercury lampLamp type
464WPower Consumption
WXGAXGAResolution
YesHDMI
YesUSB
YesWired LAN
Option (USB)Wireless LAN
10W x 1Speaker
8.54 kg (18.8 lbs)Weight
499 ×359 ×144Dimensions (W×D×H)
Sirius-PJ1 nx: 1.2 to 30.8 m (3.93 to 101 ft)
Sirius-PJ1 nw: 1.3 to 32.4 m (4.26 to 106.3 ft)
Projection Distance
(with standard lens)
30” - 500” (76.2 – 1270 cm)Projection Screen Size
Vertical and horizontal, manualKeystone
5500 lm6000 lmBrightness
LCDType of Projector
Sirius-PJ1 nwSirius-PJ1 nx
See the specifications table in the service manual for more details.

5
Sirius-PJ1Training
Slide 5
Features
This product can be installed by users, except
when mounted on a ceiling.
This product is designed for user maintenance.
Regular on-site maintenance is not needed.
LEDs show the symptoms for troubleshooting
(blinking/lit, number of times the LEDs blink, etc).
A service mode is available.
No additional notes

6
Sirius-PJ1Training
Slide 6
Flexible Installation and Projection
Can project onto screens of size 30” to 500” with five optional lenses.
Increased flexibility of installation place with vertical/ horizontal lens shift
Can change the location of the projected image without moving the
projector
Geometric correction feature allows projection of images onto spheres,
cylinders, corner angles and many more non-standard surfaces.
Do not tilt the projector to the left to right. However, there is no limit on
the upward/downward tilt angle (images can projected on the ceiling or on
the floor).
If the tilt angle is between 60 and 120 degrees, [FAN MODE] – [SETTING]
must be set to Vertical Tilt Up.
Left/Right Tilt Up/Down Tilt
No additional notes

7
Sirius-PJ1Training
Slide 7
Low Energy Consumption
4,000 hour lamp life and lower power
consumption in Eco mode
The life of 4,000 hours is only achieved if the
lamp is always used in Eco mode.
Lamp power in Eco mode is 80% of full power.
Power consumption values:
Eco Mode Off (Normal): 358 W (100-130 V), 343
W (200-240 V)
Eco Mode: 271 W (100-130 V), 264 W (200-240
V)
Standby (Normal): 9 W (100-130 V/200-240 V)
Standby (Power saving): 0.2 W (100-130 V), 0.4
W (200-240 V)
Note that in the service mode menu, Eco Mode is referred to as ‘Low Mode’.

8
Sirius-PJ1Training
Slide 8
Consumables and Options
Replacement lamp (Y203)
330W mercury lamp (Replacement Lamp Type 7)
Life: 3000 hours (normal mode), 4000 hours (Eco
mode)
» There may be a 50% decrease in brightness at the end
of the lamp’s life.
Lenses
Standard Lens Type 1 (Y101)
Replacement Lens Types 1 to 4
(Y102/Y103/Y104/Y105)
Wireless LAN unit (Y106)
IEEE 802.11b/g/n are supported
Wireless LAN Unit M1: For USA, Canada, Mexico, Brazil. Colombia, and Taiwan
Wireless LAN Unit M2: For CE Countries (27 EU countries, and Iceland,
Liechtenstein, Norway, and Switzerland), UAE, Saudi Arabia, Oman, South
Africa, Turkey, Egypt, Israel, Australia, NZ, Thailand, HK, Singapore, Malaysia,
Sri Lanka, Pakistan, Vietnam, India, Philippines, Peru, Chile, Argentina, Ecuador
Wireless LAN Unit M3: For Russia

9
Sirius-PJ1Training
Slide 9
Replacement Lenses
This shows how the standard lens and the 4 optional
replacement lenses can be used to project onto different
screen sizes over a range of distances.
40-150”
30-500”
40-500” 60-500” 60-500”
Replacement Lens Type 1
Sirius-PJ1 nx: 0.6 – 2.5 m
Sirius-PJ1 nw: 0.7 – 2.6 m
Replacement Lens Type 2
Sirius-PJ1 nx: 0.7 – 16 m
Sirius-PJ1 nw: 0.7 – 16.8 m
Standard Lens Type 1
Sirius-PJ1 nx: 1.2 – 30.8 m
Sirius-PJ1 nw: 1.3 – 32.4 m
Replacement Lens Type 3
Sirius-PJ1 nx: 3.6 – 49.2 m
Sirius-PJ1 nw: 3.8 – 51.7 m
Replacement Lens Type 4
Sirius-PJ1 nx: 5.7 – 73.8 m
Sirius-PJ1 nw: 5.9 – 77.6 m
No additional notes

10
Sirius-PJ1Training
Slide 10
Utilities
Projection Utility
A utility for projecting from a computer over a network
Advanced Network Utility
This allows you to send images from a PC to more than one
projector at the same time.
JPEG Conversion Tool
Stacking Correction Tool (the name is subject to change)
This software is for technicians.
Up to four projectors can be used to simultaneously project
an image in the same location. This is done to increase
brightness. This tool needs to be installed by an expert who
has skills to mount projectors on the ceiling.
When this tool is in use, one or more of the machines might
be accidentally put out of alignment in terms of the
projecting area. In that case, visiting maintenance will be
required to set up the projectors again.
@Remote
@Remote is not available on this model.
No additional notes

11
Sirius-PJ1Training
Slide 11
Reliability Information
Average monthly projection time: 154 hrs/month
7.00 hrs/day x 22 working days/month
Failure Rate
1st year: 0.0013 cases/unit/month
2nd year: 0.0014 cases/unit/month
3rd year: 0.0017 cases/unit/month
The failure rate of a projector increases with its
total power-up time. This is due in part to the
failure characteristics of optical engines in
projectors.
Lamp Life
Normal Mode: 3,000 hrs
Eco Mode: 4,000 hrs
No additional notes

