Rinnai Sapphire/Neo User manual

Sapphire/Neo (RIB23) Zero Clearance Box Assembly
11955-H 08-18
1
Rinnai New Zealand Ltd. 0800 746 624
Rinnai Australia Pty. Ltd. 1300 555 545
Before installation:
• Unpacktheassemblyandcheckfordamage—DONOTinstallanydamageditems
• Checkallcomponentshavebeensupplied
• Readtheseinstructionstogetanoverviewofthestepsrequiredbeforestartingthe
installation
Failuretofollowtheseinstructionscouldcausetheappliancetomalfunction.Thiscouldresultin
seriousinjuryandpropertydamage.
311
4
2
10
1
9
12
8
5
6
2
7
10
Item Qty. Description
1 1 ZCboxbase
2 2 ZCboxside
3 1 ZCboxtop
4 1 ZCboxrear
5 1 ZCspigotguideplate
6 2 Guiderailueadaptor
7 1 Airductoutletgasket
8 1 Spigottopassembly
9 1 Spigotrear
10 2 Edgeprotectorwhite
11 31 Screw8x10ABzinc
12 2 Rivetpopplain73AS4.2
Important
Toensurethespigotassemblylinesupcorrectlyinsidetheenclosureandthatthe
applianceisinstalledush,thefrontedgeofthezeroclearanceboxshouldsitush
withthefrontedgeofthecladdingsurface.
Thedrywalldropsdowntothelevelindicatedbythetwoarrowseithersideofthebox.
Sapphire / Neo (RIB23)
Zero Clearance Box assembly (R2340)

Sapphire/Neo (RIB23) Zero Clearance Box Assembly
11955-H 08-18
2
Rinnai New Zealand Ltd. 0800 746 624
Rinnai Australia Pty. Ltd. 1300 555 545
General information
Ø 146
81
790
361
Ø 53
86
45 650
Assembly
1. Rivet the spigot guide to the spigot assembly
Assembleuespigot,andrivetfromtheunderside,thespigotguideplateprovidedinthezeroclearance
boxkittothespigotassembly.
When this spigot is used with the zero clearance box
these dimples are to be drilled at Ø3.2
Alldimensionsareinmm.

Sapphire/Neo (RIB23) Zero Clearance Box Assembly
11955-H 08-18
3
Rinnai New Zealand Ltd. 0800 746 624
Rinnai Australia Pty. Ltd. 1300 555 545
Assembly
2. Assemble base, sides and rear panel of zero clearance box
Liethebasepanelontheoorandusingthescrewsprovidedintheassemblypack,screwtheside
panelstothebaseandthenattachtherearpanel.
3. Attach full spigot assembly and top panel
Drilloutthetwo3.3mmholesinthespigotwherethetwodimplesarelocated.Screwthefullspigot
assemblytothebackpanelofthezeroclearancebox(thoughthebackofbox)andattachthetoppanel.

Sapphire/Neo (RIB23) Zero Clearance Box Assembly
11955-H 08-18
4
Rinnai New Zealand Ltd. 0800 746 624
Rinnai Australia Pty. Ltd. 1300 555 545
4. Slide into the enclosure and secure
Slidetheassembledzeroclearanceboxintotheenclosureandxthetopandsidestotheenclosure.
Therearetwosetsofscrewholes,thesetyouusewillbedependentonthecladdingthickness.Thezero
clearanceboxMUSTBEinstalledushwiththecladdingsurfacetoensurealignmentoftheue.
Cladding surface
Zero clearance box
front cutout
Top of Neo engine
Top of zero clearance box
5. Apply edge protector
Applywhiteedgeprotectorsprovidedintheassemblypacktothegasandelectricalaccessholes.
6. Guide rails
Guiderails(number6onfrontpage)needtobeattachedtothetopoftheNeoengineasshown.
N
Guide rails Spigot guide plate
Assembly
