Robustel GoRugged R3000 Lite User manual

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 1/10
R3000 Lite
Hardware Manual
Version: 1.0.0
Date: July 28, 2022

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 2/10
Regulatory and Type Approval Information
Table 1: Directives
2011/65/EC
The European RoHS 2011/65/EU Directive was issued by the European parliament
and the European Council on 1 July 2011 on the restriction of the use of certain
Hazardous substances in electrical and electronic equipment.
On June 4, 2015, the Official Journal of the European Union published the RoHS2.0 Amendment
Directive (EU)
In 2015/863, four phthalates (DEHP, BBP, DBP, DIBP) were officially included in the list of restricted
substances in Appendix II of RoHS 2.0 (2011/65/EU).
From July 22, 2019, all electronic and electrical products exported to Europe (except medical and
monitoring equipment) must meet this restriction; from July 22, 2021, medical equipment and
monitoring equipment will also be included in the scope of control.
2012/19/EU
The European WEEE 2012/19/EU Directive was issued by the European parliament
and the European Council on 24 July 2012 on waste electrical and electronic equipm
Table 2: Toxic or Hazardous Substances or Elements with Defined Concentration Limits
Name of the Part
Hazardous Substances
(Pb)
(Hg)
(Cd)
(Cr (VI) )
(PBB)
(PBDE)
Metal parts
o
o
o
o
o
o
Circuit modules
o
o
o
o
o
o
Cables and cable assemblies
o
o
o
o
o
o
Plastic and polymeric parts
o
o
o
o
o
o
o:
Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is
below the limit requirement in 2011/65/EU and SJ/T11363-2006.
x:
Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials for this
part might exceed the limit requirement in 2011/65/EU and SJ/T11363-2006.
Radio Specifications
RF technologies
2G, 3G, 4G
Cellular Frequency*
4G: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28
LTE TDD: B40
3G: WCDMA: B1/B2/B5/B8
2G: GSM: B2/B3/B5/B8
Oceania
South America
4G: LTE FDD: B2/B4/B5/B13/B17
3G: UMTS: B2/B5
USA
4G: LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
3G: WCDMA: B1/B5/B8
2G: GSM: B3/B8
EMEA
4G: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/
EMEA

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 3/10
B13/B18/B19/B20/B25/B26/B28
LTE TDD: B38/B39/B40/B41
3G: WCDMA: B1/B2/B4/B5/B6/B8/B19
2G: GSM: B2/B3/B5/B8
4G: LTE FDD: B1/B3/B8/B18/B19/B26
LTE TDD: B41
3G: WCDMA: B1/B6/B8/B19
Japan
4G: LTE FDD: B1/B3/B7/B8/B20/B28A
3G: WCDMA: B1/B8
2G: GSM: B3/B8
EMEA
Max RF power
35 dBm@GSM, 25 dBm@WCDMA, 25.7 dBm@LTE
*May vary on difference models.
Simplified EU Declaration of Conformity
We, Guangzhou Robustel Co., Ltd. are located at 501, Building #2, 63 Yongan Road, Huangpu District, Guangzhou,
China, declare that this radio equipment complies with all applicable EU directives. The full text of the EU DoC is
available at the following internet address:
www.robustel.com/certifications/
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
IC Declaration of Conformity
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1)This device may not cause interference.
(2)This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes :
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d' en
compromettre le fonctionnement.
Radio Frequency Exposure Statement for IC
This device complies with IC exposure limits set forth for an uncontrolled environment. This device shall be installed
and operated with minimum distance 20cm between the radiator & body.
Cet équipement est conforme aux limites d'exposition IC définies pour un environnement non contrôlé. Cet
équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et la carrosserie.

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 4/10
Related download link
Find more product documents or tools at:
www.robustel.com/en/documentations/
Technical Support
Tel: [phone]
Email: [e-mail]
Web: www.robustel.com
Document History
Updates between document versions are cumulative. Therefore, the latest document version contains all updates
made to previous versions.
Date
Firmware Version
Document Version
Change Description
July 28, 2022
5.0.0
1.0.0
Initial release.

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 5/10
Overview
The Robustel Industrial Dual SIM Cellular VPN Router (R3000 Lite) is a rugged cellular router offering
state-of-the-art mobile connectivity for machine to machine (M2M) applications. R3000 Lite is a powerful router
developed from RobustOS, a Robustel self-developed and Linux-based operating system which is designed to be
used in Robustel hardware routers.
Package Checklist
Before commencing installation ensure your package has the following components:
Device
3PIN Terminal
Block
RCMS Card
Quick Start Guide
Card
Mounting Kit
(Optional)
Cellular Antenna
(Optional)
Power Supply
(Optional)
Ethernet Cable
(Optional)
Note: The accessories could be different on specific order.
Panel Layout (May Vary on Different Models)
Top
View
Bot

