Rockwell Automation Allen-Bradley 9000 Series User manual

Technical Data
Original Instructions
Series 9000 Photoelectric Sensors Specifications
Bulletin Numbers 42GLP, 42GRC, 42GRF, 42GRL, 42GRP, 42GRR, 42GRU, 42GSP, 42GTC, 42GTF, 42GTP, 42GTR, 42GTU
Summary of Changes
This publication contains the following new or updated information.
This list includes substantive updates only and is not intended to
reflect all changes.
Product Overview
The Series 9000™ Photoelectric Sensors include the following
features:
• Extended sensing range for maximum application flexibility
• Class 1 laser models ideal for the detection of small parts
• DC (PNP and NPN) and AC/DC (relay output, solid-state)
models
• Time delay models
• Dual (NPN and PNP) output models
• IP69K, IP67 with 1200 psi, NEMA, and ECOLAB rated
enclosures
Available Models
The following standard models are available:
• Retroreflective
• Polarized retroreflective
• Clear object detection
• Diffuse
• Transmitted beam
• Large aperture fiber-optic
• Small aperture fiber-optic
The following laser models are available:
• Polarized retroreflective
• Standard diffuse
Topic Page
Summary of Changes 1
Product Overview 1
Specifications 2
Sensor User Interface 5
Wiring Diagrams 6
Approximate Dimensions 7
Typical Response Curves 8
Topic Page
Updated Bulletin Number list. 1
Updated transmitted beam operating voltage in Table 6.3

2Rockwell Automation Publication 42G-TD001C-EN-P - June 2022
Series 9000 Photoelectric Sensors Specifications Technical Data
Specifications
Optical and Response Time Characteristics
Table 1 - All Models
Attribute Value
Certifications cULus Listed, CSA Certified, and CE Marked for all applicable
directives
Shock 30 g with 1 ms pulse duration, meets or exceeds IEC 60947-5-2
Vibration 10…55 Hz, 1 mm amplitude, meets or exceeds IEC 60947-5-2
Environmental
Enclosure type rating IP69K, IP67 with 1200 psi; NEMA 3, 4X, 6P, 12, 13; ECOLAB rated
Relative humidity 5…95%
Ambient light immunity Incandescent light 5000 lux
Electrical
Operating voltage See Table 6 on page 3.
Mechanical
Material •Housing:Valox®
•Lens:Acrylic
Connection type See Table 6 on page 3.
Table 2 - Standard Models
Attribute Value
Environmental
Operating temperature -34…+70 °C (-29…+158 °F)
User Interface
Status indicator See Table 8 on page 5.
Electrical
Current consumption 30 mA max
Protection type
• Short circuit
• Reverse polarity
•Falsepulse
•Overload
Outputs
Output type See Table 6 on page 3.
Output function Selectable light or dark operate
Load current • 250 mA at 30V DC (all models except 42GLP and 42GSP) • 2 A at 132V AC and 1 A at 264V AC (SPDT relay models)
• 300 mA at 264V AC (MOSFET models)
Table 3 - Laser Models
Attribute Value
Environmental
Operating temperature -10…+50 °C (-14…+122 °F)
Electrical
Current consumption,
max
• DC models: 45 mA
• AC/DC models: 10 mA
• AC models: 70 mA
Protection type • Overload and short circuit (DC models) •Reversepolarity
•Falsepulse
Outputs
Output type See Table 6 on page 3.
