RITE-HITE STR-4200 Dok-Lok User manual

STR-4200 Dok-Lok®
Vehicle Restraint
Installation Manual
This Manual Covers Restraints Built After Serial Numbers:
08EE400001W and up
PRINTED IN U.S.A.
RITE-HITE PRINT SHOP
PUBLICATION NO. 1351
JULY 2014
part of the SMOOTH TRANSITION DOK SYSTEMTM
MADE IN U.S.A.

2Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SAFETY WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SPECIAL APPLICATION INSTALLATION ITEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BACK COVER
TABLE OF CONTENTS
INTRODUCTION
Read and understand this manual before attempting to install or operate any DOK-LOK vehicle restraint. For best
results, have this product serviced by your authorized Rite-Hite representative. The STR-4200 DOK-LOK vehicle
restraint by Rite-Hite is intended to provide a safer workplace for workers in shipping and receiving dock areas. The
STR-4200 DOK-LOK vehicle restraint is a hydraulic restraint device that, when properly installed and operated, retains
a secure connection between the truck and dock. Signal lights and signs provide instructions to the truck driver and
DOK-LOK vehicle restraint operator that a safe condition exists. The DOK-LOK vehicle restraint is operated by
pressing push buttons on an inside control panel.
NOTICE TO USER
Your local Rite-Hite representative provides a Planned Maintenance Program (P.M.P.) which can be fitted to your
specific operation. Call your local representative or the Rite-Hite at 414-355-2600.
The Rite-Hite products in this manual are covered by one or more of the following U.S. patents: 5,546,623;
5,553,987; 5,582,498; 5,664,930; 5,702,223; 5,762,459 (RE: 37,570); 5,882,167; 6,065,172; 6,070,283; 6,085,375;
6,089,544; 6,092,970; 6,106,212; 6,116,839; 6,190,109; 6,276,016; 6,311,352; 6,318,947; 6,322,310; 6,360,394;
6,368,043; 6,431,819; 6,488,464; 6,499,169; 6,505,713; 6,520,472; 6,524,053; 6,634,049; 6,726,432; 6,773,221;
6,832,403; 6,880,301; 7,032,267; 7,062,814; 7,134,159; 7,213,285; 7,216,391; 7,363,670; 7,380,305; 7,503,089;
7,533,431; 7,546,655; 7,584,517; 7,681,271; 7,823,239; 7,841,823; 7,877,831; 7,914,042; 8,006,811; 8,065,770;
8,141,189; 8,191,194; 8,286,757; 8,287,223; 8,303,235; 8,307,956; 8,443,474; 8,464,384; 8,464,846; 8,465,245 and
pending U.S and foreign patent applications. RITE-HITE®, THINMANTM, SAFE-T-LIP®, HYDRACHEK®, WHEEL-LOKTM,
DOK-LOK®, DUAL-DOK®, SAFE-T-STRUTTM, DOK-COMMANDER®, JUMBOTM, HYDRA-RITETM, SAFE-T-GATE®, RITE-
VUTM LIGHT COMMUNICATION SYSTEM and SMOOTH TRANSITION DOK SYSTEMTM, are trademarks of Rite-Hite®.

Pub. No. 1351 — July 2014 3
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SAFETY WARNINGS
LOCKOUT/TAGOUT PROCEDURES
The Occupational Safety and Health Administration requires that, in addition to posting safety warnings and
barricading the work area, the power supply has been locked in the OFF position or disconnected. It is mandatory
that an approved lockout device is utilized. An example of a lockout device is illustrated. The proper lockout
procedure requires that the person responsible for the repairs is the only person who has the ability to remove the
lockout device.
In addition to the lockout device, it is also a requirement to tag the power control in a manner that will clearly note
that repairs are under way and state who is responsible for the lockout condition. Tagout devices have to be
constructed and printed so that exposure to weather conditions or wet and damp locations will not cause the tag to
deteriorate or become unreadable.
Rite-Hite Corporation does not recommend any particular lockout device, but recommends the utilization of an
OSHA approved device (refer to OSHA regulation 1910.147). Rite-Hite Corporation also recommends the review and
implementation of an entire safety program for the Control of Hazardous Energy (Lockout/Tagout). These regulations
are available through OSHA publication 3120.
This is the highest level statement. Failure to
follow the listed instructions will most likely
result in severe injury or death.
IMPORTANT is used to draw attention
to a procedure that needs to be followed to
prevent machine or property damage.
When working with electrical or electronic
controls, make sure that the power source has
been locked out and tagged according to OSHA
regulations and approved local electrical codes.
This is a statement of serious hazard. Failure to
follow the listed instructions could place the
individual at risk of serious injury or death.
The statements used with this level of
warning deal with a safe operating
procedure. If the procedure is ignored, the
possibility of personal injury may exist.
LOCKOUT/TAGOUT

4Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SAFETY DEVICES
• Post warnings and barricades at dock level
and at drive level to indicate that work is
being done around and under the leveler
platform.
INSTALL SAFE-T-STRUT SUPPORT
Power Moving Components
Serious Injury Could Occur
HANDS
OFF
NO
STEP
Never be under the dock leveler platform or lip
without:
• Installing the Safe-T-Strut or other
manufacturer approved supporting device.
• Turning off power to the control box.
• Lockout/Tagout power to the leveler, as
shown under Safety Warnings on page 3.

A DOK-LOK vehicle restraint may be installed on docks
with or without levelers. Consult Rite-Hite for proper
application.
Follow the six (6) step installation procedure below:
1. Inspect DOK-LOK materials.
2. Anchor or Weld track.
3. Position DOK-LOK assembly into track.
4. Hydraulic installation.
5. Electrical component and sign installation.
6. Test operation.
INSPECT DOK-LOK MATERIALS
Open and inspect all materials. Immediately report any
damage or material shortage. Study component
assemblies and determine their proper locations.
Install DOK-LOK vehicle restraint onto dock face at 27
inches off of the approach, unless otherwise noted in the
“Rite-Hite Installation/Application Guidelines”, at the
specified location by welding to an embedded steel plate
or by using the concrete anchors provided in conjunction
with welding to pit steel and a leveler frame. The track
will need to be trimmed if the mounting height is less than
26 inches. A maximum of 1 inch is allowed between the
bottom of the track and the approach.
For site specific installation information refer to Rite-Hite
Installation/Application Guidelines provided with DOK-
LOK vehicle restraint. If the recommended mounting
height cannot be achieved call your Rite-Hite
Representative or Rite-Hite at [phone].
NOTES:
a. Some levelers may be slightly recessed or protruding
within pit. A shim must be inserted between the roller
track plate and the leveler front subframe and then
must be welded in place. See page 13, figure 12.
b. If the dock conditions DO NOT allow lights and signs
to be mounted in full view of the forklift and/or truck
drivers, consult the factory.
c. If the DOK-LOK is installed with a hydraulic leveler,
verify that the leveler’s recycle function has not been
adversely affected.
d. Track MUST be centered. Offset track installations
ARE NOT allowed. If there is existing anchor hole
interference call your Rite-Hite Representative or
Rite-Hite Customer Service at [phone].
e. Approach must be concrete or there must be a
concrete pad where the base plate is installed. See
page 12.
STR-4200 DOK-LOK INSTALLATION
When lifting carriage use a proper lifting device
(ex. crane, jack). Lifting by hand may cause back
injury.
Whether there is a leveler or not, 4" bumper
protection is required. DO NOT install a DOK-
LOK vehicle restraint on docks without 4"
bumper protection.
Pub. No. 1351 — July 2014 5
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
Never be under the dock leveler platform or lip
without:
• Installing the Safe-T-Strut or other
manufacturer approved supporting device.
• Turning off power to the control box.
• Lockout/Tagout power to the leveler, as
shown under Safety Warnings on page 3.

6Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.
ANCHOR TRACK
1. Put DOK-LOK vehicle restraint track in place
centered in dock position. Refer to Rite-Hite
application guidelines for mounting height.
2. Drill holes of 5/8" diameter and minimum of 4-1/2"
deep. Clean out holes.
3. Insert anchor and drive flush with roller track plate,
making certain that the threaded wedge is put in first.
Do not disassemble anchor prior to installation.
4. Torque all anchors to 60 ft-lbs.
5. Remove track cover plate and weld top of track to
leveler front frame angle and/or pit steel.
WELD TRACK
If the installation being worked on is a “reinstallation”
electrical connections must be disconnected prior to
welding. Make sure to LOCKOUT/TAGOUT the power at
the fused disconnect, then remove sensing switch
connections from control box. Once all welding
procedures have been completed, reconnect all wires.
1. Put DOK-LOK vehicle restraint track in place.
2. Plug weld all holes that are in contact with
embedded mounting plate. All holes must be either
plug welded or anchored.
3. Remove track cover plate and weld top of track to
leveler front frame angle and/or pit steel.
NOTES:
a. Figure 2 – Never install DOK-LOK vehicle
restraint directly onto concrete block or brick
dock face.
b. Figure 2 – When welding DOK-LOK vehicle
restraint, disconnect power and ground leads to
leveler.
c. Figure 2 – Due to actual conditions, total
mounting height may be different. Refer to Rite-
Hite Application Guidelines for actual mounting
height.
d. If shims are required, shims must be the full length
of the roller track mounting plate and base plate.
See page 14.
e. Minimum electrode must be 1/8", 7018 or better.
DO NOT weld in enclosed areas without proper
ventilation.
BEFORE WELDING:
It is recommended that all power, ground and
limit switch wires are disconnected from the
sensor wires at the junction box. When welding
has been completed, reverse the above process.
Concrete anchors are provided with each
STR-4200 DOK-LOK vehicle restraint. You must
install an anchor in each roller track plate hole
except those plug-welded to embedded steel.
FIGURE 1 - ANCHOR INSTALLATION
Attach Lifting Chains
Pit Front
Curb Angle
Concrete
Dock Face
Approach
5/8” Dia. Concrete
Anchors Are Required
Wherever A Plug Weld
Is Not Possible
1/4”
Across Top
Of Track

POSITION DOK-LOK ASSEMBLY INTO
TRACK
1. Attach lifting chains to each side of DOK-LOK
carriage. See figure 2.
2. Lift DOK-LOK and position above the DOK-LOK
track.
3. Lower DOK-LOK into track until base plate is
resting on the approach.
4. Center DOK-LOK in track.
5. If approach is inclined, shim as shown in figure 3.
6. If approach is declined, shim as shown in figure 3.
NOTES:
a. Base plate must be square to track.
b. Shims must be placed under each cylinder and/or
spring tube. Shims should project 1/8” from
outside edge of base plate and welded into place.
c. Cylinder should be loose. No bind cotter pins.
7. Anchor both sides of Base Plate to approach. See
figure 4.
8. Remove guide tabs from Base Plate and discard.
See figure 4.
Pub. No. 1351 — July 2014 7
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.
FIGURE 4 - COMPLETING MECHANICAL INSTALLATION
Attach Lifting Chains
Leveler Front
Curb Angle
Embedded Mounting
Plate or Dok-Lok
Bracket
Approach
5/8” Dia. Concrete
Anchors Are Required
Wherever A Plug
Weld Is Not Possible
Typ. (8) Places
Typ.
Both Sides
1/4”
1/4”
Across Top
Of Track
Anchor Base Plate To Approach With 5/8” Dia.
Concrete Anchors. Typical Both Sides.
FIGURE 2 - WELDING INSTALLATION
Remove After
Install
1/4”
Shim to Base Plate
Approach
3-5/16”
90°
1/4”
Shim to Base Plate
Approach
3-5/16”
90°
Inclined Approach
Declined Approach
FIGURE 3 - SHIM BASE PLATE
See Note
See Note
4

8Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
HYDRAULIC INSTALLATION
1. Drill two holes through the dock wall for hydraulic
hoses to pass through. Make sure holes are free of
debris or sharp edges prior to passing hoses
through wall. Conduit may be required in some
applications to protect hoses.
2. Route hoses from DOK-LOK, through dock wall and
connect to power unit. Make sure hoses are capped
to keep out debris. See figures 5, 6 & 7.
NOTE: For optional power unit mouting location.
See page 17.
3. Secure hoses to dock face to prevent possible
damage. Any extra hosing should be coiled and
secured to the inside dock wall below the power
unit.
4. Fill power unit reservoir using the supplied hydraulic
fluid.
NOTE: Remaining hydraulic fluid will be used during
the initial startup procedures.
INSTALLATION CONT.
Hydraulic Power Unit
Pass Hoses Through Wall
Using Conduit As Required
Wire Power Unit
Into Control Box
Outside Electrical
Junction Box
Three Sensor Wires
Hydraulic Hoses Secured
To Dock Face
Pit Center Line
Dock Floor
Approach
Control Box
FIGURE 5 - HYDRAULIC INSTALLATION

