Right Weigh 201-EBT-02 User manual

ONBOARD LOAD SCALE
EXTERIOR DIGITAL |201-EBT-02(B)
2
LOW

WELCOME
2
Thank you for choosing to drive more and scale less! Here at Right
Weigh, we are commied to making our products simple to install
and easy to use. We understand that installaon can vary between
vehicles and yours may not be described in this manual. In any event,
our technical support team is ready to answer your quesons!
FOLLOW US!
[phone]
[email protected]
rightweigh.com.au
IMPORTANT!
Please read instrucons COMPLETELY and thoroughly before installaon. Right Weigh, Inc. is not
responsible or liable for any negave consequences as a result of improper installaon or
operaon including, but not limited to, product failure or damage that could affect the integrity of
the vehicle.
The installaon steps in this manual are for the sole use of trained installers. Right Weigh, Inc.
accepts no responsibility or liability for issues involving, but not limited to, incorrect installaon
that occur from misinterpretaon of the steps outlined in this document.
It is the end user’s responsibility to be aware of vehicle manufacturer policies before making
modificaons to the vehicle. Right Weigh, Inc. is not liable or responsible for issues regarding, but
not limited to, warranes with other manufacturers. This is the responsibility of the end user.
For a more detailed explanaon of the the warranty and liability of Right Weigh, Inc. please refer
to the “Warranty Statement” and “Return Policy & Repairs” secon of this document and
www.rwls.com/warranty.

ONBOARD LOAD SCALE
EXTERIOR DIGITAL |201-EBT-02(B)
Specificaons & Overview
TCA Compliance Informaon
Scale Installaon and Electrical Connecons
Operang Modes
Tractor
Dedicated Tractor-Trailer Set
Trailer / Dolly
Calibraon & Unit of Measure
Security PIN Code
Set
Change
Operate & Weigh
Mobile Device Connecon
Maintenance
Troubleshoong
Appendix A - Addional Parts
Appendix B - Wiring Insulaon
Appendix C - Esmated Steer
Revision Log
Warranty Statement
Return Policy & Repairs
4
7
9
13
14
15
16
17
19
19
20
21
22
23
24
26
27
28
29
30
31
CONTENTS
3
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Right Weigh, Inc. is under license. Other trademarks and trade
names are those of their respecve owners.

The Right Weigh 201-EBT-02(B) digital load scale has two internal air pressure
sensors. This scale will monitor one air suspension axle group with two Height
Control Valves (HCV) or two axle groups with one HCV each. An axle group
can be either a single, tandem, or triple set of axles on the truck or trailer.
SPECIFICATIONS & OVERVIEW
4
This load scale can be used to monitor one axle group with an air ride li axle if
the li axle air bags are controlled by the same height control valve as the other
axles in the group. The scale will need to be setup using mulple calibraon
mode. Refer to the Mulple Calibraon Mode (page 16) secon for more
informaon.
Drop Axle:
Independently regulated li axles cannot be considered part of an axle
group and must be in the UP posion when calibrang and weighing.
!
The 201-EBT-02B scale is not approved for use on vehicles with a
drop/li axle of any kind. For more informaon on TCA requirements,
refer to pages 7-8.
TCA OBM Requirement:
One Axle Group with 2 HCVs
2 HCVs
1 HCV 1 HCV
Two Axle Groups with 1 HCV Each

SPECIFICATIONS & OVERVIEW
5
The weight of the steer axle can be esmated if this scale is used to monitor a
tractor's drive axle group. Refer to Appendix C for more informaon.
Esmated Steer Axle:
The 201-EBT-02(B) scale has the capability of connecng to a remote sensor
that has been installed on a separate vehicle, most commonly used in drop &
hook situaons. For more informaon about this feature, please refer to the
separate 403-SK Installaon Instrucon Manual (PP-003-0084).
Remote Sensor Feature:
The Remote Sensor feature is not approved by TCA and must not be
enabled. For more informaon on TCA requirements, refer to pages 7-8.
TCA OBM Requirement:
Esmated Steer is for use on tractors with a fih wheel hitch only, it
will NOT work on straight trucks or car haulers. Re-calibraon is
required aer changing the posion of a sliding fih wheel.
To monitor the steer axle weight on a straight truck, you will need the
201-EBT-12B.
!
X