Output function Selectable light or dark operate
Leakage current, max 10 µA (DC models)
Table 4 - Optical and Response Time Characteristics—Standard and I ntrinsically Safe Transmitted Beam Models
Attribute
Sensing Mode
Retroreflective Polarized
Retroreflective Diffuse Transmitted Beam Small Aperture Fiber Optic
Large Aperture
Fiber Optic
Field of view 1.5° 3.5° for 1.5 m (4.92 ft)
6.5° for 3 m (9.8 ft) and 4 m (13 ft) range 1.5° Depends on fiber-optic cable
Light source Visible red 660 nm Infrared 880 nm
Response time 2 ms (DC), SPDT EM relay (15 ms), 2 ms (MOSFET AC/DC)
Table 5 - Optical and Response Time Characteristics—Laser Models
Attribute Sensing Mode
Polarized Retroreflective Diffuse
Spot size 20 x 25 mm (0.98 in.) at 40 m (131.23 ft) 2 x 3.5 mm (0.14 in.) at 800 nm
Response time 0.5 ms

Rockwell Automation Publication 42G-TD001C-EN-P - June 2022 3
Series 9000 Photoelectric Sensors Specifications Technical Data
Product Selection
Table 6 - Product Selection
Sensing Mode Operating Voltage Light
Source
Sensing
Distance Output Type Sensor Type Cat. No. (1)
10…30V DC
Visible red
660 nm 0.050…9.1 m (0.16…30 ft)
PNP and NPN Standard ON/OFF 42GRU-9000-QD
NPN and PNP Timing 42GTU-9000-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRU-9001-QD
Timing 42GTU-9001-QD
70…264V AC/DC
Standard ON/OFF 42GRU-9002-QD
Timing 42GTU-9002-QD
N-MOSFET Standard ON/OFF 42GRU-9003-QD
Timing 42GTU-9003-QD
10…30V DC
Visible red
660 nm 0.050…4.9 m (0.16…16 ft)
NPN and PNP Standard ON/OFF 42GRU-9200-QD
Timing 42GTU-9200-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRU-9201-QD
Timing 42GTU-9201-QD
70…264V AC/DC
Standard ON/OFF 42GRU-9202-QD
Timing 42GTU-9202-QD
N-MOSFET Standard ON/OFF 42GRU-9203-QD
Timing 42GTU-9203-QD
10…30V DC Class 1
Laser 0.3…40 m (1…130 ft)
NPN and PNP (DC only),
EM relay Standard ON/OFF 42GRU-92L0-QD
105…132V AC SPDT EM relay Standard ON/OFF 42GRU-92L2-QD
10…30V DC
Visible red
660 nm 0.050…1.2 m (0.16…4 ft)
NPN and PNP Standard ON/OFF 42GRC-9200-QD
Timing 42GTC-9200-QD
70…264V AC/DC
SPDT EM relay Standard ON/OFF 42GRC-9202-QD
Timing 42GTC-9202-QD
N-MOSFET
Standard ON/OFF 42GRC-9203-QD
Timing 42GTC-9203-QD
10…264V AC/DC
Infrared
880 nm
0.025…61 m
(0.83…200 ft) — (Emitter) —
42GRL-9000-QD
0.025…152 m
(0.83…500 ft) 42GRL-9040-QD
1…30V DC
Depends on
transmitted
beam emitter
NPN and PNP Standard ON/OFF 42GRR-9000-QD
Timing 42GTR-9000-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRR-9001-QD
70…264V AC/DC
Standard ON/OFF 42GRR-9002-QD
Timing 42GTR-9002-QD
N-MOSFET
Standard ON/OFF 42GRR-9003-QD
0.050…4.9 m
(0.16…16 ft) Timing 42GTU-9203-QD
Object
to be
Sensed
Retroreflective
Object
to be
Sensed
Polarized Retroreflective
Object
to be
Sensed
Clear Object Detection
Object
to be
Sensed
Transmitted Beam

4Rockwell Automation Publication 42G-TD001C-EN-P - June 2022
Series 9000 Photoelectric Sensors Specifications Technical Data
10…30V DC
Visible red
660 nm 0.050…1.5 m (0.16…5 ft)
NPN and PNP
Standard ON/OFF
Linear Adjustment 42GLP-9000-QD
Standard ON/OFF
Teach Push Button 42GSP-9000-QD
Standard ON/OFF 42GRP-9000-QD
Timing 42GTP-9000-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRP-9001-QD
Timing 42GTP-9001-QD
70…264V AC/DC
Standard ON/OFF 42GRP-9002-QD
Timing 42GTP-9002-QD
N-MOSFET Standard ON/OFF 42GRP-9003-QD
Timing 42GTP-9003-QD
10…30V DC Class 1
Laser 1…800 mm (0.03…31.5 in.)