Pub. No. 1351 — July 2014 9
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.
LPort
Hose
PPort
Hose
LPort
Hose
PPort
Hose
LPort
Hose
2x Bulkhead
Fittings
PPort
Hose
FIGURE 7 - HOSE ROUTING - COMBINATION POWER UNIT
LPort
Hose
PPort
Hose
LPort
Hose
PPort
Hose
LPort
Hose
2x Bulkhead
Fittings
FIGURE 6 - HOSE ROUTING - STAND ALONE POWER UNIT
NOTE: DO NOT Overtighten Hose Fittings!
NOTE: DO NOT Overtighten Hose Fittings!
NOTE: Remote Power Hoses Are Trimable,
See Page 18 For Trimming Instructions
NOTE: Stand Alone Power Hoses Are Not Trimable

10 Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.
ELECTRICAL INSTALLATION
1. Complete electrical installation per schematics.
NOTE: Schematic’s are located inside control box.
FIGURE 8 - SIGN AND ELECTRICAL COMPONENT MOUNTING
Edge of Door or
Outside Surface of
Shelter (If Equipped)
Inside Sign
Control Box
15” Ref.
48” Approx.
18” Ref.
Pit Center Line
Dock Floor
Approach
58” ± 1”
15”
48” Ref.
Outside Sign
(Normal Image) 80”
96”
Outside Sign
(Mirror Image)
32” Approx.
Hydraulic Power Unit
Outside Light Box
1”
When working with electrical or electronic
controls, make sure that the power source has
been locked out and tagged according to OSHA
regulations and approved local electrical codes.
Install per local electrical codes. Refer all
installation and service to qualified personnel.
When in doubt, call your local Rite-Hite
representative or Rite-Hite at 888-456-3625.
Grounding Electrode System must conform to
the latest addition of the National Electrical Code
(NFPA 70), where applicable, and/or local
electrical codes. Grounding Electrode
Conductors must be connected where indicated,
and where required.

CONTROL BOX AND CONDUIT
INSTALLATION PROCEDURES.
1. Install the control box on a wall adjacent to the
overhead door at approximately 48" above the floor
level. See Figure 8.
2. Drill a hole for the power supply conduit (by others) in
the bottom of the control box. All holes drilled
through the control box must be through the
bottom of the box.
CONTROL BOX INSTALLATION
GUIDELINES - TEMPERATURE
CONTROLLED APPLICATIONS.
a. Conduit should be routed to enter through the
bottom or side of the enclosure. A drip leg may be
needed if the conduit could fill with water.
b. Seal the conduit in any location where the conduit
transitions temperature zones that may produce
condensation.
c. Spacers should be installed between the enclosure
and the wall to provide tempature insulation and air
flow.
INITIAL START UP INSTALLATION
PROCEDURES
1. Apply power to the control box and enter fill mode.
a. Press and hold Diagnostic/Fill Mode Button on the
inside of the control box until horn chirps. See figure
9.
2. After horn chirps, press the following buttons in
order to enter fill mode. See figure 10.
a. LOCK
b. HORN OVERRIDE #2
c. LOCK
Pub. No. 1351 — July 2014 11
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.
Diagnostic / Fill Mode
Button
FIGURE 9 - DIAGNOSTIC / FILL MODE BUTTON
NOTE:
You must wait one
minute to exit Service
Mode.
• When drilling holes in the box, DO NOT allow
the drill to go too deeply into the box.
Damage to the control systems may occur.
• DO NOT turn control box upside down to drill
any access holes. Cover internal electrical
components prior to drilling - this will prevent
debris from contacting the internal electrical
components.
• Remove all debris from box using a shop
vacuum. NEVER use air to blow debris from
the control box.
• The control box and all wiring should be
installed by a qualified electrician in
accordance with all national and local
electrical codes.
• If rigid conduit is installed, bonding must be
maintained between conduit connections by
using ground bushings and a jumper wire.
GREEN
RED
LOCK
UNLOCK
OVERRIDEHORN
3
2
1
Control Box
Press Buttons In The Following
Order To Enter Fill Mode
1. LOCK Button
2. HORN OVERRIDE #2 Button
3. LOCK Button
DO NOT
ENTER
TRAILER
ENTER
TRAILER
FIGURE 10 - ENTER FILL MODE

3. Controls are now in Fill Mode. Holding the LOCK or
UNLOCK Button will run the pump up or down.
4. Cycle the DOK-LOK up and down to remove air
from the system. Add remaining hydraulic fluid. Stop
cycling once the support cylinders travel up and
down the full length of slots without hesitation.
5. Press Diagnostic/Fill Mode Button to exit Fill Mode.
NOTE: Must wait one minute to exit Fill Mode.
6. To complete installation test operation. See Owners
Manual.
12 Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION CONT.

