RIDGID R82234 User manual

SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
12 V LITHIUM-ION
JOBMAX™KIT
LITHIUM-ION 12 V
ENSEMBLE JOBMAX™
JUEGO DE JOBMAX™
12 V DE IONES DE LITIO
R82234
Cette ensemble JobMax™a été conçue et fabriquée conformément
à nos strictes normes de fiabilité, de simplicité d’emploi et de
sécurité d’utilisation. Correctement entretenue, elle vous donnera
des années de fonctionnement robuste et sans problème.
AVERTISSEMENT :
Pour réduire les risques de blessures, l’utilisateur doit
lire et veiller à bien comprendre le manuel d’utilisation
avant d’employer ce produit.
Merci d’avoir acheté un produit RIDGID®.
Su JobMax™para la obra ha sido diseñado y fabricado de
conformidad con nuestras estrictas normas para brindar
fiabilidad, facilidad de uso y seguridad para el operador. Con el
debido cuidado, le brindará muchos años de sólido y eficiente
funcionamiento.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario debe leer
y comprender el manual del operador antes de usar
este producto.
Le agradecemos la compra de un producto RIDGID®.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
Your JobMax™kit has been engineered and manufactured to our high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
To register your RIDGID
product, please visit:
http://register.RIDGID.com
Pour enregistrer votre
produit de RIDGID,
s’il vous plaît la visite:
http://register.RIDGID.com
Para registrar su producto
de RIDGID, por favor visita:
http://register.RIDGID.com
WARNING:
To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
Thank you for buying a RIDGID®product.

2
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
General Safety Rules.....................................................................................................................................................3-4
Règles de sécurité générales / Reglas de seguridad generales
Specific Safety Rules.....................................................................................................................................................4-5
Règles de sécurité particulières / Reglas de seguridad específicas
Symbols............................................................................................................................................................................ 6
Symboles / Símbolos
Features............................................................................................................................................................................ 7
Caractéristiques / Características
Assembly .......................................................................................................................................................................... 8
Assemblage / Armado
Operation.....................................................................................................................................................................9-12
Utilisation / Funcionamiento
Maintenance................................................................................................................................................................... 13
Entretien / Mantenimiento
Warranty ......................................................................................................................................................................... 14
Garantie / Garantía
Figure numbers (illustrations) ......................................................................................................................................... 16
Figure numéros (illustrations) / Figura numeras (ilustraciones)
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN

3 - English
GENERAL SAFETY RULES
WARNING – Read all instructions. Failure to
follow all instructions listed below may result in
electric shock, fire and/or serious injury. The term
“power tool” in all of the warnings listed below
refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
NOTE: The term “residual current device (RCD)” may
be replaced by the term “ground fault circuit interrupter
(GFCI)” or “earth leakage circuit breaker (ELCB).”
Use battery only with charger listed.
MODEL BATTERY PACK CHARGER
R82234 R86048 R86049
PERSONAL SAFETY
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
Use safety equipment. Always wear eye protection.
Dust mask, non-skid safety shoes, hard hat, or hearing
protection must be used for appropriate conditions.
Avoid accidental starting. Be sure switch is in the
locked or off position before inserting battery pack.
Carrying tools with your finger on the switch or inserting
the battery pack into a tool with the switch on invites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can
reduce dust-related hazards.
Do not wear loose clothing or jewelry. Contain long
hair. Loose clothes, jewelry, or long hair can be drawn
into air vents.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
power tool in unexpected situations.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.

4 - English
GENERAL POWER TOOL SAFETY RULES
SPECIFIC SAFETY RULES
Wear ear protectors with impact drills. Exposure to
noise can cause hearing loss.
Hold power tools by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a
“live” wire will also make exposed metal parts of the tool
“live” and shock the operator.
Know your power tool. Read operator’s manual
carefully. Learn its applications and limitations, as well
as the specific potential hazards related to this tool.
Following this rule will reduce the risk of electric shock,
fire, or serious injury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1. Failure to do so could
result in objects being thrown into your eyes, resulting in
possible serious injury.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reduce the risk of serious personal injury.
Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery tool or when changing
accessories. Following this rule will reduce the risk of
electric shock, fire, or serious personal injury.
Do not place battery tools or their batteries near fire
or heat. This will reduce the risk of explosion and possibly
injury.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped
or received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged
battery immediately.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
Do not charge battery tool in a damp or wet location.
Following this rule will reduce the risk of electric shock.
Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
Use the power tool, accessories and tool bits etc.,
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
BATTERY TOOL USE AND CARE
Ensure the switch is in the off position before insert-
ing battery pack. Inserting the battery pack into power
tools that have the switch on invites accidents.
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury and fire.
When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
When servicing a power tool, use only identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use ofunauthorized
parts or failure to follow Maintenance instructions may
create a risk of shock or injury.

5 - English
SPECIFIC SAFETY RULES
For best results, your battery tool should be charged
in a location where the temperature is more than
50°F but less than 100°F. To reduce the risk of serious
personal injury, do not store outside or in vehicles.
Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in contact
with your skin, wash immediately with soap and water,
then neutralize with lemon juice or vinegar. If liquid
gets into your eyes, flush them with clean water for
at least 10 minutes, then seek immediate medical
attention. Following this rule will reduce the risk of serious
personal injury.
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is misuse
and could result in a hazardous condition leading to
possible serious personal injury.
Do not attempt to use the handle without an accessory
head installed. Doing so could result in serious personal
injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions also
to prevent misuse of the product and possible injury.
WARNING:
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals
known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure
to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust
masks that are specially designed to filter out microscopic particles.

