Robinsons Victorian RAMSBURY 14 User manual

NOMINAL
SIZE A (mm) B (mm)
14 x 8
4459
2630
14 x 16 5110
14 x 24 7590
14 x 32 10070

2
Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety
information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk
in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409.
These instructions are divided into sections highlighted by a white number/letter on a black background at the bottom corner of most pages (see opposite
page for details); part lists, B-base, P-preparation, 1-rear, 2-porch gable, 3-end gables, 4-porch sides, 5-main frame assembly, 6a-rear roof, 6b-porch
roof, 7-vent, 8-louvre, 9-glazing, 10-vent attachment, 11-door attachment, 12 anchoring down, 13 finishing touches, 14 optional shelf, 15 optional staging.
If you need to contact us for assistance please refer to the relevant section/s. If your building is longer than 12’, i.e. has an extension then please also
refer the separate extension manual before you begin construction.
Safety Warning
 Glass and aluminium can potentially cause injury. Please ensure you wear protective goggles, gloves, headgear and suitable footwear when
assembling and glazing the building.
 Please remember that glass is fragile and should be handled with extreme care. Always clear up and dispose of any breakages immediately.
 Do not assemble the greenhouse in high winds.
 For safety reasons and ease of assembly, we recommend that this greenhouse is assembled by a minimum of two people.
 Please clear all lying snow from the greenhouse roof as it can cause the roof to buckle or collapse.
Site Preparation
 When selecting a site for your greenhouse, it is vital that you choose as flat and level an area as possible.
 A concrete or slabbed base will provide the most solid foundation for your greenhouse.
 IMPORTANT: Do not fix your building down until the building is fully assembled, including glazing.
 Avoid placing your greenhouse under trees or in other vulnerable locations.
 To minimise the risk of wind damage, try to select as sheltered a site as possible, e.g. beside a hedgerow or garden fence.
Additional Considerations
 Please bear in mind that assembling your greenhouse can be time consuming. You may need to spread the construction over two or more
days. We recommend that you avoid leaving the building partially glazed. If you ever have to leave your greenhouse half assembled and not
anchored down, weigh it down with slabs or bags of sand to stop the wind moving it.
 You will find it helpful to prepare a large, clean and clear area in which to work in. A garage floor or flat lawn area is ideal.
 If you have arranged for someone to install your greenhouse for you, please check that all components are included. The components can be
identified by their distinctive profiles, lengths and quantities detailed in the parts list (see next page).
 Anchoring down your greenhouse should be the final stage of construction (including glazing).
 Once installed your greenhouse requires little maintenance, but to maintain the smooth running of
your door(s) WD40 or similar can be applied to the door pivot pins / lock etc...
Guarantee
 Your new Robinsons greenhouse is guaranteed for 10 years against faulty manufacture of the frame-
work. This does not include glazing, moving parts, accidental damage or wind damage.
KEY
SYMBOL KEY DESCRIPTION
EXTERNAL VIEW
THINK
THIS SECTION
RELATES TO
ANOTHER
(e.g. 1 to 5)
CORRECT
DO NOT FIX DOWN!
TWIST TO LOCK
TIGHTEN
PUSH AND HOLD
CUT TO LENGTH
INTERNAL VIEW
UPDATE: Robinsons plastic / aluminium cover strips -
On a Robinsons building the glazing capping is in two parts. The lower plastic
capping screws into the glazing bars pressing the glass down onto its rubber
beading. The upper plastic / aluminium covers then need to be applied to cover
the heads of the self-tapping screws. If you are struggling to press on the cover
strips then we recommend the use of a rubber mallet or perhaps a wooden block
and hammer, a short sharp tap onto the cover at one end is all that is needed to
stretch the cover around the lower capping protrusions locking it into place. You
can then either continue to use the mallet along the length of the cover or con-
tinue just using the palm of your hand. Once in the building and the edges are
protected Robinsons 4mm thick toughened safety glass is very strong and can
cope with the vibrations caused by hitting the covers though we would not rec-
ommend that you hit the glass directly. Some of the aluminium cover caps have a
hole in them at one end which is sometimes used to hang the parts for powder
coating. You can if you wish use the hole to stop the covers from sliding in the
roof using a glazing screw, note you will have to use a countersunk screw under
the vents to avoid interference with the vent bottom.

