Rittal WS 540 User manual

Wire Station WS 540
Assembly and operating instructions
4051.100

Foreword
EN
2 Technical changes reserved Rittal Wire Station WS 540
Foreword
Dear Customer,
We thank you for choosing our Wire Station WS 540.
We wish you every success.
Yours
Rittal GmbH & Co. KG
Rittal GmbH & Co. KG
Auf dem Stützelberg
35745 Herborn
Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
www.rittal.com
We are always happy to answer any technical questions regarding our entire
range of products.

Rittal Wire Station WS 540 Technical changes reserved 3
Contents
EN
Contents
1 Scope of supply ............................................................... 4
2 Notes on documentation .................................................. 6
2.1 CE label .............................................................................................. 6
2.2 Storing the documents ....................................................................... 6
2.3 Symbols used in these assembly and operating instructions ............... 6
2.4 Intended use....................................................................................... 6
3 Safety instructions ............................................................ 7
3.1 General safety instructions .................................................................. 7
3.2 Special safety instructions................................................................... 7
4 Product description .......................................................... 9
4.1 DESKLINE® DL6 system ..................................................................... 9
4.2 Use of the DESKLINE® DL6 system .................................................... 9
4.3 PIEZO™ function description .............................................................. 9
5 Assembly and commissioning ........................................ 10
5.1 Assembly.......................................................................................... 10
5.2 Commissioning ................................................................................. 19
5.2.1 Lifting axes synchronisation ............................................................................ 19
6 Operation ....................................................................... 22
7 Maintenance .................................................................. 23
7.1 Servicing, repair ................................................................................ 23
7.2 Maintenance, care and safety instructions......................................... 23
7.2.1 Maintenance instructions ................................................................................ 23
7.2.2 Operation of products with double or improved insulation .............................. 24
7.2.3 Cleaning ......................................................................................................... 24
7.2.4 Disposal ......................................................................................................... 24
7.2.5 Notes on environmental directives and legislation ........................................... 24
8 Technical specifications .................................................. 25
9 Options .......................................................................... 26
9.1 External mounting examples for options............................................ 26
9.2 Options list........................................................................................ 28
9.3 Options assembly ............................................................................. 34

1 Scope of supply
EN
4 Technical changes reserved Rittal Wire Station WS 540
1 Scope of supply
Quantity
(items)
Designation
2M5x40
Cylinder screw, hex socket
8M6x12
8M6x16
8M6x22
6M4x12
Pan-head screw, hex socket
2M5x12
2M6x16
4M8x10
16 M8x25
2M6
Stop nut
16 M8
2M5
Washer
24 M6
8 M6 Spring lock washer
2M5x70Stud
2 Castors, locked
2 Castors, unlocked
2 Lifting columns
2 Motor cable
1 Control unit
1 Control unit mains cable
1 Control component height adjustment
1 Control component fastening bracket
Tab. 1: Scope of supply

Rittal Wire Station WS 540 Technical changes reserved 5
1 Scope of supply
EN
1 7-way socket strip with switch
2 Socket strip angle bracket
4 Table top angle bracket
1 Rear panel
1 Retainer for the cable winding
1 Table top, pre-assembled
1 Cover A, control unit
1 Cover B, socket strip
14mm
Allen key15mm
16mm
1 9/8 mm
Open-end spanner
1 13/10 mm
5 200 mm Cable tie
1 Drawer spare key
1 Foot part
Quantity
(items)
Designation
Tab. 1: Scope of supply

2 Notes on documentation
EN
6 Technical changes reserved Rittal Wire Station WS 540
2 Notes on documentation
2.1 CE label
Rittal GmbH & Co. KG confirms that the Wire Station WS 540 is compliant with
the Machinery Directive 2006/42/EC and the EMC Directive 2014/30/EU. An
appropriate declaration of conformity has been prepared. It can be found at the
end of this document, on the Rittal Homepage or accompanies the unit as a
separate document.
2.2 Storing the documents
These assembly operating instructions, together with all applicable documents,
are integral components of the product. They must be issued to everyone who
works with the machine and must always be available and on hand for the
operating and maintenance personnel.
2.3 Symbols used in these assembly and operating instructions
The following symbols are used in this documentation:
This symbol indicates an "action point" and shows that you should perform an
operation or work step.
2.4 Intended use
The Wire Station WS 540 serves as mobile workstation for the control cabinet
engineer. Your worktop is height-adjustable in the range 810 to 1350 mm.
The Wire Station WS 540 is not suitable for use by individuals with limited
physical, sensory or intellectual abilities or with a lack of knowledge and/or
experience, unless they are supervised by a person who is responsible for their
safety or have been instructed by them on how to use the unit.
Compliance with all instructions and observance of the prescribed operating
conditions constitute part of the intended use.
Danger!
Hazardous situation which will result in death or serious
injury if the instructions are not followed.
Warning!
Hazardous situation which may lead to death or serious
injury if the instructions are not followed.
Caution!
Hazardous situation which may lead to (minor) injuries if the
instructions are not followed.
Note:
Indicates situations that can lead to material damage.