Operang Temperature: -22° F to +185° F (-30° C to +85° C)
Storage Temperature: -40° F to +185° F (-40° C to +85° C)
Power Requirement: 9 VDC to 32 VDC (Switched)
Units: Pounds (LBS) or Kilograms (KG)
Housing: High impact polycarbonate blend
Display: 0.8” LCD sunlight readable
POWER
ON/OFF
MENU/
ENTER
(1)
CAL HIGH (2)
CAL LOW (3)
DOWN ARROW
(4)
UP ARROW
62 mm
127 mm
406 mm
87 mm
184 mm
208 mm
114 mm
114 mm
Technical Specificaons:
SPECIFICATIONS & OVERVIEW
6

7
TCA COMPLIANCE
INFORMATION
The 201-EBT-02B is a Transport Cerficaon Australia (TCA) Type-Approved Mass
Sensor Unit (MSU) part of a Type-Approved On-Board Mass (OBM) system. This
organizaon approves automove technology that follows a set of guidelines to
ensure consumer safety and device reliability. For more informaon visit their
website at:
hps://tca.gov.au/publicaon/obm-system-specificaon/
The 201-EBT-02B is approved for use in both Category A and Category B
Type-Approved OBM systems. In order to comply with the TCA requirements, the
below guidelines MUST be followed:
OPERATING MODE
User must set the scale operang mode to either Sensor Average (AVG), Esmated
Steer + Sensor Average (S-AVG), Independent (IDP), or Independent + Esmated Steer
(S-IDP). Mulple Calibraon (4CAL) Mode does not comply with TCA requirements.
DROP AXLES
PIN CODE
CALIBRATION
INSTALLATION
The vehicle must not have a drop/li axle. TCA does not approve the use of this
system on vehicles with drop/li axles of any kind.
It is required that the authorized user/installer create a PIN code for the gauge to
ensure that the vehicle operator cannot tamper with the calibraon sengs. See
page 19 for informaon on how to set the PIN code.
The gauge must be calibrated before use and then re-calibrated at least once every 6
months. Each calibraon event must be recorded in the Calibraon Log (PP-003-0065
page 2).
Install the gauge using the guidelines set forth in this manual. Installaon Log
(PP-003-0065 page 1) must be completed at the me of installaon. The MSU
MUST be connected to a switched power source that is on when the ignion is on.
See pages 9-12 of this manual for detailed installaon instrucons.
REMOTE SENSOR FEATURE
The Remote Sensor feature must be disabled. This feature is not is not approved by
TCA.
Guidelines for TCA Compliance: Category A & B

8
TCA COMPLIANCE
INFORMATION
MAINTENANCE
TELEMATICS DEVICE
The gauge must go through the maintenance check described on page 23 at least
every 6 months. Each maintenance event must be recorded in the Maintenance Log
(PP-003-0065 page 4).
The prime mover must have an approved telemacs device installed and the device
must be connected to the Right Weigh system.
MOBILE APP
It is required that the operator use a smart phone or tablet with a mobile app to
wirelessly connect to all MSU’s (gauges) on the vehicle. If the operator is driving a
vehicle with more than one MSU, the MSU’s must be added within the app in front to
back order. Bluetooth connecon must be maintained with all MSU’s on the vehicle in
order for the weight informaon to be considered valid. Please see page 22 for more
informaon about the app.
SECURITY SEALS
Security seal kit p/n 909-SSK must be used to secure the MSU to the vehicle at the
me of installaon. See instrucons included with security seal kit for specific
installaon requirements.
Guidelines for TCA Compliance: Category B Only