3
SECTION
No TITLE ASSEMBLY SYNOPSIS: IMPORTANT INFORMATION / CONSIDERATIONS
PARTS LIST Identify and separate all like for like components prior to assembly. The ‘parts list’ also separates parts into the various sections 1 -
13 shown below. Parts can also be identified by their profile pictures and stated lengths etc..
B BASE Base dimensions and recommendations. Ensure that your base is level as this will make assembly of the building, especially the
glazing of the roof much more straight forward. Please be aware that the hinge door on your greenhouse opens inwards, make
sure that there will be no interference between the door and the foundations.
P PREPARATION Tools required. IMPORTANT: Use WD40 or similar in the glazing bar channels and insert the black glazing rubber prior to frame
assembly.
1 REAR Take the glazing bars ‘D609’ with the rubber inserted and the diagonal braces ‘D604’, use 10mm bolts to join them to the gutter
and 15mm bolts to the cills (note how the head of the bolt slides into each glazing bar during construction). Please also remember
to slide in your 22mm bolts for attaching the decorative eave spandrels ‘DV100’ in section 6.
PORCH GABLE
Again ensuring that the gable framework is rubbered-up follow the diagrams to assemble each gable in the building. Make sure that you have inserted the extra bolts utilised in sections 4 and 5. On the roof and side corner bars not every rubber channel will
require rubber unless it is to be utilised in a partition (see separate manual and section P).
END GABLES
4 PORCH SIDES The porch sides (the L-shaped area to the left and right of the porch gable between cills and gutters level) can either be built in situ
piece by piece or built away from the structure as an L-shape and then attached in a similar manner to plain gable/s to rear.
Please ensure that where relevant you slide 2 x 22mm bolts into the side bars for the attachment of the DV100 eaves spandrels.
5 MAIN FRAME
ASSEMBLY Take the rear (1) and the end gables (3) and join them together on your base. It is a good idea to tie some ladders to the sides to support them if you do not have anyone to hold them for you. Once the porch sides (4) have been attached to the main building
then the porch gable (2) can be inserted between them in the same way you would attach a end gable to the rear. You will now
have a T-shaped framework. It is important that you check that the internal diagonal measurements within the building are equal to
ensure that the building is square, spending a little time on this now will speed up roof assembly and glazing.
6a REAR ROOF Attach the main ridge between the end gables and then the rubbered-up roof bars ‘DV255’ ensuring that they are fully butted up to
the ridge and down onto the gutter. Attach your cresting before you glaze the building to give yourself more room to work. Utilise
the 22mm bolts slid into the rear (section 1) and roof bars to attach your DV100 and DV101 spandrels. On longer models you may
need to carefully prop up the roof and tie the sides together to keep the ridge and gutters straight (i.e. not sagging or bowed) until
the building is fully glazed.
6b PORCH ROOF The porch ridge can be fitted to the porch gable supporting its free end with ladders or a wooden sprag. The porch hips ‘DV381’
can now be attached between the welded porch gutter sections and the free end of the porch ridge. A ‘lower’ height porch utilises
a DV380 bracket to allow the porch ridge to connect to the main module. Identify all of the handed roof bars and look for their
locations. Insert the rubber into their channels and when attaching ensure again that were relevant you slide in 22mm bolts for
eave (x2) and roof spandrels (x2). Eave and Roof sprandrels can now be attached using the previously inserted 22mm bolts. The
ladders / sprag supporting the porch ridge free end can now be removed.
Prior to glazing the cresting and finials should be siliconed into place. Attaching them once the glass has been installed by leaning
through vent apertures is more time consuming.
7a VENT Once the vent is glazed add silicone to the vent sides and top. Stand the vent/s on their hinge (vent top) and then leave the sili-
cone to set.
7b VENT SLAM The slam bar ‘D079’ can be moved up and down between the roof glazing bars so that it can be butted down onto the pane of
glass beneath, the autovent will be attached to it later on (10).
8 LOUVRE They attach to the building during the glazing process (9) like a piece of glass with a black separator above them. If you are fitting
an optional auto-louvre then you need to carefully drill (3mm bit) out the rivets which mount the handle to the frame. You can then
either utilise those holes or create more to mount the unit.
9 GLAZING Layout the bar cappings and covers around the building like a sundial checking that all is present and correct. You can also place
the roof cappings in the gutters so they are closer to hand. Use the capping and the self tapping screws to then hold the glass in
place. The covers then enclose the screw heads giving a neat finish. It is a good idea to glaze two roof sections first to ensure the
building is square followed by two side sections to ensure the building isn't leaning.
The porch cowling ‘DV341’ should be attached before the vents are inserted so that access through vent apertures is available.
Silicone the cowling area internally, position cowl and VERY carefully (avoiding glass below) mark, drill and screw x 2 ‘FS6018’
into place. IMPORTANT: Silicone the cowling externally and check with watering can than the cowl is water tight, note silicone can
be moulded shortly after application if you wet your fingers.
IMPORTANT: On the roof sections please make sure that you place a screw around 25mm / 1” from the bottom of each capping
strip (create a hole in the plastic if required) and that the screws are nice and tight to avoid any glass slippage.
10 VENT
ATTACHMENT Take the assembled vent and slide the vent hinge ‘D866’ into the end of the ridge allowing the vent to pivot open and closed. Vent stops go either side of the vent to stop any lateral movement (so insert stop / vent / stop). Attach the Bayliss XL autovents.
11 DOOR
ATTACHMENT Your door comes pre-constructed and locked minus the handles and their pivot pin but now it needs to be mounted to the front end of your building. Utilise the ‘DV522’ plates and twist in crop headed bolts to join the door and its frame to the building (pinch
the door frame against your long front verticals whilst tightening your ‘DV522’ plates to ensure that there is no gap). If you are
struggling to eradicate the gap between the door frame and verticals then some silicone can be carefully applied to the area to
create a vertical seal. Be careful not to lock yourself in the building and to avoid damage do not open the door until it is attached to
the front gable. Getting the door to swing perfectly without dropping or rubbing on the ground may require some small but vital
adjustments. You may also need to insert a packer underneath the door frame hinge to increase ground clearance. Part ‘DV275’
canopies the door frame top hiding the clearance space at the top of the door. The door can only be made to swing inwards.
IMPORTANT: Please do NOT let the door slam open or closed as it is likely to cause damage to the door and the frame. Please
twist the handle to open and close. Please also be aware that your door KEYS (3 provided) are unique to the building so they
should not be stored together.
12 ANCHORING
DOWN Now that the greenhouse is finished and the door and vent/s are operating without interference then you need to anchor the build- ing down using 2” rawl plugs and screws. Use a 7mm masonry bit in a hammer drill to create the holes.
13 FINISHING
TOUCHES Now that the main body of the structure is complete you can add; downpipe fittings, eave bungs, gutter stop ends. It is also impor- tant to carefully apply some silicone to the internal eaves corners and external and internal ridge corners to minimise the chance of
water entering the structure.
14 OPTIONAL
REAR
SHELVING
Robinsons integral cantilever staging and shelving attaches to the inside of the greenhouse frame using either square head bolts
(insert four into each side glazing bar ’D609’ during construction of the rear (1)) or rectangular ‘crop head’ bolts which can be fitted
retrospectively (both sets of bolts accompany the shelving/staging). This system allows the height of either the staging or the shelf
to be set at an operator specific height. Commonly the staging brackets are set 900mm from the cills though you can alter this to
suit the end user/s. The aluminium shelf / staging slats come in two lengths; (4’):1240mm ‘D2002’ and (6’):1860mm ’D2003’.
These slats can combine to create any length of staging required, i.e. 4’+6’ = 10’ etc...
15 OPTIONAL
REAR
STAGING
2 /
3