Pub. No. 1351 — July 2014 13
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SPECIAL APPLICATION INSTALLATION ITEMS
72” Min.
30”
30”
10”
NOTES:
a. Concrete pad required on all approaches of materials other than concrete.
b. Pad must be a minimum 10 inches thick. May need to be deeper due to sub-soil
climatic conditions or location codes.
C
L
36” Min.
Typ.
FIGURE 11 - CONCRETE PAD ON APPROACH
FIGURE 12 - TRIM ROLLER TRACK
Do Not Trim Front
Legs Of Track Angles
Trim Line For
Adjustment Access
Hole.
Track May Require A Cutout
For Adjustment Access Hole
On Some Kelley Levelers.
NOTE:

14 Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SPECIAL APPLICATION INSTALLATION ITEMS
Shim Length And Thickness
To Be Determined Upon
Installation
FIGURE 13 - STR42 BASE PLATE OVER A BRICK BRACKET
3/8” Shim
Overhang
Typ.
3/8” Shim
Overhang
Typ.
Drill Through
Shim To Allow
Anchor Bolt
Mounting
Typ. 3” Minimum
Wide Typ.
Brick Bracket
Brick Bracket Base Plate
Shim Underside
Of STR42 Base Plate
In Both Places
On Each Side.
Weld Shim
To Base Plate
Shim Thickness
As Required
3/8”

Pub. No. 1351 — July 2014 15
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SPECIAL APPLICATION INSTALLATION ITEMS
Pit Steel
Front Frame Angle
Shim As Required
Behind Track Angles.
1/2” THK Min. Bar
Stock For Distances
Greater Than 1” Use
Channel
Extend Lip Guide
Remove Excess
Material From
Shaded Area
As Shown.
Lip Guide
Pit Steel
Front Frame Angle
Shim (See Back View Figure 13)
Thickness As Required Full
Length Of Track Plate (3-4 Shims
3” wide x “A” x “B”)
1/2” Maximum, If Greater Longer
Anchors Are Required, If 1” or
Greater DOK-LOK Bracket
Required.
“A” Dim
Length From Top Of Pit Steel To
Bottom Of Track Plate
“B” Dim
Thickness Of Shim
“C” Dim
If Dimension “C” Is Greater Than
3” inches Consult Factory.
Shim
“A”
“B”
“C”
Back View For
Anchor Installation
Back View For
Embedded Plate
Installation
Typ. Between Holes
And Along Sides
1/4” 1-6
2-1/8”
3/4” Typ.
Weld to
Embedded
Plate Prior To
Plug Welding
1/4” 1-6
Typ. After
Welding
Shims To
Imbedded
Plate
3”
1/4” Typ.
8 - 3/16”
FIGURE 14 - RECESSED LEVELER
FIGURE 15 - PROTRUDING LEVELER FIGURE 16 - BACK VIEW
7/8” Typ.
1-1/2”

16 Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
SPECIAL APPLICATION INSTALLATION ITEMS CONT.
INSTALLATION WITH PERMANENT WHEEL
RISERS
1. Fabricate Support Spacer (supplied by others). See
chart below and figure 17.
2. Weld both sides of Base Plate Support Spacer to
Base Plate and anchor to approach. See figure 18.
NOTES:
a. Use structural channel available in a size to match
the height of Wheel Riser ± 1/4”.
b. End plates should be sized to cap ends and the
height will vary with height of the channels.
c. If site conditions warrant a spacer different than
shown, consult the factory.
Permanent
Wheel Riser
Base Plate Support Spacer Should
Match Height Of Wheel Riser.
See Fabrication Detail Above.
1
64”
4
3
4
2
1
2
2
1/4”
1”
7 -21/32”
10”
2”
4X Ø 11/16”
1/4” G
Typ.
Typ.
1/4”
4 - 1/4”
1/4”
Wheel Riser Height
Section C-C
FIGURE 17 - SPACER FABRICATION
FIGURE 18 - SPACER INSTALLATION
Item Qty. Description
1 1 Plate 1/4” x 10” x 64”
2 3 C Channel _ x 64”
3 2 Plate 1/4” x _ x 10”
4 2 Plate 1/4” x 2” x 10” 2 Holes Both Sides
1/4”

