Introduction

Safety, precautions and warnings

SAFETY PRECAUTIONS

CE compliance information for the european union

UK DE DK BG SE GZ ES NL SK HU RO FR PT BE

FI EE LV LT PL AT CY SI GR MT IT IE LU

• Replace damaged components with original factory-parts.

• Pay special attention to the polarity of all vehicle wiring.

• Use common sense when selecting the environment to operate your vehicle. Do not operate near

power cables, cellular/radio towers, deep water or unstable terrain. The operator is solely responsible

for their actions.

• The product is composed of precision electrical components. It is critical to keep the product away

from moisture and other contaminants.

• Always check the radio range of the vehicle prior to operation in order to prevent radio loss or

interference.

• Operate this product within your ability. If the vehicle is dangerous to retrieve, it never worth the risk.

• Always turn on the transmitter before connecting the battery on the model. When turning off the

model, always disconnect the battery first, and then turn off the transmitter. If this order is reversed,

the model may become uncontrollable and cause serious damage.

• Never allow transmitter batteries to run low as it may cause loss of vehicle control.

• Plastics on the vehicle are susceptible to damage or deformation due to extreme heat and cold

climate. Do not store the model near any source of heat such as oven or heater. Store the model

indoors, in a climate-controlled, room temperature environment.

The associated regulatory agencies of the following countries recognize the noted certifications for

this product as authorized for sale and use.

Thank you for purchasing our products.

This manual is written to assist you in properly operating, maintaining and repairing the vehicle. As

many of the components used are unique to this product, please retain this manual as a future

reference. Composed of precision-made components, this product is not a toy, thus it is not suited for

children under 14 years of age. Minors should be accompanied by an adult when operating. Failure

to operate or maintain this product in a safe manner can result in bodily harm. It is the owner

responsibility to operate this product in a safe manner. ROCHOBBY and its distributors are not

responsible in any way for any and all bodily harm and/ or property damage that may result from the

use of this product.

Declaration of Conformity

Products: 2.4GHz Controller

Equipment Class: 2

The objects of declaration described above are in

conformity with the requirements of the specifications

listed below.

Item Name : 2.4GHz Controller

The RED Directive 2014/53/EU

EN 60950-1:2006 + A11:2009 + A1:2010

+ A12:2011 + A2:2013

EN 300 328 V2.2.2 (2019-07)

EN 301 489-1 V2.1.1:2017

EN 301 489-17 V3.1.1:2017

MADE IN CHINA

FCC ID: N4ZR4A10

Certification

FCC Compliance Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Warning: changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

1.Reorient or relocate the receiving antenna.

2.Increase the separation between the equipment and receiver.

3.Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

4.Consult the dealer or an experienced radio/TV technician for help.

RF Exposure Compliance

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance 20cm

between the radiator and your body. This transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

Environmentally friendly disposal

Old electrical appliances must not be disposed of together with the residual waste, but have to be

disposed of separately. The disposal at the communal collecting point via private persons is for free.

The owner of old appliances is responsible to bring the appliances to these collecting points or to

similar collection points. With this little personal effort, you contribute to recycle valuable raw

materials and the treatment of toxic substances.

This product is not a toy! (14+) Recommended for ages 14 and up. Adult

supervision required for ages under 14 years old. Contains small parts, keep

out of reach of children 3 years of age and younger.

Safety symbols

Safety guide

RADIO SYSTEM

Danger Not following these instructions may lead to serious injuries or death.

Warning Not following these instructions may lead to major injuries.

Attention Not following these instructions may lead to minor injuries.

Prohibited Mandatory

Pay close attention to the following symbols and their meanings. Failure to follow these warnings

could cause damage, injury or death.

• Do not use the product at night or in bad weather like rain or thunderstorm. It can cause

erratic operation or loss of control.

• Do not use the product when visibility is limited.

• Do not use the product on rain or snow days. Any exposure to moisture (water or snow)may

cause erratic operation or loss of control.

• Interference may cause loss of control. To ensure the safety of you and others, do not

operate in the following places:

1、Near any site where other radio control activity may occur

2、Near power lines or communication broadcasting antennas

3、Near people or roads

4、On any body of water when passenger boats are present

• Do not use this product when you are tired, uncomfortable, or under the influence of alcohol

or drugs. Doing so may cause serious injury to yourself or others.