4
Section
Ref Part
No. Section Size (mm) 14 8
DV232 3548 2
D608 1160 4
DV066L
1505 2
DV066R 2
DV310L
1972 2
DV310R 2
DV312L
2438 2
DV312R 2
DV259 2879 2
DV274 3402 2
DV307 1350 4
DV252L
2451
2
DV252R
2
DV104 N/A 4
DV105 N/A 2
RUBBER 1000 (1m)
72
D174
N/A
14
D021 2514 1
DV210 2517 1
D604 1316 2
D609 1160 3
RUBBER 1000 (1m)
7
D174
N/A
2
Section
Ref Part
No. Section Size (mm) 14 8
DV345 303 1
DV348 923 1
DV357 923 1
DV361 303 1
DV363 1160 2
DV394
327X947 1
DV395 1
D609 1160 2
RUBBER 1000 (1m)
10
D174
N/A
4
MAIN FRAME
QUANTITIES
VENTS / DOORS etc
SEPERATE
Part
No. 15 12
SYBOL
M6X11
10mm
131
SYBOL
M6X11
CROP
10mm
20
SYBOL
M6X15
15mm
43
SYBOL
M6X22
22mm
40
SYNUTM6
M6
NUT
234
FS6018
19mm
2
DV301L
537 1
DV301R 1
D608 1160 2
DV233L
2173 1
DV233R 1
DV269 468 2
DV300 1193 2
DV250L
1345
1
DV250R
1
D671 610 1
DV275 904 1
D163 90 2
DV104 N/A 2
DV105 N/A 1
RUBBER 1000 (1m)
18
D174
N/A
2

