RIHO Spring IF00418.4 User manual

Spring Under Basin Cabinet
Installatiehandleiding | Installation manual | Manuel d’installation |
Montageanleitung | Návod k instalaci | Instrukcja instalacji |
Telepítési kézikönyv | Руководство по установке
IF00418.4

RIHO
�
� î / 
 A
  


Spring Glow
Spring Rise
Spring Vow 40 & 46
600/800/1000
15
150
595 595
900
1200
15
150
600
595
595
900
600/800/1000
120
490
150
705
900
1000/1200
120
490
150
705
500/600
900
600/800/1000
80
150
745
530
900
1000/1200
80
150
745
530
500/600
900
Supply and discharge dimensions (mm)
IF00418.4

Supply and discharge dimensions (mm)
Spring Blush
600/800/1000/1200
15
150
595
900
Spring Dew
900
600/800/1000
15
150
595
900
1200
15
150
595
600
3
IF00418.4
Spring Tablet 40 & 46
850
600/800/1000/1200
30
150
530
850
30
150
530
600
1200
745 745

Under Basin Cabinet
Page 3 & 4
2. Measure and mark holes
for attaching wall brackets
W
900
H
W-60
900-H-110
32
mmØ8
4x
1. Check supply & discharge dimensions
H = Height Washbasin W = Width Under Basin Cabinet
3. Drill holes and insert wall plugs
4. Mount wall brackets
5. Remove drawers from cabinet 6. Attach hanging brackets on cabinet
7. Mount cabinet on wall 8. Level under basin cabinet
Bottom drawers
2. Click & Lift
1. Slide out drawer first
4
IF00418.4

Under Basin Cabinet
9. Mark holes for safety pins
11. Drill the two holes and insert wall plugs
mmØ8
2x
10. Unmount cabinet from wall
12. Mount under basin cabinet back on wall
13. Screw in safety pins
14. Check level & attach
slide over bracket covers
15. Insert drawers back in cabinet
16. Identify drawer system
Type 2
2. Gently push drawer &
pull slider until click sound
1. Pull out sliders &
place drawers on top
5
IF00418.4
Type 4

IF00418.4
Under Basin Cabinet
18. Place washbasin/countertop & seal
19. Finish off sealing
6
20. Place countertop basin
21. Mark drain hole
1/2
1/2
600/800/1000/1200
(single drain)
1/4
1/21/2
1/2 1/4
1/2
1200
(double drains)
17. Adjust/level drawers
1
3
4
2
Vertical Adjustment
Fixation/Lock
Remove Front Panel
Horizontal Adjustment
Type 2 Type 4
Fixation/Lock
Vertical Adjustment
Horizontal Adjustment
For miter cabinets:
Remove rubber bumpers on front of side panels
before adjusting drawers.
For washbasins, skip to step 24

IF00418.4
Under Basin Cabinet
6
22. Drill drain hole(s)
35mmØ
23. Place countertop basin and seal
24. Attach pop-up & siphon
Only for washbasin with overflow












 


  








 








 