9
SCALE INSTALLATION
& ELECTRICAL CONNECTIONS
DUMP AIR FROM SUSPENSION SYSTEM
2
Security seal kit p/n 909-SSK must be used to secure the MSU to the vehicle.
For more informaon on TCA requirements, refer to pages 7-8.
TCA OBM Requirement (Category B only):
Be sure to choose a locaon that is easily accessible and safe from potenal damage
(forkli posts, re caps, etc.)
DO NOT mount the scale directly to the chassis or any other main
beam unless it is approved by the vehicle manufacturer. Doing so
may void the warranty with the vehicle manufacturer.
CHOOSE LOCATION
1
Mount the bracket in the chosen locaon
and install the gauge box to the bracket
using supplied hardware.
The 201-EBT-02 scale is designed to be mounted on the outside of a truck or trailer,
however it must sll be mounted in a protecve enclosure. A protecve box and
mounng bracket are included with the 201-EBT-02B.
Make sure to use BOTH supplied mounng bolts to secure the
bracket to the vehicle. Using only one bolt can result in a cracked
bracket and the scale falling off the vehicle.
!
!

10
ROUTE AIR LINE TO GAUGE
6
Route the new 1/4” air line from the tee fing assembly to the gauge.
Secure air line with zip es. Insert the air line into the push-to-connect
fing on the back of the gauge. DO NOT ROTATE THE AIR FITTING!
SCALE INSTALLATION
& ELECTRICAL CONNECTIONS
CUT EXISTING AIR LINE
3
Choose a tee fing that matches the size of
the exisng air line, then install a female NPT
tube fing onto the tee as shown. Use Teflon
tape or equivalent to seal threads, ghten
securely. For more informaon on the parts
needed for air line installaon, see Appendix A.
4
ASSEMBLE TEE FITTING
Cut the air line going to one of the air bags in
the suspension group to be monitored.
Insert the cut ends of the exisng air line and the
new 1/4” air line into the tee fing assembly as
shown. Tighten all three tube nuts securely.
5
INSTALL TEE FITTING
The air fings on the back of the gauge are directly connected to the
internal circuit board. Applying ground(-) or posive(+9-32) voltage to
air fings will cause immediate air sensor failure!
!
REPEAT STEPS 3-6 WITH
SECOND HCV
7
A second air line should go from an air bag
connected to the second HCV to fing B on the
back of the gauge.
For a dedicated tractor-trailer set, fing A should
connect to the drive axle group and fing B
should connect to the trailer axle group.
HCV 1
HCV 2
AIR BAG
AIR BAG

11
SCALE INSTALLATION
& ELECTRICAL CONNECTIONS
DO NOT connect directly to a baery or any constant power source, gauge
should be connected to a switched source so that it can be disconnected
from power when not in use. Most users connect the power to vehicle
marker lights or the AUX/ABS wire.
Electrical connecons MUST be insulated, see Appendix B for instrucons.
The two unterminated wires coming out of the harness are used to power the
scale. Connect the RED wire to a switched posive (+) power source and the
BLACK wire to chassis ground (-). The required supply voltage must be between 9
and 32 volts DC. For more informaon on wiring connecon and insulaon, see
Appendix B.
!
INSTALL POWER CABLE
8
Insert the male connector on the harness onto the female connector on the back
of the scale. Make sure to orient the connector properly so that the small cutout
on both connectors line up. Once the connector has been pressed in, thread the
collar into the scale unl it is hand ght.
BLACK = GROUND
RED = POWER
CONNECTION HARNESS
The MSU’s MUST be connected to a switched power source that is on when
the ignion is on. For trailers, use the AUX/ABS wire. For tractors, an ignion
accessory wire must be located. Verify that power is switched with the
ignion aer installaon. For more informaon on TCA requirements, refer
to pages 7-8.
TCA OBM Requirement:
If using the Remote Sensor Feature, stop these
instrucons at this me and follow the
instrucons on the 403-SK installaon manual
to finish product installaon.