5
Section
Ref Part
No. Section Size (mm) 14 8
D866 639 3
D863L 613 3
D863R 613 3
D862 593 3
D079
PLUS FLUFF 590 3
D114 N/A 6
D220
PLUS FS6060 SCREW N/A 6
D205 N/A 6
D522 N/A 10
D119 1
DV120 N/A 6
D841 N/A 6
D211 PIPE 1625 6
D207 N/A 6
D201 N/A 6
D208 N/A 3
DV219 N/A 3
DV218 N/A 3
SILICONE
D982 100 2
DV100 N/A 5
DV101 N/A 5
DV201 2517 1
DV350 1850 1
DV253 1345 2
DV255 2450 3
D138 1167 1
DV375L/R 830 1+1
DV382L/R 1935 1+1
DV380 N/A 1
DV381 1668 2
DV389 1105 1
RUBBER 1000 (1m) 34
6 DV341 N/A 1
Section
Ref Part
No. Section Size (mm) 14 8
1, 4 D618 1144 9
2 D662 600 1
6 D823 516 1
6 D870 601 6
6 DV403L/R 1505 2 + 2
11 DV479 1384 1
3 DV610L/R 1972 2 + 2
3 DV612L/R 2438 2 + 2
6 DV653 1378 2
6 DV655 1880 3
3 DV659 2879 2
2 DV633L/R 2173 1 + 1
6 DV675L/R 863 1 + 1
6 DV687L/R 1365 1 + 1
D610 1160 6
D620 1144 6
D871 601 4
DV650 1345 2
DV652 1871 4
2, 3
1, 5
6
6
6
2, 3 D614 1162 6
1, 5 D619 1144 16
2 D666 602 1
11 DV480 1384 1
3 DV611L/R 1972 2 + 2
3 DV613L/R 2438 2 + 2
3 DV615L/R 1505 2 + 2
2 DV634L/R 2173 1 + 1
6 DV656 1378 4
6 DV658 2481 7
3 DV665 2879 2
6 DV679L/R 863 1 + 1
6 DV688L/R 1968 1 + 1