6 - English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper in-
terpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Precautions that involve your safety.
Read Operator’s Manual To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye Protection Always wear eye protection with side shields marked to comply with
ANSI Z87.1.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Recycle Symbol
This product contains lithium-ion (Li-ion) batteries. Local, state or
federal laws may prohibit disposal of lithium-ion batteries in ordinary
trash. Consult your local waste authority for information regarding
available recycling and/or disposal options.
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotational speed, at no load
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in minor or
moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in property damage.
Li - Ion

7 - English
FEATURES
PRODUCT SPECIFICATIONS
Motor..................................................................12 Volt DC
Switch.............................. VSR (Variable Speed Reversible)
Drill Head:
Chuck ...........................................................3/8 in. Keyless
No Load Speed .....................................0-550 r/min. (RPM)
Torque................................................................... 120 in.lb.
Ratchet Head:
Drive Shank ............................................................... 3/8 in.
No Load Speed .....................................0-220 r/min. (RPM)
Torque................................................................... 250 in.lb.
Impact Driver Head:
Coupler...............................................................1/4 in. Hex
Impacts Per Minute ......................................... 0-3,100 IPM
No Load Speed ..................................0-2,000 r/min. (RPM)
Torque................................................................... 650 in.lb.
KNOW YOUR JOBMAX™KIT
See Figure 1, page 16.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all op-
erating features and safety rules.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
The power handle has a direction of rotation (forward/
reverse/center lock) selector located below the switch trigger
for changing the direction of bit rotation. Setting the direction
of rotation selector in the OFF (center lock) position will lock
the switch trigger to help reduce the possibility of accidental
starting when not in use.
INTERCHANGEABLE HEADS
The power handle has a variety of interchangeable heads
for use in different job applications.
LED LIGHT
The LED light, located above the switch trigger, illuminates
when the switch trigger is depressed. This provides extra
light for increased visibility.
TRIGGER SAFETY
The trigger will not operate the power handle unless an
accessory head is attached.
VARIABLE SPEED
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
DRILL & IMPACT DRIVER HEADS:
RIGHT ANGLE DESIGN
The right angle head design of the drill and the impact driver
allows you to get into tight work areas for drilling, driving,
and impacting.
DRILL HEAD:
KEYLESS CHUCK
The drill head has a keyless chuck that allows you to hand
tighten or release drill bit in the chuck jaws.
IMPACT DRIVER HEAD:
1/4 IN. HEX COUPLER
Quickly and easily change bits without the need for tools.
IMPACTS PER MINUTE
This tool features an impact speed of 0-3,100 BPM (the
number of impacts per minute).
RATCHET HEAD:
3/8 IN. DRIVE SHANK WITH ADAPTOR
The ratchet head has a 3/8 in. drive shank. To use 1/2 in.
sockets, first install the included adaptor on the drive
shank.

8 - English
UNPACKING
This product has been shipped completely assembled.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if it is not completely
assembled or if any parts appear to be missing
or damaged. Use of a product that is not properly
and completely assembled could result in serious
personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-866-539-1710 for assistance.
PACKING LIST
R8223400 Power Handle
with R8223402 Drill Head
R8223401 Impact Driver Head
R8223403 Ratchet Head
Phillips Bit
1/2 in. Ratchet Adaptor
Motor Pinion Cap
Batteries (2)
Charger
Tool Bag
Operator’s Manual
ASSEMBLY
WARNING:
If any parts are damaged or missing do not operate
this product until the parts are replaced. Use of
this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
To prevent accidental starting that could cause
serious personal injury, always remove the battery
pack from the product when assembling parts.

9 - English
INSTALLING THE BATTERY PACK
See Figure 2, page 16.
Lock the switch trigger on the tool by placing the
direction of rotation (forward/reverse/center lock)
selector in center position.
Place battery pack in the tool. Align raised rib on battery
pack with the groove inside the tool.
Make sure the latch on the back of the battery pack
snaps in place and battery pack is secured in the tool
before beginning operation.
CAUTION:
When placing battery pack in the tool, be sure
raised rib on battery pack aligns with the bottom of
the tool and latches into place properly. Improper
installation of the battery pack can cause damage
to internal components.
REMOVING THE BATTERY PACK
See Figure 2, page 16.
Lock the switch trigger on the tool by placing the
direction of rotation selector in center position.
Depress latch on back of battery pack and pull battery
pack away from tool to remove.
WARNING:
Battery tools are always in operating condition.
Therefore, switch should always be locked when
not in use or carrying at your side.
SWITCH TRIGGER
See Figure 3, page 16.
To turn the tool ON, depress the switch trigger. To turn it
OFF, release the switch trigger.
VARIABLE SPEED
See Figure 3, page 16.
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
NOTE: You might hear a whistling or ringing noise from the
switch during use. Do not be concerned; this is a normal
part of the switch function.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
See Figure 3, page 16.
The direction of bit rotation is reversible and is controlled
by a selector located below the switch trigger. With the tool
held in normal operating position, the direction of rotation
selector should be positioned to the left of the switch trigger
for forward movement. The movement direction is reversed
when the selector is to the right of the switch trigger.
WARNING:
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a
second is sufficient to inflict severe injury.
WARNING:
Always wear eye protection with side shields
marked to comply with ANSI Z87.1. Failure to do
so could result in objects being thrown into your
eyes, resulting in possible serious injury.
WARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this product.
The use of attachments or accessories not
recommended can result in serious personal injury.
APPLICATIONS
You may use this product for the purposes listed below:
Drill Head:
Drilling in all types of wood products (lumber, plywood,
paneling, composition board, and hard board)
Drilling in ceramics, plastics, fiberglass, and laminates
Drilling in metals
Driving screws
Ratchet Head:
Removing and installing threaded fasteners
Impact Driver Head:
Driving screws, lag bolts
Tightening nuts and bolts
Removing screws, nuts, and bolts
For complete charging instructions, refer to the Operator’s
Manual for the battery packs and chargers listed in the
General Safety Rules.
BATTERY PROTECTION FEATURES
RIDGID 12 V lithium-ion batteries are designed with features
that protect the lithium-ion cells and maximize battery life.
Under some operating conditions, these built-in features
may cause the battery and the tool it is powering to act
differently from nickel-cadmium batteries.
During some applications, the battery electronics may
signal the battery to shut down, and cause the tool to stop
running.
NOTE: To prevent further shut down of the battery, avoid
forcing the tool.
If releasing the trigger does not reset the battery and tool,
the battery pack is depleted. If depleted, the battery pack will
begin charging when placed on the lithium-ion charger.
OPERATION