12
SCALE INSTALLATION
& ELECTRICAL CONNECTIONS
Installaon Log (PP-003-0065 page 1) must be completed at the me of
installaon. For more informaon on TCA requirements, refer to pages 7-8.
TCA OBM Requirement:
LOG INSTALLATION EVENT
9

To comply with TCA OBM system requirements, ONLY Sensor Average (AVG), Sensor
Average + Esmated Steer (S-AVG), Independent (IDP), and Independent + Esmated
Steer (S-IDP) modes may be used. Please see pages 7-8 for more informaon.
TCA OBM Requirement:
OPERATING MODES
13
Press the UP arrow buon to cycle
through the operang modes. To confirm
your selecon, turn the scale off by
pressing the ON/OFF buon.
With the scale OFF, press and hold both the
UP and DOWN arrow buons, and then
press the ON/OFF buon. Release all 3
buons. The scale will display the current
mode.
PRESS
HOLDING
PRESS
CHANGING OPERATING MODES
1
2
If using the Remote Sensor Feature, the feature must be enabled before seng the
operang mode. For details on enabling the Remote Sensor feature and seng the
operang mode when using this feature, see the 403-SK Instrucon Manual
(PP-003-0084).
!
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
Each vehicle configuraon requires a specific operang mode. The modes available
on this gauge are:
AVG -Tractor or Trailer, One Axle Group
S-AVG - Tractor Drive’s and Esmated Steer
4CAL - Trailer, One Axle Group with Mulple Configuraons
IDP - Two Axle Groups
S-IDP - Tractor Drive and Trailer Axle Groups and Esmated Steer
See the tables on the following pages to find your vehicle configuraon and set the
gauge to the corresponding operang mode.
The load scale can only be setup in one operang mode at a me.
If the mode is changed, the calibraon data will be reset to factory
defaults, requiring re-calibraon.

14
OPERATING MODES
TRACTOR
VEHICLE CONFIGURATION OPERATING MODE
Axle Group 1 - Air Suspension
Single, Tandem, or Tri Axle
Group (2 HCV)
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
12
1
(ESTIMATED)
AIR SUSPENSION SPRING SUSPENSION
The numbers on the images indicate the
axle groups that will be displayed on the
gauge. To cycle through the axle group on
the gauge, press the MENU buon.
Axle Group 1 - Esmated Steer
Axle Group 2 - Air Suspension
Single, Tandem, or Tri Axle Group
(1 HCV)
*Recalibraon required for steer axle
aer sliding fih wheel. For more
informaon about the esmated
steer feature, see appendix C.

OPERATING MODES
15
VEHICLE CONFIGURATION OPERATING MODE
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
DEDICATED TRACTOR-TRAILER SET
12
(ESTIMATED)
3
Axle Group 1 - Esmated Steer
Axle Group 2 - Drive Axle Group
Air Suspension Single, Tandem, or Tri Axle Group (1 HCV)
Axle Group 3 - Trailer Axle Group
Air Suspension Single, Tandem, or Tri Axle Group (1 HCV)
1
2
Axle Group 1 - Drive Axle Group
Air Suspension Single, Tandem, or Tri Axle Group (1 HCV)
Axle Group 2 - Trailer Axle Group
Air Suspension Single, Tandem, or Tri Axle Group (1 HCV)
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS

16
OPERATING MODES
Mulple Calibraon (4CAL) mode CANNOT be used. For
more informaon on TCA requirements, refer to pages 7-8.
TCA OBM Requirement:
TRAILER / DOLLY
VEHICLE CONFIGURATION OPERATING MODE
Air Suspension Single, Tandem,
or Tri Axle Group (2 HCV) with
1 Integrated Air Ride Li Axle
Air Suspension Single, Tandem,
or Tri Axle Group (2 HCV) with
2 Integrated Air Ride Li Axles
www.rwls.com
ON/OFF
HOLD 3 SECONDS
CALIBRATE
C
HIGH
1C
LOW
234
ENTER
MENU
i
EL-003-0004
1 2 3 4 C/H C/L KG LBS
EXAMPLE:
1
2
EXAMPLE:
1
2
3
4
1
1
*In 4CAL mode,
the scale can store
four sets of
calibraon data
for trailers that
have various
operang
condions.
This trailer axle group has 1
integrated li axle. Calibraon
set “1” is when the li axle is up
and set “2” is when the li axle
is down.
On some 4-axle heavy-haul
trailers, there are two fixed
axles, a li axle, and a flip axle
all on the same HCV. Many
operators use calibraon set “1”
when only two axles are down,
calibraon set “2” and “3” when
three axles are down, and
calibraon set “4” when all four
axles are down.