• The 2.4GHz radio band is limited to line of sight. Always keep your model in sight as a large

object can block the RF signal and lead to loss of control.

• Do not touch any part of the model that may generate heat during operation, or immediately

after use. The engine, motor or speed control, may be very hot and can ause serious burns.

• Misuse of this product may lead to serious injury or death. To ensure the safety of you and

your equipment, read this manual and follow the instructions.

• Make sure the product is properly installed in your model. Failure to do so may result in

serious injury.

• Make sure to disconnect the receiver battery before turning off the transmitter. Failure to do

so may lead to unintended operation and cause an accident.

• Ensure that all servo operate in the correct direction. If not, adjust the direction first.

• Make sure the model stays within the systems maximum range to prevent loss of control.

PRODUCT INTRODUCTION

The history of common folk owning cars is not very long. This 'weird' but efficient vehicle was a luxury

only for the very rich, until the advent of mass-produced cars. These days, countries all over the world

have popular affordable cars for the people. Although the original intentions of research and

development vary, their common concepts are compactness, convenience and multi-functionality.

Dr. Ferdinand Porsche, the founder of the Porsche Car company, was a genius designer whose design

ideas have influenced many today. He has designed the Beetle, the Elephant heavy tank destroyer, the

Type82 Kübelwagen, the Type166 Schwimmwagen and Lohner-Porsche Mixed Hybrid, the world's first

car powered by hub-mounted motors in the wheel. While Ferdinand Porsche was designing , Adolf Hitler

was waging war across Europe and plunging the World into chaos. The fates of these two Austrians were

intertwined in the 1930s, when Hitler made two promises to the German people after his election as head

of the Third Reich: one was to have steak on dinner; the other was to have a car for every German family.

The car had a very specific requirement, being able to carry 2 adults and 3 children at the same time, i.e.

a standard German family, and travel at a speed of up to 100km/h, while selling for no more than 1000

Reichsmark.

In fact, during the whole war, none of this people's cars was sold to the people, they were all being

requisitioned by the army and converted into military vehicles, the most famous of which is the

Kübelwagen (Released in Nov, 2021, Product No. 11241) . We feel honored if you already own it in your

RC collection. If not, this car could be a great start to realistic scale RC models. The post-war civilian

version was the Beetle, which later became world-famous.

We start with engine. The Boxer air-cooled engine serves as the core of the car, an engine used in

several later generations of classic cars and lasted 65 years in the Beetle, a saga that came to an end

when the last Beetle, number 21,529,464, rolled off the production line in Puebla, Mexico, on July 30,

2003. Initially the Type82 used a 985cc engine, later upgraded to 1131cc, then gradually increased

displacement, and in the Porsche 356 used a 1488cc engine, doubling the horsepower from the very

beginning. The cylinders of the horizontally opposed engine are distributed on both sides, a 130 motor in

the right cylinder position, and another 130 motor reserved for the left side, which can output twice as

much power when applied to the VW T1 or Porsche356 platform. The engine crankshaft flywheel is

connected by a belt to drive the generator and the cooling fan as well. The semi-circular fan fairing is a

major feature, in which the airflow is distributed to the cylinders on both sides. All is faithfully restored on

the model, meaning you can observe the blades rotating through the fan intake when the motor is

running. The Kübelwagen has 4 forward gears and the maximum speed of each gear respectively goes

as 1st gear 18.4km/h; 2nd gear 32.4km/h; 3rd gear 54.2km/h; 4th gear 83.6km/h. The corresponding red

line of gearshift tips is available on the dashboard. On the model, we designed a 2-speed shift to simulate

the speed of the 1st and 3rd gears of the real car. The power crosses over from the top of the rear axle

differential and then returns to the rear axle. The model shares the same structure as the real engine,

with the benefit of compactness, making it easy to switch between 4WD and RWD modes. This shift

function is perfectly reproduced on the model to provide more driving pleasure when driving off-road.

Background

About Model

Now let’s move to chassis. The popular portal axle in today's climbing car market has been in

mass production for barrel cars as much as 82 years ago, from which wheelside reducer reduction

ratio of 15:21 has learned a lot, making the barrel car chassis minimum ground clearance of

310mm, dwarfing all modern off-road cars on the market today. On the real car, the front and rear

wheel speeds are balanced by increasing the front axle differential gear ratio while on the model

we set the door axle reduction ratio to 1:1 for common front and rear axle differentials.