10 - English
WARNING:
Make sure to insert the drill bit straight into the
chuck jaws. Do not insert the drill bit into the chuck
jaws at an angle then tighten, as shown in figure 6.
This could cause the drill bit to be thrown from the
drill, resulting in possible serious personal injury or
damage to the chuck.
Tighten the chuck jaws securely on the bit.
NOTE: Rotate the chuck body in the direction of the
arrow marked LOCK to close the chuck jaws. Do not use
a wrench to tighten or loosen the chuck jaws.
REMOVING BITS
See Figures 5 - 6, pages 16 - 17.
Remove the battery pack from the tool.
Open the chuck jaws.
NOTE: Rotate the chuck body in the direction of the arrow
marked UNLOCK to open the chuck jaws. Do not use a
wrench to tighten or loosen the chuck jaws.
Remove the drill bit.
DRILLING
See Figure 7, page 17.
Check the direction of rotation selector for the correct
setting (forward or reverse).
Secure the material to be drilled in a vise or with clamps
to keep it from turning as the drill bit rotates.
Hold the drill firmly and place the bit at the point to be
drilled.
Depress the switch trigger to start the drill.
Move the drill bit into the workpiece, applying only enough
pressure to keep the bit cutting. Do not force the drill or
apply side pressure to elongate a hole. Let the tool do
the work.
WARNING:
Be prepared for binding at bit breakthrough. When
these situations occur, drill has a tendency to grab
and kick opposite to the direction of rotation and
could cause loss of control when breaking through
material. If not prepared, this loss of control can
result in possible serious injury.
When drilling hard, smooth surfaces, use a center punch
to mark the desired hole location. This will prevent the
drill bit from slipping off-center as the hole is started.
When drilling metals, use a light oil on the drill bit to keep
it from overheating. The oil will prolong the life of the bit
and increase the drilling action.
If the bit jams in the workpiece or if the drill stalls, stop
the tool immediately. Remove the bit from the workpiece
and determine the reason for jamming.
Setting the direction of rotation selector in the OFF (center
lock) position helps reduce the possibility of accidental
starting when not in use.
CAUTION:
To prevent gear damage, always allow the chuck,
square head, or coupler to come to a complete
stop before changing the direction of rotation.
To stop the tool, release the switch trigger and allow the tool
to come to a complete stop.
NOTE: The tool will not run unless the direction of rotation
selector is pushed fully to the left or right.
Avoid running the tool at low speeds for extended periods
of time. Running at low speeds under constant usage may
cause the tool to become overheated. If this occurs, cool the
tool by running it without a load and at full speed.
CHANGING HEADS
See Figure 4, page 16.
Remove the battery pack from the tool.
Depress the latches on both sides of the tool with one
hand while pulling the head away from the tool with your
other hand.
Place the desired head on the tool and push until the
head clicks into position. Pull on the head to make sure
it is securely installed before proceeding.
NOTE: The head can be installed at 90° angles to best
suit your application needs.
DRILL OPERATION
KEYLESS CHUCK
See Figure 5, page 16.
The drill head has a keyless chuck to tighten or release drill
bits in the chuck jaws. The arrows on the chuck indicate
which direction to rotate the chuck body in order to LOCK
(tighten) or UNLOCK (release) the drill bit.
WARNING:
Do not hold the chuck body with one hand and use
the power of the tool to tighten the chuck jaws on
the drill bit. The chuck body could slip in your hand,
or your hand could slip and come in contact with
the rotating drill bit. This could cause an accident
resulting in serious personal injury.
INSTALLING BITS
See Figures 5 - 6, pages 16 - 17.
Remove the battery pack from the tool.
Open or close the chuck jaws to a point where the opening
is slightly larger than the bit size you intend to use. Also,
raise the front of the drill slightly to keep the bit from falling
out of the chuck jaws.
Insert the drill bit.
OPERATION