NPN and PNP Standard ON/OFF 42GRP-92L0-QD
105…132V AC SPDT EM relay 42GRP-92L2-QD
10…30V DC
Infrared
880 nm
0.050…3.04 m
(0.16…10 ft)
NPN and PNP Standard ON/OFF 42GRP-9040-QD
Timing 42GTP-9040-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRP-9041-QD
Timing 42GTP-9041-QD
70…264V AC/DC Standard ON/OFF 42GRP-9042-QD
Timing 42GTP-9042-QD
70…264V DC;
40…264V AC N-MOSFET Standard ON/OFF 42GRP-9043-QD
Timing 42GTP-9043-QD
10…30V DC 0.050…4.2 m
(0.16…14 ft) NPN and PNP Standard ON/OFF 42GRP-9070-QD
70…264V AC/DC 50.8 mm…4.2 m
(2 in.…14 ft) SPDT EM relay Standard ON/OFF 42GRP-9072-QD
10…30V DC
Visible red
660 nm Depends on fiber-optic cable
NPN and PNP Standard ON/OFF 42GRF-9100-QD
Timing 42GTF-9100-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRF-9101-QD
Timing 42GTF-9101-QD
70…264V AC/DC
Standard ON/OFF 42GRF-9102-QD
Timing 42GTF-9102-QD
N-MOSFET Standard ON/OFF 42GRF-9103-QD
Timing 42GTF-9103-QD
10…30V DC
Infrared
880 nm Depends on fiber-optic cable
NPN and PNP Standard ON/OFF 42GRF-9000-QD
Timing 42GTF-9000-QD
10…55V DC;
20…40V AC SPDT EM relay
Standard ON/OFF 42GRF-9001-QD
Timing 42GTF-9001-QD
70…264V AC/DC
Standard ON/OFF 42GRF-9002-QD
Timing 42GTF-9002-QD
N-MOSFET Standard ON/OFF 42GRF-9003-QD
Timing 42GTF-9003-QD
Recommended DC micro (M12) quick-disconnect cordset, straight, 4-pin, 2 m (6.6 ft) 889D-F4AC-2
Recommended DC pico (M8) quick-disconnect cordset, straight, 4-pin, 2 m (6.6 ft) 889D-F4AB-2
(1) Connection Options: The -QD suffix describes a 4-pin DC micro (M12) integral QD for DC models, a 5-pin mini QD for SPDT EM Relay models, and a 4-pin mini (M12) integral QD for N-MOSFET
models.
For additional connection options:
- Remove the -QD suffix for a 2 m (6.6 ft) cable without QD (Example: 42GRU-9200).
- For NPN and PNP models replace the -QD suffix with a -QD1 for a 4-pin mini-integral QD (for example, 42GRU-9200-QD1). For N-MOSFET models, replace the -QD suffix with a -QD1 for a 4-pin
AC micro (M12) integral QD (for example, 42GRU-9203-QD1).
- See ProposalWorks™ for available connection options in 600V 2 m (6.6 ft) cables.
Table 6 - Product Selection (Continued)
Sensing Mode Operating Voltage Light
Source
Sensing
Distance Output Type Sensor Type Cat. No. (1)
Object
to be
Sensed
Diffuse
Object
to be
Sensed
Small Aperture Fiber Optic
Object
to be
Sensed
Large Aperture Fiber Optic

Rockwell Automation Publication 42G-TD001C-EN-P - June 2022 5
Series 9000 Photoelectric Sensors Specifications Technical Data
Cordsets and Accessories
Sensor User Interface
(1) Transmitted beam receivers do not have a flashing (low margin) state.
(2) The sensors timing can be set as short (0…1.5 s) or long (0…15 s).
Description Cat. No.
Cordsets
AC micro QD, straight, 4-pin, 2 m (6.5 ft) 889D-F4AEA-2
Mini QD, 1.8 m (6 ft) 5-pin 889N-F5AF-6F
Mini QD, 2 m (6 ft) 4-pin 889N-F4AF-6F
Mounting bracket 30 mm (1.2 in.) swivel/tilt 60-2439
Heavy-duty impact 60-2702
Spare reflector,
corner cube
76 mm (3 in.) diameter with mounting hole 92-39
32 mm (1.25 in.) diameter with mounting hole 92-47
Extended range lens assembly [260 °C (500 °F)] 60-1844
60-2559
Fiber-optic cable lens extender 60-2738
Table 7 - Standard Sensors
42GRx Versions — Top View Detail Status Indicator Color State Status
Red OFF Margin < 2.5X
ON Margin > 2.5X
Green OFF Output is de-energized
ON Output is energized
Yellow OFF Power is OFF
ON Power is ON
Table 8 - Time Delay Sensors
42GTx Versions — Top View Detail Status Indicator Color State Status
Red OFF Margin < 2.5X
ON Margin > 2.5X
Green OFF Output is de-energized
ON Output is energized
Yellow
OFF Power is OFF
ON Power is ON
Sensitivity Adjustment (1)
Red Indicator
Green Indicator
Yellow Indicator
Light/Dark Operate Switch (1)
Sensitivity Adjustment
Select Short/Long Off Delay (2)
Select Short/Long On Delay (2)
Select Light/Dark Operate
Red Margin SCP Indicator
Green Output Indicator
Yellow Power Indicator
Off Delay Adjustment
Select One Shot Operate
On Delay Adjustment

6Rockwell Automation Publication 42G-TD001C-EN-P - June 2022
Series 9000 Photoelectric Sensors Specifications Technical Data
Wiring Diagrams
Figure 1 - Standard and Laser Models
(1) Load can be placed on either black wire to create sourcing or on white wire to create sinking.