Solid load-bearing chassis with stamped central ridge tube chassis and body bears high torsional

resistance. The central drive shaft and electrical wiring are hidden in the ridge tube. The one piece

injection model features the texture of metal stamping with plastic as location and size of each

reinforcement are restored according to the actual car. The front and rear wheels adopt

torsion-bar-sprung independent suspension, allowing long travel capability with little space

occupation. We use torsion springs instead of torsion bar springs to present the front and rear

suspension, easy to disassemble and change tuning.

With regards to tires, the car adopts newly developed road tires and can be used with wheel hub

of model Kübelwagen. The simulated wheels need to be fixed with 5 screws like the real car, and

the spare tire in the front is readily accessible after opening the hood. Here you can also charge

the battery at your convenience with battery properly stored in the actual car fuel tank.

Can the doors be opened? Let’s try the door handle. Pull outward- the door can be opened with

the built-in spring lock push, when closed you can hear the spring lock crisp "kata" sound. Door

interiors are engraved with simulated fabric texture; Soft rubber seats share the same soft texture

of the actual car cushion, perfect for 1 / 12 figures. As always does, the model features a servo

operated steering wheel and front wheels for perfect synchronized action.

Generally speaking, rear passengers do not have a separate door which reduced the likelihood of

a successful escape for rear officers in an emergency. To facilitate escape in the event of an attack

and rollover, foldable soft canopy is set in the roof window. In the model, we set up a removable

plastic roof carved with a fine weave pattern to simulate the texture of the cloth canopy. When

removed, figures can be placed in the rear if you like.

For the electronic system, a 4-channel digital proportional remote control system is applied. In

addition to 1&2 channels for steering and throttle control, the 3rd channel controls the gearshift

and the 4th channel switching between 4WD and RWD. There is also integrated light control,

which allows you to turn on the headlights during normal night driving. The taillights are

accompanied by a brake linkage effect.

More exciting product features and designs are right there. Go and discover them yourself.

Length: 339mm

Width: 139mm

Height: 139mm

Wheel base: 202mm

Wheels: D:58mm , W:12mm

Departure angle: 26°

Approach angle: 31°

Motor: 130 Brushed motor

Battery : 2S Lipo 7.4V 380mAh x1

Max Speed: 8km/h

Remote control distance: 60m

Approx. operating duration time: 20mins

Remote control: 2.4G Transmitter + Three-in-one receiver

with ESC and LED light group control board

Key functions: Two-speed transmission /

4WD-RWD Mode / Smart light effect

Four-wheel independent suspension

Rear portal axles

Front and rear axle planetary gear differentials

Perfect restoration of Air-cooled horizontally

opposed four-cylinder engine

130 motor in the cylinder

Cooling fan driven by belt

The third channel for the two-speed transmission

controls

The fourth channel for switching between

4WD-RWD Mode

Servo Operated Synchronized Steering Wheel and

Front Wheels

Openable doors with spring loaded latch

Realistic fabric soft rubber seats

Openable front storage compartment hatch

Openable Engine hatch

Excellent light function

Realistic tires, wheels and spare tire

Perfect for 1/12 figures

30 stainless steel ball bearings

Full metal gears

Full metal drive shaft

4CH 2.4GHz digital proportional remote control

system

Three-in-one receiver with ESC and LED light

group control board

9G servo x 3pcs

Features

Specification

139mm

113mm

139mm 339mm

202mm

28mm 31°

26°

Transmitter intruction

Transmitter Overview

Intruction

FS-R4A1 based on ANT protocol is a three-in-one receiver with ESC and LED light group control

board. It has an external single antenna, can output PWM signal and light control signal, can

implement two-way transmission, adopts automatic binding, and has a compact design, which can be

adapted to various model cars.

Steering wheel, 35 degrees on each side

(CH1)

Throttle trigger, 25 degrees in front and

12.5 degrees at rear (CH2)

Click (CH4) [Click for the lighting effect

function, long press for other functions,

such as two/four-wheel drive switching]

Three-position toggle switch (CH3)

Lanyard hole

Handle, 4*AAA battery compartment

ST.REV

R.LED

RX.BATT

ST.D/R

TH.D/R

Switch to the electric adjustment mode

TH.REV

G.LED

BIND

ST.TRIM

TH.TRIM

Power Switch

[1]

[2]

[3]

[4]

[5]

[6]

[7]

[8]

[9]

[10]

[11]

[12]

[13]

[14]

[15]

[16]

[17]

[18]

[1]

[2]

[3]

[4]

[5]

[6]

[7] [13]

[12]

[14]

[16]

[15]

[17]

[18]

[8]

[9]

[11]

[10]

*[3]Click (CH4)Note: Not all models have this feature.

