Robustel GoRugged R2000 User manual

Hardware Installation Quick Guide
R2000--Industrial Dual SIM Cellular VPN Router
Package Contents
Before installing R2000 router, verify that the package contains the following items:
1 x Robustel R2000 Industrial Dual SIM Cellular VPN Router
1 x Terminal block for power
1 x Quick Start Guide with download link of other documents or tools
Optional accessories (sold separately)
AC/DC power adapter
SMA cellular antenna (HSPA+/LTE)
Stubby/magnet RP-SMA Wi-Fi antenna
Wall mounting kit
35 mm DIN rail mounting kit
*Contact your sales representative if any of the above items is missing or damaged*
Environmental Requirements
Power input:
9 to 26V DC (
A014401, A014402, A014403, A014404, A014405, A014406, A014701, A014702,
A014703, A014704, A014705, A014706);
9 to 36V DC
Power consumption: Idle: 100 mA @ 12 V, Data Link: 500 mA (peak) @ 12 V
Operating temperature: -20 to 65°C
Operating humidity: 5 to 95% RH
Hardware Introduction
As shown in the following figures, R2000 router has two Ethernet ports (2 x LAN or 1 x LAN + 1 x WAN)
and two cellular SIM card slots.
Reset Button
Restore the R2000 to factory default settings by using a pointed object (such as a Pointed pen) to keep
pushing the button about 16 seconds once power on, until all the LED light blink one by one recurrently.
When all the LED light blinks hold on 2 seconds, it means that the router loads default successfully.
In addition, reboot R2000 by pushing the button for 2~7 seconds under working status.
Ethernet Port
Each Ethernet port has two LED indicators. The yellow one is Link indicator and the green one doesn’t
mean anything. There are three status of Link indicator.
Indicator
Status
Description
Link Indicator
Off
Connection is down.
On
Connection is up.
Blink
Data is being transmitted

Router shall be grounding reliably
under the rule which in order to
avoid lightning strike damage.

When use the power adapter, please
note the power polarity.

Please pay attention to waterproof in
the storage, transportation and
operation environment.

Suggest to mounting the router on a
horizontal flat surface.

If warranty label was damaged in
warranty period of product, no free
maintenance.
Caution

Insert SIM Card
Wall Mount
Din Rail
Hardware Installation
Step 1: After unpacking the unit, please refer to the following figure insert the SIM into the R2000 router.
Note: recommended torque for inserting is 0.5N.m and the maximum torque is 0.7N.m
Step 2: Connect router with an external SMA antenna. Make sure the antenna is within correct frequency
range and is screwed tightly.
Note: recommended torque for mounting is 0.35N.m
Step 3: Use a wire connect the ground screw of router to ground surface before connecting devices.
(Optional)
Step 4: Use a standard cross-over Ethernet cable to connect R2000 to PC with Eth0 or Eth1 port.
Step 5: The router may be placed on a horizontal surface such as a desktop, mounted on a DIN-rail, or
mounted on the wall.
Wall Mount
Use 4 pcs of M2.5*4 countersunk head cross recess screws to fix the router on the two metal
plates. And then use 2 pcs of M3*6 screw with point-end to mount the router with two metal
plates on the wall.
Please note: recommended torque for mounting is 0.5N.m and the maximum torque is 0.7N.m
Din Rail
Mount the router on a DIN rail with 3 pcs of M3*6 countersunk head cross recess screw screws,
and then hang the DIN-Rail on the holder. You need to choose a standard holder.
Please note: recommended torque for mounting is 1.0N.m and the maximum torque is 1.2N.m
LED Indicators
Name
Color
Status
Function
RUN
Green
Blinking
Router is ready.
On
Router is starting.
Off
Router is power off.
PPP
Green
Blinking
PPP Indicator: Null
On
PPP Indicator: PPP connection is up.
Off
PPP Indicator: PPP connection is down.
USR
Green
Blinking
SIM: using backup SIM card.
NET: register to a low level network.
Off after blinking
SIM: working fine.
NET: working fine.
Light up
OpenVPN: OpenVPN is connected.
IPSec: IPSec is connected.
GRE: GRE is connected.
Off after lighting up
OpenVPN: OpenVPN is disconnected.
IPSec: IPSec is disconnected.
GRE: GRE is disconnected.
Green
On
Signal level: 21-31 (Perfect signal level).
Yellow
On
Signal level: 11-20 (Average signal level).
Red
On
Signal level: 1-10 (Exceptional signal level).
When the network is disconnected, those three signal LEDs are designed as a
binary combination code to indicate a series of error report.
(Green Yellow Red) On: 1 Off: 0
001 AT command failed
010 no SIM card detected
011 it need to enter the PIN code
100 it need to enter the PUK code
101 registration failed
110 something wrong happened in the module

E-mail: [email protected]
© 2016 Guangzhou Robustel Technologies Co., Limited. All rights reserved. Subject to change without notice. Web: www.robustel.com
Step 6: R2000 router supports reverse polarity protection, but always connects to the power adapter
correctly. There are two cables associated with the power adapter. Following to the color of
the head, connect the cable marked red to the positive pole through a terminal block, and
connect the yellow one to the negative in the same way.
Step 7: (Optional) If you want to power on R2000 by Ethernet, please refer to the following topology
and connect R2000 to PSE (Power Sourcing Equipment).
POE power input voltage range is 48~57 VDC.
Note: It is not recommended to use DC power supply and PD power supply simultaneously.