11 - English
NOTE: This tool has an electric brake. When the switch
trigger is released, the chuck stops turning. When the brake
is functioning properly, sparks will be visible through the
vent slots on the housing. This is normal and is the action
of the brake.
WOOD DRILLING
For maximum performance, use high speed steel bits for
wood drilling.
Begin drilling at a very low speed to prevent the bit from
slipping off the starting point. Increase the speed as the
drill bit bites into the material.
When drilling through holes, place a block of wood behind
the workpiece to prevent ragged or splintered edges on
the back side of the hole.
METAL DRILLING
For maximum performance, use high speed steel bits for
metal or steel drilling.
Begin drilling at a very low speed to prevent the bit from
slipping off the starting point.
Maintain a speed and pressure which allows cutting
without overheating the bit. Applying too much pressure
will:
• Overheat the drill;
• Wear the bearings;
• Bend or burn bits; and
• Produce off-center or irregular-shaped holes.
When drilling large holes in metal, start with a small bit,
then finish with a larger bit. Also, lubricate the bit with oil
to improve drilling action and increase bit life.
RATCHET OPERATION
INSTALLING AND REMOVING SOCKETS
See Figure 8, page 17.
Always select the correct size socket for nuts and bolts.
Using the wrong size socket may damage the nut or bolt
and cause the fastening torque to be inaccurate or incon-
sistent.
Remove the battery pack from the tool.
Push a 3/8 in. socket onto the drive shank until the detent
pin locks it into place.
NOTE: If a 1/2 in. socket is needed, first install the 3/8 in.
to 1/2 in. socket adaptor.
To remove the socket, pull it away from the drive shank.
OPERATING THE RATCHET
See Figure 9, page 17.
Proper fastening torque is determined by the kind of bolt,
the size of the bolt, or the material of the workpiece. This
tool is designed only to speed the installation and removal
process and is not intended to replace a torque wrench. For
OPERATION
applications where proper torque is important, always use a
torque wrench to verify that proper torque is achieved.
NOTE: Do not use this tool to install lug nuts on wheels.
Install the desired socket.
Adjust the dial on the back of the ratchet head to choose
the desired rotation direction of the socket.
NOTE: The direction of rotation selector below the switch
trigger has no affect on the rotation direction of the ratchet
head.
Hold the tool in front of the workpiece with the socket
over the nut or bolt.
Depress the switch trigger and fasten or loosen as de-
sired.
NOTE: After fastening, always check the torque with a
torque wrench.
CAUTION
Do not turn the tool off and attempt to use the tool
manually to gain extra torque on the nut or bolt
being tightened. Doing so could cause damage to
the fastener and/or the tool.
IMPACT DRIVER OPERATION
INSTALLING BITS
See Figure 10, page 17.
Remove the battery pack from the tool.
Pull the coupler away from the impact driver head (1).
Insert driver bit to be used into the coupler (2).
Release the coupler (3).
Pull on the bit to make sure it is secured in the coupler.
There may be some play in the installed bit; this is nor-
mal.
NOTE: Use only impact quality bits with a locking groove.
WARNING:
Make sure the bit is secured in the coupler before
using the impact driver. Failure to do so could
cause serious personal injury.
REMOVING BITS
See Figure 10, page 17.
Remove the battery pack from the tool.
Pull the coupler away from the impact driver head.
Remove driver bit from the coupler.
CAUTION:
The impact driver is not designed to be used as
a drill.

12 - English
OPERATION
DRIVING OR REMOVING SCREWS
See Figure 11, page 17.
Place the direction of rotation selector in the correct posi-
tion for the operation.
Place the bit on the screw head and slowly depress the
switch trigger. Start the bit slowly for more control.
As screw is driven, impacting will begin.
WARNING:
Do not drive a screw where there is likely to be
hidden wiring behind the surface. Contact with a
“live” wire will make exposed metal parts of the tool
“live” and possibly shock the operator. If you must
drive a screw where hidden wire may be present,
always hold tool by insulated gripping surfaces
(handle) when performing the operation to prevent
a shock to the operator, as seen in figure 11.

13 - English
MAINTENANCE
WARNING:
When servicing use only identical RIDGID®
replacement parts. Use of any other parts may
create a hazard or cause product damage.
WARNING:
Always wear eye protection with side shields
marked to comply with ANSI Z87.1. Failure to do
so could result in objects being thrown into your
eyes, resulting in possible serious injury.
WARNING:
To avoid serious personal injury, always remove
the battery pack from the tool when cleaning or
performing any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
REPLACING THE MOTOR PINION CAP
See Figure 12, page 17.
If over time you notice the noise of the tool getting louder
than usual, check the condition of the motor pinion cap. If the
cap is excessively damaged so that the metal gear is clearly
visible, remove it and replace with the spare cap included.
NOTE: To reduce the noise level of the tool, do not operate
without the motor pinion cap installed.
WARNING:
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may
result in serious personal injury.
BATTERY PACK REMOVAL AND PREPARATION
FOR RECYCLING
WARNING:
Upon removal, cover the battery pack’s terminals
with heavy-duty adhesive tape. Do not attempt to
destroy or disassemble battery pack or remove any
of its components. Lithium-ion batteries must be
recycled or disposed of properly. Also, never touch
both terminals with metal objects and/or body
parts as short circuit may result. Keep away from
children. Failure to comply with these warnings
could result in fire and/or serious injury.
NOTE: FIGURES (ILLUSTRATIONS) START ON PAGE 16
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.

