RIHO SCANDIC NXT 204 User manual

SCANDIC NXT 204
Installatiehandleiding | Installation manual | Manuel d’installation |
Montageanleitung | Návod k instalaci | Instrukcja instalacji |
Telepítési kézikönyv | Руководство по установке
NXT 204
SCANDIC
*

IW01412.5 -1-
Æ3mm Æ6mm

SCANDIC NXT 204
-2-
x1
x1
x2
x1
x1
**
x1
x2
x1
x10
18
17
**
208933 (131604251)
208934 (131604252)
L R 208938 (131604261)
208939 (131604262)
x1 x1 x1
x1
x1
4 x2
x10
8
8x1
x1
208954 (131604292)
208955 (131604293)
x2
13
9
x2
14
x2
15
x2
10 x2x2
13
x2
10
x2
11
x2
12
x1
16
x2x1
16
*>1000
L
R
208817 (562020003)
209507 (562550107)
209503 (562528039)
209508 (562550108)
209504 (562528040)
L
R
208747 (160110220)
208750 (160110234)
208842 (562010000H)
208473 (130805097)
208466 (130602734)
209509 (562550109)
209505 (562528041)
209510 (562550111)
209506 (562528042)
208843 (562010002H)
208969 (562550106)
208959 (562528038)
208971 (562550127)
208960 (562528054)
209510 (562550111)
209506 (562528042)
208952 (131604290)
208953 (131604291)
209509 (562550109)
209505 (562528041)
209510 (562550111)
209506 (562528042)
209509 (562550109)
209505 (562528041)
208747 (160110220)
208750 (160110234) 208842 (562010000H) 208843 (562010002H)
208817 (562020003) 208969 (562550106)
208959 (562528038)
208952 (131604290)
208953 (131604291)
100 cm
*
208971 (562550127)
208960 (562528054)
160 cm
208972 (562550128)
208961 (562528055)

IW01412.5 -3-
6
6
01
(768mm ~ 772mm)
(868mm ~ 872mm) (968mm ~ 972mm)
2000
B
A
C
(1168mm ~ 1172mm)
(1368mm ~ 1372mm)
(1568mm ~ 1572mm)
*
*
(1768mm ~ 1772mm)
*
*
*
>1000
*
(968mm ~ 972mm)
(868mm ~ 872mm)
(768mm ~ 772mm)
(768mm ~ 772mm)
(868mm ~ 872mm) (968mm ~ 972mm)
2000
B
A
C
(1168mm ~ 1172mm)
(1368mm ~ 1372mm)
(1568mm ~ 1572mm)
*
*
(1768mm ~ 1772mm)
*
*
*
>1000
*
(968mm ~ 972mm)
(868mm ~ 872mm)
(768mm ~ 772mm)
*
11mm
30mm
A
B
1732mm
232mm 40mm
40mm

SCANDIC NXT 204
-4-
02

IW01412.5 -5-
2x
13mm
B
A
9mm
03

SCANDIC NXT 204
-6-
*
04
4
4
232mm
34mm
A
B
40mm 40mm
1732mm

IW01412.5 -7-
05
2mm
2x A
2mm
B

SCANDIC NXT 204
-8-
06
2x
25mm
A
2mm
B
2mm

IW01412.5 -9-
07
3
5 mm
max. 1000 mm
C
4
567
8
10 11
12
9
C
!
(1168mm ~ 1172mm)
(1368mm ~ 1372mm)
(1568mm ~ 1572mm)
(1768mm ~ 1772mm)
*
*
*
>1000 *
*
12
C - 2mm