IMPORTANT Do not connect an NPN and PNP load simultaneously.
1 Brown
2 White: NPN
4 Black: PNP
3 Blue
2 Red w/White
4 Green No Conn.
3 Red
1 Red w/Black
3 Brown
4 White: NPN
1 Black: PNP
2 Blue
TT
T T
(+)
( - )
Brown
White: NPN
Black: PNP
Blue
(+)
( - )
Load
Brown
White
Black
Blue
(+) ~
( - ) ~
3 Brown
4 White
1 Black
2 Blue
Brown
Orange (C)
Black (NO)
Blue
White (NC)
4 Brown
3 Orange (C)
1 Black (NO)
2 Blue
5 White (NC)
(+) ~
( - ) ~
(+)
( - )
Load Load
Load
Load Load
(+) ~
( - ) ~
Load
(+) ~
( - ) ~
(+) ~
( - ) ~
4 White
Brown
Blue
(+) ~
( - ) ~
3 Brown
1 Black
2 Blue
(+) ~
( - ) ~
Not Used
Not Used
2 White
1 Brown
4 Black
3 Blue
(+) ~
( - ) ~
Not Used
Not Used
4 Green
1 Red w/Black
3 Red
2 Red w/White
(+) ~
( - ) ~
Not Used
Not Used
Load
Load
3
2
4
1
32
41
(1) (1)
Cable Model: 9_ _0 4-pin DC Micro QD Model: 9_ _0-QD 4-pin DC Mini QD Model: 9_ _0-QD1
Cable Model: 9_ _1, 9_ _2 5-pin AC/DC Mini QD Model: 9_ _1-QD, 9_ _2-QD
Transmitted Beam Source
Cable Model: 42GRL-90_ _ AC/DC Mini QD Model: 42GRL-9_2-QD
DC Micro QD Model: 42GRL-9_0-QD 4-pin DC Micro QD Model: 42GRL-90_3-QD1
Cable Model: 9_ _3 AC/DC Mini QD Model: 9_ _3-QD AC/DC Micro QD Model: 9_ _3-QD1

Rockwell Automation Publication 42G-TD001C-EN-P - June 2022 7
Series 9000 Photoelectric Sensors Specifications Technical Data
Approximate Dimensions
Dimensions are shown in mm (in.). Dimensions are not intended to be used for installation purposes.
Figure 2 - All Versions (Except Fiber Optic) — Cable Version
Figure 3 - Fiber-optic Versions — Cable Version
Figure 4 - ClearSight™ 9000 Sensor — Cable Version
Figure 5 - Connector Version
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
32.66
(1.286)
16.76
(0.660) 2.0 m (6.5 ft)
Cable Length
6.5 (0.255/0.245) dia.
74.93
(2.950) 69.85
(2.750)
55.62
(2.190)
31.75 (1.250)
103.63
(4.080)
Max Travel
40.00
(1.575)
20.98
(0.825)
15.24
(0.600)
7.62
(0.300)
41.91
(1.650)
30.35
(1.195)
24.69
(0.970)
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
15.87 (0.625)
5.46 (0.215)
27.05
(1.065)
42.41 (1.670)
47.75
(1.880)
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
103.63
(4.080)
Max Travel
2.0 m (6.5 ft) Cable Length
6.47/6.22 (0.255/0.245) dia.
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
M30 x 1.5
External Thread
1/2 in. NPSM
Internal Thread
32.66
(1.286)
2.0 m (6.5 ft.)
Cable Length
6.47/6.22
(0.25/0.24) dia.