14 - English
WARRANTY
Proof of purchase must be presented when requesting war-
ranty service.
Limited to RIDGID®hand held and stationary power tools
purchased 2/1/04 and after. This product is manufactured
by One World Technologies, Inc. The trademark is licensed
from RIDGID, Inc. All warranty communications should be
directed to One World Technologies, Inc., attn: RIDGID Hand
Held and Stationary Power Tool Technical Service at (toll
free) 1-866-539-1710.
90-DAY SATISFACTION GUARANTEE POLICY
During the first 90 days after the date of purchase, if you are
dissatisfied with the performance of this RIDGID®Hand Held
and Stationary Power Tool for any reason you may return
the tool to the dealer from which it was purchased for a full
refund or exchange. To receive a replacement tool you must
present proof of purchase and return all original equipment
packaged with the original product. The replacement tool
will be covered by the limited warranty for the balance of
the 3 YEAR service warranty period.
WHAT IS COVERED UNDER THE 3 YEAR
LIMITED SERVICE WARRANTY
This warranty on RIDGID®Hand Held and Stationary Power
Tools covers all defects in workmanship or materials and nor-
mal wear items such as brushes, chucks, motors, switches,
cords, gears and even cordless batteries in this RIDGID®
tool for three years following the purchase date of the tool.
Warranties for other RIDGID®products may vary.
HOW TO OBTAIN SERVICE
To obtain service for this RIDGID®tool you must return it;
freight prepaid, or take it in to an authorized service center
for RIDGID®branded hand held and stationary power tools.
You may obtain the location of the authorized service center
nearest you by calling (toll free) 1-866-539-1710 or by log-
ging on to the RIDGID®website at www.ridgid.com. When
requesting warranty service, you must present the original
dated sales receipt. The authorized service center will re-
pair any faulty workmanship, and either repair or replace
any part covered under the warranty, at our option, at no
charge to you.
One World Technologies, Inc.
P.O. Box 35, Hwy. 8
Pickens, SC 29671
RIDGID®HAND HELD AND STATIONARY POWER TOOL 3 YEAR LIMITED SERVICE
WARRANTY
WHAT IS NOT COVERED
This warranty applies only to the original purchaser at retail
and may not be transferred. This warranty only covers de-
fects arising under normal usage and does not cover any
malfunction, failure or defect resulting from misuse, abuse,
neglect, alteration, modification or repair by other than an
authorized service center for RIDGID®branded hand held
and stationary power tools. Consumable accessories pro-
vided with the tool such as, but not limited to, blades, bits
and sand paper are not covered.
RIDGID, INC. AND ONE WORLD TECHNOLOGIES, INC.
MAKE NO WARRANTIES, REPRESENTATIONS OR
PROMISES AS TO THE QUALITY OR PERFORMANCE
OF ITS POWER TOOLS OTHER THAN THOSE SPECIFI-
CALLY STATED IN THIS WARRANTY.
ADDITIONAL LIMITATIONS
To the extent permitted by applicable law, all implied war-
ranties, including warranties of MERCHANTABILITY or FIT-
NESS FOR A PARTICULAR PURPOSE, are disclaimed. Any
implied warranties, including warranties of merchantability
or fitness for a particular purpose, that cannot be disclaimed
under state law are limited to three years from the date of
purchase. One World Technologies, Inc. and RIDGID, Inc.
are not responsible for direct, indirect, incidental or conse-
quential damages. Some states do not allow limitations on
how long an implied warranty lasts and/or do not allow the
exclusion or limitation of incidental or consequential dam-
ages, so the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.

15 - English
NOTES

3 - Français
RÈGLES DE SÉCURITÉ GÉNÉRALES
AVERTISSEMENT – Lire toutes les
instructions. Le non-respect de toutes les
instructions ci-dessous peut entraîner un choc
électrique, un incendie et/ou des blessures graves.
Le terme « outil électrique », utlisé dans tous les
avertissements ci-dessous, désigne tout outil
fonctionnant sur secteur (câblé) ou sur batteries
(sans fil).
CONSERVER CES INSTRUCTIONS
SÉCURITÉ DU LIEU DE TRAVAIL
Garder le lieu de travail propre et bien éclairé. Les
endroits encombrés ou sombres sont propices aux
accidents.
Ne pas utiliser d’outils électriques dans des
atmosphères explosives, par exemple en présence
de liquides, gaz ou poussières inflammables. Les
outils électriques produisent des étincelles risquant
d’enflammer les poussières ou vapeurs.
Garder les enfants et badauds à l’écart pendant
l’utilisation d’un outil électrique. Les distractions
peuvent causer une perte de contrôle.
SÉCURITÉ ÉLECTRIQUE
Les fiches des outils électriques doivent correspondre
à la prise secteur utilisée. Ne jamais modifier la fiche,
de quelque façon que ce soit. Ne jamais utiliser
d’adaptateurs de fiche avec des outils mis à la terre.
Les fiches et prises non modifiées réduisent le risque de
choc électrique.
Éviter tout contact du corps avec des surfaces mises
à la terre, telles que tuyaux, radiateurs, cuisinières et
réfrigérateurs. Le risque de choc électrique est accru
lorsque le corps est mis à la terre.
Ne pas exposer les outils électriques à l’eau ou
l’humidité. La pénétration d’eau dans ces outils accroît
le risque de choc électrique.
Ne pas maltraiter le cordon d’alimentation. Ne jamais
utiliser le cordon d’alimentation pour transporter
l’outil et ne jamais débrancher ce dernier en tirant sur
le cordon. Garder le cordon à l’écart de la chaleur,
de l’huile, des objets tranchants et des pièces en
mouvement. Un cordon endommagé ou emmêlé accroît
le risque de choc électrique.
Pour les travaux à l’extérieur, utiliser un cordon
spécialement conçu à cet effet. Utiliser un cordon
conçu pour l’usage extrérieur pour réduire les risques
de choc électrique.
S’il est nécessaire d’utiliser l’outil électrique dans
un endroit humide, employer un dispositif à courant
résiduel. L’utilisation d’un tel dispositif réduit le risque de
décharge électrique.
NOTE : Il est possible de remplacer le terme « appareil
à courant résiduel (RCD) » par le terme « interrupteur de
défaut à la terre (GFCI) » ou « disjoncteur de mise à la
terre (ELCB) ».
Ne recharger qu’avec l’appareil indiqué.
MODÈLE
BLOC-PILE CHARGEUR
R82234 R86048 R86049
SÉCURITÉ PERSONNELLE
Rester attentif, prêter attention au travail et faire
preuve de bon sens lors de l’utilisation de tout
outil électrique. Ne pas utiliser cet outil en état de
fatigue ou sous l’influence de l’alcool, de drogues
ou de médicaments. Un moment d’inattention pendant
l’utilisation d’un outil électrique peut entraîner des
blessures graves.
 Utiliser l’équipement de sécurité. Toujours porter une
protection oculaire. Suivant les conditions, le port d’un
masque filtrant, de chaussures de sécurité, d’un casque
ou d’une protection auditive est recommandé.
 Éviter les démarrages accidentels. S’assurer que
la gâchette est verrouillée en position d’arrêt avant
d’insérer le bloc de batteries. Le transport d’outils avec
le doigt sur le commutateur ou l’insertion du bloc de
batterie avec le commutateur en position de marche est
une invite aux accidents.
Retirer les clés de réglage avant de mettre l’outil en
marche. Une clé laissée sur une pièce rotative de l’outil
peut causer des blessures.
Ne pas travailler hors de portée. Toujours se tenir
bien campé et en équilibre. Ceci permettra de mieux
contrôler l’outil en cas de situation imprévue.
Porter une tenue appropriée. Ne porter ni vêtements
amples, ni bijoux. Garder les cheveux, les vêtements
et les gants à l’écart des pièces en mouvement. Les
vêtements amples, bijoux et cheveux longs peuvent se
prendre dans les pièces en mouvement.
Si les outils sont équipés de dispositifs de
dépoussiérage, s’assurer qu’ils sont connectés et
correctement utilisés. L’usage de ces dispositifs peut
réduire les dangers présentés par la poussière.
Ne porter ni vêtements amples, ni bijoux. Attacher
ou couvrir les cheveux longs. Les vêtements amples,
bijoux et cheveux longs peuvent se prendre dans les ouïes
d’aération.
Ne pas utiliser l’outil sur une échelle ou un support
instable. Une bonne tenue et un bon équilibre permettent
de mieux contrôler l’outil en cas de situation imprévue.
UTILISATION ET ENTRETIEN DES OUTILS
ÉLECTRIQUES
Ne pas forcer l’outil. Utiliser l’outil approprié pour
l’application. Un outil approprié exécutera le travail
mieux et de façon moins dangereuse s’il est utilisé dans
les limites prévues.