CALIBRATION
& UNIT OF MEASURE
17
The 201-EBT-02(B) load scale must be calibrated both empty and loaded to
work properly. The scale associates the weight you enter with the air
pressure in the suspension system at the me of calibraon. You will need to
calibrate once while the vehicle is empty, and again while the vehicle is
loaded for each axle group being monitored.
Only enter on-the-ground weight of axle or group being
monitored. DO NOT use gross weight, tare weight, etc.
CHANGING UNITS
With the gauge on, press and hold the UP ARROW
and then press the MENU buon. This will toggle
the sengs between pounds and kilograms.
+
!
1: While the vehicle is empty, obtain axle group weights from a cerfied
in-ground scale.
2: Park on a level surface. Shi the transmission to neutral and set the parking
brakes. Chock the wheels to prevent unexpected vehicle movement, then
release the parking and service brakes.
3: Make sure the Height Control Valve (HCV) has fully inflated the air bags. If
needed, briefly dump the air from the suspension and allow the HCV to refill
the system.
4: Press the ON/OFF buon to turn on the Right Weigh
load scale.
5: Press the blue MENU buon to select the proper axle
group or calibraon set.
6: Press and hold the C LOW buon unl the “C/L” symbol
appears.
7: Adjust the value using the UP and DOWN arrows so that
it matches your scale cket for the axle group.
8: To save, press and hold the C LOW buon unl the “C/L”
symbol disappears.
EMPTY CALIBRATION POINT
9: Repeat steps 5-8 for all axle groups or calibraon sets.
It is required to log calibraon events in the Calibraon Log. F or more
informaon on TCA requirements, see pages 7-8.
TCA OBM Requirement:
CALIBRATION

RE-CALIBRATION
It is required to re-calibrate every 6 months for each axle group being
measured. For more informaon on TCA requirements, refer to pages 7-8.
TCA OBM Requirement:
LOADED CALIBRATION POINT
Repeat “empty calibraon point” steps 1-3 with the vehicle
fully loaded.
4: Press the ON/OFF buon to turn on the Right Weigh
load scale.
5: Press the blue MENU buon to select the proper axle
group or calibraon set.
6: Press and hold the C HIGH buon unl the “C/H” symbol
appears.
7: Adjust the value using the UP and DOWN arrows so that
it matches your scale cket for the axle group.
8: To save, press and hold the C HIGH buon unl the
“C/H” symbol disappears.
9: Repeat steps 5-8 for all axle groups or calibraon sets.
18
CALIBRATION
& UNIT OF MEASURE

19
With the gauge off, press and
hold both the C LOW and C
HIGH buons, then press the
ON/OFF buon. Release all
three buons. The gauge will
display "CodE".
Press the MENU buon and
“00000” will display on the
screen. Enter a 5 digit PIN code
using the 1, 2, 3, and 4 buons.
Press the MENU buon again
to save the code.
**If the display shows “-----”,
then there is already a code set.
See next page to change
exisng PIN code**
PRESS
HOLDING
PRESS
1
2
The authorized person / installer must set a PIN code on the gauge to prevent
tampering. For more informaon on TCA requirements, see pages 7-8.
TCA OBM Requirement:
SET SECURITY PIN CODE

20
With the gauge off, press and
hold both the C LOW and C
HIGH buons, then press the
ON/OFF buon. Release all
three buons. The gauge will
display "CodE".
Press the MENU buon and
“-----” will display on the
screen. Enter the previous
PIN code. If the code entered
is correct, the display will
show “Good”.
Press the MENU buon and
enter the new 5-digit PIN
code using the 1, 2, 3, and 4
buons. Press the MENU
buon again to save the
code.
HOLDING
PRESS
PRESS
PRESS
1
2
3
CHANGE SECURITY PIN CODE
