Overview
Robustel R1510 router is a Dual Ethernet port (LAN + WAN) 3G/4G router with advanced software functions at a
very competitive price point.
Package Checklist
Before commencing installation ensure your package has the following components:
Device
2PIN Terminal
Block
3PIN Terminal
Block
Cellular Antenna
Wi-Fi Antenna
SIM Card Sticking
Patch
Mounting Kit
(Optional)
Power Supply
(Optional)
Ethernet Cable
(Optional)
Note: The accessories could be different on specific order.
Panel Layout(May vary on difference models)

Robustel R1510 Hardware Manual
RT048_HM_R1510 6/10
Interface Descriptions
1. Power Supply. 2PIN 3.5mm pitch terminal block.
PIN
Power
DI/DO
Description
1
V+
--
Power input Positive, 9-36VDC
2
V-
--
Power input Negative
3
--
DI
Digital input (Maximum absolute voltage: 30V. Maximum absolute current: 20mA)
4
--
GND
Ground
5
--
DO
Digital output (Maximum absolute voltage: 30V. Maximum absolute current: 20mA)
DI&DO Internal Diagram
2. LED Indicator.
Name
Color
Status
Description
RUN
Green
On, solid
Router is powered on (System is initializing)
On, blinking
Router starts operating
Off
Router is powered off
MDM
Green
On, solid
Link connection is working
On, blinking
Data is sent and received.
Off
Link connection is not working
USR
USR-OpenVPN
Green
On, solid
OpenVPN connection is established
Off
OpenVPN connection is not established
USR-IPsec
Green
On, solid
IPsec connection is established
Off
IPsec connection is not established

Robustel R1510 Hardware Manual
RT048_HM_R1510 7/10
RSSI
Green
On, solid
Signal Level: Best Signal Level
Wireless module: 21-31dB (signal strength)
On, slow blinking (1s)
Signal Level: Average Signal Level
Wireless module: 11-20dB (signal moderate)
On, fast blinking
Signal Level: Abnormal Signal Level
Wireless module: 21-31dB (signal weak)
Off
No signal
WLAN
Green
On, solid
WLAN is enabled and working properly
Green
Off
WLAN is disabled or not working properly
Note: You can choose the display type of USR LED. For more details, please refer to
RT123_SM_RobustOS Software Manual, Services > Advanced > System >System Settings > User LED Type.
3. Reset Button.
Function
Operation
Reboot
Press and hold the RST button for 2~ 5 seconds under the operating status.
Restore to default
configuration
Press and hold the RST button for 5~10 seconds, the RUN LED starts blinking quickly, the router will restore to default
configuration.
Restore to factory
default settings
Once the operation of restoring default configuration is performed twice within one minute, the router will restore to factory
default settings.
Note: The more details please refer to RT123_SM_RobustOS Software Manual, 2.3 Factory Reset.
4. Ethernet Ports. There are two Ethernet ports on R1510, including ETH0 (WAN/LAN), and ETH1. Each has two
LED indicators. The green one is a link indicator but the yellow one doesn’t mean anything. For details about
status, see the table below.
Ethernet LED Indicator
Status
Description
Link indicator
(Green)
On, solid
Connection is established
On, blinking
Data is being transferred
Off
Connection is not established

Robustel R1510 Hardware Manual
RT048_HM_R1510 8/10
Hardware Installation
1. SIM Card Installation. Insert the SIM cards into the device, then stick the sticker.
2. Antenna Installation. Rotate the antenna into the antenna connector accordingly.
3. Terminal Block Installation. Insert the 2PIN、3PIN terminal blocks into the interfaces connector.
4. Mounting Kit installation.
1Wall mounting

Robustel R1510 Hardware Manual
RT048_HM_R1510 9/10
2DIN rail mounting
5. Connect the Router to a Computer
6. Power Supply installation. There are two cables associated with the power adapter. Following to the color of
the head, connect the cable marked red to the positive pole through a terminal block, and connect the yellow
one to the negative in the same way.
Note: The range of power voltage is 9 to 36V DC.

Robustel R1510 Hardware Manual
RT048_HM_R1510 10/
10
Login to the Device
1. Connect the router’s Ethernet port to a PC with a
standard Ethernet cable.
2. Before logging in, manually configure the PC with
a static IP address on the same subnet as the
gateway address, click and configure "Use the
following IP address".
3. To enter the gateway's web interface, type
http://192.168.0.1 into the URL field of your
Internet browser.
4. Use login information shown in the product label
when prompted for authentication.
5. After logging in, the home page of the web
interface is displayed, then you can view system
information and perform configuration on the
device.
6. The automatic APN selection is ON by default, if
need to specify your own APN, please go to the
menu Interface->Link Manager->Link
Setting->WWAN Settings to finish the specific
setting.
7. The more configuration details please refer to
RT123_SM_RobustOS Software Manual.
(END)