4 - Français
RÈGLES DE SÉCURITÉ PARTICULIÈRES
Lors de l’usage d’une tournevis à percussion, porter
une protection auditive. L’exposition au bruit peut
causer une perte auditive.
Lorsque l’outil est utilisé pour un travail risquant de
le mettre en contact avec des fils électriques cachés
ou son propre cordon d’alimentation, le tenir par les
surfaces de prise isolées. Tout contact avec un fil sous
tension électrifierait les parties métalliques de l’outil,
causant un choc électrique à l’opérateur.
Apprendre à connaître l’outil. Lire attentivement le
manuel d’utilisation. Apprendre les applications et
les limites de l’outil, ainsi que les risques spécifiques
relatifs à son utilisation. Le respect de cette consigne
réduira les risques d’incendie, de choc électrique et de
blessures graves.
Toujours porter une protection oculaire avec écrans
latéraux certifiée conforme à la norme ANSI Z87.1. Si
cette précaution n’est pas prise, des objets peuvent être
projetés dans les yeux et causer des lésions graves.
Protection respiratoire. Porter un masque facial ou
un masque antipoussière si le travail produit de la
poussière. Le respect de cette consigne réduira les
risques de blessures graves.
Protection auditive. Porter une protection auditive
lors de l’utilisation prolongée. Le respect de cette règle
réduira les risques de blessures graves.
Ne pas utiliser l’outil si le commutateur ne permet
pas de le mettre en marche ou de l’arrêter. Tout outil
qui ne peut pas être contrôlé par son commutateur est
dangereux et doit être réparé.
Débrancher l’outil et/ou retirer le bloc-piles avant
d’effectuer des réglages, de changer d’accessoire ou
de remiser l’outil. Ces mesures de sécurité préventives
réduisent les risques de démarrage accidentel de
l’outil.
Ranger les outils motorisés hors de la portée des
enfants et ne laisser personne n’étant pas familiarisé
avec l’outil ou ces instructions utiliser l’outil. Dans les
mains de personnes n’ayant pas reçu des instructions
adéquates, les outils sont dangereux.
Entretenir les outils motorisés. Vérifier qu’aucune
pièce mobile n’est mal alignée ou bloquée, qu’aucune
pièce n’est brisée et s’assurer qu’aucun autre
problème ne risque d’affecter le bon fonctionnement
de l’outil. En cas de dommages faire réparer l’outil
avant de l’utiliser de nouveau. Beaucoup d’accidents
sont causés par des outils mal entretenus.
Garder les outils bien affûtés et propres. Des outils
correctement entretenus et dont les tranchants sont bien
affûtés risquent moins de se bloquer et sont plus faciles
à contrôler.
Utiliser l’outil, les accessoires et embouts, etc.,
conformément à ces instrutions pour les applications
en tenant compte des conditions et du type de
travail à exécuter. L’usage d’un outil motorisé pour des
applications pour lesquelles il n’est pas conçu peut être
dangereux.
UTILISATION ET ENTRETIEN DE LA PILE
S’assurer que le commutateur est en position d’arrêt
avant d’insérer le bloc-piles. L’insertion du bloc-piles
dans un outil dont le commutateur est en position de
marche peut causer un accident.
Ne recharger qu’avec l’appareil spécifié par le
fabricant. Un chargeur approprié pour un type de pile
peut créer un risque d’incendie s’il est utilisé avec un
autre type de pile.
Utiliser exclusivement le bloc-pile spécifiquement
indiqué pour l’outil. L’usage de tout autre bloc peut créer
un risque de blessures et d’incendie.
Lorsque le bloc-piles n’est pas en usage, le garder
à l’écart d’articles tels qu’attaches trombones,
pièces de monnaie, clous, vis et autres petits objets
métalliques risquant d’établir le contact entre les deux
bornes. La mise en court-circuit des bornes de piles peut
causer des étincelles, des brûlures ou un incendie.
En cas d’usage abusif, du liquide peut s’échapper des
piles. Éviter tout contact avec ce liquide. En cas de
contact accidentel, rincer immédiatement les parties
atteintes avec de l’eau. En cas d’éclaboussure dans
les yeux consulter un médecin. Le liquide s’échappant
des piles peut causer des irritations ou des brûlures.
DÉPANNAGE
Les réparations doivent être confiées à un technicien
qualifié, utilisant exclusivement des pièces identiques
à celles d’origine. Ceci assurera le maintien de la sécurité
de l’outil.
Utiliser exclusivement des pièces identiques à celles
d’origine pour les réparations. Se conformer aux
instructions de la section Entretien de ce manuel.
L’usage de pièces non autorisées ou le non-respect des
instructions peut présenter des risques de choc électrique
ou de blessures.
RÈGLES DE SÉCURITÉ GÉNÉRALES