Rittal Wire Station WS 540 Technical changes reserved 7
3 Safety instructions
EN
3 Safety instructions
3.1 General safety instructions
Read the safety-related information and other notes particularly carefully.
3.2 Special safety instructions
Warning!
Read the assembly and operating instructions to minimise
the risk of injury.
Warning!
Read all the safety instructions and notices.
Failure to observe the safety instructions and notices may
cause electric shock, fire and/or severe injury. The non-
observance of the listed rules can damage or destroy the
product.
Note:
Keep all the safety instructions and notices in a safe place for future
use.
Before using the Wire Station WS 540, read all the enclosed safety
instructions and assembly and operating instructions carefully.
Retain all the supplied documents, and ensure that all the relevant
documents are forwarded together with the Wire Station WS 540.
Warning!
For your own safety and to protect the Wire Station WS 540,
pay particular attention to all text passages marked with this
symbol.
Warning!
Pay attention to the closing movement of mechanical parts
of the machines/equipment.
Warning!
Pay attention to moving mechanical parts.
Warning!
There is risk of tipping with imbalanced loading of the Wire
Station WS 540 caused by mounting options. The optional
stabiliser must be mounted.
Danger!
Climbing on surfaces is forbidden.

3 Safety instructions
EN
8 Technical changes reserved Rittal Wire Station WS 540
– The prescribed maximum work surface load of 60 kg must not be exceeded.
– Do not use the Wire Station WS 540 to lift persons.
– Do not allow anyone to sit or stand on the Wire Station WS 540 while in use.
– Ensure that the Wire Station WS 540 is secured against unintentional rolling
when used.
– The Wire Station WS 540 was designed for flat, hard ground, and is therefore
unsuitable for use on sloping, uneven ground.
– The optional stabiliser must be mounted for imbalanced loading of the Wire
Station WS 540, such as caused by mounted options.
– The Wire Station WS 540 was designed for indoor use, and therefore should
not be used outdoors.
– The Wire Station WS 540 is not designed for use
– in an environment where inflammable or explosive gases or vapours are likely
to occur,
– or by children or infirm persons.
– Everyone who connects, assembles or uses the system must have access to
these assembly and operating instructions. Follow the instructions. The non-
observance of the listed instructions can cause accidents or severe injury.
– Installation is not permitted if the product has visual damage.
Prior to installation, uninstallation or troubleshooting
Stop the DL6 drives.
Switch off the power supply and withdraw the mains plug.
Remove any weight from the DL6.
Prior to commissioning
Ensure that the system has been installed in accordance with the assembly
and operating instructions.
Ensure that the voltage at the control unit is correct before the system is
connected to the power grid.
The individual elements of the system must be connected with each other
before the control unit is connected to the power grid.
During operation
Interrupt the power supply if the control unit issues strange noises or smells
during operation.
Ensure that the cables are not damaged.
Withdraw the mains plug before the Wire Station WS 540 is moved.
Danger!
Sitting on the work surface is also forbidden.