• Product Name: FS-R4A1

• Adaptive transmitter: FS-MG41

• Model Type: Car

• Channels: 4

• Numbers of Light Interfaces: 7

• RF: 2.4GHz ISM

• 2.4G Protocol: ANT

• Antenna: Single antenna

• Input Power: Lipo (2S)/NiMH (5~7Cell)

• BEC Output: 6V/1A

• Continuous/Peak Current: 10A/50A

• Data Output: PWM

• Temperature Range: -10℃ —+60℃

• Humidity Limit: 20%~95%

• WaterProof: PPX4

• Online Update: No

• Dimensions: 33mm*30mm*12mm

• Weight: About 11g

• Certification: CE, FCC ID: N4ZR4A10

Overview

Specifications

[1]

[6][7][8][9][10]

[11]

[12]

[13]

[14]

[15]

[16] [17] [18] [19] [20] [21] [22]

[23]

[24]

[25]

[2]

[3]

[4]

[5]

[1] CH1

[2] CH3

[3] CH4

[4] Left-turn light port

[5] Head light port

[6] Right-turn light port

[7] Head light port

[8] Fog light port

[9] Fog light port

[10] Antenna

[11] Power switch

[12] Battery line anode

[13] Battery line cathode

[14] Motor port "M+"

[15] Motor port "M-"

[16] Stickers

[17] LED

[18] Left-turn light port

[19] Right-turn light port

[20] Reversing light port

[21] Stop light interface

[22] Tail light interface

[23] Channel signal end

[24] Power anode

[25] Power cathode

ESC protection

This receiver has multiple prompt functions such as power-on self-check display, overheating alarm

prompt,and low/high voltage alarm prompt.

• Self-check display: all car lights will be on for 1S when the receiver is powered on;

• Overheating alarm: When the internal temperature of the ESC is detected to exceed 110 °C,motor

has no output, all car lights flash promptly, and the normal output will be restored when the

temperature is lower than 70°C;

• Low/high voltage alarm: When the receiver enters the low voltage protection, motor has no output,

and all the lights flash slowly; when the receiver enters the high voltage protection, all channels have

no output. All car lights flash promptly.

ESC function instructions

1.Connect related equipment:

Make sure the ESC is off before connection.Connect the motor with M+ and M- of ESC. Connect the

steering servo to the 3Pin interface marked with "ST" of ESC (- + S connected

correspondingly).Connect the battery with the positive and negative poles of ESC correspondingly.

2. Normal boot, identification throttle midpoint:

After connecting related equipment as step 1, turn on the radio first, move the throttle trigger to the

neutral position. Turn on the switch of ESC at last. The receiver will automatically recognize the

battery type when it is powered on again. Then it can run it.

Notes:

a. The ESC can be run after completing self-inspection (about 3 seconds) if power on, otherwise it

cannot be operated normally.

b. If there is no power output and the red light of ESC flashes quickly after power on, please check

whether the throttle trim of the transmitter is set to the "0" position, the receiver will automatically

recognize the midpoint of the trim throttle after restarting;

c. If the rotation direction is not correct during running, exchange the two wires connecting motor and

ESC.

d. To make sure everything is ok, please turn on the transmitter first and finally turn on the ESC, turn

off the ESC first and finally turn off the transmitter.

Notes: Please refer to the relevant sections for details about the battery type, drag brake force and

running mode of the ESC.

Binding

The receiver automatically enters the binding state once it is powered on.

Press the BIND Key to turn on the transmitter and allow it to enter its binding state. Here, G.LED

flashes quickly, and operator releases the BIND Key.

1. When the receiver is powered on and waits for 1 second, it will automatically enter the binding state

if it is not connected;

2. After the binding is successful, the LED indicator of the receiver is always on.

Notes: (1) Set the transmitter to its binding state first, and then set the receiver to its binding state. If

the binding is not completed within 10s, the indicator light of the receiver will enter its slow flashing

state. (2) If re-binding is successful, all the settings of the car lights will be restored to their default

values.