5 - Français
RÈGLES DE SÉCURITÉ PARTICULIÈRES
Les outils fonctionnant sur batteries n’ayant pas
besoin d’être branchés sur une prise secteur, ils sont
toujours en état de fonctionnement. Tenir compte des
dangers possibles lorsque l’outil n’est pas en usage
et lors du remplacement des batteries. Le respect de
cette consigne réduira les risques d’incendie, de choc
électrique et de blessures graves.
Ne pas placer les outils électriques sans fil ou leurs
batteries à proximité de flammes ou d’une source
de chaleur. Ceci réduira les risques d’explosion et de
blessures.
Ne pas écraser, faire tomber ou endommager le
batteries. Ne jamais utiliser un batteries ou un
chargeur qui est tombé, a été écrasé, a reçu un choc
violent ou a été endommagé de quelque façon que
ce soit. Une batterie endommagée risque d’exploser.
Éliminer immédiatement toute batterie endommagée,
selon une méthode appropriée.
Les batteries peuvent exploser en présence d’une
source d’allumage, telle qu’une veilleuse. Pour réduire
les risques de blessures graves, ne jamais utiliser un
appareil sans fil, quel qu’il soit, en présence d’une flamme
vive. En explosant, une batterie peut projeter des débris
et des produits chimiques. En cas d’exposition, rincer
immédiatement les parties atteintes avec de l’eau.
Ne pas recharger un outil fonctionnant sur batteries
dans un endroit humide ou mouillé. Le respect de cette
règle réduira les risques de choc électrique.
Pour un résultat optimal, le batteries de l’outil doivent
être rechargées dans un local où la température est
de 10 à 38 °C (50 à 100 °F). Ne pas ranger l’outil à
l’extérieur ou dans un véhicule.
Si l’outil est utilisé de façon intensive ou sous des
températures extrêmes, des fuites de batterie peuvent
se produire. En cas de contact du liquide avec la peau,
rincer immédiatement la partie atteinte avec de l’eau
savonneuse, puis neutraliser avec du jus de citron ou
du vinaigre. En cas d’éclaboussure dans les yeux, les
rincer à l’eau fraîche pendant au moins 10 minutes,
puis contacter immédiatement un médecin. Le respect
de cette règle réduira les risques de blessures graves.
Ne pas essayer de modifier ce produit ou de créer
des accessoires non recommandés pour le produit.
De telles altérations ou modifications sont considérées
comme un usage abusif et peuvent créer des conditions
dangereuses, risquant d’entraîner des blessures
graves.
Ne pas tenter d’utiliser la poignée si la tête de
l’accessoire n’a pas été installée. Ne pas suivre cette
directive peut entraîner des blessures graves.
Conserver ces instructions. Les consulter fréquemment
et les utiliser pour instruire les autres utilisateurs
éventuels. Si cet outil est prêté, il doit être accompagné
de ces instructions, afin d’éviter un usage incorrect et
d’éventuelles blessures.
AVERTISSEMENT :
La poussière dégagée lors du ponçage, sciage, meulage, perçage de certains matériaux et lors d’autres opérations
de construction contient des produits chimiques reconnus causer le cancer, des malformations congénitales ou
des lésions de l’appareil reproducteur. Voici certains exemples de ces produits chimiques :
• le plomb contenu dans la peinture au plomb,
• la silice cristalline contenue dans les briques, le béton et d’autres produits de maçonnerie, ainsi que
• l’arsenic et le chrome contenus dans le bois de construction traité par produits chimiques.
Le risque présenté par l’exposition à ces produits varie en fonction de la fréquence de ce type de travail. Pour réduire
l’exposition à ces produits chimiques : travailler dans un endroit bien aéré et utiliser des équipements de sécurité
approuvés tels que masques antipoussière spécialement conçus pour filtrer les particules microscopiques.