Pub. No. 1351 — July 2014 17
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
INSTALLATION WITH TRENCH DRAIN
1. If trench drain is below the base plate, embed PVC
pipe in concrete for drainage. Concrete should
extend a minimum of 6 inches to either side of of
mounting plate.
NOTE: If concrete can not be used, consult factory.
SPECIAL APPLICATION INSTALLATION ITEMS CONT.
FIGURE 19 - TRENCH DRAIN
Embedded PVC Pipe
Overhead View Side View

18 Pub. No. 1351 — July 2014
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
OPTIONAL POWER UNIT MOUNTING LOCATION
Optional Power Unit Mounting Location.
Ensure Hoses Are Protected By Channel Or Other
Means. Protection Not To Project More Than 3 Inches
Off Dock Face. Protection Must Extend Down To 8
Inches Off Of The Approach. Must Notch Out A section
For Sensor Wires To Pass Through To Junction Box.
Consult Factory For Specific Applications.
Wire Power Unit
Into Control Box
Outside Electrical
Junction Box
Pit Center Line
Dock Floor
Approach
Control Box
FIGURE 20 - OPTIONAL HYDRAULIC INSTALLATION
Optional Routing: Hydraulic
Hoses Secured To Dock Face
Optional Routing: Three
Sensor Wires
Optional: Channel Or Other
Hose/Wire Protecting Device
Optional: Channel or Other
Device Notched For Three
Sensor Wires
Optional: Power Unit
Mounting Location
48” Approx.

Pub. No. 1351 — July 2014 19
RITE-HITE®STR-4200 DOK-LOK®Installation Manual
HOSE TRIMMING INSTRUCTIONS
NOTE:
Trimmable hoses provided for combination power unit
with RHV Leveler applications ONLY. Disregard these
instructions for ALL other applications.
1. Cut hose to required length using a fine tooth
hacksaw. Clean hose bore after cutting. See figure
21.
2. Liberally lubricate hose cover with heavy weight oil.
Place socket in vise and turn hose into socket
counterclockwise unit it bottoms out. When
assembling long lengths of hose, it may be necessary
to put hose in vise just tight enough to prevent from
turning, and screw socket onto the hose
counterclockwise until it bottoms out. See figure 22.
3. Liberally lubricate nipple threads and inside of hose
using heavy weight oil.
4. Screw nipple clockwise into socket and hose. Leave
1/32 to 1/16 inch clearance between nipple hex and
socket. See figure 23.
5. Blow out hose assembly with clean compressed air
before routing hose.
6. Route hoses between vehicle restraint and power
unit.
FIGURE 21 - CUT HOSE TO LENGTH
Clean hose bore
after cutting
FIGURE 22 - INSTALL SOCKET
FIGURE 23 - INSTALL NIPPLE

Global Sales & Service Office:
RITE-HITE
8900 N. Arbon Drive
P.O. Box 245020
Milwaukee, Wisconsin 53224
Phone: [phone]
1-800-456-0600
www.ritehite.com
Representatives in all Major Cities
RITE-HITE STANDARD WARRANTY
Rite-Hite warrants that its products will be free from defects in design, materials, and workmanship for a period
of 365 days from the date of shipment. All claims for breach of this warranty must be made within 30 days after
the defect is or can, with reasonable care, be detected and in no event no more than 30 days after the warranty
has expired. In order to be entitled to the benefits of this warranty, the products must have been properly
installed, maintained, and operated within their rated capacities and/or specified design parameters, and not
otherwise abused. Periodic lubrication and adjustment is the sole responsibility of the owner. This warranty is
Rite-Hite’s exclusive warranty. RITE-HITE EXPRESSLY DISCLAIMS ALL IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. Non-standard warranties,
if any, must be specified by Rite-Hite in writing.
In the event of any defects covered by this warranty, Rite-Hite will remedy such defects by repairing or replacing
any defective equipment or parts, bearing all the costs for parts, labor, and transportation. This shall be the
exclusive remedy for all claims whether based on contract, negligence, or strict liability.
LIMITATION OF LIABILITY
RITE-HITE SHALL NOT IN ANY EVENT BE LIABLE FOR ANY LOSS OF USE OF ANY EQUIPMENT OR
INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, WHETHER FOR BREACH OF WARRANTY,
NEGLIGENCE, OR STRICT LIABILITY.