13.33
(0.52)
6.12
(0.24)
40.00
(1.575)
16.76 (0.66)
55.62
(2.190)
103.63
(4.080)
Max Travel
31.75 (1.250)
69.85
(2.750)
74.93
(2.950)
30.35
(1.19)
24.64
(0.97)
5.21 (0.20) x
8.13 (0.32)
Slots, 2 Places
15.24
(0.60)
7.62
(0.30)
20.96
(0.82)
27.05
(1.06)
5.46
(0.21)
15.87
(0.62)
Mounting
Hole
Centerline
41.91
(1.65)
42.42
(1.67)
47.75
(1.88)
103.63
(4.080)
Max Travel
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread 2.0 m (6.5 ft)
Cable Length
6.47/6.22 (0.255/
0.245) dia.
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
Mounting
Hole
Centerline
Table 9 - Thread Sizes
Style AC DC
Micro 1/2-20 UNF
2 keyways M12 x 1 1 keyway
Mini 7/8-16 UN
1 keyway
97
(3.8) 32.89
(1.295)
Cable Length
2 m (6.5 ft)
6.47/6.22
(0.255/0.245) Dia.
39.50
(1.555)
65.23 (2.568)
100.60 (3.961)
Max. Travel
120°
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread
25.1
(0.99)
68.07
(2.68)
}
42.41
(1.670)
41.91
(1.65)
15.87 (0.625)
47.88
(1.885)
5.46 (0.215)
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Plcs.
24.64 (0.970)
30.35 (1.195)
Centerline of Slots
13.41 (0.528)
20.96 (0.825)
Top View
100.60 (3.961)
Max Travel
Top View
Centerline of Slots
5.21 (0.205) x
8.13 (0.320)
Slot, 2 Places
M30 x 1.5 External
Thread 1/2 in. NPSM
Internal Thread
Cable Length 2 m (6.5 ft)
6.47/6.22 (0.255/0.245) Dia.
13.97 (0.550) 17.78 (0.700)
Micro Style Mini Style
Micro Style Mini Style

8Rockwell Automation Publication 42G-TD001C-EN-P - June 2022
Series 9000 Photoelectric Sensors Specifications Technical Data
Typical Response Curves
Table 10 - Non-clear Object Detection Versions
Retroreflective Polarized Retroreflective Standard Diffuse Long Range Diffuse
Transmitted Beam with 61 m (200 ft)
Light Source Visible Red Fiber Optic
Standard Diffuse
Visible Red Fiber Optic
Transmitted Beam Small Aperture Fiber Optic
Retroreflective
Large Aperture Fiber Optic
Standard Diffuse Large Aperture Fiber Optic
Transmitted Beam
Large Aperture Fiber Optic
Retroreflective
Table 11 - Clear Object Detection Versions
Response Curve Beam Pattern
76 (3)
Reflector
16 (0.625)
Reflector
32 (1.25)
Reflector
Distance [mm (in.)]
Operating Margin
0.3 m
(1 ft)
51
(2)
15 m
(50 ft)
1.5 m
(5 ft)
0.6 m
(2 ft)
3 m
(10 ft)
1
2
4
8
10
20
40
80
100
1
2
4
8
10
20
40
80
100
Operating Margin
Distance [mm (in.)]
51
(2)
152
(6)
1.5 m
(5 ft)
0.3 m
(1 ft)
6 m
(20 ft)
3 m
(10 ft)
15 m
(50 ft)
76 (3)
Reflector
16 (0.625)
Reflector
32 (1.25)
Reflector
Operating Margin
51
(2)
1
2
4
8
10
20
40
80
100
152
(6)
1.5 m
(5 ft)
0.6 m
(2 ft)
3 m
(10 ft)
6 m
(20 ft)
0.3 m
(1 ft)
White Paper,
216 x 279.4
(8.5 x 11)
Distance [mm (in.)]
Operating Margin
Distance [mm (in.)]
1
1000
254
(10)
2540
(100)
25400
(1000)
10
100
25.4
(1)
9072
9040
Operating Margin
Distance [m (ft)]
0.3
(1)
10
4
1
100
40
1000
400
10000
4000
1.8
(5) 3 (10) 15 (50) 30 (100) 150 (500)
900X
904X
Distance [mm (in.)]
