RIOTEC DC9253AP User manual

1
Quick Guide
-DC9253AP (with Battery)
-DC9253AN (without Battery)
1 H92P/H92N
Connect to micro USB port of OTG device
2 H92P/H92N
3

* Before you use it, please switch to "C" for battery charge for
3~4 hours.
*Under “C mode”, you can raise/lower soft-keyboard easily.
4

H92P Scan Holder is with Li-Ion battery inside. When in
charging, please use the original power adaptor of
smartphone (recommend). Through it, it charges both OTG
device and H92P internal battery at the same time. When in
low battery (Red LED flashing), please charge it
immediately.
LED Indicator Information
Green LED OFF Full charged (Charge mode)
Green LED ON Charging (Charge mode)
Red LED Flashing Low battery (Operation mode)
Attention: Under “Operation mode” please do not charging,
otherwise the OTG device's battery will be charging back to
H92P’s battery.
5


The touch trigger is in the central area of mini scanner. (for both side).
Please check the above drawing for your reference.
Installation
Before using scanner, please make sure that the OTG device is fully charged.
1. Under USB HID interface
** When plugged into OTG device, it will be recognized and begin to scan
the barcode.
2. Under USB Serial interface
** Please install PL-2303 driver into your OTG device first. PL-2303 driver
can be downloaded from Google Play
** Connect scanner to your OTG device, then, you can know which serial
port scanner connects to.
** The data you scan will be sent to serial port and your APP can get the
data from serial port directly.
Reset Configuration to Default :
If you are unsure of the scanner configuration or have scanned the
incorrect codes, please scan A1 to A2 for USB HID or B1 for RS232 or
USB Serial. This will reset the scanner to its factory defaults.
USB HID RS232 / USB Serial.
A1 B1
A2
*Note : Please install PL-2303 driver for USB serial
Trigger
Area
Suction Cup
PU Glue
(Can be used
repeatedly)
Micro USB
cable (OTG)
Mini
scanner
Micro USB
H92P with
Li- Ion Battery/
H92N without
Battery
Micro USB
LED Indicator
H92P only
O = Operation mode C = Char
g
e mode
LED Indicator
H92P only

2
Keyboard Language (For USB HID only)
Scan the appropriate country code as below to program the
keyboard layout for your country or language. As a general
rule, the following characters are supported, but need special
care for countries other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~
USA
(Original setting)
Italian
Norway France
Germany Vietnam
Sweden Spain
Denmark
P
ortu
g
al
Switzerland Hun
g
ary
1D Symbologies – 1
ENABLE CODABAR DISABLE
ENABLE Code 39 DISABLE
ENABLE Code 32 DISABLE
ENABLE
Code 39
FULL ASCII DISABLE
ENABLE Interleaved 25 DISABLE
ENABLE Code93 DISABLE
ENABLE Matrix 25 DISABLE
ENABLE IATA 25 DISABLE
1D Symbologies – 2
ENABLE CODE 11 DISABLE
ENABLE ISBT 128 DISABLE
ENABLE GS1-128 DISABLE
ENABLE TELEPEN DISABLE
ENABLE UPC-A DISABLE
ENABLE EAN-13 DISABLE
ENABLE EAN-8 DISABLE

3
1D Symbologies – 3
ENABLE MSI DISABLE
ENABLE
GS1
Omnidirectional DISABLE
ENABLE
GS1 DataBar
Limited DISABLE
ENABLE
GS1 DataBar
Expanded DISABLE
ENABLE CHINA POST DISABLE
ENABLE PLESSY CODEL DISABLE
ENABLE INDUSTRIAL 25 DISABLE
 Information in this document is subject to change without notice.
Q_200325_01