12
Sirius-PJ1Training
Slide 12
Lamp Near-end/End Alerts
There is no near-end alert.
The lamp end alert occurs when the machine calculates
that the life time has expired.
If used in Normal Mode only, the alert appears after 3,000
hrs projection time
If used in Eco Mode only, the alert appears after 4,000 hrs
projection time
If the user switches between modes, the machine
calculates when to display the alert based on how long the
lamp was used in each mode.
If the projector is used for 100 hours after the lamp has
reached the end of its life, the projector will turn off and go
into standby mode.
In this condition, the lamp hours cannot be reset using the
menu.
The user must replace the lamp, then press the Help button
on the remote control for 10 seconds to reset the lamp
clock back to zero (do this only after replacing the lamp).
No additional notes

13
Sirius-PJ1Training
Slide 13
Disposal of Broken Lamps
Projector lamps normally contain mercury
vapour.
These lamps can rupture due to impact or being
used longer than their life expectancy.
The time that the breakage will occur differs
widely for each lamp and its circumstances of
use.
These lamps must be disposed of in accordance
with local environmental regulations.
No additional notes

14
Sirius-PJ1Training
14
Slide 14 14
Overview External View - Front
Slide 14 14
Overview External View - Front
1. Remote Sensor (rear)
2. Lens Shift Dial (horizontal): This moves the projected image left/right
3. Ventilation (outlet)
4. Lens Shift Dial (vertical): This moves the projected image up/down
5. Lamp Cover
6. Control Panel
7. Security Bar: Users can attach an anti-theft device here
8. Adjustable Tilt Foot
9. Indicator Section
10. Remote Sensor (front)
11. Zoom Lever/Zoom Ring
12. Focus Ring
13. Lens
14. Lens Release Button
15. Mono Speaker
16. Lens Cap

15
Sirius-PJ1Training
15
Slide 15 15
Overview External View - Rear
Slide 15 15
Overview External View - Rear
1. Ventilation (inlet) / Filter Cover: The wireless LAN unit’s USB (LAN) port is
located inside here.
2. Ventilation (outlet)
3. Terminal Panel
4. AC Input
5. Built-in Security Slot

16
Sirius-PJ1Training
Slide 16
Operation Panel
For details: Service manual > 1. Product Information > Overview
5. The left and right arrow buttons can be used to adjust the speaker volume.

17
Sirius-PJ1Training
Slide 17
Menus
Source Wireless LAN
Enabled
Eco Mode
High Altitude Mode High Temperature
Alert
Control Panel
Lock Enabled
Off Timer
Remaining Time
This slide shows the Source Menu, and explains the symbols that appear on the
menu screen.
For details of all functions, see the user’s manual.
High Altitude Mode: The fans operate at a higher speed in this mode. Use this
when the projector’s location is more than 1500 m (5500 ft) above sea level
(otherwise, the projector could overheat and shut down automatically). If you use
Eco Mode, also use High Altitude Mode if the projector’s location is more than
1000 m (3200 ft) above sea level.
¾Also, if you use high altitude mode at less than 1500 m (5500 ft) above sea
level, the projector could become too cool, causing images to flicker. Switch
[FAN MODE] to [AUTO].
High Temperature Alert: High temperature detected inside the projector, Eco
Mode is enforced
¾If the projector overheats, it shuts down automatically. Wait a few moments
then turn back on again.

18
Sirius-PJ1Training
Slide 18
Menus
This slide shows the other four menu tabs.
Note that in the Adjust, Setup, and Info tabs, there is more than one page.
¾For example, in the Adjust tab, there are three pages: Picture, Image
Options, and Video.

19
Sirius-PJ1Training
19
Slide 19 19
9Interface
Overview Connection Ports
1. LAN Port (RJ-45)
2. HDMI IN Connector (Type A)
3. DisplayPort IN Connector
4. USB Port (Type A)
5. MONITOR OUT (COMP. 1) Connector (Mini D-Sub 15 Pin)
6. COMPUTER 1 IN/ Component Input Connector (Mini D-Sub 15 Pin)
7. COMPUTER 1 AUDIO IN Mini Jack (Stereo Mini)
8. PC CONTROL Port (D-Sub 9 Pin): Use this port to connect a PC or control
system. This enables the user to control the projector using serial
communication protocol. Be sure to use a cross cable.
9. COMPUTER 2 IN / Component Input Connector (Mini D-Sub 15 Pin)
10. COMPUTER 2 AUDIO IN Mini Jack (Stereo Mini)
11. Service Connector (Stereo Mini)
12. COMPUTER 3 AUDIO IN Mini Jack (Stereo Mini)
13. AUDIO OUT Mini Jack (Stereo Mini)
14. COMPUTER 3 IN/Component (R/Cr, G/Y, B/Cb, H, V) Connectors (BNC ×5)
15. VIDEO/S-VIDEO AUDIO IN L/MONO, R (RCA)
16. VIDEO IN Connector (RCA)
17. S-VIDEO IN Connector (Mini DIN 4 Pin)

20
Sirius-PJ1Training
Slide 20
Locations of Main Units - 1
After removing the top cover, you see the main board (called the MAIN IO or MAIN
PWB).
This board must be removed to access the adjustments.
After you remove the main board, you can see these major subassemblies:
OPT BASE: Contains the LCD panels, cross prism, and projection lens housing
Engine unit: Contains the relay lens, field lens, polarizers and the dichroic mirrors
Integrators: These are the PBS units
Main Board
OPT BASE
Engine Unit
Integrators
Please ignore the callouts [A] and red circles in the diagram.
