Mounting instruction Compas up-light 26102004, Cat.No.: 99082030 Page 1 af 1
Mounting instruction for COMPAS up-light fittings.
This instruction manual describes the recommended mounting method for Roblon Fiber Optics´
COMPAS-LINE of recessed up-light fittings. The instruction is only valid for COMPAS fittings
with straight flange ( 0313 0100 and 0313 0101) for flushed mounting
in a flag stones.
1A. Drill a hole in the flag stone ∅100 mm (+2/-0 mm).
1B. The hole surface must be scratched so it becomes uneven and must be cleaned for dust, as
described in the glue applicated.
2A. Fasten the aluminium bracket to the 40 mm high fixing bush with the 2 screws. Fit the plastic
fitting bush in the hole. The bush is now fixed in an 11 mm distance to the flag stone´s top
edge. See drawing.
2B. Secure the bush to the flag stone with exterior cement (HILTI glue HIT-HY 150) through the
4 holes in the bush wall. The cement has a 6 minutes pot time and a 50 minutes hardening
time (at +20 °C). (at +5 °C: 25 minutes pot time / 90 minutes hardening time).
2C. Secure carefully that the bush is centered in the hole in the flag stone.
3A. Place a ∅150 - ∅200 mm well (e.g. plastic conduit) where the fitting is supposed to be fitted.
This is done to prevent sand and gravel from interfering with the entry of the fiber cable.
3B. Drill a Ø 50 mm hole in the side wall of the well. Fit a plastic conduit Ø 50 mm from the well
to the light source.
4A. Conduct a flexible conduit, Ø 14-18.5 mm outside diametre (e.g. DMI Nyflex nr. 2641). This
type is recommende due to it´s strength and temperature resistance. The diametre parameter is
the most important in order to secure water tightness between the conduit and the fitting!
There must be app. 300 mm flexible conduit above well level.
4B. Finish with sand og gravel around the fitting well, lead the flexible conduit through the hole
and place the flag stone with the hole centered over the well.
5. After having finished all conduits and placed all stones, the fiber cables can now be either
pushed forward through the flexible conduits or drawn with a cable finder
6. Fit the flexible conduit to the Compas fitting and screw the fitting to the fitting bush.
7. The fiber cable is secured to the connector with the set screw, the Compas Insert is placed in
the Compas fitting and the fitting is closed with O-ring, glass and flange.
