Ritron SLX Series User manual

Meticulous attention to value-added design and engineering has produced the next
generation of affordably priced portable radios...the SLX Series. This lightweight
and ultra small portable radio is the perfect solution for virtually any 2-way radio
user...from basic job site applications, to in-plant repeater systems, to
sophisticated users that require selective signaling...the SLX Series
radio is budget-friendly and reliable, yet feature-rich.
For more than 25 years, Ritron has been designing, manufacturing
and supplying professional wireless communication products
and systems worldwide.
Ritron products are built military tough for harsh and
demanding conditions.
The SLX series radio is one of the smallest, lightest,
most flexible professional grade portable radios on
the market today.Get your hand around one today!
Call 800-USA-1-USA (872-1-872) for moredetails.
Introducing the
SLX SERIES
•5/1 Watt VHF, 136-174MHz1
•4/1 Watt UHF, 406-470MHz1
•60 Channel Capability
•Military Durability
•IP-54 Water & Dust Intrusion2
•MIL-STD 810F Shock & Vibration2
•Ultra small —only 3.93”h x 1.33”d x 2.2”w
•Lightweight —only 9.6 oz. with battery
• Wide or Narrow Band Selectable by Channel
•15 Hour Battery Life with 1800mAh Li-ion Battery3
• 8 Character Alphanumeric LCD Backlit Display
•6Programmable Function Buttons
•Emergency Call Button
•Audio AccessoryConnector
•Scan/Priority Scan
•Voice Scrambler
•VOX Capability
•CTCSS/DCS Signaling
•2-Tone & 5-Tone Encode/Decode by Channel4
•DTMF Encode by Channel4
•Caller/Group ID5
•Low Battery Alert
•Status Icons
•One Year Warranty
Each SLX radio includes: flex antenna, 1800mAh Li-ion battery pack,
spring action belt clip, dual slot 2.5 hr.charger.

General: VHF: SLX-100 UHF: SLX-400
FCC ID: AIERIT21-150 AIERIT21-450
FCC Rule Parts: 90, 95 90, 95
IC Certification 1084A-RIT21150 1084A-RIT21450
Dimensions: 3.93” H X 1.33” D X 2.2” W
Weight w/ Battery: 9.6 oz. 9.6 oz.
LCD Display: 8 Character Alphanumeric
Emission Designators: 8K50F3E (Narrow) 11K0F3E (Narrow)
16K0F3E (Wide) 16K0F3E (Wide)
Frequency Range1:136-174 MHz 405-470 MHz
Max. Freq Separation: 38 MHz 65 MHz
RF Channels: 60 60
Channel Steps: 5/6.25/12.5/20/25 kHz 6.25/12.5/25 kHz
Temperature Range: - 30°C to + 60°C - 30°C to + 60°C
Frequency Stability: +2.5 ppm +2.5 ppm
Certifications2: IP-54 Water & Dust Intrusion
MIL-STD 810F Shock & Vibration
Battery Life3(90-5-5): 15 hours 15 hours
Programmable Function Buttons: 6 6
Selective Signaling4:CTCSS/DCS/
2-Tone & 5-Tone Encode/Decode/
DTMF Encode
MDC-1200 Optional
Transmitter:
RF Power Output: 1W/5 W 1W/4 W
Modulation: +2.5 kHz/+ 5.0 kHz +2.5 kHz/+ 5.0 kHz
Spurious & Harmonics: -65 dBc -65 dBc
Audio Response: Meets EIA Requirements
FM Hum and Noise: -40 dB @ 12.5 kHz -40 dB @ 12.5 kHz
-45dB @ 25 kHz -45dB @ 25 kHz
Audio Distortion: Less than 5% Less than 5%
Time Out Timer: Adjustable Adjustable
Receiver:
Receiving System: Dual Conversion, superheterodyne
I.F.System: 21.4 MHz/455 kHz 45.3 MHz/455 kHz
Sensitivity (12 dB SINAD): .20 µV Typical .20 µV Typical
.25 µV max .25 µV max
Selectivity (EIA): - 65 dB @ 12.5 kHz - 65 dB @ 12.5 kHz
-70 dB @ 25 kHz - 70 dB @ 25 kHz
Spurious Rejection (EIA): - 70 dB - 70dB
Image Rejection (EIA): - 70 dB - 70dB
Intermodulation (EIA): - 65 dB - 65dB
FM Hum and Noise: -40 dB @ 12.5 kHz -40dB @ 12.5kHz
-45 dB @ 25 kHz - 45dB @ 25kHz
Audio Output: 0.8 Watt into 16 Ohms, < 5% distortion
1-The antenna supplied with standard SLX model radio is pre-cut for operation
within the following frequency ranges VHF: 150-165MHz, UHF: 450-470MHz.
Order optional un-cut antenna for operation outside of the standard frequency band.
2-To meet IP-54 and MIL-STD 810F the audio accessory cover must be firmly attached.
3-BatteryLife: 90-5-5 duty cycle at high power,15 hours with Battery Saver ON
11 hours with BatterySaver OFF.
4-Refer to the manual for details relating to this feature capability.
5-Caller ID capacity is 16.
6-Time required to charge one (1) Battery Pack.
Batteries are charged in sequence; front to rear.
BP-Li-18
1800 mAh Li-Ion
Battery Pack
OutPost CallboxTeleswitch Wireless
Switch Control RPM 60 Series Mobile Radio Liberty Repeater Patriot Base Station Wireless Intercom
SBC-SLX
Spring Action
Belt Clip
Your Ritron Dealer:
BC-SLX
Dual Slot
Desktop 2.56 Hr.
Rapid Charger
RSM-5X
Speaker Microphone with
Rotating Spring Action Clip
RHD-12X
Behind-the-head
Headset with
Boom Microphone,
Pendant PTT
and Clip
RHD-11X
Security Earset with
Pendant Microphone,
PTT and Clip
RHD-10X
Single Earbud with
Pendant Microphone,
PTT and Clip
For superior durability all SLX audio accessories feature
alow-profile molded strain relief connector
SLX is PC Programmable by dealer using Ritron SLX software.
Menu selectable features as allowed by PC programming profile.
Note: Specifications are subject to change without notice.
-
-
-
-
