Rock-N-Roller Multi-Cart R64C User manual

R6RT Model Specifications Your RocknRoller Multi-Cart shipping box should
contain a frame and the following parts: Recommended Tools For Assembly
Length (Compact) 28” 4 x ½” at washers
Length (Extended) 42.5” 4 x ½” lock nuts Channel Lock Pliers
(not included)
Width (Frame Bed) 12.5” 1 x 1” (25 mm) square plastic endplug (spare)
Width (Rear Casters) 18” 1 x ¾” (20 mm) square plastic endplug (spare)
Height (Folded) 9.5” 4 x 4”x 1” (100 mm x 25 mm) stem casters
Height (Unfolded) 33.25” 1 x Flat Wrench
Front Casters 4” x 1” 1 x Assembly/instruction sheet
Rear Casters 8” x 2.5” 2 x 570 mm Non-skid Tape (optional - place where preferred)
Weight 22 lbs.
Load Capacity 500 lbs.
Installing Swivel Casters
Attach swivel casters as shown. While tightening lock nuts, grip bearing cap with channel lock pliers or pipe wrench to prevent
threaded stem from turning. Tighten lock nuts rmly, but not excessively tight. Check lock nut tightness on caster stems periodically.

Extending Frame
Loosen wingbolts 1/4 turn. Step on
rear axle and push in extension
stop button. Pull up on frame as
shown until stop button engages.
Retighten wingbolts.
Raising Foldable Sides
Firmly press down on release cable
while raising other end of foldable
side as shown.
Repeat with other side.
Removable Shelves Solid Deck Cable/headphone
hanger Laptop Shelf Flex Straps
