1
Soleil-PJ1Training
Slide 1
Y024/Y025/Y026/Y027/Y028/Y029
Service Training
Altair-PJ1
Version 1.0
This training course provides service technician training for the Altair-PJ1
series.

2
Soleil-PJ1Training
Slide 2
Y024/Y025/Y026/Y027/Y028/Y029
Service Training
Product Overview
This section provides an overview of the machine, and the options that can
be installed.

3
Soleil-PJ1Training
Slide 3
What Models are there in the Series?
These are DLP projectors.
YesYesWXGA3000 lmY027PJWX3340N
NoYesXGA3000 lmY028PJX4240N
No
No
Yes
No
Auto Focus
NoXGA3000 lmY024PJX3340
YesXGA3000 lmY025PJX3340N
NoWXGAPJWX3340
YesWXGA3000 lmY029PJWX4240N
Network
3000 lmY026
ResolutionBrightnessModelModel Name

4
Soleil-PJ1Training
Slide 4
Main Specifications - 1
WXGAWXGA
Auto
3500 (5200)Lamp life (Eco)
297 ×
××
×235 ×
××
×100Dimensions (W×
××
×D×
××
×H)
40-240 40-24030-20030-200Projection size (inch)
Altair-PJ1 dwnAltair PJ1 dw Altair-PJ1 dxnAltair-PJ1 dx
YesHDMI
300WMax. Power Consumption
3.0 kg (6.6 lbs)Less than 2.9 kg (6.4 lbs)Weight
YesNo@Remote
YesNoPJLink
YesNoWireless LAN
Service Use, PC-Free
Presentation Use
Service Use OnlyUSB
YesNoWired LAN
High-pressure mercury lamp
(Standard mode: 230 W, Eco mode: 124 W)
Lamp type
3000lmBrightness
Desk Edge Model
Type DLP
Resolution XGA XGA
Focus Manual
Speaker 10W x 1
PointBlank Dongle Connector Yes
Altair-PJ1
Additional USB port: Users can use this to display JPEG or MPEG2 files
without PC or network connection.
LAN: For use with PJLInk. Users can also use the LAN to project files that
are stored on a PC or server on the network. @Remote will also be
available.
To enable projection of a file from a PC over a network, a network utility can
be downloaded to the PC or installed from the CD that comes with the
projector. No lengthy installation procedure is required.

5
Soleil-PJ1Training
Slide 5
Main Specifications - 2
3500 (5200)Lamp life (Eco)
ManualFocus
60-14050-120Projection size (inch)
Short Throw Model
YesHDMI
325WMax. Power Consumption
3 kg (6.7 lbs)Less than 3 kg (6.7 lbs)Weight
Yes@Remote
YesPJLink
YesNoWireless LAN
Service Use, PC-Free
Presentation Use
Service Use OnlyUSB
YesWired LAN
High-pressure mercury lamp
(Standard mode: 250 W, Eco mode: 135 W)
Lamp type
3000lmBrightness
Altair-PJ1 sx Altair-PJ1 swn
Type DLP
Resolution XGA WXGA
Dimensions (W×
××
×D×
××
×H) 257 ×
××
×144 ×
××
×221
Speaker 10W x 1
PointBlank Dongle Connector Yes
Altair-PJ1
Additional USB port: Users can use this to display JPEG or MPEG2 files
without PC or network connection.
LAN: For use with PJLInk. Users can also use the LAN to project files that
are stored on a PC or server on the network. @Remote will also be
available.
To enable projection of a file from a PC over a network, a network utility can
be downloaded to the PC or installed from the CD that comes with the
projector. No lengthy installation procedure is required.

6
Soleil-PJ1Training
Slide 6
Features
This product can be installed by users.
The DE model is designed for table-top and
ceiling mount use.
The ST model is designed for table-top and wall
mount use.
This product is designed for user maintenance.
Regular on-site maintenance is not needed.
There is no display panel, but LEDs show the
symptoms for troubleshooting (blinking/lit,
number of times the LEDs blink, etc).
A service mode is available.
No additional notes

7
Soleil-PJ1Training
Slide 7
A: From the screen to the optical outlet
B: From the optical axis to the bottom of the
projected image
Relationship Between the
Projection Distance and the Screen Size
6~14 cm
(2~6 inches)
59~149 cm
(1.94~4.88 feet)
50~120 inches
Y028
Y029
Y026/Y027
Y024/Y025
5~11 cm
(2~4 inches)
61~148 cm
(2~4.85 feet)
60~140 inches
4~24 cm
(1~9 inches)
68~720 cm
(2.22~23.61 feet)
30~200 inches
3~18 cm
(1~7 inches)
77~733 cm
(2.53~24.06 feet)
40~240 inches
BAProjection Size
No additional notes

8
Soleil-PJ1Training
Slide 8
Network Features (Altair-PJ1)
Easy network setup
For network projection, Altair-PJ has an installation-
free network utility. Just download the file from the
Ricoh website to your PC or execute the program on
the attached CD, type in the PIN code, and you are
ready to project images.
¾Download network utility
from Ricoh website
[Step 1]
[Step 1] [Step 2]
[Step 2]
¾Type in the pass code
[Step 3]
[Step 3]
¾Make wireless network
connection on the PC
No additional notes

9
Soleil-PJ1Training
Slide 9
Network Features (Altair-PJ1)
@Remote capability
Remaining Lamp hour information
Power and status reporting
Projection server function
JPEG files stored on a web server can be
projected without a PC. Files can be uploaded
onto the web server using the supplied software:
JPEG conversion tool type A.
No additional notes

