Rockwell Automation Allen-Bradley PowerFlex Series User manual

Publication 20P-IN069A-EN-P
PowerFlex® DC Drive
Frame D Overvoltage Clipping Board Fuse Replacement
Installation Instructions
What This Kit Includes •Fuses 14x51 mm, 10 A, 90V (3)
•Static strap
Tools That You Need •Flathead screwdriver
ATTENTION: Only qualified personnel familiar with DC drives
and associated machinery should plan or implement the installation,
start-up and subsequent maintenance of the system. Failure to comply
may result in personal injury and/or equipment damage.
ATTENTION: To avoid an electric shock hazard, ensure that all
power to the drive has been removed before performing the following.
ATTENTION: This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. Static control precautions are required
when installing, testing, servicing or repairing this assembly.
Component damage may result if ESD control procedures are not
followed. If you are not familiar with static control procedures,
reference A-B publication 8000-4.5.2, “Guarding Against
Electrostatic Damage” or any other applicable ESD protection
handbook.

Publication 20P-IN069A-EN-P
2
What You Need to Do
1. Remove and lock-out all incoming power to the drive.
2. Disconnect the DPI cable from the HIM (if present).
3. Insert a flathead screwdriver into the holes in the right side of the protective
covers on the drive and turn the latch 90° counter-clockwise.
4. Open the control panel to the left.
ATTENTION: Remove power before making or breaking cable
connections. When you remove or insert a cable connector with
power applied, an electrical arc may occur. An electrical arc can
cause personal injury or property damage by:
•sending an erroneous signal to your system’s field devices,
causing unintended machine motion
•causing an explosion in a hazardous environment
Electrical arcing causes excessive wear to contacts on both the
module and its mating connector. Worn contacts may create electrical
resistance.
L1 L2 L3
O
I
=
90°
Disconnect DPI cable
Overvoltage clipping
board mounted inside
drive on this side wall.
Resistors mounted
inside drive on back
wall of frame.

3
Publication 20P-IN069A-EN-P
5. Remove the three fuses at locations F11, F21 and F31.
6. Install the new fuses.
7. Close the control panel. See steps 3. and 4. on page 2.
8. Replace the DPI cable (if present).
XCD
X1UVW1
XUVW
F31 F21 F11

Publication 20P-IN069A-EN-P - May 2010
