Rockwell Automation Allen-Bradley VisiSight 42JS Series User manual

Installation Instructions
Original Instructions
VisiSight Photoelectric Sensors
Catalog Numbers 42JS-B2MNB1-x, 42JS-B2MNB2-x, 42JS-B2MPB1-x, 42JS-B2MPB2-x, 42JS-D2MNA1-x, 42JS-D2MNA2-x, 42JS-D2MPA1-x, 42JS-
D2MPA2-x, 42JS-E1EZB1-x, 42JS-E2EZB1-x, 42JS-P2MNA2-x, 42JS-P2MNB1-x, 42JS-P2MPA2-x, 42JS-P2MPB1-x, 42JS-R9MNA1-x, 42JS-R9MNA2-x,
42JS-R9MPA1-x, 42JS-R9MPA2-x
Description
The 42JS VisiSight™ family of sensors offers a full range of sensing
modes in miniature rectangular housing. Visible light source is offered
in all models for ease of alignment. Additional transmitted beam
infrared status-indicator source models are offered for excellent
crosstalk immunity.
The 42JS VisiSight family provides an indication if the sensor operation
is unstable. An indicator flashes if the signal level is too close to the
detection threshold. This indicator helps in easy alignment of the sensor
and forewarns against detection of a background.
Features
• Visible light source that is offered on all models for ease of
alignment
• Optional snap-on adapter for 18 mm mounting
• Patented ASIC design offers linear sensitivity adjustment,
stability indication, and excellent noise immunity
• Compact sealed housing and cavity-free design to minimize
collection of dust and debris while allowing for easy sensor
cleanup
• Threaded metal M12 or M8 connector on pigtail
•360° visible status indicators
• Additional transmitted beam models available with Infrared
light source for excellent cross talk immunity
• Input to disable light source on transmitted beam emitter
Specifications
Electrical
Outputs
Topic Page
Description 1
Features 1
Specifications 1
Sensor Indicators 2
Wiring Diagrams 3
Dimensions 3
Accessories 3
Typical Response Curves 5
Margin Curves 6
Attribute 42JS
Environmental
Operating Environment IP67
Operating Temperature -20…+60°C (-4…+140°F)
Vibration 10…55 Hz, 1 mm amplitude; meets or exceeds IEC 60947- 5- 2
Shock 30 g (1.06 oz) with 1 ms pulse duration; meets or exceeds IEC 60947- 5- 2
Relative Humidity 5…95% (noncondensing)
Ambient Light Immunity Incandescent light 5000 Lux
Optical Standard
Diffuse
Background
Suppression
Polarized
Retro
Transmitted
Beam
Sensing Range 1800 mm (31.5in.) 4
250 mm (9.8 in.) 5
6…55 mm
(0.24…2.17 in.) 2
2…130 mm
(0.07…5.12 in.) 3
30 mm…3.0 m
(1.18 in…9.84 ft) 10 m (32.8 ft)
Field of View 4° 414° 2
2.8° 4°
5.5° 517° 3
Spot Size at max. rated
range
60 mm
(2.36 in.) 47.6 mm (0.30 in.)
@ 55 mm (2.16 in.)
2175 mm
(6.89 in.)
700 mm
(27.56 in.)
40 mm
(1.57 in.) 5
11.5 mm (0.45 in.)
@ 130 mm
(5.12in.)3
Light Source Visible red (645 nm)
Visible red (645
nm)
& Infrared (850
nm)
Sensitivity Adjustments Single-turn
potentiometer No adjustment
Single-turn
potentiometer
adjustment and no
adjustment models
Single-turn
potentiometer
Voltage 10…30V DC
Current Consumption 25 mA
Protection Short circuit, overload, false pulse, transient noise, reverse polarity
Response Time 1 ms
Output Type PNP or NPN by cat. no.
Output Mode Complementary light and dark operate
Output Current 100 mA
Output Leakage Current 10 µA max

2Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017
VisiSight Photoelectric Sensors
Mechanical
1 See Typical Response Curves for sensing range with the 18 mm (0.71 in.) mounting adapter.
2 For 55 mm (2.16 in.) background suppression models (42JS- B2MNB1- F4 and 42JS- B2MPB1- F4).
3 For 130 mm (5.12 in.) background suppression models (42JS- B2MNB2- F4 and 42JS- B2MPB2- F4).
4 For 800 mm (31.49 in.) diffuse models (42JS- D2MNA1- F4 and 42JS- D2MPA1- F4).
5 For 250 mm (9.8 in.) diffuse models (42JS- D2MNA2- F4 and 42JS- D2MPA2- F4).
Sensor Indicators
Indicator Status
6 Black wire or pin four of connector.
Background Suppression Sensors
Sensor Alignment
1. Verify that the sensitivity knob is set at its maximum (factory
default) setting.
2. Pan the sensor to the left, right, up, and down to center the beam on
the sensed object (for diffuse), reflector (for retroreflective), or
transmitter (for transmitted beam). Affix the sensor position when
the green status indicator is ON (not flashing) and the yellow
output indicator is ON (light sensed and L.O. output energized).
This configuration assures a good margin and that the signal
received is greater than twice the signal that is required to energize
the L.O. output.
3.
a. For diffuse applications, remove the object being sensed and
observe the green status indicator. If the green indicator is
flashing (at 6 Hz), the sensor is receiving more than half the
signal required to energize the L.O. output when there can be
minimal or no received signal. It indicates that the sensor is
getting close to detection of the background. Stability can be
optimized by reducing the reflectivity of the background or
reducing the sensitivity. Reduce the sensitivity to shorten the
sensing range. If sensitivity is reduced, check that both the green
and yellow indicators are on when the object is detected (step 2).
In applications where the full range is needed, for example,
sensitivity cannot be reduced, the green indicator can be left
flashing.
b. For retroreflective and transmitted beam applications, place the
object to be sensed in the beam path and observe the green
indicator. If the green indicator is flashing (at 6Hz), that sensor
is receiving more than half the signal required to energize the
L.O. output when there can be minimal or no signal received. It
indicates that the object being detected is letting some light go
through (semi-transparent or too small). Adjust sensitivity and
repeat step 2.
Crosstalk Avoidance
For applications of transmitted-beam sensors which require adjacent
pairs to be mounted close, use the red indicator and infrared indicator
pairs as adjacent pairs.
The following spacing (center to center) between the adjacent pairs can
be maintained to avoid crosstalk:
1. Red indicator pair that is adjacent to the infrared indicator pair:
a. 60 mm (2.4 in.) for sensing range up to 1.6 m (4.8 ft)
b. 20 mm (0.8 in.) for sensing range greater than 1.6 m (4.8 ft)
2. Two adjacent pairs of red indicator models or two adjacent pairs of
infrared indicators: 360 mm (14 in.).
Housing Material ABS
Lens Material PMMA
Cover Material PMMA
Connection Types 2 m (6.5 ft) cable, 4-pin DC micro (M12) QD, 4-pin pico (M8) QD
Supplied Accessories Mounting hardware (M3x25) stainless steel screws
Optional Accessories Snap-on adapter for 18 mm mounting (IP40), mounting brackets, cordsets,
reflectors
Indicator Color State Function
Green
OFF Power is Off
ON Power is On
Flashing (6 Hz) Unstable (0.5 < Margin < 2)
Flashing (1.5 Hz) Output short circuit protection active
Yellow OFF Output de-energized 6
ON Output energized 6
Yellow Output
Status Indicator
Sensitivity
Adjustment Knob
Minimum Maximum
Green Status
Indicator
Target
IMPORTANT Due to the detection method, targets traveling horizontally to
the sensor optics are detected. Targets traveling vertically
cannot be accurately detected. For excellent reliable
background suppression, a minimum separation distance of
6mm (0.24in.) is recommended between the target and the
background.

Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017 3
VisiSight Photoelectric Sensors
Two pairs of red indicators or two pairs of infrared indicators can be
mounted adjoining each other by transposing the emitter and receiver
positions of the second pair vs. the first pair. There is no crosstalk as
each receiver only receives signal from one emitter.
Mounting the Sensor
Securely mount the sensor on a firm, stable surface, or support. An
application that is subject to excessive vibration or shifting can cause
intermittent operation. Adapters and mounting brackets are available
for a flexible installation that can may include vibration and shock while
shifting. See Accessories on page 3 for more details.
Wiring Diagrams
Cable connection is shown in the following diagrams. Pin numbers
correspond to an M12 or M8 male connector on the sensor.
PNP Models with Complementary Outputs
Transmitted Beam Emitter
7 For normal operation, black wire (pin 4) needs no connection. To disable light source, connect black wire
(pin 4) to +V.
Approximate Dimensions [mm (in.)]
Accessories
The sensor can be mounted using an 18 mm snap-on adapter 8
(60-AJS-18) as shown. Align the slotted hole with the slotted hole on
the sensor and snap on.
To remove the sensor from the adapter, undo the snap by using a flat
screwdriver.
8Damage can occur to snap-on adapter if torque above 1.69 N•m (15 in•lb) is applied to the 18 mm mounting
nut.
1
1
2
4
3
2
3
4
+
–
+
–
PNP Models with
Complementary Outputs
NPN Models with
Complementary Outputs
Brown (1)
Black (4)
White (2)
Blue (3)
L.O.
D.O.
Load
Load
Brown (1)
Black (4)
White (2)
Blue (3)
L.O.
D.O. Load
Load
+
–
Brown (1)
Black (4)
Blue (3)
7
IMPORTANT To avoid damage to the sensor or mounting adapter, follow
the torque specifications.
10.0
(0.40)
31.6 (1.24)
32.3 (1.27)
17.3
(0.68)
33.0
(1.30)
35.0
(1.38)
14.0
(0.55)
25.4
(1.00)
26.4
(1.04)
3.0
(0.12)
20.0 (0.79)
20.6 (0.81)
16.0
(0.63)
Sensitivity
Adjustment
Clearance
for M3 or #4
40screw
(2places)
M18 Mounting Nut
M18 x 1.0
thread
60--AJS--18
60--2657

4Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017
VisiSight Photoelectric Sensors
Mounting Bracket—60-BJS-L1
9
9In high vibration applications, use mounting hardware that is supplied with the sensor to attach the 18mm
adapter to the sensor.
Mounting Bracket—60-BJS-L2
10
10 Damage can occur to the sensor housing if torque above 0.28N•m (2.5 in•lb) is applied to the mounting
screws.
Swivel/Tilt Mounting
12.0
(0.47)
18.6
(0.73)
33.0
(1.30)
14.0
(0.55)
24.0
(0.95)
8.0
(0.32)
15°
R.25.4
(R.1.00)
12.0
(0.47)
33.0
(1.30)
14.0
(0.55)
38.9
(1.53)
18.6
(0.73)
8.0
(0.32)
R.25.4
(R.1.00)
20°
10
60--BJS--L2
60--2619

Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017 5
VisiSight Photoelectric Sensors
Typical Response Curves
800 mm
250 mm
10
(0.39)
100
(3.9)
1000
(39.4)
1
10
100
1000
800 mm
250 mm
-- 4 0
-- 3 0
-- 2 0
-- 1 0
0
10
20
30
40
0 100
(3.9)
200
(7.87)
300
(11.8)
400
(15.7)
700
(27.5)
800
(31.5)
500
(19.6)
600
(23.6)
900
(35.4)
1
10
100
10000
-- 5
-- 4
-- 3
-- 2
-- 1
0
2
3
4
5
0.1
(0.004)
1
(0.04)
10
(0.39)
100
(3.9)
010
(0.39)
20
(0.78)
30
(1.18)
40
(1.57)
50
(1.96)
60
(2.36)
1000
1
Standard Diffuse Standard Diffuse—Beam Pattern
Background Suppression (55 mm) Background Suppression (55 mm)—Beam Pattern
With 18 mm adaptor Without 18 mm adaptor
Operating Margin
Beam Diameter (mm)
Operating Margin
Beam Diameter (mm)
With 18 mm
Adapter
Without 18 mm
Adapter
With 18 mm
Adapter
Without 18 mm
Adapter
Distance [mm (in.)] Distance [mm (in.)]
Distance [mm (in.)] Distance [mm (in.)]
1
10
100
10000
-- 6
-- 4
-- 8
-- 2
-- 1 0
0
2
10
4
6
0.1
(0.004)
1
(0.04)
10
(0.39)
100
(3.9)
020
(0.79)
40
(1.57)
80
(3.15)
100
(3.93)
120
(4.72)
60
(2.36)
1000
8
1000
(39.3)
140
(5.51)
--250
--200
--150
--100
-- 5 0
0
50
100
150
200
250
1
10
100
1000
0.1
(0.33)
1
(3.28)
10
(32.8)
02
(6.56)
4
(13.1)
6
(19.7)
8
(26.2)
10
(32.8)
100
(328)
Background Suppression (130 mm) Background Suppression (130 mm)—Beam Pattern
Transmitted Beam—Visible Red and Infrared Transmitted Beam—Beam Pattern
Operating Margin
Beam Diameter (mm)
Operating Margin
Beam Diameter (mm)
With 18 mm
Adapter
Without 18 mm
Adapter
With 18 mm
Adapter
Without 18 mm
Adapter
Distance [mm (in.)] Distance [mm (in.)]
Distance [mm (in.)] Distance [mm (in.)]
Infrared
Visible Red
Infrared
Visible Red

6Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017
VisiSight Photoelectric Sensors
Margin Curves
Polarized Retroreflective Beam Patterns
Margin
Distance (m [ft])
1
10
100
92-47 Reflecto
92-47 Reflector with Adapter
Margin
Distance (m [ft])
1
10
100
92-124 Reflecto
92-124 Refl ctor with Adapter
0.1
(0.0039)
1
(0.039)
10
(0.39)
100
(3.94)
1000
(39.37)
10000
(393.7)
0.1
(0.0039)
1
(0.039)
10
(0.39)
100
(3.94)
1000
(39.37)
10000
(393.7)
Margin
Distance (m [ft])
1
10
100
92-125 Reflecto
92-125 Reflector with Adapter
0.1
(0.0039)
1
(0.039)
10
(0.39)
100
(3.94)
1000
(39.37)
10000
(393.7)
Polarized Retroreflective Polarized Retroreflective
Polarized Retroreflective
Beam Diameter (mm)
Distance (m [ft])
2000
2
(6.6)
6
(19.7)
5
(16.4)
4
(13.1)
3
(9.8)
1
(3.3)
0
-2000
-1500
-1000
-500
0
500
1000
1500
92-124 with Adapter
92-124
92-47 with Adapter
92-47 Reflecto
Beam Diameter (mm)
Distance (m [ft])
2000
2
(6.6)
6
(19.7)
5
(16.4)
4
(13.1)
3
(9.8)
1
(3.3)
0
-2000
-1500
-1000
-500
0
500
1000
1500
92-125 with Adapter
92-125 Reflecto

Rockwell Automation Publication 42JS-IN001B-EN-P - January 2017 7
VisiSight Photoelectric Sensors
Notes:

Allen-Bradley, Rockwell Automation, Rockwell Software, and VisiSight are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: [phone]
Rockwell Automation maintains current product environmental information on its website at
http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
Publication 42JS-IN001B-EN-P - January 2017 PN-404357
10002690745 Ver 00
Supersedes Publication 42JS-IN001A-EN-P - May 2010 Copyright © 2017 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Rockwell Automation Support
Use the following resources to access support information.
Documentation Feedback
Your comments will help us serve your documentation needs better. If you have any suggestions on how to improve this document, complete the
How Are We Doing? form at http://literature.rockwellautomation.com/idc/groups/literature/documents/du/ra-du002_-en-e.pdf.
Technical Support Center Knowledgebase Articles, How-to Videos, FAQs, Chat, User
Forums, and Product Notification Updates. https://rockwellautomation.custhelp.com/
Local Technical Support Phone Numbers Locate the phone number for your country. http://www.rockwellautomation.com/global/support/get-support-now.page
Direct Dial Codes Find the Direct Dial Code for your product. Use the code to
route your call directly to a technical support engineer. http://www.rockwellautomation.com/global/support/direct-dial.page
Literature Library Installation Instructions, Manuals, Brochures, and
Technical Data. http://www.rockwellautomation.com/global/literature-library/overview.page
Product Compatibility and Download
Center (PCDC)
Get help determining how products interact, check
features and capabilities, and find associated firmware. http://www.rockwellautomation.com/global/support/pcdc.page