10
Soleil-PJ1Training
Slide 10
New Options - Interactive Tool Kit
The Interactive Tool Kit consists of an electronic pen, adapters
for the projector and computer, and a drawing software.
The user can use the pen to manipulate and perform operations on the projected
image and save the changes using the drawing software. Although the electronic
pen can be used in place of a mouse to operate the PC projection screen, it is
difficult to obtain the same level of positioning accuracy. The user should use a
mouse connected to the PC if required.
Electronic pen
Electronic pen Adapters
Adapters
For Projector (Cartridge)
For Projector (Cartridge)
For PC (USB dongle)
For PC (USB dongle)
Drawing software
Drawing software
*
* Support language :English/Chinese/ Japanese Support language :English/Chinese/ Japanese
The characteristics of the Interactive Tool Kit are as follows.
1.It allows you to interact on any surface
2.It requires no calibration
3.The pen works from a distance or on the projected image surface
It allows flexible installation and interaction with large images

11
Soleil-PJ1Training
Slide 11
From browser
From iTunes
Download
documents
When the presenter
flips a page.....
Synchronize and
share the data
Transfer to
participant’s iPad
Transfer to Altair
Connection with less than 10 units in a meeting is preferableConnectivity
Soleil PJ1b (PJ WX4130N), Regulus (PJ X3241N, PJ WX3231N)
Projector model
Wireless LAN (Wi-Fi) IEEE 802.11a/b/g/n *In the same broadband area
Wireless connection
Apple iPad/iPad2 (3G+Wi-Fi model, Wi-Fi model) / OS version: iOS 4.3.4
iPad version
System requirements
Free download from the iTunes store
*You need to install iTunes on your PC before searching for the Ricoh Smart presenter.
Operating instructions Æhttp://www.ricoh.co.jp/software/other/rtp/
Ricoh TAMAGO Presenter was developed as free trial software.
Interactivity with Other Digital Devices
Ricoh TAMAGO Presenter for iPad
No additional notes

12
Soleil-PJ1Training
Slide 12
Over a meter away
iHub Altair
Interactivity with Other Digital Devices
Collaboration with iHub (Unified Communication System)
Target: Small meetings of
2 – 5 people
Altair can be placed over a
meter away from iHub,
which means no glare
affects the video camera
on iHub.
No additional notes

13
Soleil-PJ1Training
Slide 13
Low Energy Consumption
5,200 hour lamp life and lower power
consumption in Eco mode
0.30W power consumption in standby mode
0.60W power consumption in wired LAN standby
mode
0.94W power consumption in wireless LAN
standby mode
Note that in the service mode menu, Eco Mode is referred to as ‘Low Mode’.

14
Soleil-PJ1Training
Slide 14
Consumables and Options - 1
Replacement lamp (Y212)
Mercury lamp
Life: 3,500 hours (normal mode), 5,200 hours
(Eco mode)
» The lamp is regarded as having reached its yield when
its maximum brightness has decreased to 50% of the
original level.
» When this occurs, a message to this effect is projected.
3D glasses (Y107)
DLP link is a technology that allows DLP
projectors to transmit 3D data.
DLP link technology sends data seamlessly to the
glasses between frames to create a 3D image.
For more about DLP link: http://www.dlp.com/projector/dlp-innovations/dlp-
link.aspx

15
Soleil-PJ1Training
Slide 15
Consumables and Options - 2
“Point Blank” Optional Interactive Tool Kit (Y117)
Digital pen
Module for projector
Module for PC
CD-ROM (drawing software)
Replacement Air Filter (Y213)
China only

16
Soleil-PJ1Training
Slide 16
Reliability Information
Average monthly projection time: 58.3 hrs/month
2.65 hrs/day x 22 working days/month
Failure Rate (cases/unit/month)
The failure rate of a projector increases with its total power-up
time. This is due in part to the failure characteristics of optical
engines in projectors.
Lamp Life
Normal Mode: 3,500 hrs (DE model 230W/ ST model 250W )
Eco Mode: 5,200 hrs (DE model 124W/ ST model 135W )
0.002590.003100.002181
st
year
0.003910.004690.003293
rd
year
0.003080.003690.002602
nd
year
Y028 sx
Y029 swn
Y025 dxn
Y027 dwn
Y024 dx
Y026 dw
No additional notes

17
Soleil-PJ1Training
Slide 17
Lamp Near-end/End Alerts
There is no near-end alert.
The lamp end alert occurs when the machine
calculates that the life time has expired.
If used in Normal Mode only, the alert appears
after 3,500 hrs projection time
If used in Eco Mode only, the alert appears after
5,200 hrs projection time
If the user switches between modes, the machine
calculates when to display the alert based on
how long the lamp was used in each mode.
No additional notes

18
Soleil-PJ1Training
Slide 18
Disposal of Broken Lamps
Projector lamps normally contain mercury vapor.
These lamps can rupture due to impact or being
used longer than their life expectancy.
The time that the breakage will occur differs
widely for each lamp and its circumstances of
use.
These lamps must be disposed of in accordance
with local environmental regulations.
No additional notes

19
Soleil-PJ1Training
Slide 19
Operation at High Altitude
In a high-altitude location (higher than 1500 m
above sea level) where air is thin, cooling
efficiency is reduced so use the projector with
[High Altitude Mode] turned [On].
No additional notes

20
Soleil-PJ1Training
Slide 20
Front
Left Right
External View
Intake vent
Exhaust vent Lens
Interfaces
Optical receiver
Top Basic operation keys
Focus adjuster
Speaker
Remote controller
Optical receiver: For the remote controller