525
LEVEL WITH THE DOOR THRESHOLD OPENING.
TITLE:
525
Property of 'Robinsons Greenhouses' © 2020 GUIDANCE NOTE FOR ROBINSONS DWARF WALL GREENHOUSES.
FOOTINGS CONCRETE STRIP FOOTINGS SHOULD BE A MINIMUM OF 400mm WIDE X 200mm DEEP. IF THE SITE IS ON MADE UP GROUND IT IS IMPORTANT THAT THE FOOTINGS ARE CUT INTO THE COMPACTED GROUND BELOW. WHERE THE GROUND IS LIABLE TO MOVEMENT SUCH AS HEAVY CLAY OR LOOSE SANDY SOIL REINFORCING SHOULD BE ADDED TO THE CONCRETE FOOTINGS. WALLS IT IS MOST IMPORTANT THAT THE BRICKWORK IS IN ACCORDANCE WITH THE 'mm' DIMENSIONS PROVIDED AND IS SQUARE, LEVEL AND UPRIGHT, THE DIAGONAL MEASUREMENTS SHOULD BE EQUAL. WALLS SHOULD BE DOUBLE SKIN. THE TOP COURSE OF BRICKS SHOULD BE LAID FROG DOWN. IF ENGINEERING BRICKS ARE USED FOR THE TOP COURSE PLEASE ENSURE THEY ARE SOLID NOT CELLULAR (WITH HOLES THROUGH THEM) OR FIXING DOWN OF THE GREENHOUSE WILL BE A PROBLEM. BRICKS SHOULD BE A GOOD QUALITY STOCK BRICK, SAND FACED FLETTON TYPE BRICKS ARE NOT SUITABLE. GABLE DOOR OPENING THE DOOR THRESHOLD REQUIRES BRICK WORK ACROSS THE OPENING WHICH SHOULD BE LEVEL WITH THE FINISHED FLOOR LEVEL (F.F.L) OF THE GREENHOUSE. THE OPENING FOR THE DOORWAY AND THE HEIGHT TO THE TOP OF THE WALL FROM THE THRESHOLD LEVEL REQUIRE THE HIGHEST ACCURACY AND ARE MOST IMPORTANT SO THAT THE DOOR FITS THE APERTURE CORRECTLY. PLEASE ALSO BE AWARE THAT THE DOOR OPENS INWARDS AND THEREFORE THE FOUNDATIONS NEED TO AVOID ANY DOOR INTERFERENCE. IT IS ADVISABLE TO MAKE A WOODEN TEMPLATE TO CHECK THE DOOR APERTURE DIMENSIONS. IN ORDER TO SUPPORT THE OUTER EDGE OF THE DOOR THRESHOLD THERE MUST BE A PROJECTION OF BRICKWORK / CONCRETE DIRECTLY INFRONT OF THE DOORWAY WITH A MINIMUM WIDTH OF 50mm. THIS NEEDS TO BE
RAMSBURY
WITH 2 BAY RUGBY PORCH
DIMENSION VARIABLES (mm)
MODEL LENGTH 'L' RETURN 'Y' DIAGONAL 'D'
8 LONG 2630mm 331mm 4403.5mm
16 LONG 5110mm 1571mm 6212mm 24 LONG 7590mm 2811mm 8371.5mm 32 LONG 10070mm 4051mm 10671.5mm 40 LONG 12550mm 5291mm 13037.5mm 44 LONG 13790mm 5911mm 14235mm
DOORWAY
OPENING
974mm
DIMENSION VARIABLES (mm)
MODEL LENGTH 'L' RETURN 'Y' DIAGONAL 'D'
8 LONG 2630mm 331mm 4403.5mm
16 LONG 5110mm 1571mm 6212mm 24 LONG 7590mm 2811mm 8371.5mm 32 LONG 10070mm 4051mm 10671.5mm 40 LONG 12550mm 5291mm 13037.5mm 44 LONG 13790mm 5911mm 14235mm
'Y'mm
LENGTH 'L' mm
4459mm
3532mm 927mm
FOR DOOR
THRESHOLD
1968mm
50mm MIN
497
mm
RETURN
DIAGONAL'D'mm

7
PARTITION
ONLY
REFER TO
SEPARATE
MANUAL
Feed glazing rubber into each glazing bar and
trim to length. Notice that some channels are
only used on a partition. Applying a lubricant to
the aluminium channels will speed up insertion.
The frame is assembled by feeding square
headed bolts, either 10mm, 15mm or 22mm in
length into the slots on glazing bars and then
locating those bolts through holes in purlings
and cills, etc… Twist in (rectangular) crop
headed bolts are also used towards the end of
construction to attach components to the frame
when the glazing bar slots are no longer ex-
posed at the ends.
10mm 15mm
PARTITION
ONLY
REFER TO
SEPARATE
MANUAL
22mm

8
DV210
D021
15mm
10mm
22mm
22mm
15mm
10mm
22mm
22mm
15mm
10mm
22mm
22mm
REAR 14 x 8
Part No mm Quantity
DV210 2517 1
D021 2514 1
D604 1316 2
D609 1160 3
D174 2
SYBOL
M6X11 3
SYBOL
M6X15 5
SYBOL
M6X22 6
SYNUT
M6 8
D227
Rubber 1000 7
8

9
D604
D604
15mm
D609
10mm
D609
TRANSIT
BOLT ON
DIAGONALS
15mm
22mm

10
D608
10mm
10mm
10mm
10mm
15mm
15mm
D608
DV300
DV300
DV233L
DV233R
15mm
10mm
15mm 15mm
15mm
15mm
10mm
10mm
10mm
10mm
DV250L
DV250R
10mm
15mm
10mm
10mm
PORCH GABLE
Part No mm Quantity
D608 1160 2
D671 610 1
DV233L 2173 1
DV233R 2173 1
DV250L 1345 1
DV250R 1345 1
DV269 468 2
DV275 904 1
DV300 1193 2
Part No mm Quantity
D174 2
M6X10 28
M6X15 8
M6NUT 36
DV104 2
D227 18m
DV105 1
D163 2
DV301L 537 1
DV301R 537 1
DV269 DV269
DV275
D671
DV301R
DV301L
10mm 10mm

11
DV301L /
DV301R
DV250L
DV301L /
DV301R
D174
DV300
DV250R
D608
DV105 D671
DV233L /
DV233R
DV250L /
DV250R
DV233L /
DV233R
D608
DV300
DV250L /
DV250R
DV269
DV104
DV104
DV250L /
DV250R
FLIP VIEW
DV233LH /
DV233RH
DV275
D163