6 - Français
SYMBOLES
Certains des symboles ci-dessous peuvent être présents sur produit. Veiller à les étudier et à apprendre leur signification.
Une interprétation correcte de ces symboles permettra d’utiliser produit plus efficacement et de réduire les risques.
SYMBOLE NOM DÉSIGNATION / EXPLICATION
Symbole d’alerte de
sécurité Précautions destinées à assurer la sécurité.
Lire le manuel d’utilisation Pour réduire les risques de blessures, l’utilisateur doit lire et veiller à
bien comprendre le manuel d’utilisation avant d’utiliser ce produit.
Protection oculaire Toujours porter une protection oculaire avec écrans latéraux certifiée
conforme à la norme ANSI Z87.1.
Avertissement
concernant l’humidité Ne pas exposer à la pluie ou l’humidité.
Symbole Recycler
Ceproduitutilisedesbatteriesaulithium-ion(Li-ion).Lesréglementations
locales ou gouvernementales peuvent interdire de jeter les batteries au
lithium-ion dans les ordures ménagères. Consulter les autorités locales
compétentes pour les options de recyclage et/ou l’élimination.
V Volts Tension
A Ampères Intensité
Hz Hertz Fréquence (cycles par seconde)
W Watt Alimentation
min Minutes Temps
Courant continu Type ou caractéristique du courant
n
o
Vitesse à vide Vitesse de rotation à vide
.../min Par minute Tours, coups, vitesse périphérique, orbites, etc., par minute
Les termes de mise en garde suivants et leur signification ont pour but d’expliquer le degré de risque associé à l’utilisation
de ce produit.
SYMBOLE SIGNAL SIGNIFICATION
DANGER: Indique une situation extrêmement dangereuse qui, si elle n’est pas évitée, aura
pour conséquences des blessures graves ou mortelles.
AVERTISSEMENT : Indique une situation potentiellement dangereuse qui, si elle n’est pas évitée,
pourrait avoir pour conséquences des blessures graves ou mortelles.
ATTENTION : Indique une situation potentiellement dangereuse qui, si elle n’est pas évitée,
pourrait avoir pour conséquences des blessures légères ou de gravité modérée.
ATTENTION : (Sans symbole d’alerte de sécurité) Indique une situation pouvant entraîner des
dommages matériels.
Li - Ion

7 - Français
CARACTÉRISTIQUES
FICHE TECHNIQUE
Moteur ...................................................................12 V c.c.
Commutateur .................. Vitesse variable/réversible (VSR)
Tête de perceuse :
Mandrin ........................................10 mm (3/8 po), sans clé
Vitesse à vide .........................................0-550 r/min (RPM)
Couple............................................... 120 po-lb (13,56 Nm)
Tête à rochet :
Axe d’entraînement ....................................9,5 mm (3/8 po)
Vitesse à vide .........................................0-220 r/min (RPM)
Couple............................................... 250 po-lb (28,25 Nm)
Tête de tournevis à percussion :
Coupleur...........................................6,35 mm (1/4 po) hex.
Chocs par minute............................... 0 à 3 100 coups/min
Vitesse à vide ......................................0-2 000 r/min (RPM)
Couple............................................... 73,44 Nm (650 po-lb)
VEILLER À BIEN CONNAÎTRE L’ENSEMBLE
JOBMAX™
Voir la figure 1, page 16.
Lasécuritéd’utilisationdeceproduitexigelacompréhension
des informations apposées sur l’outil et contenues dans ce
manuel d’utilisation, ainsi que la connaissance du travail
à exécuter. Avant d’utiliser ce produit, se familiariser avec
toutes ses fonctions et règles de sécurité.
SÉLECTEUR DE SENS DE ROTATION
(SÉLECTEURDESENSDEROTATION/VERROUOUILLAGE
CENTRAL)
La poignée motorisée est équipée d’un sélecteur de sens de
rotation (marche avant / arrière / verrouillage central) situé
ci-dessous de la gâchette. La gâchette peut être verrouillée
en position d’ARRÊT (position centrale) pour empêcher le
démarrage de l’outil lorsqu’il n’est pas utilisé.
TÊTES INTERCHANGEABLES
La poignée motorisée comprend plusieurs têtes inter-
changeables qui peuvent être utilisées pour différentes
applications.
LAMPE À DEL
La lampe à DEL, située au-dessus de la gâchette, éclaire
quandlagâchetteest enfoncée.Celaprocure plusdelumière
pour une visibilité accrue.
SÉCURITÉ DE LA GÂCHETTE
La gâchette ne permet pas de faire fonctionner la poignée
motorisée si aucun accessoire n’est fixé.
VITESSE VARIABLE
La pression exercée sur la gâchette permet de contrôler la
vitesse de rotation.
TÊTES DE PERCEUSE ET DE TOURNEVIS À
PERCUSSION :
CONCEPTION À ANGLE DROIT
Le format à angle droit de la perceuse et du tournevis à
percussionpermet àl’utilisateur d’effectuerdes applications
de perçage, de vissage et de martelage dans des endroits
étroits.
TÊTE DE PERCEUSE :
MANDRIN SANS CLÉ
Comme le nom l’indique, les forets et embouts peuvent être
serrés dans le mandrin à la main.
TÊTE DE TOURNEVIS À PERCUSSION
COUPLEUR HEXAGONAL DE 6,35 mm (1/4 po)
Permet de changer d’embout sans aucun outil.
CHOCS PAR MINUTE
La vitesse de chocs de cet outil est de 0 à 3 100 coups/min
(le nombre de chocs par minute).
TÊTE À ROChET :
TIGE D’ENTRAÎNEMENT DE 9,53 mm (3/8 po)
AVEC ADAPTATEUR
La tige à rochet comprend une tige d’entraînement de
9,53 mm (3/8 po). Pour utiliser des douilles de 12,7 mm
(1/2 po), installer d’abord l’adaptateur fourni sur la tige
d’entraînement.