This function is used to protect the safety of the model and the operator when the receiver cannot

normally receive the signal from the transmitter and is out of control. The receiver defaults that the

throttle channel is fixed to be out of control and enters the brake state. After other channels are out

of control, the receiver has no signal output. If you set it on the transmitter, it will output according to

the set value.

Attention:

• Make sure the product is installed and calibrated correctly, failure to do so may result in serious

injury.

• Please carefully check each power device and car frame instructions to ensure the power matching

is reasonable before use. Avoid damaging power system due to incorrect matching.

• Do not let the external temperature of the system exceed 90°C /194°F , because high temperature

will damage the power system.

• Make sure the receiver's battery is disconnected before turning off the transmitter, failure to do so

may lead to unintended operation or loss of control.

• After use, remember to disconnect the battery and the ESC. If the battery isn't disconnected, the

ESC will consume electric energy all the time even if it is off. It will discharge completely if connect

the battery for a long time, thus resulting in the failure of the battery or the ESC. We are not

responsible for any damage caused by this!

• Make sure the receiver is mounted away from motors or any device that emits excessive electrical

noise.

• Keep the antenna of the receiver at least 1cm away from conductive materials such as carbon or

metal.

• Do not power on the receiver during the setup process to prevent loss of control.

Failsafe

ESC Parameter Setting

Dial Switch sign

Running Mode

FWD/REV/BRK

FWD/REV

Lipo

NiMH

50%

75%

100%

Battery Type Drag Brake

Setting Method:

There are three parameters can be set for the ESC, which are "Running mode", "Battery type", "Drag

brake", There are slide switches numbered 1 2 3 4 on the radio panel . The above parameters can be

set by dialing down and up.

The specific operation is as follows:

The Dial Switch on the transmitter is used to set ESC parameters, that is, the Dial Switch is located

at different positions and the corresponding parameter values are different.

When No. 1 slide switch is on the down, it indicates that the operation mode is set to

FWD / REV / BRK.

When No. 1 slide switch is on the up, it indicates that the operation mode is set to FWD/REV.

When No. 2 slide switch is on the down, it indicates that the battery type is set to Lipo.

When No. 2 slide switch is on the up, it indicates that the battery type is set to NiMH.

When No. 3 and No.4 slide switch are on the down, it indicates that the drag brake force is set to 0%.

When No. 3 slide switch is on the down and No.4 slide switch is on the up, it indicates that the drag

brake force is set to 50%.

When No. 3 slide switch is on the up and No.4 slide switch is on the down, it indicates that the drag

brake force is set to 75%.

When No. 3 and No.4 slide switch are on the up, it indicates that the drag brake force is set to 100%.

Parameter Explanation:

1. Running Mode

FWD/REV/BRK: This mode adopts "double click” reverse mode, that is, when the throttle trigger is

pushed from netural range to the reverse area for the first time, the motor is only braking and will not

reverse; when the throttle trigger is moved back to the netural range and pushed to the reverse area

for the second time, it will reverse. This mode is applicable to general models.

FWD/REV: This mode adopts "one click" reverse mode, that is, when the throttle trigger is pushed

from netural range to the reverse area, the motor immediately generates reverse action, which is

generally applied to rock crawler.

Parameter setting method:

When No. 1 slide switch is on the down, it indicates that the operation mode is set to FWD / REV /

BRK.

When No. 1 slide switch is on the up, it indicates that the operation mode is set to FWD/REV.

2. Battery Type

There are LiPo and NiMH cells. The low-pressure protection value is different under different types.

It can be set according to the actual use.

Parameter setting method:

When No. 2 slide switch is on the down, it indicates that the battery type is set to Lipo.

When No. 2 slide switch is on the up, it indicates that the battery type is set to NiMH.

3. Drag Brake Force

The drag brake means that when the throttle trigger moves from the forward or reverse area to netural

range, it will produce certain braking force to the motor, the larger the value is, the greater the drag

brake force is. Select proper braking force according to the actual situation.

Parameter setting method:

When No. 3 and No.4 slide switch are on the down, it indicates that the drag brake force is set to 0%.

When No. 3 slide switch is on the down and No.4 slide switch is on the up, it indicates that the drag

brake force is set to 50%.

When No. 3 slide switch is on the up and No.4 slide switch is on the down, it indicates that the drag

brake force is set to 75%.

When No. 3 and No.4 slide switch are on the up, it indicates that the drag brake force is set to 100%.

Lighting function

Getting started

Transmitter Battery Installation