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 6/10
Interface Descriptions
1. LED Indicator.
Name
Color
Status
Description
RUN
Green
On, fast blinking
(250ms blink time)
Router is powered on (System is initializing)
On, blinking
(500ms blink time)
Router starts operating
Off
Router is powered off
USR-SIM
Green
On, solid
Main Card is being used
On, blinking
Backup card is being used
Off
NO SIM card
USR-NET
Green
On, solid
Network is joined successfully and worked in an optimum one
On, blinking
Network is joined successfully but worked in a lower-level than
standard
Off
Network is not joined or joining
USR-OpenVPN
Green
On, solid
OpenVPN connection is established
Off
OpenVPN connection is not established
USR-IPsec
Green
On, solid
IPsec connection is established
Off
IPsec connection is not established
PPP
Green
On, solid
Link connection is established
Off
Link connection is not established
Green
Three lights are solid green
High signal strength (21-31) is available
Two lights are solid green
Medium signal strength (11-20) is available
One light is solid green
Low signal strength (1-10) is available
Off
No signal
When the network is disconnected, those three signal LEDs are designed as a binary combination code to indicate a series of error
report.
Blinking: 1 Off: 0
bit2 bit1 bit0
0 0 1 AT command failed
0 1 0 no SIM card detected
0 1 1 need to enter the PIN code
1 0 0 need to enter the PUK code
1 0 1 registration failed
1 1 0 module error
1 1 1 not support the module
Note: You can choose the display type of USR LED. For more details, please refer to
RT123_SM_RobustOS Software Manual Service > Advanced > System >System Settings > User LED Type.
2. USB Interface.
Function
Operation
Firmware upgrade
USB interface is used for batch firmware upgrading, but cannot be used for sending or receiving data from slave devices which
connected to it. You can insert a USB storage device into the router’s USB interface, such as a U disk or a hard disk. If there have a
supported configuration file or a router firmware in this USB storage device, the router will automatically update the
configuration file or the firmware. For more details, see RT123_SM_RobustOS Software Manual.

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 7/10
3. PIN Assignment
4. Reset Button
Function
Operation
Reboot
Press and hold the RST button for 2~ 5 seconds under the operating status.
Restore to default
configuration
Press and hold the RST button for 5~10 seconds, the RUN LED starts blinking quickly, the router will restore to default
configuration.
Restore to factory
default settings
Once the operation of restoring default configuration is performed twice within one minute, the router will restore to factory
default settings.
Note: The more details please refer to RT123_SM_RobustOS Software Manual, 2.3 Factory Reset.
5. Ethernet Ports. R3000 Lite Router has one Ethernet port with two LED indicators. The yellow one is link indicator
and the green one is speed indicator. For details about status, see the table below.
Indicator
Status
Description
Link indicator
On, solid
Connection is established
On, blinking
Data is being transferred
Off
Connection is not established
Speed indicator
On, solid
100 Mbps mode
Off
10 Mbps mode
PIN
Debug (232)
RS-232
RS485 (2 Line)
Direction
1
Data+(A)
--
2
RXD
Router→Device
3
TXD
Router←Device
4
DRXD
Router←Device
5
GND
GND
GND
6
Data-(B)
--
7
RTS
Router←Device
8
CTS
Router→Device
9
DTXD
Router→Device
5 4 3 2 1
9 8 7 6
PIN
Polarity
10
Positive
11
Negative
12
GND
10 11 12

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 8/10
Hardware Installation
1. SIM Card Installation. Loosen the screws associated with the cover by using a screwdriver and then find the
SIM card slot. Press the card with finger until you hear a click and then tighten the screws associated with the
cover by using a screwdriver. Put back the cover and tighten the screws associated with the cover by using a
screwdriver.
2. Antenna Installation. Rotate the antenna into the antenna connector accordingly.
3. Mounting Kit installation. (Optional)
·Wall mounting
·DIN rail mounting

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 9/10
4. Power Supply installation. Following to the color of the head, connect the cable marked red to the positive
pole through a terminal block, and connect the yellow one to the negative in the same way.
Note: The range of power voltage is 9 to 36V DC.
5. Connect the Router to a Computer. Connect an Ethernet cable to the port marked ETH at the bottom of the
R3000 Lite, and connect the other end of the cable to your computer.

Robustel R3000 Lite Hardware Manual
RT025_HM_R3000_Lite 10/10
Support: [e-mail]
Website: www.robustel.com
©2022 Guangzhou Robustel Co., Ltd.
All rights reserved. Subject to change without notice.
5. After logging in, the home page of the web
interface is displayed, then you can view system
information and perform configuration on the
device.
6. The automatic APN selection is ON by default, if
need to specify your own APN, please go to the
menu Interface->Link Manager->Link
Setting->WWAN Settings to finish the specific
setting.
7. The more configuration details please refer to
RT123_SM_RobustOS Software Manual.
(END)
Login to the Device
1. Connect the router’s Ethernet port to a PC with a
standard Ethernet cable.
2. Before logging in, manually configure the PC with
a static IP address on the same subnet as the
gateway address, click and configure "Use the
following IP address".
3. To enter the gateway's web interface, type
http://192.168.0.1 into the URL field of your
Internet browser.
4. Use login information shown in the product label
when prompted for authentication.
