Rigel MULTI-FLO Installation guide

How do I use Multi-Flo in Remote
Control mode on Med-eBase?
To use the remote control mode the user will need to install the Gadget
Serial V2.4 Driver. The Gadget serial driver is available at rigelmedical.com in
the download section. To install the gadget serial driver the Multi-Flo needs
to be turned on and connected to the PC using the USB serial cable.
Equipment required:
- Multi-Flo
- PC running Med-eBase V2.4 or higher
- Gadget serial driver install files
- USB Serial cable or memory stick
1) On the Multi-Flo menu scroll down and select remote control mode. The
Multi-Flo will then try to connect with the PC.
2) The PC will attempt to download the install drivers for the gadget serial.
As the driver is located on the PC and cannot be found on the internet this
step is not required. Click on the icon when it appears as seen below.
3) Select “skip obtaining driver software” which is blue and underlined to
stop widows looking for driver as the Rigel device won’t be able to connect
to the PC while the computer is performing this task. Select yes on the
driver software installation screen to skip the driver update.

4) Once this is complete open the Control Panel and go to ‘Devices and
Printers’. The gadget serial will be an unspecified device. Right click on the
gadget serial and select properties.
5) In the General tab select Update Drivers and then choose ‘Browse my
computer for driver software’.
6) Select the folder where the gadget serial files are located. Select Ok to
choose the folder and then next.
7) Once the driver is installed select next and then close the Control Panel.
To confirm the gadget serial driver is installed correctly:
8) Open Med-eBase V2.4making sure the Multi-Flo is connected and in
Remote Control Mode.
9) On Med-eBase select ‘Download from Tester’ by either selecting Tools >
Download or the icon.
10) Choose Multi-Flo as the instrument type and then select Gadget serial
as the COM port.
Note: If Med-eBase was open while installing the gadget serial driver the
user may be required to close Med-eBase and reopen it or Rescan
COM ports to locate the gadget serial.

If you require more help, please contact us at
https://www.seaward.com/gb/enquire/.