12
Part No mm Quantity
DV066L 1505 2
DV066R 1505 2
D608 1160 4
DV232 3548 2
DV252L 2451 2
DV252R 2451 2
DV259 2879 2
DV274 3402 2
DV307 1350 4
DV310L 1972 2
DV310R 1972 2
DV312L 2438 2
DV312R 2438 2
END GABLE X 2 Part No mm Quantity
D174 14
M6X10 64
M6X15 26
M6NUT 90
DV104 4
D227 72m
DV105 2
DV232
D608
10mm
10mm
10mm
10mm
15mm
15mm
D608
DV307
DV307
DV310R
DV259
DV274
DV252R
10mm
15mm
10mm
15mm 15mm
15mm
15mm 10mm
10mm
10mm
10mm
DV066R
DV066L
10mm
15mm
10mm
10mm
10mm
15mm
10mm
10mm
DV252L
DV312L
DV312R
DV310L

13
DV252L
DV232
D174
DV307
DV232
DV252R
D608
DV105 DV259
DV310L /
DV310R
DV252L /
DV252R
DV310L /
DV310R
DV066L /
DV066R DV312L /
DV312R
D608
DV307
DV252L /
DV252R
DV274
DV104
DV104
DV252L /
DV252R
FLIP VIEW

14
D609
D609
DV363
DV363
DV348
DV357
DV394
DV395
DV345
22mm
10mm
10mm
15mm
15mm
10mm
22mm
22mm
15mm
10mm
10mm
10mm
DV361
PORCH SIDES 14x8
Part No mm Quantity
D609 1160 2
DV345 303 1
DV348 923 1
DV357 923 1
DV361 303 1
DV363 1160 2
DV394
327X947 1
DV395 1
D174 4
D227
Rubber 1000 10
SYBOL
M6X11 8
SYBOL
M6X15 4
SYBOL
M6X22 4
SYNUT
M6 12

15
EQUAL

16
REAR ROOF 14x8
Part No mm Quantity
DV100 n/a 5
DV201 2517 1
DV255 2450 3
D227
Rubber 1000 15
SYBOL
M6X11 6
SYBOL
M6X22 12
SYNUT
M6 22
DV282
ROFINALU
DV281
RO
CRE
ALU
CUT
6mm
SILICONE
D119
EQUALx2
 End finials need to be pinched onto the ridge using ‘DV282’ grub screws.
 Depending on your ridge length a half cresting may need to be cut. Some
spacer bar may also be required ‘DV281’ cut into two equal sections.
 Each finial and cresting piece needs to be siliconed ‘D119’ into place.
1
DV201
1

17
2
DV255
D609
3 DV255
22mm
22mm
DV100
4
10mm
10mm
4
4
2
3 DV201

18
PORCH ROOF 14x8
Part No mm Quantity
D982 100 2
DV101 n/a 5
DV253 1345 2
DV350 1850 1
D138 1167 1
DV375L/R 830 1 + 1
DV380 n/a 1
DV381 1668 2
DV382L/R 1935 1 + 1
DV389 1105 1
D227
Rubber 1000 19
SYBOL
M6X11 22
SYBOL
M6X22 18
SYNUT
M6 46
DV253
DV395
DV361
DV348
DV345
DV381
D609
DV357
DV382L DV382R
DV389
DV375R
DV375L
DV363
DV380
DV101
DV350
DV100
DV394
D138 D982

19
D119
SILICONE
FLIP VIEW
FLIP VIEW
IMPORTANT: Because your porch gutter sections are welded together to eliminate the chance of any leaks the holes circled above can vary slightly
in their locations. They may therefore require slight alteration to marry up with DV363 and DV379. Using an 8mm drill bit to enlarge the standard 7mm
holes will for example give a little more play to aid fitting.
DV380
D138
D982
FS6006/
FS6504
FLIP VIEW

20
D1208
1 of -
610 x 610
pane
D866
D863R
D863L
D866 639 1
D863L 613 1
D863R 613 1
D862 593 1
Part No mm Quantity
D220
PLUS
SCREW
N/A 2
D205 N/A 2
SYBOL
M6X11 10 4
SYNUT
M6 M6 4
8 X 12 S/T
FS6017 10 2
Part No mm Quantity
8 x 19 S/T
FS6018 19 2
D863R
D866
2
2
D1208
1 of -
610 x 610
pane