Rittal Wire Station WS 540 Technical changes reserved 9
4 Product description
EN
4 Product description
The Wire Station WS 540 was developed and optimised to permit ergonomic,
effective, and time-saving working. The Wire Station WS 540 has four lockable
castors that allow the Wire Station WS 540 to be moved anywhere required.
The height-adjustable work surface of the Wire Station WS 540 allows it to be
adjusted individually to your work situation.
The wide range of options is an additional advantage. We developed them so
you can extend the Wire Station WS 540 in accordance with your individual
needs and requirements. All possible options are listed in Section "9".
4.1 DESKLINE® DL6 system
Each DESKLINE® DL6 drive is equipped with a motor. The software in the CBD6
ensures parallel running and memory function, even for unbalanced loading of
the table. This software also includes the Soft Start/Stop function that ensures
smooth starting and braking of the table.
4.2 Use of the DESKLINE® DL6 system
Irrespective of the weight, the switch-on duration of 10% ~ 6 minutes/hour or
max. 2 minutes for continuous operation specified on the data sheet must not
be exceeded, because this can cause overheating of the motor, brake or spindle
nut. Exceeding the switch-on duration can significantly reduce the service life of
the system.
4.3 PIEZO™ function description
To provide optimised protection against jamming and blocking the work surface,
LINAK has developed DL columns with integrated PIEZO sensor. This option
minimises the risk of damage on a table caused by an obstruction jamming or
blocking in the rising or lowering direction. For example, during downward travel
on a stool or container or during upward travel against a windowsill. The system
improves personal safety to some extent. It does not, however, satisfy the
regulations regarding personal safety, i.e. personal protective equipment must
also be worn.

5 Assembly and commissioning
EN
10 Technical changes reserved Rittal Wire Station WS 540
5 Assembly and commissioning
5.1 Assembly
The following schematics show the assembling of the Wire Station WS 540.

Rittal Wire Station WS 540 Technical changes reserved 11
5 Assembly and commissioning
EN
Table top
angle bracket
Rear panel

5 Assembly and commissioning
EN
12 Technical changes reserved Rittal Wire Station WS 540
Socket strip angle
bracket

Rittal Wire Station WS 540 Technical changes reserved 13
5 Assembly and commissioning
EN

5 Assembly and commissioning
EN
14 Technical changes reserved Rittal Wire Station WS 540
Retainer for the cable
winding

Rittal Wire Station WS 540 Technical changes reserved 15
5 Assembly and commissioning
EN

5 Assembly and commissioning
EN
16 Technical changes reserved Rittal Wire Station WS 540
To mount the "cover A, control unit", it is desirable to raise the table to simplify
access. First, synchronise the lifting axes (see section 5.2.1 "Lifting axes
synchronisation"). The table can then be moved upwards with the Up key (see
section 6 "Operation").

Rittal Wire Station WS 540 Technical changes reserved 17
5 Assembly and commissioning
EN
Cover A, control unit

5 Assembly and commissioning
EN
18 Technical changes reserved Rittal Wire Station WS 540
Cover B, socket strip

Rittal Wire Station WS 540 Technical changes reserved 19
5 Assembly and commissioning
EN
5.2 Commissioning
5.2.1 Lifting axes synchronisation
Fig. 1: Hand-held unit
Legend
1 Down key
2 Up key
To synchronise both lifting axes, they must now be initialised. Unless done
previously, connect the Wire Station WS 540 to the power grid.
The DESKLINE system is initialised by pressing the Down key on the hand-held
unit (fig. 1, item 1). The key must be kept pressed until the drives have reached
the lower limit position. Once all drives have stopped at the lowest limit position,
the Down key must be released for 2-3 seconds and then kept pressed for a
further 6-8 seconds. The initialisation is then completed. The system is lowered
and raised again by 5 mm during the initialisation. Under no circumstances,
release the Down key during the initialisation.
Synchronisation procedure
Keep the Down key on the hand-held unit pressed until the drives have
reached the lower limit position.
Release the Down key for 2-3 seconds.
Now keep the Down key pressed again for a further 6-8 seconds.
After successful initialisation, move the lifting axes with the Up key to the
uppermost position.
Note:
If the key is released before the operation has completed, the
initialisation is interrupted and must be begun again. No downward
travel of the system is possible if the initialisation was interrupted.

5 Assembly and commissioning
EN
20 Technical changes reserved Rittal Wire Station WS 540
Fig. 2: Work table – upper position
When the Wire Station WS 540 is at the upper position, you can fix the Wire
Station WS 540 supply cable to the rear panel.
Fig. 3: Supply cable fixing
After fixing the supply cable, move the lifting axes again to the lowermost
position. The synchronisation of the lifting axes has now completed and the
Wire Station WS 540 is operational.
200 mm cable tie