Operating Margin
25.4
(1.0)
10000
4000
1000
400
100
40
10
4
1
0.6 m
(2 ft)
2.54
(0.1) 0.3 m (1 ft)
76.2
(3.0)
White Paper
216 X 279.4
(8.5 x 11)
2.3 (0.09) Glass Fiber
1.0 (0.04) Plastic Fiber
0.5 (0.02) Plastic Fiber
0.5 (0.02) Plastic Fiber Bundle
1.0 (0.04) Plastic Fiber Coiled
Distance [mm (in.)]
Operating Margin
0.3 m
(1 ft)
25.4
(1.0)
10000
4000
1000
400
100
40
10
4
1
0.6 m
(2 ft)
2.54
(0.1) 76.2 (3.0)
1.5 (0.6) Glass Fiber
1.0 (0.04) Plastic Fiber
0.5 (0.02) Plastic Fiber
0.5 (0.06) Plastic
Fiber Coiled
1.0 (0.04) Plastic
Fiber Coiled
Distance [mm (in.)]
Operating Margin
1.0 (0.04)
Plastic Fiber
2.3 (0.09)
Glass Fiber
With 76 (3)
Reflector
0.5 (0.02)
Plastic Fiber
Coiled
1.0 (0.04) Plastic
Fiber Coiled
0.5 (0.02)
Plastic Fiber
10000
4000
1000
400
100
40
10
4
1
0.3 m
(12 ft)
76.2
(3)
0.6 m
(24 ft)
2.54
(0.1)
25.4
(1)
1.5 m
(5 ft)
Operating Margin
Distance [mm (in.)]
0.61 m
(2 ft)
152.4
(6.0)
0.3 m
(1 ft)
2.54
(0.1)
25.4
(1.0)
10000
4000
1000
400
100
40
10
4
1
White Paper
216 x 279.4
(8.5 x 11)
3.18 (0.125) Glass Fiber
1.52 (0.06) Glass Fiber
0.69 (0.027) Glass Fiber
Operating Margin
Distance [mm (in.)]
0.69 (0.027) Glass Fiber
3.18 (1.25) Glass Fiber
1.52 (0.060) Glass Fiber
10000
4000
1000
400
100
40
10
4
1
0.61 m
(2 ft)
152.4
(6.0) 0.3 m (1 ft)
2.54
(0.1) 25.4 (1.0)
Operating Margin
Distance [mm (in.)]
1.52 (0.060)
Glass Fiber
3.18 (0.125)
Glass Fiber
0.69 (0.027)
Glass Fiber
1.5 m
(5 ft)
With 78 (3)
Reflector
0.3 m
(1 ft)
2.54
(0.1)
25.4
(1.0)
10000
4000
1000
400
100
40
10
4
1
Operating Margin
10
1
254
(10) 2540 (100)
25.4
(1)
Distance to Reflector [mm (in.)]
Distance with 92-90
Reflector [mm (in.)]
Beam Diameter [mm]
-0.2
0.2
0.4
0.6
0 304
(12) 609 (24) 914
(36)
0.8
1
0
1219
(48)
-0.4
-0.6
-0.8
-1

Rockwell Automation Publication 42G-TD001C-EN-P - June 2022 9
Series 9000 Photoelectric Sensors Specifications Technical Data
Notes:

Publication 42G-TD001C-EN-P - June 2022
Supersedes Publication 42G-TD001B-EN-P - March 2022 Copyright © 2022 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Rockwell Automation Support
Use these resources to access support information.
Documentation Feedback
Your comments help us serve your documentation needs better. If you have any suggestions on how to improve our content, complete the
form at rok.auto/docfeedback.
Technical Support Center Find help with how-to videos, FAQs, chat, user forums, and product notification updates. rok.auto/support
Knowledgebase Access Knowledgebase articles. rok.auto/knowledgebase
Local Technical Support Phone Numbers Locate the telephone number for your country. rok.auto/phonesupport
Literature Library Find installation instructions, manuals, brochures, and technical data publications. rok.auto/literature
Product Compatibility and Download Center
(PCDC)
Download firmware, associated files (such as AOP, EDS, and DTM), and access product
release notes. rok.auto/pcdc
Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec.
Allen-Bradley, ClearSight, expanding human possibility, ProposalWorks, Rockwell Automation, and Series 9000 are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Otomasyon Ticaret A.Ş. Kar Plaza İş Merkezi E Blok Kat:6 34752, İçerenköy, İstanbul, Tel: [phone] EEE Yönetmeliğine Uygundur
